2010 SUZUKI KIZASHI Owners Manual

5-78
OTHER CONTROLS AND EQUIPMENT
57L20-03E
Interior Light SwitchFront
57L51021
Rear
57L51022
The interior light switch has three posi-
tions, which functions as described below.ON (1)
The light comes on and stays on regard-
less of whether the door is open or closed.
DOOR (2)
The light comes on when the door is
opened. After closing all doors, the light
will remain on for about 15 seconds and
then fade out. If you press the engine
switch to change the ignition mode to
“ACC” or “ON” during this time, the light will
start to fade out immediately. If you change
the ignition mode to “LOCK” (OFF) by
pressing the engine switch, the light will
remain on for about 15 seconds and then
go out.
OFF (3)
The light remains off even when the door is
opened.
NOTE:
If the rear interior light switch is set to
“DOOR”, the light is turned on or off at the
same time the front interior light is turned
on or off.
79J075
NOTE:
The number of doors involved in the light-
ing operation of the interior light depends
on the vehicle specification. If there is a
switch (rubber projection) at the door
opening as shown, the door is involved in
the lighting operation. The trunk lid is not
involved in this operation.
(2)(1) (3)
(1) (3)
(2)
EXAMPLE

5-79OTHER CONTROLS AND EQUIPMENT
57L20-03E
Courtesy Lights
57L51023
Each front door has a courtesy light (1) on
its inside bottom. It lights automatically
when the door is opened.
Footwell Lights
57L51024
A footwell light is provided in the leg space
in front of each front seat. When a front
door is opened, the footwell light on the
same side lights automatically.
Trunk Light
57L50019
When you open the trunk lid, the trunk light
comes on and remains on as long as you
keep the lid open.
(1)
CAUTION
Do not leave the trunk lid open for a
long time, or the battery will dis-
charge.

5-80
OTHER CONTROLS AND EQUIPMENT
57L20-03E
Spot Light
57L51048
Push the switch (1) to turn on the light and
push it again to turn off the light.
Accessory SocketLidded Instrument Panel Box
57L51025
Center Console Box
57L51062
The accessory socket will work when the
ignition mode is changed to “ACC” or “ON”
by pressing the engine switch.
12-volt accessory sockets are located both
on the center console and on the lidded
instrument panel box.
Each socket can be used to provide 12
volt/120 watt power for electrical accesso-
ries when used alone. Make sure that the
cap remains on the socket when the socket
is not in use.
(1)
CAUTION
 To prevent the fuse from being
blown, when using sockets at the
same time, do not exceed the total
combined power capacity of 120
watts.
 Use of inappropriate electrical
accessories can cause damage to
your vehicle’s electrical system.
Make sure that any electrical acces-
sories you use are designed to
plug into this type of socket.
 When an electric device is con-
nected to the accessory socket,
close the lid carefully so as not to
damage the device or lid.

5-81OTHER CONTROLS AND EQUIPMENT
57L20-03E
Universal Serial Bus (USB) Socket
57L51061
Connect your portable digital music player,
etc. to this socket to enjoy music through
the vehicle’s audio system using it as a
source. Refer to “Audio Systems” in the
“OTHER CONTROL AND EQUIPMENT”
section.
Cigarette Lighter (if equipped)
57L51068
The cigarette lighter will work when you
press the engine switch to change the igni-
tion mode to “ACC” or “ON”.
To use the cigarette lighter, push it all the
way into the receptacle and release it. It
will automatically heat up and will pop out
to its normal position when it is ready for
use.
CAUTION
If you close the lid of the lidded
instrument panel box with a device
still connected to the USB socket, the
equipment and the socket may be
damaged.
CAUTION
Holding the cigarette lighter in can
overheat and damage the lighter.
Release the lighter after you push it
in.
CAUTION
To avoid damage to the cigarette
lighter socket, do not use it as an
accessory power source. Some
accessories’ power plug can damage
the inner mechanism of the cigarette
lighter socket.

5-82
OTHER CONTROLS AND EQUIPMENT
57L20-03E
Ashtray (if equipped)
79J047
You can fit the ashtray into any of the cup
holders on the center console.
57L51065
Assist Grips
54G249
Assist grips are provided for convenience.
WARNING
Make sure tobacco is fully extin-
guished before closing the ashtrays.
Never throw waste in the ashtrays: it
could create a fire hazard.
CAUTION
When fitting the ashtray into a cup
holder on the center console, orient it
as shown in the illustration. Doing
otherwise may damage the ashtray
and/or the center console.
CAUTION
To avoid damaging the assist grip
and the molded roof lining, do not
hang down the assist grip.

5-83OTHER CONTROLS AND EQUIPMENT
57L20-03E
Coat Hooks
57L51049
You can hang clothing on the coat hooks.
These hooks are not designed for large or
heavy items.
Sunroof (if equipped)You can tilt or slide the sunroof by operat-
ing the “TILT” part of the sunroof switch or
the “SLIDE” part of the sunroof switch after
pressing the engine switch to change the
ignition mode to “ON”.
There is a system to prevent being pinched
by the sunroof.
When the system senses that something is
pinched when the sunroof is sliding for-
ward, the sunroof will automatically reverse
direction and slide rearward. This system
will operate when the sunroof is closing
automatically. This system does not oper-
ate when tilting the sunroof down.
Make sure there are no hands or other
obstructions in the path of the sunroof
when you close the sunroof even though
there is a system to prevent being pinched
by the sunroof.
57L51026
To tilt the sunroof up, slide the sun shade
rearward by hand and push the “TILT UP”
part (1) of the sunroof switch. To tilt the
sunroof down, push the “SLIDE OPEN”
part (2) of the sunroof switch.
If you push the switch for more than a sec-
ond, the sunroof will automatically tilt up or
down fully. To stop the sunroof halfway,
push the switch briefly.
WARNING
Your vehicle is equipped with side
curtain air bags, do not hang sharp
items like a hanger on the coat hook.
When hanging the clothes, hang it on
hook without using a hanger.
WARNING
 The system to prevent being
pinched by the sunroof does not
work in the area where the sunroof
is almost completely closed.
 The system to prevent being
pinched by the sunroof may not
work if the battery is not suffi-
ciently charged.
(2)
(1)

5-84
OTHER CONTROLS AND EQUIPMENT
57L20-03E
57L51027
To slide the sunroof rearward, push the
“SLIDE OPEN” part (2) of the sunroof
switch. To slide the sunroof forward, push
the “TILT UP” part (1) of the sunroof
switch.
If you push the switch for more than a sec-
ond, the sunroof will automatically slide
fully rearward or forward. To stop the sun-
roof halfway, push the switch briefly.
57L51028
The sun shade will open manually and
cannot be closed when the sunroof is slid
rearward.How to reactivate the system to prevent
being pinched by the sunroof
When you disconnect the negative (–) ter-
minal from the battery or change the fuses,
the features below will not operate.
 The system to prevent being pinched by
the sliding sunroof.
 The system to automatically open or
close the sunroof fully.
In this case, you must reactivate the fea-
tures using the following procedures.
1) Press the engine switch to change the
ignition mode to “ON”.
2) Push and hold the “TILT UP” part (1) of
the sunroof switch, the sunroof will tilt
up fully and then down slightly. After the
movement stops completely, release
the switch. The features are reacti-
vated.
3) Make sure you can open or close the
sunroof automatically by pushing the
sunroof switch for more than about a
second.
(2)
(1)

5-85OTHER CONTROLS AND EQUIPMENT
57L20-03E
65D612
 Be sure to close the sunroof when you
leave the vehicle unattended.
 Periodically inspect the guide rail for dirt
and clean it if any dirt has accumulated.
Glove Box
57L51029
(2) Unlock
(3) Lock
To open the glove box, pull the latch lever
(1). To close it, push the lid until it latches
securely.
To lock the glove box, insert the key
attached to your keyless start system
remote controller into the lock, turn the key
fully clockwise, and pull it out of the lock in
this position.
WARNING
 Never allow any part of your body
such as hands or head to get out of
the sunroof opening while the vehi-
cle is moving.
 Be sure there are no hands or other
obstructions in the path of the sun-
roof when you close the sunroof.
 Always take the keyless start sys-
tem remote controller with you
when leaving the vehicle even if
only for a short time. Also do not
leave children alone in a parked
vehicle. Unattended children could
use the sunroof switches and get
trapped by the sunroof.
CAUTION
Do not put your body weight on the
roof around the sunroof such as by
sitting on it.
WARNING
Never drive with the glove box lid
open. It could cause injury if an acci-
dent occurs.
(1)
(3) (2)
