2010 SUZUKI KIZASHI Owners Manual

2-86
BEFORE DRIVING
57L20-03E
Warning and Indicator MessagesThe display shows warning and indicator
messages to let you know about certain
vehicle problems.
A tone may also sound to alert you.
If warning and indicator messages appear
on the display, follow the messages.
Master warning indicator
78K049
When the display shows warning and indi-
cator messages, the master warning indi-
cator may also come on or blink.NOTE:
 When the problem that causes a mes-
sage to appear is corrected, the mes-
sage will disappear.
 If a message is displayed, and other
problems requiring a message occur, the
message for each of the problems will be
alternately displayed about every 5 sec-
onds.
 When you pull and hold the DISP switch
(2) for about 2 seconds while a message
is displayed, the message will disappear
temporarily. If the problem that caused
the message is not corrected, the mes-
sage will appear again after 5 seconds.

2-87BEFORE DRIVING
57L20-03E
Warning and indicator messages
(#1) This message will disappear for a while even if the problem that caused the message to appear is not corrected.Warning and Indicator
MessageMaster Warning
IndicatorSound Cause and Remedy
57L30073
Blinks
(only while vehicle
is in motion)“Ping” (one time from interior
buzzer; only while vehicle is
in motion)A door or the engine hood is not properly
closed. Stop in a safe place and close the
door or engine hood properly. (#1)
NOTE:
After disconnecting and reconnecting the
battery cable, the display image may show
that the passenger door is open even
though it is the driver’s door that is open.
The display will show the correct image
when you press the engine switch to
change the ignition mode to “ON”.
57L21087
Off Off This message is displayed when the “ACC”
position is selected as the power supply
position. (#1)

2-88
BEFORE DRIVING
57L20-03E
Warning and Indicator
MessageMaster Warning
IndicatorSound Cause and Remedy
57L21088
Off Off The brake pedal is depressed. Press the
engine switch to start the engine.
CVT
57L21089
Off Off The engine switch is pressed with the gear-
shift lever in a position other than “P” or “N”
and/or without depressing the brake pedal.
Try again as instructed by the message.

2-89BEFORE DRIVING
57L20-03E
Warning and Indicator
MessageMaster Warning
IndicatorSound Cause and Remedy
Manual Transaxle
57L21120
Off Off The engine switch is pressed without
depressing the brake and clutch pedals. Try
again as instructed by the message.
CVT
57L21090
Off Off The engine switch is pressed with the gear-
shift lever in a position other than “P”. Try
again as instructed by the message.

2-90
BEFORE DRIVING
57L20-03E
Warning and Indicator
MessageMaster Warning
IndicatorSound Cause and Remedy
57L21091
Blinks “Ping” (one time from interior
buzzer)There is a problem with the steering lock
system.
Have your vehicle inspected by an autho-
rized SUZUKI dealer.
57L21092
Blinks “Ping” (one time from interior
buzzer)There is a problem with the keyless push
start system.
Have your vehicle inspected by an autho-
rized SUZUKI dealer.

2-91BEFORE DRIVING
57L20-03E
Warning and Indicator
MessageMaster Warning
IndicatorSound Cause and Remedy
57L21093
Blinks Repeated beeps under cer-
tain conditions (for about 2
seconds from exterior and/or
interior buzzers)The remote controller may be outside the
vehicle or its battery may have become dis-
charged. Locate the remote controller or
touch the engine switch with the remote
controller.
If the message still appears, replace the
remote controller battery.
57L21094

2-92
BEFORE DRIVING
57L20-03E
(#1) This message will disappear for a while even if the problem that caused the message to appear is not corrected.Warning and Indicator
MessageMaster Warning
IndicatorSound Cause and Remedy
57L21095
Blinks Continuous beep (from inte-
rior buzzer)The headlights and position lights are left
on. Turn them off.
57L21096
Off Off This message is displayed when the “ON”
position is selected as the power supply
position. (#1)

2-93BEFORE DRIVING
57L20-03E
(#1) This message will disappear for a while even if the problem that caused the message to appear is not corrected.Warning and Indicator
MessageMaster Warning
IndicatorSound Cause and Remedy
57L21097
Off “Ping” (one time from interior
buzzer)Fuel is low. Refill immediately. (#1)
57L21101
Blinks “Ping” (one time from interior
buzzer)The steering lock is not disengaged. While
lightly turning the steering wheel in both
directions, press the engine switch again.
