2010 SUZUKI KIZASHI Owners Manual

5-70
OTHER CONTROLS AND EQUIPMENT
57L20-03E
Error Display Messages
Display
Possible cause
Possible solution
XM
Ck AntennaXM antenna unconnected. Connect the XM antenna.
No SignalXM broadcasts unreceivable because of
poor receiving conditions.Move to an area where XM broadcasts can be received
well.
Ch Off AirChannel not in service.This channel is not currently in service. Tune to another
channel.
Ch UnavailChannel unavailable. This channel is out of service. Tune to another channel.
Ch UnauthChannel unauthorized. This channel is not authorized. Tune to another channel.

5-71OTHER CONTROLS AND EQUIPMENT
57L20-03E
CD
ERROR 1The disc cannot be read.Insert the disc with its label side up.
Check the disc that it is not warped and is free of flaws.
If ERROR 1 does not go out when a normal disc is
inserted, consult your dealer.
ERROR 3The player developed an error of an uni-
dentified cause.If CD is inserted in the unit, press the CD eject button to
remove the disc.
If the disc cannot be ejected, consult your dealer.
USB/iPod
®ERROR 1No operation by some cause.Unplug the USB device and plug it again.
If ERROR 1 does not go out when a normal disc is
inserted, consult your dealer.
ERROR 3The USB device is disconnected. Check the connection of the USB device.
ERROR 4The current consumption of the USB
device exceeds 500 mA.Check the USB device.Display
Possible cause
Possible solution

5-72
OTHER CONTROLS AND EQUIPMENT
57L20-03E
Bluetooth
®ERROR 1The player developed an error of an uni-
dentified cause.Disconnect the Bluetooth
®-ready device and connect it
again.
If ERROR 1 does not go out, consult your dealer.
FailedFailed to establish pairing Try to establish the pairing again.
Memory FullReaching the upper limit of the register-
able device countDelete the registered data of unnecessary devices and
try to establish the pairing again.
Not Avail.Inoperable during driving Operate the system after pulling over your car.
Pardon?Failed voice recognition Press the Talk button and say what you said again.
Not LinkedTelephone disconnected Try to establish the pairing again.
Display
Possible cause
Possible solution

5-73OTHER CONTROLS AND EQUIPMENT
57L20-03E
Fuel Filler Door
57L51054
(2) Unlock
57L51058
The fuel filler door (3) is located on the left
rear side of the vehicle. To access the fuel
filler cap, the fuel filler door must be
opened by unlocking it using the power
door locking switch (1), keyless start sys-
tem remote controller, request switch, or
key and then pushing the fuel filler door (3)
at the location indicated by the arrow.If the fuel filler door fails to openIf the fuel filler door fails to open due to a
problem in the system or a flat battery,
have the vehicle inspected by an autho-
rized SUZUKI dealer. If you must open the
door immediately, do the following.
57L51055
Remove the trim (1) inside the trunk.
57L51056
Pull the rod (2) toward you. The fuel filler
door will be unlocked.
Push the rod inward to lock the door.
(3) Unlock
(4) Lock
(1)
(3) (2)
(3)
(1)
(2)(3)
(4)

5-74
OTHER CONTROLS AND EQUIPMENT
57L20-03E
57L51057
From the outside, push the part indicated
by the arrow of the fuel filler door (5) (see
the illustration). The door will open slightly.
Fuel Filler Cap
79K053
To remove the fuel filler cap:
1) Open the fuel filler door.
2) Remove the cap by turning it counter-
clockwise.
57L51019
NOTE:
The cap holder (1) can hold the fuel filler
cap (2) when refueling.
To reinstall the fuel filler cap:
1) Turn the cap clockwise until you hear
several clicks.
2) Close the fuel filler door.
(5)
WARNING
Remove the fuel filler cap slowly. The
fuel may be under pressure and may
spray out, causing injury.Open CloseEXAMPLE
WARNING
Fuel is extremely flammable. Do not
smoke when refueling, and make
sure there are no open flames or
sparks in the area.
(1) (2)

5-75OTHER CONTROLS AND EQUIPMENT
57L20-03E
Engine Hood
57L51020
To open the engine hood:
1) Pull the hood release handle (1)located on the outboard side of the
driver’s side of the instrument panel.
This will disengage the engine hood
lock halfway.
57L51066
2) Push the under-hood release lever (2) sideways with your finger, as shown in
the illustration. While pushing the lever,
lift up the engine hood.
WARNING
• Avoid spilling fuel. Any spilt fuelmust be wiped clean with a soft
cloth. Leaving the fuel as is could
lead to a fire or other unexpected
accident. Fuel will also cause
spots, discoloration or cracks on
the paintwork in the area.
 Close the fuel filler cap firmly after refueling. A loose cap may cause
fuel leakage and eventually a fire.
 If you need to replace the fuel cap, use a genuine SUZUKI cap. Use of
an improper cap can result in a
malfunction of the fuel system or
emission control system. It may
also result in fuel leakage in the
event of an accident.
(1)
(2)

5-76
OTHER CONTROLS AND EQUIPMENT
57L20-03E
57L50015
3) Continue to lift up the hood until it ishigh enough to support with the prop
rod (3). To close the engine hood:
1) Lift the hood up slightly and remove the
prop rod from the hole (5). Put the prop
rod back to the holding clip (4).
2) Lower the hood close to the bumper, then let it drop down. Make sure the
hood is securely latched after closing.
(4)
(3)(5)
WARNING
Make sure the hood is fully closed
and latched before driving. If it is not,
it can fly up unexpectedly during
driving, obstructing your view and
resulting in an accident.

5-77OTHER CONTROLS AND EQUIPMENT
57L20-03E
Sun Visor
57L50032
(1) Hook
(2) Vanity mirror cover
(3) Ticket holder
(4) Extension
The sun visors can be pulled down to block
glare coming through the windshield, or
they can be unhooked and turned to the
side to block glare coming through the side
window.
The extension (4) can be drawn out to
block glare widely. Both the driver’s and passenger’s sun
visors have a ticket holder on the side fac-
ing the interior when they are pulled down.
The ticket holder is on the vanity mirror
cover.
(1)
(2)
(3)
(4)
CAUTION
When unhooking and hooking a sun
visor, be sure to handle it by the hard
plastic parts or the sun visor can be
damaged.
CAUTION
Do not leave cards or similar plastic
objects in the ticket holder when
parking under the sun. The cabin
temperature may rise high enough to
cause the plastic objects to crack or
deform.
