2010 PEUGEOT 5008 Owners Manual

PRACTICAL INFORMATION
BATTERY
Procedure for charging your battery
when it is fl at or for starting the engine
using another battery.
Access to the battery Starting using another battery

 Connect the red cable to the posi-
tive terminal (+) of the fl at battery A ,
then to the positive terminal (+) of
the slave battery B .

 Connect one end of the green or
black cable to the negative terminal
(-) of the slave battery B .

 Connect the other end of the green
or black cable to the earth point C
on your vehicle (engine mounting).

 Operate the starter, let the engine
run.

 Wait until the engine returns to idle
and disconnect the cables.
The battery is located under the bonnet.
To gain access to it:

 open the bonnet using the interior re-
lease lever, then the exterior safety
catch,

 secure the bonnet stay,

 remove the plastic cover to gain
access to the two terminals,

 unclip the fusebox to remove the
battery, if necessary.

PRACTICAL INFORMATION
194
Do not disconnect the terminals
while the engine is running.
Do not charge the batter-
ies without disconnecting the
terminals fi rst.
Do not push the vehicle to start the
engine if it is fi tted with a 6-speed
electronic gear control gearbox or an
automatic gearbox.
The batteries contain harmful
substances such as sulphuric
acid and lead. They must be dis-
posed of in accordance with regulations
and must not, in any circumstances, be
discarded with household waste.
Take used remote control batteries
and vehicle batteries to a special col-
lection point.
Charging the battery using a
battery charger


Disconnect the battery from the vehicle.

 Follow the instructions for use pro-
vided by the manufacturer of the
charger.

 Reconnect starting with the negative
terminal (-).

 Check that the terminals and con-
nectors are clean. If they are
covered with sulphate (whitish or
greenish deposit), remove them and
clean them.
It is advisable to disconnect
the battery if the vehicle is to
be left unused for more than
one month. Before disconnecting the battery
Wait 2 minutes after switching off the
ignition before disconnecting the battery.
Close the windows and the doors
before disconnecting the battery.
Following reconnection of the
battery
Following reconnection of the battery,
switch on the ignition and wait 1 minute
before starting to permit initialisation of
the electronic systems. However, if prob-
lems remain following this operation,
contact a PEUGEOT dealer.
Referring to the corresponding section,
you must yourself reinitialise:
- the remote control key,
- the panoramic sunroof blind,
- the GPS satellite navigation system.
Disconnecting the cables

 Raise the locking tab fully.
Reconnecting the cables

 Position the open clip 1 of the cable
on the positive terminal (+) of the
battery.

 Press vertically on the clip 1 to posi-
tion it correctly against the battery.

 Lock the clip by lowering the tab 2 .
Do not force the tab as lock-
ing will not be possible if the
clip is not positioned correctly;
start the procedure again.

PRACTICAL INFORMATION
195
Let the engine run for the
duration specifi ed to ensure
that the battery charge is suf-
fi cient.
Do not repeatedly and continuously
restart the engine in order to charge
the battery.
A fl at battery prevents the engine
from starting (refer to the "Battery"
paragraph). If the telephone is being used
at this time:
- it will be maintained for 5 minutes with the hands-free kit of your
Peugeot Connect Sound or
Peugeot Connect Navigation,
- it will still be possible to fi nish the call with the Peugeot Connect
Media.
Exiting economy mode
These functions are reactivated auto-
matically next time the vehicle is driven.

 In order to resume the use of these
functions immediately, start the en-
gine and let it run:
- for less than ten minutes, to use the equipment for approximately
fi ve minutes,
- for more than ten minutes, to use the equipment for up to approxi-
mately thirty minutes.
CHANGING A WIPER BLADE
Removing

 Raise the corresponding wiper arm.

 Unclip the wiper blade and remove it.
Fitting

 Put the corresponding new wiper
blade in place and clip it.

 Fold down the wiper arm carefully.
Before removing a front wiper
blade

 Within one minute after switching off
the ignition, operate the wiper stalk
to position the wiper blades verti-
cally on the windscreen.
After fitting a front wiper blade

 Switch on the ignition.

 Operate the wiper stalk again to
park the wiper blades.
LOAD REDUCTION MODE
System which manages the use of certain
functions according to the level of charge
remaining in the battery.
When the vehicle is being driven, the load
reduction function temporarily deactivates
certain functions, such as the air condi-
tioning, the heated rear screen...
The deactivated functions are reactivat-
ed automatically as soon as conditions
permit.
ENERGY ECONOMY MODE
System which manages the duration of
use of certain functions to conserve a
suffi cient level of charge in the battery.
After the engine has stopped, you can
still use functions such as the audio and
telematics system, windscreen wip-
ers, dipped beam headlamps, courtesy
lamps, etc. for a maximum combined
duration of thirty minutes.
Switching to economy mode
Once the thirty minutes are over, a
message appears on the multi-function
screen indicating that the vehicle has
switched to economy mode and the ac-
tive functions are put on standby.

PRACTICAL INFORMATION
196
TOWING THE VEHICLE
Procedure for having your vehicle towed
or for towing another vehicle using a re-
movable towing eye.
Access to the tools Towing your vehicle

 On the front bumper, unclip the cover
by pressing at the bottom.

 Screw the towing eye in fully.

 Install the towing bar.

 Switch on the hazard warning lamps
on the towed vehicle.
 On the rear bumper, unclip the cover
by pressing at the bottom.

 Screw the towing eye in fully.

 Install the towing bar.

 Switch on the hazard warning lamps
on the towed vehicle.
Towing another vehicle
The towing eye is installed under the
left-hand concertina board, in the boot
interior trim.
To gain access to it:

 open the boot,

 raise the concertina board,

 remove the towing eye from the
holder. When towing with all four
wheels on the ground, always
use a towing bar.
When towing with only two
wheels on the ground, always use
professional lifting equipment.
When towing with the engine off,
there is no longer any braking or
steering assistance.


Place the gear lever in neutral
(position N on the electronic
gear control gearbox or auto-
matic gearbox).
Failure to observe this special condi-
tion could result in damage to certain
braking components and the absence
of braking assistance the next time
the engine is started.

PRACTICAL INFORMATION
197
TOWING A TRAILER, A CARAVAN, ETC.
Your vehicle is primarily designed for
transporting people and luggage, but it
may also be used for towing a trailer. Driving advice
The maximum towing load on a long
slope depends on the gradient and the
ambient temperature.
In all cases, pay attention to the coolant
temperature.
Side wind

 Take into account the increased
sensitivity to side wind.
Cooling
Towing a trailer on a slope increases
the temperature of the coolant.
As the fan is electrically controlled, its
cooling capacity is not dependent on
the engine speed.

 To lower the engine speed, reduce
your speed. Braking
Towing a trailer increases the braking
distance.
Tyres
 Check the tyre pressures of the towing
vehicle and of the trailer, observing the
recommended pressures.
Lighting

 Check the electrical lighting and sig-
nalling on the trailer.
The rear parking sensors will
be deactivated automatically if
a genuine PEUGEOT towbar
is used.
 If the warning lamp and the

STOP warning lamp come
on, stop the vehicle and
switch off the engine as
soon as possible.
Towbar suitable for the attachment of a
trailer or caravan with additional lighting
and signalling.
Distribution of loads

 Distribute the load in the trailer so
that the heaviest items are as close
as possible to the axle and the nose
weight approaches the maximum
permitted without exceeding it.
Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towing load
must be reduced by 10 % and so on for
every 1 000 metres of altitude.
Refer to the "Technical Data" section for
details of the weights and towing loads
which apply to your vehicle.
Driving with a trailer subjects the towing
vehicle to more signifi cant stress and its
driver must be particularly careful.
We recommend the use of
genuine PEUGEOT towbars
and their harnesses that have
been tested and approved from the
design stage of your vehicle, and that
the fi tting of the towbar is entrusted
to a PEUGEOT dealer.
If the trailer is not fi tted by a PEUGEOT
dealer, it is imperative that it is fi tted
using the electrical pre-equipment
installed at the rear of the vehicle, in
accordance with the manufacturer's in-
structions.

PRACTICAL INFORMATION
198
FITTING ROOF BARS Maximum authorised weight
on the roof rack, for a loading
height not exceeding 40 cm
(with the exception of bicycle
carriers): 65 kg.
If the height exceeds 40 cm, adapt
the speed of the vehicle to the pro-
fi le of the road to avoid damaging the
roof bars and the fi xings on the roof.
Be sure to refer to national legislation
in order to comply with the regulations
for transporting objects which are lon-
ger than the vehicle.
When fi tting transverse roof bars, use
the four quick-fi t fi xings provided for this
purpose:

 lift the concealing fl aps,

 open the fi xing covers on each bar
using the spanner,

 put each fi xing in place and lock
them on the roof one by one,

 close the fi xing covers on each bar
using the key.
If your vehicle is fi tted with
roof fi nishers, do not use them
for carrying loads. VERY COLD CLIMATE SCREEN
Removable protective screen which
prevents the accumulation of snow at
the radiator cooling fan.
Before fi tting or removing the screen,
ensure that the engine is off and cool-
ing fan has stopped. It is recommended
that the screen be fi tted and removed
by a PEUGEOT dealer.

 Offer up one of the three screens to
the front of the lower section of the
front bumper (do not use the upper
ventilation grille position).

 Press on the edges A to engage its
fi xing clips.

 Press on the middle at B to com-
plete the engagement of the fi xing
clips.

 Repeat the operation for the other
two screens.
Fitting

PRACTICAL INFORMATION
198
FITTING ROOF BARS Maximum authorised weight
on the roof rack, for a loading
height not exceeding 40 cm
(with the exception of bicycle
carriers): 65 kg.
If the height exceeds 40 cm, adapt
the speed of the vehicle to the pro-
fi le of the road to avoid damaging the
roof bars and the fi xings on the roof.
Be sure to refer to national legislation
in order to comply with the regulations
for transporting objects which are lon-
ger than the vehicle.
When fi tting transverse roof bars, use
the four quick-fi t fi xings provided for this
purpose:

 lift the concealing fl aps,

 open the fi xing covers on each bar
using the spanner,

 put each fi xing in place and lock
them on the roof one by one,

 close the fi xing covers on each bar
using the key.
If your vehicle is fi tted with
roof fi nishers, do not use them
for carrying loads. VERY COLD CLIMATE SCREEN
Removable protective screen which
prevents the accumulation of snow at
the radiator cooling fan.
Before fi tting or removing the screen,
ensure that the engine is off and cool-
ing fan has stopped. It is recommended
that the screen be fi tted and removed
by a PEUGEOT dealer.

 Offer up one of the three screens to
the front of the lower section of the
front bumper (do not use the upper
ventilation grille position).

 Press on the edges A to engage its
fi xing clips.

 Press on the middle at B to com-
plete the engagement of the fi xing
clips.

 Repeat the operation for the other
two screens.
Fitting

PRACTICAL INFORMATION
199
ACCESSORIES
"Protection": anti-theft alarm, window etch-
ing, wheel security bolts, fi rst
aid kit, warning triangle, high
visibility jacket, stolen vehicle
tracking system, dog guard,
snow chains.
Removal
Do not forget to remove the
very cold climate screen:
- when the ambient tempera-
ture exceeds 10 °C,
- when towing,
-
at speeds above 75 mph (120 km/h).
You can obtain a wide range of
accessories and original parts from the
PEUGEOT network.
These accessories and parts have been
tested and approved for reliability and
safety.
They are all adapted to your vehicle and
benefi t from PEUGEOT's recommenda-
tion and warranty.
The product range offered by PEUGEOT
Accessories is structured around 5 catego-
ries: PROTECTION - TOURING - IN-CAR
TECHNOLOGY - STYLING - UNIVERSAL:
Depending on the model, the clips point
either to the left or to the right.

 Pass your fi ngers through the upper
grille location.

 From behind, push the clips in the
opposite direction then pull the part
towards you.

 Start with the upper screen 1 , then
the centre screen 2 and fi nish with
the lower screen 3 .
