2010 PEUGEOT 5008 Owners Manual

4
EXTERIOR
Welcome lighting
This additional exterior and interior lighting,
controlled remotely, makes your approach
to the vehicle easier when the light is poor. 90
Panoramic sunroof
This roof provides incomparable visibility
and light in the passenger compartment.
105
Directional lighting
This lighting automatically provides addi-
tional visibility when cornering. 92

5
EXTERIOR
Visual and audible front and/or rear
parking sensors
This system warns you if an obstacle is
detected behind or in front of the vehicle
in reverse or forward gear. 159
Parking space sensor
This system measures the size of the
parking space available between two ve-
hicles or obstacles.
161
Temporary tyre repair kit
This kit is a complete system, consisting
of a compressor and an integrated seal-
ant product, for the temporary repair of
a tyre. 171 When washing your vehicle in a car wash:
- remove the aerial,
- fold back the mirrors.

6
OPENING
Remote control key

A. Unfolding/Folding of the key.
Normal locking
(press once; fi xed lighting of
the direction indicators).
Deadlocking of the vehicle
(press twice in succession;
fi xed lighting of the direction
indicators).
Complete or selective unlocking
of the vehicle
(rapid fl ashing of the direction
indicators).
or
73 When the light is poor, detected by a sen-
sor, the remote switching on of the dipped
beam headlamps and sidelamps makes
your approach to the vehicle easier.
This function can be programmed via
the confi guration menu.
90 86
Fuel tank

1. Opening the fuel fi ller fl ap.

2.
Opening and hooking the fuel fi ller cap.
The type of fuel to be used is indicated
on the inner face of the fuel fi ller fl ap.
Capacity of the tank: approximately
60 litres.
Welcome lighting

OPENING
Boot Panoramic sunroof

1. Opening the blind.

2. Closing the blind.

1. Unlocking the vehicle.

2. Opening the boot.
84 105

8
INTERIOR
Electric parking brake
This combines the functions of automatic
application on switching off the engine and

automatic release on acceleration.
Manual application/release is possible.
135
Audio and communication systems
This equipment benefi ts from the latest tech-
nology: MP3 compatible Peugeot Connect
Sound, Peugeot Connect USB, Bluetooth,
Peugeot Connect Navigation or Peugeot
Connect Media with 16/9 retractable colour
screen, JBL audio system, auxiliary sockets.
211
Head-up display
This system projects certain information
into the fi eld of vision of the driver: the
speed, the cruise control/speed limiter
and the Distance alert.
143
Dual-zone digital air conditioning
This system allows different levels of
comfort to be set for the driver and front
passenger. It then controls these levels
automatically according to the ambient
conditions. 59
Peugeot Connect
Navigation
251
281
Peugeot Connect
Sound .
Peugeot Connect
Media
Peugeot Connect
USB 232,
288
Bluetooth 237,
269,
291
PEUGEOT
Assistance 209

9
INSTRUMENTS AND CONTROLS

1. Audio and telematics system
steering mounted control stalk.

2. Steering lock and ignition.

3. Wipers/screenwash/trip computer
control stalk.

4. Instrument panel.

5. Driver’s airbag.
Horn.

6. Gear lever.

7. Electric parking brake.

8. 12 V accessories socket.

9. Centre console.

10. Panoramic sunroof control.

11. Handbook storage compartment.

12. Manual headlamp adjustment.
Instrument panel navigator associated with the Peugeot
Connect Media.

13. Alarm button.
Parking sensors button.
Dynamic stability control button (ESP/ASR).

14. Door mirror controls.
Electric window controls.
Child lock.

15. Front door window demist/defrost
vent.

16. Windscreen demist/defrost vent.

10
INSTRUMENTS AND CONTROLS

1. Steering wheel adjustment.

2. Cruise control/speed limiter
switches.

3. Lighting and direction indicator
control stalk.

4. Central adjustable air vents.

5. Head-up display.

6. Multifunction screen.

7. Passenger's airbag.

8. Side adjustable air vent.

9. Glove box - Audio/video sockets -
Passenger's airbag deactivation.

10. Bonnet release.

11. 12 V accessories socket.

12. Heating/air conditioning controls.

13. Audio and telematics system.

14. Buttons:
- head-up display,
- hazard warning lamps,
- Distance alert,
- central locking.

11
SITTING COMFORTABLY
Driver's seat
Forwards-backwards Height
Manual adjustment
62
Electric adjustment
63 Seat back angle
