2010 Hyundai Accent Owner's Manual

1
FEATURES OF YOUR HYUNDAI
109109109
Defrost-Level
Air is discharged through the wind- shield defroster nozzle, side defrosternozzle, side ventilator.
B670D06MC
HEATING CONTROLS
B690A01MC-GAT
B670E02A-AAT Temperature Control This control is used to adjust the degree of heating or cooling desired. For normal heating operation, set the air intake control to the fresh air ( ) position and the air flow control to the floor ( ) position.For faster heating, the air intake con- trol should be set in the recirculate ( ) position.If the windows fog up, set the air flow control to the defrost ( ) position. (Push the A/C button to turn the airconditioning system on and set the air intake control to the fresh air ( ) position.)For maximum heat, move the tem- perature control to "Warm".
Cool
Warm
B670E01MC B690A01MC-D

1FEATURES OF YOUR HYUNDAI
110DEFROSTING/DEFOGGINGVENTILATION
B720A01MC-GAT Use the heating/ventilation system to defrost or defog the windshield: To remove interior fog on the windshield:
o Set the air flow control to the defrost(
) position. (Push the A/C button
to turn the air conditioning system on and set the air intake control to thefresh air ( ) position.)
o Set the temperature control to the
desired position.
o Set the fan speed control between "1" and "4" position.
B710A01A-AAT
To operate the ventilation system:
o Set the air intake control to "Fresh"
mode ( ).
o To direct all intake air to the dash- board vents, set the air flow control to the (
) position.
o Adjust the fan speed control to the desired speed.
o Set the temperature control between "Cool" and "Warm".
B710A01MC-D B720A01MC-D
BI-LEVEL HEATING
B700A02A-AAT
Your Hyundai is equipped with bi-level heating controls. This makes it pos- sible to have cooler air from the dash- board vents and warmer air from thefloor outlets at the same time. To use this feature:
o Set the air intake control to the fresh air ( ) position.
o Set the air flow control at the bi-level
( ) position.
o Adjust the fan speed control to the desired speed.
o Set the temperature control between "Cool" and "Warm".
B700B01MC-D

1
FEATURES OF YOUR HYUNDAI
111111111
To remove the frost or exterior fog on the windshield:
o Set the air flow control to the defrost (
) position. (Push the A/C button
to turn the air conditioning system on and set the air intake control to the fresh air ( ) position.)
o Set the temperature control to warm.
o Set the fan speed control to position "3" or "4".
B720A02MC-DNOTE:
When the A/C is operated continu-ously on the floor-defrost level ( )
or defrost level ( ), it may cause
fog to form on the exterior wind- shield. If this occurs, set the air
flow control to the face level posi-
tion ( ) and fan speed control to
the low position.B730A01L-AAT
Operation Tips
oTo keep dust or unpleasant fumes from entering the car through the
ventilation system, temporarily set the air intake control at the ( )
position. Be sure to return the control
to the ( ) position when the
irritation has passed to keep fresh air
in the vehicle. This will help keep the
driver alert and comfortable.
oAir for the heating/cooling system is drawn in through the grilles justahead of the windshield. Care should
be taken that these are not blocked
by leaves, snow, ice or other ob-
structions.
oTo prevent interior fog on the wind- shield, set the air intake control to
the fresh air ( ) position, fan
speed to the desired position, turn on the air conditioning system, and ad- just temperature control to desired
temperature.

1FEATURES OF YOUR HYUNDAI112
B740B01MC-AAT
Air Conditioning Operation
(Cooling)
To use the air conditioning to cool the
interior:
oTurn on the fan control switch.
oPush the air conditioning switch by pushing in on the switch.
The air conditioning indicator light
should come on at the same time.
oSet the temperature control to "Cool". ("Cool" provides maximum cooling.
The temperature may be moderated
by moving the control toward "Warm".) oAdjust the fan control to the desired
speed. For greater cooling, turn the
fan control to one of the higher speeds
or temporarily select the ()posi-
tion on the air intake control.B740B01MC-D
AIR CONDITIONING SYSTEM
B740A01MC-D
B740A01A-AAT
(If Installed)
Air Conditioning Switch
The air conditioning is turned on by pushing the A/C button on the heating/ air conditioning control panel.

1
FEATURES OF YOUR HYUNDAI113113113
For dehumidified heating: oTurn on the fan control switch.
oTurn on the air conditioning switch. The air conditioning indicator light
should come on at the same time.
oSet the air intake control switch to the fresh air (
) position.
oAdjust the fan control to the desired
speed.
oFor more rapid action, set the fan at one of the higher speeds.
oAdjust the temperature control to provide the desired amount of
warmth.
B740C01MC-AAT
De-Humidified HeatingB740C01MC-D
B740D01A-AAT
Operation Tips
oIf the interior of the car is hot when
you first get in, open the windows for
a few minutes to expel the hot air.
oWhen you are using the air condi-
tioning system, keep all windows
closed to keep hot air out.
oWhen moving slowly, as in heavy traffic, shift to a lower gear.
This increases engine speed, which in turn increases the speed of the air conditioning compressor.
oOn steep grades, turn the air condi- tioning off to avoid the possibility of
the engine overheating.
oDuring winter months or in periods when the air conditioning is not usedregularly, run the air conditioning
once every month for a few min-utes.
This will help circulate the lubricants
and keep your system in peak oper-
ating condition.

1FEATURES OF YOUR HYUNDAI114AUTOMATIC HEATING AND COOLING CONTROL SYSTEM
B970A01Y-AAT
(If lnstalled)
Your Hyundai is equipped with an auto- matic heating and cooling control sys-
tem controlled by simply setting the desired temperature. B970B01MC-GAT
Heating and Cooling Controls
B970B01MC
6
.A UTO (Automatic Control) Switch
7
.D isplay Window
8
.A ir Flow Control Switch
9
.O FF Switch
1
.T emperature Control
2
.A ir Conditioning Switch
3
.A ir lntake Control Switch
4
.D efroster Switch
5
.B lower Fan Control

1
FEATURES OF YOUR HYUNDAI115115115B970C01NF-GAT
Automatic Operation
The FATC (Full Automatic Tempera-
ture Control) system automatically con-
trols heating and cooling by doing as follows:
1
.P ush the "AUTO" switch. The indi-
cator light will illuminate confirming
that the Face, Floor and/or Bi-Level modes as well as the blower speedand air conditioner will be controlledautomatically. 2
.T urn the "TEMP" knob to set the
desired temperature.
The temperature will increase to the
maximum 32°C(90°F) by turning the
knob clockwise.The temperature will decrease to the minimum 17°C(62°F) by turning the
knob counterclockwise.
NOTE:
If the battery has been discharged or
disconnected, the temperature mode will reset to Centigrade degrees.
This is a normal condition and you
can change the temperature mode
from Centigrade to Fahrenheit as
follows; Press the "OFF" and "AUTO " switch
simultaneously for 3 seconds.The display shows that the unit of
temperature is adjusted to Centigrade
or Fahrenheit (°C

°F or °F


°C).
B970C01MC B970C02MC
1JBA4067
Photo Sensor
NOTE:
Never place anything over the sen- sor which is located on the instru-
ment panel to ensure better control
of the heating and cooling system.

1FEATURES OF YOUR HYUNDAI116B980B01NF-AAT
Fan Speed Control
The fan speed can be set to the desired
speed by turning the fan speed control
knob. The higher the fan speed is, the
more air is delivered. Pressing the "OFF"
switch turns off the fan. B670C03Y-AAT
Air Intake Control Switch
This is used to select fresh outside air
or recirculation of inside air. To change the air intake control mode,
(Fresh mode, Recirculation mode) push
the control switch.
FRESH MODE (
) : The indicator
light on the button goes on when the air intake control is in fresh mode.
RECIRCULATION MODE ( ) : The
indicator light on the button is illumi-
nated when the air intake control is in
recirculation mode. B670C03MC
B980B01MC
B980A01Y-AAT
MANUAL OPERATION
The heating and cooling system can be
controlled manually as well by pushing
buttons other than the "AUTO" switch. In this state, the system sequentially
works according to the order of buttons
selected.
The function of the switchs which are not selected will be controlled automati-
cally.
Press the "AUTO" switch in order to
convert to automatic control of the sys- tem.
