2010 Hyundai Accent Owner's Manual

1
FEATURES OF YOUR HYUNDAI
101FLOOR MAT ANCHOR(S)
B571A03Y-AAT (If Installed)
!
CAUTION:
To prevent damage to the goods or the vehicle, care should be taken when carrying fragile or bulky ob- jects in the luggage compartment.!
WARNING:
Avoid eye injury. DO NOT over- stretch. The luggage net ALWAYS keep your face and body out of its recoil path. DO NOT use when thestrap has visible signs of wear or damage.
When loading objects in the luggage compartment, use the four rings lo-cated in the luggage compartment to attach the luggage net as shown illus- tration. This will help prevent the ob-jects from sliding.
CARGO AREA COVER
B650A01A-GAT (3 Door) Nothing should be carried on top of the luggage cover. Loose materials could result in injury to vehicle occupants during sudden braking.
B650A01MC When using a floor mat on the front floor carpet, make sure it attaches to the floor mat anchor(s) in your vehicle. This keepsthe floor mat from sliding forward.OMC040174
!WARNING:
o Make sure the floor mat is properly placed on the floor carpet. If the floor mat slips and interferes with the movement of the pedals duringdriving, it may cause an accident.
o Don't put an additional floor mat
on the top of the anchored floormat, otherwise the additional mat may slide forward and interfere with the movement of the pedals.

1FEATURES OF YOUR HYUNDAI
102
!WARNING:
o Do not place the sun visor in such a manner that it obscures visibil- ity of the roadway, traffic or other objects.
o Do not move the sun visor out to cover the side window if there isan item attended to it such as agarage door remote control, pens, air fresheners or the like. These objects could cause injury if thecurtain airbag is deployed.
SUN VISOR
B580A02MC-AAT
B580A01MC
Your Hyundai is equipped with sun visors to give the driver and front pas- senger either frontal or sideward shade. To reduce glare or to shut out direct rays of the sun, turn the sun visor down. Ticket holders and vanity mirrors are provided on the back of the sun visor for the driver and the front passenger (IfInstalled). NOTE: The Supplemental Restraint System (SRS) label containing useful infor- mation can be found on the topsideof the sun visor.B580A02MC

1
FEATURES OF YOUR HYUNDAI
103STEERING WHEEL
B580C01JM-AAT Sun Visor Extender (If Installed)
Your vehicle is equipped with sun visor extenders that may be used when the visor is in the side glass position.
B580C01MC
B500B01B-GAT Illuminated Vanity Mirror (If Installed) Opening the lid of the vanity mirror will automatically turn on the mirror light. OMC025100 Electronic Power Steering (If Installed) Power steering uses the motor to assist you in steering the vehicle. If the engineis off or if the power steering system becomes inoperative, the vehicle may still be steered, but it will require in-creased steering effort. The motor driven power steering is controlled by power steering controlunit which sense the steering wheel torque, steering wheel position and ve- hicle speed to command the motor.The steering wheel becomes heavier as the vehicle’s speed increases and becomes lighter as the vehicle’s speeddecreases for the better control of the steering wheel. Should you notice any change in theeffort required to steer during normal vehicle operation, have the power steer- ing checked by an authorized Hyundaidealer.

1FEATURES OF YOUR HYUNDAI
104HORN
B610B01L-GAT
Press the pad on the steering wheel to sound the horn.
OMC025046
!
STEERING WHEEL TILT LEVER
B600A01A-AAT To Adjust the Steering Wheel:
1. Push the lever downward to unlock.
2. Raise or lower the steering wheel to
the desired position.
3. After adjustment, securely tighten the lever by pulling it upward.
WARNING:
Do not attempt to adjust the steering wheel while driving as this may re-sult in loss of control of the vehicle which may cause serious injury or death.
OMC025045
NOTE: The following symptoms may occur during normal vehicle operation:
o The EPS warning light does not
illuminate.
o The steering wheel becomes
heavier after turning the ignitionswitch on. This happens as the system performs the EPS system diagnostics. When the diagnos-tics is completed, the steering wheel will return to its normal condition.
o Click noise may be heard from the EPS relay after the ignition switchis turned to the ON or LOCK posi-tion.
o Motor noise may be heard when
the vehicle is at a stop or at a lowdriving speed.
o The steering effort can suddenly
increase, if the operation of EPSsystem is stopped to prevent seri- ous accidents when the malfunc- tion of EPS system is detected byself-diagnosis.

1
FEATURES OF YOUR HYUNDAI
105105105HEATING AND COOLING CONTROL
B710A01TB-GAT (If Installed)
1. Side Defroster Nozzle
2. Side Ventilator
3. Windshield Defroster Nozzle
4. Center Ventilator B710B01MC-AAT Center Ventilator/Side Ventilator
B710A01MC
B710B01MC
The center ventilators are located in the middle of the dashboard. The side ven- tilators are located on each side of dashboard. To change the direction ofthe air flow, move the knob in the center of the vent up-and-down and side-to- side.The vents are opened when the vent knob is moved to "
" position. The
vents are closed when the vent knob is moved to "
". Keep these vents clear
of any obstructions.

1FEATURES OF YOUR HYUNDAI
106
This is used to select fresh outside air or recirculating inside air.FreshRecirculation
With the "
" mode selected, air en-
ters the vehicle from outside and is heated or cooled according to the other functions selected. With the "
" mode selected, air from
within the passenger compartment is drawn through the heating system and heated or cooled according to the otherfunctions selected.
HEATING AND VENTILATION
B670A02A-GAT
(If Installed)
1. Temperature control
2. Air conditioning switch
3. Air intake control switch
4. Air flow control
5. Fan speed control B670B01A-AAT Fan Speed Control (Blower Control) This is used to turn the blower fan on or off and to select the fan speed. This blower fan speed, and thereforethe volume of air delivered from the system, may be controlled manually by setting the blower control betweenthe "1" and "4" positions. B670C03A-AAT Air Intake Control Switch
B670A01MC-D
OMC025083B670C02MC

1
FEATURES OF YOUR HYUNDAI
107107107
Face-Level
Selecting the "Face" mode will cause air to be discharged through the facelevel vents.
B670D03MC-GAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, instrument panel outlets, or windshield. Five sym-bols are used to represent Face, Bi- Level, Floor, Floor-Defrost and Defrost air position.
B670D02MC
B670D01MC-D
NOTE: It should be noted that prolonged operation of the heating system in "
" mode will give rise to misting
of the windshield and side windows and the air within the passenger com- partment will become stale. In addi-tion prolonged use of the air condi- tioning with the "
" mode selected
may result in the air within the pas- senger compartment becoming ex- cessively dry.

1FEATURES OF YOUR HYUNDAI
108
Bi-Level
Air is discharged through the face vents and the floor vents. Floor-Level
Air is discharged through the floor vents,windshield defroster nozzle, side de-froster nozzle and side ventilator. Floor-Defrost Level
Air is discharged through the wind-shield defroster nozzle, the floor vents,side defroster nozzle and side ventila- tor.
B670D03MCB670D04MC B670D05MC
