2010 Hyundai Accent Owner's Manual

1
FEATURES OF YOUR HYUNDAI
69
B300A01A-GAT SPEEDOMETER
OMC029513
OMC029513L
Type A
Type B
B270A01A-AAT BRAKE PAD WEAR WARNING SOUND The front disc brake pads have wear indicators that should make a high- pitched squealing or scraping noisewhen new pads are needed. The sound may come and go or be heard all the time when the vehicle is moving. It mayalso be heard when the brake pedal is pushed down firmly. Excessive rotor damage will result if the worn pads arenot replaced. See your Hyundai dealer immediately.
INSTRUMENT CLUSTER
The needle on the gauge indicates the approximate fuel level in the fuel tank. The fuel capacity is given in Section 9. NOTE: The "
" symbol means the fuel
filler lid is placed on the left side of the vehicle.
B280A02TG-AAT FUEL GAUGE
OMC029420K
Type AType B
CAUTION:
Avoid driving with a very low fuel level. If you run out of fuel, it could cause the engine to misfire and re- sult in excessive loading of the cata-lytic converter.
!

1FEATURES OF YOUR HYUNDAI
70
Your Hyundai's speedometer is cali- brated in kilometers per hour or miles per hour.
OMC029513N
Type C
OMC029512L
OMC029512
Gasoline (Type A)
Gasoline(Type B)
OMC029512N
OMC029516L
Gasoline (Type C)
Diesel
B330A02A-AAT TACHOMETER
The tachometer registers the speed of your engine in revolutions per minute (rpm).

1
FEATURES OF YOUR HYUNDAI
71
B310B01MC-GAT ODOMETER/TRIP ODOMETER (Without Trip Computer) 1. Odometer The odometer records the total driving distance in kilometers or miles, and isuseful for keeping a record for mainte- nance intervals. It is normal for a new vehicle to have the odometer indicatingless than 50km. NOTE: Any alteration of the odometer may void your warranty coverage.
B310B01MC 2. Trip Odometer
Pushing in the TRIP switch for less than 1 second when the ignition switch is in "ON" position changes the display as follows;
OMC029054
Type A
Type B
! CAUTION:
The engine should not be increased to such a speed that the needle en- ters the red zone on the tachometer face. This can cause severe enginedamage and may void your warranty.

1FEATURES OF YOUR HYUNDAI
72
TRIP A: First distance you have trav-
eled from your origination point to a first destination. TRIP B: Second distance from the first
destination to the final destination.When the TRIP switch is pressed for more than 1 second, trip odometer will reset to 0.
B310C01O-GAT ODOMETER/TRIP ODOMETER (With Trip Computer)
1. Odometer The odometer records the total driving distance in kilometers or miles, and is useful for keeping a record for mainte- nance intervals.It is normal for a new vehicle to have the odometer indicating less than 50 km. NOTE: Any alteration of the odometer may void your warranty coverage. B400B03MC
Trip Odometer
Odometer
B310B02MC
B310B03MC
Trip odometer records the distance of 2 trips in kilometers or miles. Type A
Type B

1
FEATURES OF YOUR HYUNDAI
73TRIP COMPUTER
B400B01MC
The trip computer is a microcomputer- controlled driver information gauge that displays information related to driving such as outside temperature, tripmeter,average fuel consumption and distance to empty on the LCD.
B400B01MC-GAT (If Installed)
2. Trip Odometer
o This mode indicates the drive dis-
tance travelled since the last drive time reset.
o Refer to the explanation of the trip
computer (see page 1-74, Tripmeter).
OUTSIDE TEMPERATURETRIPMETER
AVERAGE FUEL CONSUMPTION DISTANCE TO EMPTY
TRIP Switch
Pushing in the TRIP switch for less than 1 second when the ignition switch is in "ON" position changes the displayas follows;
OMC029054

1FEATURES OF YOUR HYUNDAI
74
3. Average Fuel Consumption
(L/100km or MPG)
B400B04MC
o This mode calculates the average fuel consumption from the total fuel used and the distance since the lastaverage consumption reset.
o The total fuel used is calculated from
the fuel consumption input.
o Average fuel consumption is reset to zero (--) if the battery is discon-nected.
o To reset the average fuel consump- tion to zero (--), press the TRIPswitch for more than 1 second.
o When you drive 0.5 km (0.5 mile) and less after resetting, the average fuelconsumption will be displayed to '--'.
Odometer
Average Fuel Consumption
2. Tripmeter (km or miles)
o This mode indicates the total dis-tance travelled since the last tripmeter reset. Total distance is also reset tozero if the battery is disconnected.
o Pressing the TRIP switch for more
than 1 second when the tripmeter isbeing displayed clears the tripmeter to zero.
o The meter's working range is from 0 to 999.9 kms (999.9 miles). B400B03MC
Odometer Tripmeter1. Outside Temperature
(°C or °F)
This mode indicates the outside tem-
perature between -40°C (-40°F) and
80°C (176°F) . B400B02MC
Odometer
Outside Temperature

1
FEATURES OF YOUR HYUNDAI
75
o When the distance to empty is less
than 50 km (30 miles), the distance to empty digits (----) will blink untilmore fuel is added.
NOTE:
o The distance to empty can differ from the actual tripmeter accord- ing to driving conditions.
o The distance to empty can vary according to the driving condi-tions, driving pattern or vehicle speed.
4. Distance to Empty
(km or miles)
o This mode indicates the estimated distance to empty from the currentfuel level in the fuel tank.
o The trip computer may not register
additional fuel if less than 6 liters(1.36 gallons) of fuel are added to the vehicle. B400B05MC
Distance to empty symbol
Distance to empty
B400B06MC
Odometer
B340A01A-AAT Combination Turn Signal, Head- light And High-beam SwitchTurn Signal Operation Pulling down on the lever causes the turn signals on the left side of the car to blink. Pushing upwards on the levercauses the turn signals on the right side of the car to blink. As the turn is com- pleted, the lever will automatically re-turn to the center position and turn off the turn signals at the same time. If either turn signal indicator light blinksmore rapidly than usual, goes on but does not blink, or does not go on at all, there is a malfunction in the system.Check for a burned-out fuse or bulb or see your Hyundai dealer. MULTI-FUNCTION LIGHT SWITCH

1FEATURES OF YOUR HYUNDAI
76
Parking Light Auto Cut
o The purpose of this feature is toprevent the battery from being dis- charged. The system automatically turns off the headlights and parking lights whenthe driver removes the ignition key and opens the driver- side door.
o With this feature, the parking light will be turned off automatically if thedriver parks on the side of road at night.If necessary, to keep the lights on when the ignition key is removed, perform the following :
1) Open the driver-side door.
2) Turn the parking lights OFF and ON again using the light switch on the steering column.
B340C04FC-GAT Headlight Switch
To operate the headlights, turn the bar- rel on the end of the multi-function switch. The first position turns on theparking lights, sidelights, tail lights and instrument panel lights. The second position turns on the headlights. NOTE: The ignition must be in the "ON" position to turn on the headlights.
OMC049601
B340B01A-AAT Lane Change Signal To indicate a lane change, move the lever up or down to a point where it begins flashing.The lever will automatically return to the center position when released.OMC049600
