2009 MERCEDES-BENZ SLR Owner's Manual

289 Operation
Tires and wheels
Uniform Tire Quality Grading Standards
A tire information system that provides
consumers with ratings for a tire’s traction,
temperature and treadwear. Ratings are
determined by tire manufacturers using
government testing procedures. The
ratings are molded into the sidewall of the
tire.
Vehicle maximum load on the tire
Load on an individual tire that is
determined by distributing to each axle its
share of the maximum loaded vehicle
weight and dividing it by two.
Rotating tires
Tire rotation can be performed on vehicles
with tires of the same dimension all
around. If your vehicle is equipped with
tires of the same dimension all around,
tires can be rotated, observing a
front-to-rear rotation pattern that will
maintain the intended rotation (spinning)
direction of the tire (
page 262).In some cases, such as when your vehicle
is equipped with mixed-size tires (different
tire dimension front vs. rear), tire rotation
is not possible.
If applicable to your vehicle’s tire configu-
ration, tires can be rotated according to
the tire manufacturer’s recommended in-
tervals in the tire manufacturer’s warranty
pamphlet located in your vehicle literature
portfolio. If none is available, tires should
be rotated every 3 000 to 6 000 miles
(5 000 to 10 000 km), or sooner if neces-
sary, according to the degree of tire wear.
The same rotation (spinning) direction
must be maintained (
page 262).
Rotate tires before the characteristic tire
wear pattern becomes visible (shoulder
wear on front tires and tread center wear
on rear tires).
!
A wheel change should only be carried out
at an authorized Mercedes-Benz Center. Other-
wise there is a danger of damaging the vehicle by
jacking it up incorrectly.
Warning!
G
Rotate front and rear wheels only if the tires
are of the same dimension.
If your vehicle is equipped with mixed-size
tires (different tire dimensions front vs.
rear), tire rotation is not possible.

290 OperationTires and wheelsThoroughly clean the mounting face of
wheels and brake disks, i.e. the inner side
of the wheels/tires, during each rotation.
Check for and ensure proper tire inflation
pressure.
For information on wheel change, see the
“Practical hints” section (
page 365).
Anti-theft wheel nuts
Your vehicle is equipped with anti-theft
wheel nuts that prevent the theft of your
vehicle’s wheels.
1Anti-theft wheel nut
2Wheel nut key
Removing anti-theft wheel nuts

Unscrew anti-theft wheel nut1 using
wheel nut key2.

Replace anti-theft wheel nut1 with
one of the regular wheel bolts.

Fasten the wheel bolt and tighten it
with a torque wrench to a tightening
torque of 95 lb-ft (130 Nm).
Warning!
G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
95 lb-ft (130 Nm).
Only use Genuine Mercedes-Benz wheel
bolts specified for your vehicle’s rims.
Warning!
G
Pull the parking brake lever up as many
notches as possible and move the gear se-
lector lever to park positionP, before loos-
ening the wheel bolts. Otherwise the vehicle
may move and cause an accident and/or
serious personal injury. !
Do not use air tools, such as an impact
wrench, when installing or removing the
anti-theft wheel nuts. An impact wrench can
damage the anti-theft wheel nuts and the wheel
nut key, or cause them to malfunction.
!
Store wheel bolts and anti-theft wheel nuts
not currently in use in a safe place to avoid
damage to the threads.

291 Operation
Tires and wheels
Fitting anti-theft wheel nuts
Unscrew a wheel bolt from one of the
wheels.

Replace that wheel bolt with one of the
anti-theft wheel nuts1 delivered with
your vehicle.

Fasten anti-theft wheel nut1 using
wheel nut key2 and tighten with a
torque wrench to a tightening torque of
95 lb-ft (130 Nm).Warning!
G
The wheels could come loose if the wheel
bolts are not tightened to a torque of 95 lb-ft
(130 Nm). Have the tightening torque
checked after changing a wheel.
Warning!
G
The wheels could come loose if the wheel
bolts are not tightened to a torque of 95 lb-ft
(130 Nm). Have the tightening torque
checked after changing a wheel.i
Keep the anti-theft wheel nut key in a conve-
nient place in your vehicle where you and service
personnel can always find it easily when it is
needed.
i
If you should lose the anti-theft wheel nut
key or one of the anti-theft wheel nuts, please
contact an authorized Mercedes-Benz Center for
a replacement.

292 OperationWinter drivingBefore the onset of winter, have your
vehicle winterized at an authorized
Mercedes-Benz Center. This service
includes:

Check of anticorrosion and antifreeze
concentration.


Addition of cleaning concentrate to the
water of the windshield and headlamp
cleaning system. Add MB Concentrate
“MB Summerfit” to a premixed wind-
shield washer solvent/antifreeze
which is formulated for below freezing
temperatures (
page 401).


Battery test. Battery capacity drops
with decreasing ambient temperature.
A well charged battery helps to make
sure that the engine can be started,
even at low ambient temperatures.


Tire change. Mercedes-Benz recom-
mends M+S rated radial-ply tires with a
minimum tread depth of approximately 1/6in (4 mm) on all four wheels for the
winter season.
Winter tires*
Always use winter tires at temperatures
below 45°F (7°C) and whenever wintry
road conditions prevail. Not all M+S rated
tires provide special winter performance.
Make sure the tires you use show the
mountain/snowflake.marking on the
tire sidewall. These tires meet specific
snow traction performance requirements
of the Rubber Manufacturers Association
(RMA) and the Rubber Association of Can-
ada (RAC) and have been designed specif-
ically for use in snow conditions. Use of
winter tires is the only way to achieve the
maximum effectiveness of the ABS and
ESP
® in winter operation.
For safe handling, make sure that all
mounted winter tires are of the same make
and have the same tread design.Always observe the speed rating of the
winter tires installed on your vehicle. If the
maximum speed for which your tires are
rated is below the speed rating of your
vehicle, you must place a notice to this
effect where it will be seen by the driver.
Such notices are available from your tire
dealer or from any authorized
Mercedes-Benz Center.
After you have fitted the winter tires,
restart the TPMS (
page 274).
!
A wheel change should only be carried out
at an authorized Mercedes-Benz Center. Other-
wise there is a danger of damaging the vehicle by
jacking it up incorrectly.
Warning!
G
Winter tires with a tread depth of less than 1/6in (4 mm) must be replaced. They are no
longer suitable for winter operation, in par-
ticular because they do not provide suffi-
cient grip. This could cause you to lose
control of your vehicle and cause an acci-
dent.

293 Operation
Winter driving
Snow chains
Snow chains should only be driven on
snow-covered roads at speeds not to
exceed 30 mph (50 km/h). Remove chains
as soon as possible when driving on roads
without snow.Please observe the following guidelines
when using snow chains:


Use of snow chains is not permissible
with all wheel/tire combinations.


Snow chains should only be used on
the rear wheels. Follow the manufac-
turer’s mounting instructions.


Only use snow chains that are
approved by Mercedes-Benz. Any au-
thorized Mercedes-Benz Center will be
glad to advise you on this subject.


Use of snow chains may be prohibited
depending on location. Always check
local and state laws before installing
snow chains.
i
When driving with snow chains, you may
wish to deactivate the ESP
® (page 86) before
setting the vehicle in motion. This will improve
the vehicle’s traction.
!
If snow chains are mounted to the front
wheels, they may scrape against the body or axle
components. The tires or the vehicle could be
damaged as a result.
!
Use of snow chains is not permissible with
tire sizes:


255/35 ZR19 (96Y) XL (Summer tires only)


295/30 ZR19 (100Y) XL


295/35 ZR18 (99Y)

294 OperationMaintenanceIn order to maintain the performance and
safety of your vehicle, we strongly recom-
mend that you have your vehicle serviced
by an authorized Mercedes-Benz Center,
every 12 months, even if the vehicle has
covered less than 10 000 miles
(15 000 km) in that time.
The maintenance service indicator will
notify you when the next maintenance ser-
vice is due within the next 12 months or
10 000 miles (15 000 km), whichever
comes sooner.Before the next maintenance service is
due, one of the following messages will ap-
pear in the right multifunction display while
you are driving or when you switch on the
ignition:
Service In .. Days
Service In .. Miles

When the maintenance service is due, the
following message appears in the multi-
function display:
Service Due Now
Clearing the maintenance service indicator message
The maintenance service indicator mes-
sage is automatically cleared after 30 sec-
onds when you switch on the ignition. You
can also clear it yourself.
1Reset button
Press reset button 1.
The maintenance service indicator
message is cleared and the standard
display appears in the multifunction
display (
page 117).
!
Failure to have the vehicle maintained in ac-
cordance with the Maintenance Booklet and
maintenance service indicator at the designated
times/mileage will result in vehicle damage not
covered by the Mercedes-Benz Limited
Warranty.
!
Excessive load on the brake system causes
increased wear of brake pads and brake disks. If
the brake pads have to be replaced multiple
times within one maintenance service interval,
the brake disks must be checked. Observe the
information given in the Maintenance Booklet
and contact an authorized Mercedes-Benz
Center.

295 Operation
Maintenance
Maintenance service term exceeded
If you have exceeded the suggested main-
tenance service term, you will see the fol-
lowing message in the right multifunction
display:Service Exceeded By .. Days
Service Exceeded By .. MilesAny authorized Mercedes-Benz Center will
reset the maintenance service indicator
following a completed maintenance
service.Calling up the maintenance service due
date
Switch on the ignition (
page 40).

Press buttonè orÿ on the
multifunction steering wheel repeated-
ly until the standard display appears in
the multifunction display (
page 117).

Press button k or j on the
multifunction steering wheel until the
maintenance service indicator service
symbol 9 appears in the left multi-
function display and the maintenance
service deadline appears in the right
multifunction display.
i
If the vehicle is not be used for a longer pe-
riod of time, do not disconnect the consumer
battery. Instead, maintain the condition of the
battery by using the battery charger approved by
Mercedes-Benz for use on the SLR and supplied
with the car (
page 372). This charger automat-
ically controls the charge rate, and can be left
connected to the car for long periods without
damage to the battery.
If the battery supplying the vehicle’s electrical
consumers is disconnected, the days of discon-
nection will not be included in the count shown
by the maintenance service indicator. To arrive
at the true maintenance service deadline, you
will need to subtract these days from the days
shown in the maintenance service indicator.
Do not confuse the maintenance service indica-
tor with the engine oil level indicator:.

296 OperationMaintenanceResetting the maintenance service indicator
In the event that the maintenance service
on your vehicle is not carried out by an
authorized Mercedes-Benz Center, you can
have the maintenance service indicator
reset. The automotive maintenance facility
carrying out the maintenance service will
find the information for resetting the
maintenance service indicator in the
maintenance-relevant information for your
vehicle. Such information is available from
any authorized Mercedes-Benz Center or
directly from Mercedes-Benz.
i
If the maintenance service indicator was in-
advertently reset, have an authorized
Mercedes-Benz Center correct it.
Only reset if the proper maintenance service has
been performed. Resetting the system without
performing the proper service as called for by
the maintenance service indicator will result in
engine damage and/or other vehicle damage not
covered by the Mercedes-Benz Limited
Warranty.
