2009 MERCEDES-BENZ SLR Owner's Manual

193 Controls in detail
Automatic climate control
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside. This setting cuts off the
intake of outside air and recirculates the
air in the passenger compartment.Activating

Press button , (
page 186).
The indicator lamp on the button
comes on.Deactivating

Press button , (
page 186).
The indicator lamp on the button goes
out.
At outside temperatures above 79°F
(26°C) the system will not automatically
switch back to outside air.
Warning!
G
Fogged windows impair visibility, endanger-
ing you and others. If the windows begin to
fog on the inside, switching off the air
recirculation mode immediately should clear
interior window fogging. If interior window
fogging persists, make sure the air
conditioning (
page 194) is activated, or
press buttonP.
i
The air recirculation mode is activated auto-
matically


at high outside temperatures


if the concentration of carbon monoxide
(CO) and nitrogen oxide (NO
X) in the outside
air increases, for example in a tunnel
A quantity of outside air is added after approxi-
mately 30 minutes.
If you have turned off the air conditioning
(
page 194) or the outside temperature is be-
low 41°F (5°C), the air recirculation mode will
not switch on automatically.
i
The manually selected air recirculation
mode is deactivated automatically


after 5 minutes if the outside temperature is
below approximately 41°F (5°C)


after 5 minutes if the air conditioning is
turned off


after 30 minutes if the outside temperature
is above approximately 41°F (5°C)

194 Controls in detailAutomatic climate controlAir conditioning
The air conditioning (cooling) function is
operational when the engine is running and
cools the vehicle interior down to the se-
lected temperature. In addition, the cool-
ing function dehumidifies the air in the
vehicle interior, thus preventing the
windows from fogging up.Deactivating
It is possible to deactivate the cooling
function of the automatic climate control
system. The air in the vehicle will then no
longer be cooled or dehumidified.

Press ± button (
page 186).
The indicator lamp on the ±
button comes on. The cooling function
switches off after a short delay.Activating
Moist air can fog up the windows. You can
dehumidify the air with the air
conditioning.

Press ± button again (
page 186).
The indicator lamp on the ± button
goes out.
The air conditioning uses the refrigerant
R134a. This refrigerant is free of CFCs
which are harmful to the ozone layer.
Warning!
G
If you turn off the cooling function, the
vehicle will not be cooled when weather
conditions are warm. The windows can fog
up more quickly. Window fogging may
impair visibility and endanger you and/or
others.i
Condensation may drip out from underneath
the vehicle. This is normal and not an indication
of a malfunction.
i
Under certain circumstances, e.g. when the
fuel system is too hot and needs to be cooled,
the cooling switches on again automatically. The
red lamp on the ± button the automatic
climate control panel flashes.
After cooling the fuel system sufficiently, the air
conditioning switches off again and the red lamp
stops flashing.
!
If you press the ± button on the auto-
matic climate control panel and it starts to flash,
this indicates that the air conditioning is losing
refrigerant. The compressor has turned off. The
air conditioning cannot be turned on again.
Have the air conditioning checked at the nearest
authorized Mercedes-Benz Center.

195 Controls in detail
Automatic climate control
Residual heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.Activating

Turn the SmartKey in the starter switch
to position1 or0 or remove it from the
starter switch.

Press button T (
page 186).
The indicator lamp on button comes
on.Deactivating

Press button T (
page 186).
The indicator lamp on button goes out.
The residual heat is automatically turned
off:


when the ignition is switched on


after about 30 minutes


if the battery voltage drops


if the coolant temperature is too low
i
How long the system will provide heating
depends on the coolant temperature and the
selected temperature. The blower will run at low
speed regardless of the air distribution control
setting.

196 Controls in detailOpen airOpening and closing the door windows
The door windows are opened and closed
electrically. The switches for the door win-
dows are located on the door sill on the
driver’s side (
page 34). The switch for
the passenger side is located on the door
sill on the passenger side.
1Left window
2Right window

Switch on the ignition (
page 40).
Warning!
G
When closing the door windows, make sure
there is no danger of anyone being harmed
by the closing procedure.
The closing of the door windows can be im-
mediately halted by releasing the switch or,
if switch was pulled past the resistance
point and released, by either pressing or
pulling the respective switch.
If the window encounters an obstruction
t h a t b l o c k s i t s p a t h i n a c i r c u m s t a n c e w h e r e
you pulled the switch past the resistance
point and released it to close the window,
the automatic reversal function will stop the
window and open it slightly.
If the window encounters an obstruction
t h a t b l o c k s i t s p a t h i n a c i r c u m s t a n c e w h e r e
you are closing the window by pulling and
holding the switch, or by pressing and hold-
ing button‹ on the SmartKey, or by
pressing and holding the ,button on the
climate control panel, the automatic
reversal function will not operate.
When leaving the vehicle, always remove the
SmartKey from starter switch, take it with
you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious
personal injury.i
After switching off the ignition (
page 40)
or removing the SmartKey from the starter
switch, the door windows can be operated


until you open a door


for at least 5 minutes if no door was opened

197 Controls in detail
Open air
Opening the door windows
Press switch1 or2 to the resistance
point.
The corresponding window will move
downwards until you release the
switch.
Closing the door windows

Pull switch1 or2 to the resistance
point.
The corresponding window will move
upwards until you release the switch.Fully opening the door windows
(Express-open)

Press switch1 or2 past the
resistance point and release.
The corresponding window opens
completely.
Fully closing the door windows
(Express-close)

Pull switch1 or2 past the
resistance point and release.
The corresponding window closes
completely.Stopping the door windows

Press or pull respective switch again.
Warning!
G
If you pull and hold the switch up when
closing the window, and upward movement
of the window is blocked by some obstruc-
tion including but not limited to arms, hands,
fingers, etc., the automatic reversal will not
operate.
Warning!
G
Driver’s door only:
If within 5 seconds you again pull the switch
past the resistance point and release, the
automatic reversal will not function.
!
If the upward movement of the window is
blocked during the closing procedure, the
window will stop and open slightly.
Remove the obstruction, pull the switch again
past the resistance point and release.
If the window still does not close when there is
no obstruction, then pull and hold the switch
again. The window will then close without the
obstruction sensor function.

198 Controls in detailOpen airSynchronizing power windows
The power windows must be synchronized
each time

after the battery has been
disconnected


if the power windows cannot be fully
opened (Express-open) or closed
(Express-close)

Switch on the ignition (
page 40).

Pull the power window switches until
the windows are closed.
Hold the switches for approximately
1 second.
The power windows are synchronized.
Opening and closing the soft top
For safety reasons, the soft top can only be
opened and closed when the vehicle is
stationary.
Also for safety reasons, the door windows
open automatically if the soft top is not
opened or closed completely and a door is
open.
Warning!
G
To prevent possible accidents, only drive the
vehicle with the soft top either completely
closed and locked, or fully lowered into its
storage compartment.
If the soft top does not open or close com-
pletely, the soft top hydraulic system is de-
pressurized and the soft top is lowered:

after approximately seven minutes
when the ignition is switched on


after approximately 15 seconds when
the ignition is switched off
Shortly before the soft top is lowered, a
warning will sound and the K symbol and
the message
Top Lowering
appear in the
multifunction display.
Lock the soft top again before driving any
further. Otherwise, the unlocked soft top
could open while the vehicle is in motion and
cause you to lose control of the vehicle. You
or others could be injured as a result.

199 Controls in detail
Open air
Your vehicle is equipped with a semi-auto-
matic soft top. This means that you will
have to release or lock the soft top manu-
ally by means of a handle. The soft top can
be opened or closed electrically using the
buttons on the soft top switch.
1Handle
Handle1 serves to release or lock the
soft top.
Warning!
G
When opening or closing the soft top, make
sure that nobody is trapped or injured by the
moving parts such as the soft top linkage.
If potential danger exists, release the soft
top switch. The soft top folding mechanism
stops immediately.Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious
personal injury.
!
The opened soft top is stored behind the
roll-over bars. Never sit on the stored soft top
and never store objects on it. You will otherwise
damage the soft top.
Never use the space that emerges between the
roll-over bars and the rear window when the soft
top is closed as a storing space.
!
When you open or close the soft top, make
sure


there is sufficient clearance, as the soft top
swings upwards


that the soft top fabric is not frozen


that the soft top is not dirty or wet


that no items are placed on the soft top
Otherwise the soft top or other vehicle compo-
nents could be damaged.
!
Please keep in mind that weather conditions
can sometimes change rapidly. Make sure to
close the soft top when leaving the vehicle. If
water enters the vehicle interior, vehicle elec-
tronics could be damaged which is not covered
by the Mercedes-Benz Limited Warranty.

200 Controls in detailOpen airThe soft top switch is located on the lower
part of the center console.Soft top switch cover2Cover
3To open the soft top
4To close the soft topOpening the soft top

Switch on the ignition.

Fold down handle1.

Turn the handle clockwise as far as it
will go and leave it in this position (re-
lease position).

Push the soft top up by means of the
handle as far as it will go.
The soft top is released. An acoustic
signal indicates that you can now open
the soft top electrically.

Open soft top switch cover2.

Press and hold button3, until the soft
top has opened completely and until it
has locked.
While the soft top is opening, the K
symbol and the message
Top In
Operation
appear in the multifunction
display.
The windows open.
The opening process is completed.
i
Make sure that the soft top is dry before
opening it. Otherwise, water may enter the inte-
rior.
!
Leave the handle in the release position. Do
not turn it back. Otherwise, the locking mecha-
nism could be damaged when closing the soft
top.
