2009 Hyundai Getz Owner's Manual - RHD (UK, Australia)

1- 54 FEATURES OF YOUR HYUNDAI
B460A01Y-AAT SUNROOF (If installed) Sun Shade
Your HYUNDAI is equipped with a sliding sunshade which you can manu- ally adjust to let in light with the sunroof closed, or to block sunlight. B470A01FC
WARNING:
Never adjust the sunshade whiledriving.
!
Front side
B450A01TB-GAT DRINK HOLDER (If Installed) The drink holder is used for holding cups or cans. Either holder can be a drink holder or aashtray holder. HTB105-D
Rear side
B455A01TB-GAT CONSOLE TRAY There is a multipurpose compartment to accept pens or CD case in the console tray.
HTB307

FEATURES OF YOUR HYUNDAI 1- 55
!
B460B01GK-GAT Opening the Sunroof System The sunroof can be electrically opened or closed with the ignition key in the "ON" position. The sunroof is moved toits fully open position by pushing the "Open" switch, and to stop at the de- sired position, push in any switches(Open, Close, Up, Down). To close, press and hold the "CLOSE" button. Release the button when the sunroofreaches the desired position. HFC2021WARNING:
o Do not close a sunroof if anyone’s hands, arms or body are betweenthe sliding glass and the sunroofsash, as this could result in in- jury.
o Do not place your head or arms
out of the sunroof opening at anytime.
CAUTION:
o Do not open the sunroof in se- verely cold temperature or when it is covered with ice or snow.
o Periodically remove any dirt that
may have accumulated on theguide rails.
!
HFC2022
B460C01GK-GAT Tilting the Sunroof System The sunroof is moved to its fully tilt up position by pushing the "UP" switch, and to stop at the desired position,push in any switches (Open, Close, Up, Down). To tilt down, press and hold the"DOWN" button. Release the button when the sunroof reaches the desired position. NOTE: After washing the car or after there is rain, be sure to wipe off any water that is on the sunroof before oper-ating it.

1- 56 FEATURES OF YOUR HYUNDAI
HTB050
With Sunroof Without unroof
B480A01E-AAT FRONT INTERIOR LIGHT Map Light The two map light switches are located on both sides of the front overhead console. Push in the map light switchto turn the light on or off. This light produces a spot beam for convenient use as a map light at night or as apersonal light for the driver and the passenger.
B460E02TB-GAT Resetting the Sunroof System If the battery has been recharged, disconnected, or if the sunroof opera- tion is stopped by that ignition key isturned to the "OFF" position while it is moving, you may need to reset the sunroof. To do this;
1. Turn the ignition switch "OFF".
2. With pressing "open" "up" button at
the same time, turn the ignitionswitch "ON".
3. If the sunroof is set like this, the sunroof is reset with tilting up/downautomatically once for all.
! CAUTION:
If the sunroof is not reset, it may not be operated properly.
With SunroofWithout Sunroof
HTB303
The interior courtesy light has a button of three positions. The three positions are:
oDR Type A In the "DR" position, the interior cour- tesy light comes on when any door isopened regardless of the ignition key position. The light goes out when the door is closed.
B490A01TB-AAT INTERIOR LIGHT

FEATURES OF YOUR HYUNDAI 1- 57
Type B In the "DR" position, the interior cour- tesy light comes on when any door isopened regardless of the ignition key position. The light goes out gradually 6 seconds after the door is closed.
oON In the "ON" position, the light stays on at all times.
o OFF In the "OFF" position, the light stays off at all times even though a door is open.
!
!
WARNING:
To avoid the possibility of injury in case of an accident or a sudden stop, the glove box door should bekept closed when the car is in mo- tion.
o To open the glove box, pull on the glove box release lever.
B500A01A-AAT GLOVE BOX
HTB101-D
HTB102
B491A01TB-GAT SPECTACLE CASE (If Installed) The spectacle case is located on the driver side of roof trim.Pull the end of the cover to open the spectacle case.
WARNING:
Do not keep objects such as sharp or unsuitable things inside the spec- tacle case. Such objects can be thrown out in the event of a suddenstop or an accident, possibly injur- ing the passengers in the vehicle.

1- 58 FEATURES OF YOUR HYUNDAI
B510B01FC-GAT Electric Type (If installed) The outside rearview mirrors can be adjusted to your preferred rear vision, both directly behind the vehicle, and tothe rear of the left and right sides. The remote control outside rearview mirror switch controls the adjustmentsfor both right and left outside mirrors. HTB104-D
B510A01A-AAT OUTSIDE REAR VIEW MIRROR Manual Type (If installed) The outside rearview mirrors are equipped with a remote control for your convenience. It is operated by thecontrol lever in the bottom front corner of the window.
HTB306
CAUTION:
If the mirror control is jammed withice, do not attempt to break it free using the control handle or by ma- nipulating the face of the mirror. Use an approved spray de-icer (notradiator antifreeze) to release the frozen mechanism or move the ve- hicle to a warm place and allow theice to melt.
!
Before driving away, always check that your mirrors are positioned so you can see behind you, both to the left and rightsides, as well as directly behind your vehicle. When using the mirror, always exercise caution when attempting tojudge the distance of vehicles behind or along side of you.

FEATURES OF YOUR HYUNDAI 1- 59
HTB213
To adjust the position of either mirror:
1. Move the selecting switch to the
right or left to activate the adjustable mechanism for the correspondingdoor mirror.
2. Now, adjust mirror angle by de-
pressing the appropriate perimeterswitch as illustrated.
!
CAUTION:
o Do not operate the switch con- tinuously for an unnecessary length of time.
o Scraping ice from the mirror face could cause permanent damage.To remove any ice, use a sponge,soft cloth or approved de-icer.!
B510D01HP-DAT OUTSIDE REARVIEW MIRROR
HEATER (If Installed) The outside rearview mirror heater is actuated in connection with the rear window demister. To heat the outsiderearview mirror glass, push in the switch for the rear window demister. The rear- view mirror glass will be heated fordemisting or defogging and will give you improved rear vision in inclement weather conditions. Push the switch again toturn the heater off. The outside rearview mirror heater automatically turns itself off after 20 minutes. HTB039
WARNING:
Be careful when judging the size ordistance of any object seen in the passenger side rear view mirror. It is a convex mirror with a curvedsurface. Any objects seen in this mirror are closer than they appear.

1- 60 FEATURES OF YOUR HYUNDAI
!
HTB251-D
B520A01A-AAT DAY/NIGHT INSIDE REARVIEW MIRROR (If installed) Your Hyundai is equipped with a day/ night inside rearview mirror. The "night" position is selected by flipping the tabat the bottom of the mirror toward you. In the "night" position, the glare of headlights of cars behind you is re-duced. HTB103
Always engage the hand brake beforeleaving the car. This also turns on the hand brake indicator light when the key is in the "ON" or "START" position.Before driving away, be sure that the hand brake is fully released and the indicator light is off.B530A03A-DAT HAND BRAKEB510C01A-AAT FOLDING THE OUTSIDE REAR- VIEW MIRRORS To fold the outside rearview mirrors, push them towards the rear. The outside rearview mirrors can befolded rearward for parking in narrow areas.
HTB205-D
WARNING:
Do not adjust or fold the outsiderearview mirrors while the vehicle is moving. This could result in lossof control, and an accident which could cause death, serious injury or property damage.

FEATURES OF YOUR HYUNDAI 1- 61
!
CAUTION:
Driving with the hand brake applied will cause excessive brake pad (or lining) and brake rotor wear.! Releasing the hand brake To release the hand brake, first apply the foot brake and pull up the handbrake lever slightly. Secondly, depress the release button and lower the hand brake lever while holding the button.
WARNING:
o The transaxle gear shift lever should be in neutral position with the hand brake fully engaged when the vehicle is being transported on a car carrier. During transpor- tation the vehicle should be loadedon a flat deck and not on an incline position of the car carrier.
o Whenever leaving vehicle or park- ing always set the hand brake asfar as possible and fully engage the vehicle's transaxle into the parkposition. Vehicles not fully engaged in park with the hand brake set are at riskfor moving inadvertently and in- juring yourself or others.
Applying the hand brake To engage the hand brake, first apply the foot brake and then without press-ing the release button in, pull the hand brake lever up as far as possible. In addition it is recommended that whenparking the vehicle on a gradient, the shift lever should be positioned in the appropriate low gear on manual transaxlevehicles or in the P (Park) position on automatic transaxle vehicles.
In addition to the lower-mounted rearstop lights on either side of the car, the high mounted rear stop light in thecentre of the rear window or inserted in the rear spoiler also lights when the brakes are applied.
B550A01S-DAT HIGH-MOUNTED REAR STOP LIGHT
B550A01TB
