2009 Hyundai Getz Owner's Manual - RHD (UK, Australia)

1- 46 FEATURES OF YOUR HYUNDAI
OTB048095R
OTB048090R
B340B01A-DAT Lane Change Signal
B340C02FC-DATHeadlight Switch
To indicate a lane change, move the lever up or down to a point where it begins flashing.The lever will automatically return to the centre position when released. To operate the headlights, turn the bar-rel on the end of the multi-function switch. The first position turns on theparking lights, sidelights, tail lights and instrument panel lights. The second position turns on the headlights inaddition. The high headlight beam indicator light will come on when the headlights are turned on. NOTE: The ignition must be in the "ON" position to turn on the headlights.
B340A01A-DAT COMBINATION TURN SIGNAL, HEADLIGHT AND HIGH-BEAMSWITCH Turn Signal Operation Pulling down on the lever causes the turn signals on the right side of the car to blink. Pushing upwards on the lever causes the turn signals on the left sideof the car to blink. As the turn is com- pleted, the lever will automatically re- turn to the centre position and turn offthe turn signals at the same time. If either turn signal indicator light blinks more rapidly than usual or goes on butdoes not blink, or does not go on at all, there is a malfunction in the system. Check for a burned-out fuse or bulb orsee your Hyundai dealer.

FEATURES OF YOUR HYUNDAI 1- 47
B340D01S-DAT High-beam and Low-beam Switch
Parking light auto cut (If installed)
o The purpose of this feature is to
prevent the battery from being dis- charged. The system automaticallyturns off the small light when the driver removes the ignition key and opens the driver- side door.
o With this feature, the parklight will be turned off automatically if the driverparks on the side of road at night.
If necessary, to keep the lights on whenthe ignition key is removed, perform thefollowing :
1) Open the driver-side door.
2) Turn the parklights OFF and ON again using the light switch on the steering column. To turn on the headlight high beams, firstly operate the low beam by turning the barrel to the low beam position then push the lever forward (away from you). The High Beam Indicator Light will come on at the same time. For low beams, pull the lever back toward you.
OTB048093ROTB048094R
B340E01A-AAT Headlight Flasher To flash the headlights, pull the switch lever toward you, then release it. The headlights can be flashed even thoughthe headlight switch is in the "OFF" position.

1- 48 FEATURES OF YOUR HYUNDAI
B350A01A-AAT WINDSHIELD WIPER AND WASHER SWITCH The windshield wiper switch has three positions:
1. Intermittent wiper operation
2. Low-speed operation
3. High-speed operation NOTE: To prevent damage to the wiper sys- tem, do not attempt to wipe away heavy accumulations of snow or ice.Accumulated snow and ice should be removed manually. If there is only a light layer of snow or ice, operate theheater in the defrost mode to melt the snow or ice before using the wipers.
Rear window wiper/washer (If Installed)Windshield wiper/washer
OMC048910R
OMC048911R
B350A01TB-GAT WINDSHIELD WIPER/WASHER SWITCH
A : Wiper speed control· MIST – Single wipe
· OFF – Off · INT – Intermittent wipe · LO – Low wiper speed · HI – High wiper speed
B : Intermittent wipe time adjustment
C : Wash with brief wipes
D : Rear wiper/washer control ·
– Wash with brief wipes
· ON – Continuous wipe
· OFF – Off
OMC048912R
(1)
(2) (3)

FEATURES OF YOUR HYUNDAI 1- 49
B350C01FC-GAT Adjustable Intermittent Wiper
Operation (If Installed)
To use the intermittent wiper feature, place the wiper switch in the "INT" position. With the switch in this posi-tion, the interval between wipes can be varied from approximately 1 to 18 sec- onds by turning the interval adjusterbarrel (1).
Mist Wiper Operation
If a single wipe is desired in mist, push the windshield wiper and washer con- trol lever upwards.
To use the windshield washer, pull the wiper/washer lever toward the steer- ing wheel. When the washer lever isoperated, the wipers automatically make two passes across the wind- shield. The washer continues to oper-ate until the lever is released.
B350B01O-GAT Windshield Washer Operation
NOTE:
o Do not operate the washer more
than 15 seconds at a time or when the fluid reservoir is empty.
o In icy or freezing weather, be sure the wiper blades are not frozen tothe glass prior to operating thewipers.
o In areas where water freezes in
winter, use windshield washerantifreeze.
OMC048913R
OMC048914R
OMC048915R

1- 50 FEATURES OF YOUR HYUNDAI
B370A01A-AAT HAZARD WARNING SYSTEM The hazard warning system should be used whenever you find it necessary to stop the car in a hazardous location.When you must make such an emer- gency stop, always pull off the road as far as possible.The hazard warning lights are turned on by pushing in on the hazard switch. This causes all turn signal lights toblink. The hazard warning lights will operate even though the key is not in the ignition.To turn the hazard warning lights off, push in on the switch a second time. B380A01HP-DAT REAR WINDOW DEMISTER SWITCH The rear window demister is turned on by pushing in on the switch. To turn the demister off, push in on the switch asecond time. The rear window demister automatically turns itself off after about 20 minutes. To restart the demistercycle, push in on the switch again after it has turned itself off.
HTB039
B350A01TB-AAT Tail Gate Wiper And Washer Switch
1. : The washer fluid will be sprayed onto the rear window and the wiper operates while the rear win-dow wiper barrel is placed in this position.
2.ON : When the point indicates "ON",
the rear window wiper oper-ates continuously.
3.OFF
B370A01TB-D
OMC048916R

FEATURES OF YOUR HYUNDAI 1- 51
B360B01FC-GAT FRONT FOG LIGHT SWITCH (If Installed)
To turn on the front fog lights, push the switch in the "ON" position. They will come on when the headlight switch isin the first or second position.
CAUTION:
Do not clean the inner side of therear window glass with an abrasive type of glass cleaner or use a scraper to remove foreign deposits fromthe inner surface of the glass as this may cause damage to the demister elements. NOTE: The engine must be running for the rear window demister to operate.
!
HTB2030-D
B400A01E-AAT DIGITAL CLOCK
HTB2033-D
There are three control buttons for the digital clock. Their functions are: HOUR -Push "H" to advance the hour
indicated.
MIN -Push "M" to advance the
minute indicated.
RESET - Push "R" to reset minutes to
":00" to facilitate resetting the clock to the correct time. When this is done:
Pressing "R" between 10 : 30 and 11 :29 changes the readout to 11 : 00. Pressing "R" between 11 : 30 and 12 :29 changes the readout to 12 : 00.

1- 52 FEATURES OF YOUR HYUNDAI
CAUTION:
Do not use electric accessories or equipment other than the Hyundai genuine parts in the socket.!
B420A02A-AAT CIGARETTE LIGHTER (If installed) For the cigarette lighter to work, the key must be in the "ACC" position or the "ON" position. To use the cigarette lighter, push it allthe way into its socket. When the ele- ment has heated, the lighter will pop out to the "ready" position.Do not hold the cigarette lighter pressed in. This can damage the heating ele- ment and create a fire hazard.If it is necessary to replace the ciga- rette lighter, use only a genuine Hyundai replacement or its approved equiva-lent.
HHR2098A
The instrument panel lights can be made brighter or dimmer by turning the instrument panel light control knob. HTB182-D
B410A01A-AAT INSTRUMENT PANEL LIGHT CONTROL (RHEOSTAT)

FEATURES OF YOUR HYUNDAI 1- 53
B500D01TG-DAT POWER OUTLET (If installed)
These supply 12V electric power to operate electric accessories or equip- ment only when the key is in the "ON" or "ACC" position.
!
CAUTION:
o Only use the power outlet when the engine is running. The use of this outlet with the engine not running may cause the battery to be discharged.
o Do not use the power outlet to connect electric accessories orequipment other than those de-signed to operate on 12 volts.
o Some electronic devices can cause
electronic interference whenplugged into the power outlet. These devices may cause exces- sive audio noise and malfunctionsin other electronic systems or de- vices used in your vehicle.
OHTB029040R
B430A01TB-GAT FRONT ASHTRAY (If installed) The front ashtray may be opened by pulling it up by its top edge. To closethe ashtray cover firmly, let the lid grip protrude outside. To remove the ash- tray to empty or clean it, pull the coverup all the way out. Either holder can be a drink holder or a ashtray holder. HTB100-D
