2009 Hyundai Getz Owner's Manual - RHD (UK, Australia)

1- 6 FEATURES OF YOUR HYUNDAI
The outside door handle will function normally, regardless of the position of the child protector door lock.
HTB212-D
B040G02FC-GAT Central Door Lock (If Installed)
HTB057-D
UN- LOCK
LOCK
B040D01FC-GAT Locking From the Inside To lock the doors from the inside, sim- ply close the door and push the lock switch to the "LOCK" position. Whenthis is done, neither the outside nor the inside door handle can be used. NOTE: When the door is locked, the red mark on the switch is not visible and the character "LOCK" on the switch is visible. B040E04A-DAT CHILD-PROTECTOR REAR DOOR LOCK
Your Hyundai is equipped with a "child- protector" rear door lock assembly. When the lock mechanism is engaged,the rear door cannot be opened from the inside. It's use is recommended whenever there are small children inthe rear seat. To engage the child-protector feature so that the door cannot be opened from inside, move the child-protector lever to the "
" position and close the door.
Move the lever to the "
" position
when normal door operation is desired. HTB058-D
The central door locking is operated by pushing the driver's door lock switchtoward the front or rear of the vehicle. If the passenger and rear doors are open when the switch is pushed, thedoor will remain locked when closed.

FEATURES OF YOUR HYUNDAI 1- 7
B070B01TB-D
NOTE:
o When pushing the switch toward
the rear, all doors and tail gate will unlock.When pushing the switch toward the front, all doors and tail gate will lock.
o When the door is unlocked, the red mark on the switch is visibleand the character "LOCK" on theswitch is visible.
o The central door locking is oper-
ated by turning the key (with theft-alarm system: driver's door and passenger's door, without theft- alarm system: driver's door only)toward the front or rear of the vehicle.
o If the door is locked/unlocked mul- tiple times in rapid successionwith either the vehicle key or door lock switch, the system may stopoperating temporarily in order to protect the circuit and prevent damage to system components. B070A01A-DAT THEFT-ALARM SYSTEM (If Installed) This system is designed to provide protection from unauthorised entry into the car. This system is operated inthree stages: the first is the "Armed" stage, the second is the "Alarm" stage, and the third is the "Disarmed" stage.If triggered, the system provides an audible alarm with blinking of the turn signal lights.
B070B01O-DAT Armed Stage Park the car and stop the engine. Arm the system as described below.
1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine bonnet
and tail gate are locked.
3) Lock the doors using the transmitter
of the keyless entry system.
After completion of the steps above, the turn signal lights will blink once toindicate that the system is armed.

1- 8 FEATURES OF YOUR HYUNDAI
HTB202
B070D01TB-AAT Disarmed Stage
B070C01FC-DATAlarm Stage The alarm will be activated if any of the following occurs while the car is parkedand the system is armed.
1) A front or rear door is opened with-
out using the transmitter.
2) The tail gate is opened without us-
ing the transmitter.
3) The engine bonnet is opened.The alarming horn will sound and the turn signal light will blink continuously for 27 seconds (It happens 3 times). To turn off the system, unlock the dooror tail gate with the transmitter. The system will be disarmed when the driver's or passenger's door is un- locked by depressing the button on thetransmitter. After completion of the step above, the turn signal lights will blink twice to indicate that the system is disarmed. NOTE: Once the system has been dis- armed, it can not be rearmed except by repeating the arming procedures.
NOTE:
1) If any door, tail gate or engine
bonnet remains open, the system will not be armed.
2) If this happens, rearm the system as described above.
! CAUTION:
Do not arm the system until all passengers have left the car. If the system is armed while apassenger(s) remains in the car, the alarm may be activated when the remaining passenger(s) leavesthe car.

FEATURES OF YOUR HYUNDAI 1- 9
CAUTION:
Only the transmitter can disarm the armed stage. If the transmitter does not disarm the system, it is neces-sary to take the following steps;
1. Unlock the door with the key, which will cause, the alarm to be activated.
2. Insert the key in the ignition key cylinder and turn the ignition keyto "ON" position.
3. Wait for 30 seconds. After completing the steps above, the system will be disarmed.! B070F02TB-GAT Keyless Entry System (If Installed) Locking doors
1. Close all doors.
2. Push the button on the transmitter.
3. At the same time all doors lock, the
turn signal lights will blink once to indicate that the system is armed.
Unlocking doors
1. Push the button on the transmitter.
2. At the same time all doors unlock, the turn signal light will blink twice to indicate that the system is disarmed.
NOTE: The transmitter will not work if any of following occur:
- The ignition key is in ignition switch.
- You exceed the operating distance limit (10 m).
- The battery in the transmitter is
weak.
- Other vehicles or objects may be
blocking the signal. - The weather is extremely cold.
- The transmitter is close to a radio
transmitter such as a radio station or an airport which can interfere with normal operation of the trans- mitter.
When the transmitter does not workcorrectly, open and close the doorwith the ignition key. If you have a problem with the transmitter, con- tact an authorized Hyundai Dealer. NOTE: Keep the transmitter away from wa- ter or any liquid. If the keyless entrysystem is inoperative due to expo- sure to water or liquids, it will not be covered by your manufacturer ve-hicle warranty.

1- 10 FEATURES OF YOUR HYUNDAI
!
HTB257-D
B050A01A-AAT WINDOW GLASS
To raise or lower the window, turn the window regulator handle clockwise or counterclockwise. WARNING:
When opening or closing the win-dows, make sure your passenger's arms, hands and body are safely out of the way.3. Remove four screws back side of the built-in circuit. HTB054
HTB055
Battery
4. Remove the old battery from the case and note the polarity. Make sure the polarity of the new battery is the same (+side facing up), then insert it in the transmitter.
HTB053
B070E01TB-DAT Replacing the battery When the transmitter's battery be- comes weak, it may take several pushes on the button to lock or unlockthe doors, and the LED will not light. Replace the battery as soon as pos- sible. Battery type : CR1220 Replacement instructions:
1. Remove the screw with a phillips
screwdriver.
2. Carefully separate the case with a flat-head screwdriver as shown in the illustration.

FEATURES OF YOUR HYUNDAI 1- 11
!
!
HTB064-D
(1)
HTB066-D
In order to prevent operation of the passenger front and rear windows, a window lock switch is provided on thearmrest of the driver's door. To disable the power windows, press the window lock switch.To revert to normal operation, press the window lock switch a second time. Auto-Down Window (Driver's Side) The Auto-Down window is moved to its fully open position by pushing the switch. To stop at the desired positionpush the switch again.
B060A01E-AAT POWER WINDOWS (If Installed)
The power windows operate when the ignition key is in the "ON" position. The main switches are located on thedriver's armrest and control the front and rear windows on both sides of the vehicle. The windows may be openedby depressing the appropriate window switch and closed by pulling up the switch. To open the window on thedriver's side, press the switch(1) down. The window moves as long as the switch is operated. B080A02FC-GAT ADJUSTABLE SEATSWARNING:
1) Be careful that someone's head, hands and body are not trapped by a closing window.
2) Never try to operate the main switch on the driver's door andthe individual door window switch in opposing directions atthe same time. If this is done, the window will stop and cannot be opened or closed.
3) Do not leave children alone in the car. Always remove the ignitionkey for their safety.
WARNING:
Never attempt to adjust the seatwhile the vehicle is in motion. This could result in loss of control, or an accident which may cause death,serious injury, or property damage.

1- 12 FEATURES OF YOUR HYUNDAI
To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at the outsideedge of the seat. Now lean back until the desired seatback angle is achieved. To lock the seatback into position,release the recliner control lever. WARNING:
To minimise risk of severe injury inthe event of a collision or a sudden stop, both the driver and passen- ger seatbacks should always be inan upright position while the ve- hicle is in motion. The protection provided by the seat belts andairbags may be reduced significant- ly when the seatbacks are reclined. There is greater risk that the driverand passenger will slide under the seat belt which may result in seri- ous injury if a crash occurs whenthe seatbacks are reclined. The seat belt cannot provide full protection to an occupant if the seat back isreclined.
HTB026-D
B080C01A-AAT Adjusting Seatback Angle
!
B080B01FC-GAT FRONT SEATS Adjusting Seat Forward andRearward
HTB024-D
!
To move the seat toward the front or rear, pull the lock release lever upward. This will release the seat on its track so you can move it forward or rearward to the desired position. When you find the position you want, release the lever and slide the seat forward or rearward on its track until it locks into the desired posi- tion and cannot be moved further.WARNING:
To ensure the seat is locked securely, attempt to move the seat forward or rearward without using the lock re- lease lever.

FEATURES OF YOUR HYUNDAI 1- 13
HFC2028
Lock knob
!WARNING:
B080D03JM-GAT Adjustable Headrests
Headrests are designed to help reduce the risk of neck injuries. To raise the headrest, pull it up. Tolower it, push it down while pressing the lock knob. To remove the head- rest, raise it as far as it can go thenpress the lock knob while pulling up- ward. This should only be done when the seat is not occupied. B080D01JM
o For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the sameheight of the center of gravity of an occupant's head. Generally, the center of gravity of mostpeople's head is similar with the height of the top of their eyes. Also, adjust the headrest as closeto your head as possible. For this
reason, the use of a cushion thatholds the body away from theseatback should not be recom- mended. o Do not operate vehicle with the
headrests removed as injury to the occupants may occur in the event of an accident. Headrests may provide protection againstneck injuries when properly ad- justed.
o Do not adjust the headrest posi- tion of the driver’s seat while thevehicle is in motion.
B083D01NF-AAT Active Headrests (If Installed) The active headrest is designed to move forward and upward during a rear impact. This helps to prevent the driver'sand front passenger's head from mov- ing backward and thus helps prevent neck injuries. HNF2041-1
