YOUR VEHICLE AT A GLANCE
F10
G255A01TB-DAT INDICATOR SYMBOLS ON THE INSTRUMENT PANEL * A detailed explanation of these items will be found on page 1-37
SRS (Airbag) Service Reminder Indicator ABS Service Reminder Indicator Turn Signal Indicator Lights High Beam Indicator Light Oil Pressure Warning Light Hand Brake/Brake Fluid Level Warning Light Charging System Warning LightTail Gate Open Warning Light
Door Ajar Warning Light and Chime
Low Fuel Level Warning Light Malfunction Indicator Light Seat Belt Reminder Light
O/D OFF Indicator (Automatic transaxle only)
Immobiliser Indicator Light
Electronic Stability Program Indicator Lights (If Installed)
Engine Coolant Temperature Indicator

FEATURES OF YOUR HYUNDAI 1- 29
The SRS consists of the following com- ponents:
- Driver's Airbag Module
- Passenger's Airbag Module
- SRS Service Reminder Indicator(SRI)
- SRS Control Module (SRSCM)
The SRSCM continually monitors all elements while the ignition is "ON" to determine if a frontal or near-frontalimpact is severe enough to require airbag deployment.
B240B01FC-GAT SRS Components and Functions
HTB203
Rear impact
Side Impact Rollover
o Front airbags are not intended to deploy in side-impact, rear-im- pact or rollover crashes. In addi- tion, airbags will not deploy in frontal crashes below the deploy-ment threshold speed.
o For maximum safety in event of
collision, all occupants shouldwear their seat belts to minimise the risk of severe injury or death. Do not sit or lean unnecessarilyclose to the airbag while the ve- hicle is in motion. o The SRS airbag system must de-
ploy very rapidly to provide pro- tection in a crash. If an occupantis out of position because of not wearing a seat belt, the airbag may forcefully contact the occupantcausing serious or fatal injuries.
B240B01L-D

1- 30 FEATURES OF YOUR HYUNDAI
The SRS service reminder indicator (SRI) on the instrument panel will blink for about 6 seconds after the ignitionkey is turned to the "ON" position or after the engine is started, after which the SRI should go out. The airbag modules are located both in the centre of the steering wheel and in the front passenger's panel above theglove box. When the SRSCM detects a considerable impact to the front of the vehicle, it will automatically deploy theairbags.
Passenger's Airbag
Upon deployment, tear seams molded directly into the pad covers will sepa- rate under pressure from the expan-sion of the airbags. Further opening of the covers then allows full inflation of the airbags. A fully inflated airbag in combination with a properly worn seat belt slowsthe driver's or the passenger's forward motion, thus reducing the risk of head or chest injury. HTB204-D
B240B02L-DB240B03L-D

FEATURES OF YOUR HYUNDAI 1- 37
!
B260B01HP-GAT
SRS (Airbag) Service Re
minder Indicator (SRI)
The SRS service reminder indicator (SRI) comes on and flashes for about 6 seconds after the ignition key isturned to the "ON" position or after the engine is started, after which it will go out. This light also comes on when the SRS is not working properly. If the SRI doesnot flash, or continuously remains on after flashing for about 6 seconds when you turned the ignition key to the "ON"position or started the engine, or if it comes on while driving, have the SRS inspected by an authorisedHyundai Dealer. B260C01A-AAT
O/D OFF Indicator (Automatic transaxle
only) (If Installed)
When the overdrive switch is turned on, the overdrive off indicator will go out. This amber indicator will be illumi-nated when the overdrive switch is turned off. B260D01A-AAT Turn Signal Indicator Lights
The blinking green arrows on the in- strument panel show the direction indi-cated by the turn signals. If the arrow comes on but does not blink, blinks more rapidly than normal, or does notilluminate at all, a malfunction in the turn signal system is indicated. Your dealer should be consulted for repairs.B260P02Y-GAT ABS Service Reminder Indicator (SRI)(If Installed)
When the key is turned to the "ON" position, the Anti-Lock Brake System will come on and then go off in a fewseconds. If the ABS SRI remains on, comes on while driving, or does not come on when the key is turned to the"ON" position, this indicates that there may be a problem with the ABS. If this occurs, have your vehiclechecked by your Hyundai dealer as soon as possible. The normal braking system will still be operational, butwithout the assistance of the anti-lock brake system.
WARNING:
If both ABS SRI and Parking Brake/ Brake fluid level warning lights re-main "ON" or come on while driv- ing, there may be a problem with E.B.D (Electronic Brake Force Dis-tribution). If this occurs, avoid sudden stops and have your vehicle checked byyour Hyundai dealer as soon as possible.
B260F01A-AAT High Beam Indicator Light
The high beam indicator light comes on whenever the headlights are switched to the high beam or flash position.

10- 4 INDEX
High-Mounted Rear Stop Light.................................... 1-62
How to use luggage Room ......................................... 1-66
Horn ............................................................................ 1-69
I Ignition Switch ............................................................. 2-3
Immobilizer System ..................................................... 1-3
Instrument Cluster and Indicator Lights ...................... 1-35
Instrument Panel Light Control (Rheostat) .................. 1-52
Interior Light ................................................................ 1-57
Intermittent Wiper ....................................................... 1-49
JJump Starting .............................................................. 3-3
KKey If you lose y our keys .............................................. 3-10
Positions ................................................................... 2-3
L
Lubrication Chart .......................................................... 9-4
Luggage Board ............................................................ 1-67
Luggage Net ............................................................... 1-67
Luggage side trim ....................................................... 1-66M Maintenance Intervals
Explanation of scheduled maintenance items........................................................................ 5-7 ~ 5-9
Maintenance under severe usage conditions ............ 5-6
Scheduled maintenance ................................... 5-4 ~ 5-5
Service requirements ................................................ 5-2
Mirrors Outside rearview mirror heater .................................1-60
O
Odometer .................................................................... 1-41
Outside rearview Mirror............................................... 1-59
Outside rearview Mirror Heater................................... 1-60
P
Power Steering Fluid Level ......................................... 6-22
Power windows ........................................................... 1-11
RRear seat .................................................................... 1-15
Rear Seat F old Down ................................................. 1-16
Rear Window Demister Switch ................................... 1-50
Running in your New Hyundai ..................................... 1-3
