2008 TOYOTA TUNDRA display

DESTINATION SEARCH
452008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
— Destination search by
Quick access
1. Push the “DEST” button.
2U5089aG
2. Touch any of the quick access touch
screen buttons on the “Destination”
screen.
The screen changes and displays the map
location of the quick access point and the
route preference. (See “Starting route
guidance” on page 61.)
To use this function, it is necessary to set
“Quick access” for each memory point. (To
register “Quick Access”, see page 95.)
INFORMATION
Guidance starts from the current vehicle
position to the quick access point if
“Enter” is touched even while driving.
— Destination search by
“Address”
There are 2 ways to input a destination by ad-
dress.
1. Push the “DEST” button.
2. Touch “Address” on the “Destination”
screen.
2U5003aG
(a) Inputting a house number and a street
name
2U5004aG
1. Touch numerals directly on the screen
to input a house number.
After inputting a house number, touch “OK”
to display the screen for inputting a street
name.
It is possible to input a street name first.
Touch “Street” to display the screen for in-
putting a street name.

DESTINATION SEARCH
462008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5005aG
2. Input the street name and touch “List”.
2U5006G
3. When the desired street name is found,
touch the corresponding touchscreen
button.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 61.)
If the same address exists in more than one
city, the current screen changes to the city list
screen.
2U5007G
4. Select or enter the desired city.
“Input Name”: To narrow down the listed
items by inputting the city name.

DESTINATION SEARCH
482008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5011aG
To search by city, the following three methods
are possible.
1. Input the city name
2. Select from the nearest 5 cities
3. Select from the last 5 cities
INFORMATION
To change the search area, touch
“Search Area”.
To cancel the city setting, touch “Any
City”.
INPUTTING THE CITY NAME
1. Touch “Input City Name”.
2U5013G
2. Input a city name.
2U5014aG
3. Touch the touchscreen button of the
desired city name from the displayed list.
“Map”: To display the selected destination
and the route preference. (See “Starting
route guidance” on page 61.)
The current screen changes to the screen for
inputting a house number or a street name.
(See “(a) Inputting a house number and a
street name” on page 45.)

DESTINATION SEARCH
492008 TUNDRA Navigation from Oct.07 Prod.(OM34469U) SELECTING FROM THE NEAREST 5
CITIES
1. Touch “Nearest 5 Cities”.
2U5012aG
2. Touch the touchscreen button of the
desired city name from the displayed list.
The current screen changes to the screen for
inputting a house number or a street name.
(See “(a) Inputting a house number and a
street name” on page 45.)SELECTING FROM THE LAST 5 CITIES
2U5091aG
Touch the touchscreen button of the de-
sired city name.
If the navigation has not be used, no cities will
be displayed on the screen.
The current screen changes to the screen for
inputting a house number or a street name.
(See “(a) Inputting a house number and a
street name” on page 45.)
— Destination search by “POI
Name”
1. Push the “DEST” button.
2. Touch “POI Name” on the
“Destination” screen.
2U5015G
3. Input the name of the Point of Interest.

DESTINATION SEARCH
502008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5016aG
4. Touch the touchscreen button of the
desired destination.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 61.)
When inputting the name of a specific Point of
Interest, and there are two or more sites with
the same name, the list screen is displayed.
2U5017G
Touch the touchscreen button of the de-
sired destination.
If the same name exists in more than one city,
a search can be performed more easily with
“City” and “Category”. (See “(a) Selecting
a city to search” on page 50 and “(b)
Selecting from the categories” on page 52.)
INFORMATION
The desired Point of Interest can be
displayed on the map screen. (See “ —
Display POI icons” on page 76.)
(a) Selecting a city to search
2U5092bG
Touch “City”.

DESTINATION SEARCH
512008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5093aG
To search by city, the following three methods
are possible.
1. Input the city name
2. Select from the nearest 5 cities
3. Select from the last 5 cities
INFORMATION
To change the search area, touch
“Search Area”.
To cancel the city setting, touch “Any
City”.
INPUTTING THE CITY NAME
1. Touch “Input City Name”.
2U5019G
2. Input the city name.
2U5020aG
3. Touch the touchscreen button of the
desired city name from the displayed list.SELECTING FROM THE NEAREST 5
CITIES
1. Touch “Nearest 5 Cities”.
2U5018aG
2. Touch the touchscreen button of the
desired city name.

DESTINATION SEARCH
522008 TUNDRA Navigation from Oct.07 Prod.(OM34469U) SELECTING FROM THE LAST 5 CITIES
2U5094aG
Touch the touchscreen button of the de-
sired city name.
If the navigation has not be used, no cities will
be displayed on the screen.(b) Selecting from the categories
2U5097aG
Touch “Category”.
2U5021G
If the desired POI category is on the screen,
touch the name to display a detailed list of the
POI category.If the desired POI category is not on the
screen, touch “List All Categories” to list all
POI categories.
2U5022aG
When the desired category is touched, the
POI name list screen is displayed.

DESTINATION SEARCH
532008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
— Destination search by “POI
Category”
The destination can be set by selecting the
search point and the POI category.
1. Push the “DEST” button.
2. Touch “POI Category” on the “Destina-
tion” screen.
2U5023aG
Set the search point by the following
method:
1. Input the city center
2. Set the current position as the search
point
3. Set the search point via the map screen
4. Set the search point from any destination
It is possible to display the names of POIs lo-
cated within approximately 20 miles (32 km)
from the selected search point.INPUTTING THE CITY CENTER
1. Touch “Input City Center”.
2U5024G
2. Input the city center name.
2U5025aG
3. Touch the touchscreen button of the
desired city center name.
2U5026G
When an arrow facing the desired point is
touched, the map scrolls in that direction. Re-
leasing the finger from the arrow will stop the
scrolling
4. Touch “Enter”.
The search point is set and the “POI
Category” screen will be displayed.
