HAC-212
< ECU DIAGNOSIS >[WITH 7 INCH DISPLAY]
A/C AUTO AMP.
WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM :
DTC Inspection Priority Chart
INFOID:0000000003884792
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : DTC IndexINFOID:0000000003884793
Compressor : ON
Air outlet : AUTO
Air inlet : FRE (Fresh)
Blower fan speed : AUTO
Set temperature : Setting before communication error occurs
Priority Detected items (DTC)
1 U1000: CAN COMM CIRCUIT
 U1010: CONTROL UNIT (CAN)
2 B257B: AMB TEMP SEN (SHORT)
 B257C: AMB TEMP SEN (OPEN)
 B2578: IN CAR SENSOR (OUT OF RANGE [LOW])
 B2579: IN CAR SENSOR (OUT OF RANGE [HI])
 B2581: EVAP TEMP SEN (SHORT)
 B2582: EVAP TEMP SEN (OPEN)
 B2630: SUNLOAD SEN (SHORT)
 B2631: SUNLOAD SEN (OPEN)
 B2632: DR AIRMIX ACTR (SHORT)
 B2633: DR AIRMIX ACTR (OPEN)
 B2634: PASS AIRMIX ACTR (SHORT)
 B2635: PASS AIRMIX ACTR (OPEN)
 B2636: DR VENT DOOR FAIL
 B2637: DR B/L DOOR FAIL
 B2638: DR D/F1 DOOR FAIL
 B2639: DR DEF DOOR FAIL
 B263D: FRE DOOR FAIL
 B263E: 20P FRE DOOR FAIL
 B263F: REC DOOR FAIL
 B2654: D/F2 DOOR FAIL
 B2655: B/L2 DOOR FAIL
 B2656: BTC FRE DOOR FAIL
DTCItems
(CONSULT-III screen terms)Reference
U1000 CAN COMM CIRCUITHAC-164, "
DTC Logic"
U1010 CONTROL UNIT (CAN)HAC-165, "DTC Logic"
B257B AMB TEMP SEN (SHORT)HAC-166, "DTC Logic"
B257C AMB TEMP SEN (OPEN)HAC-166, "DTC Logic"
B2578 IN CAR SENSOR (OUT OF RANGE [LOW])HAC-169, "DTC Logic"
B2579 IN CAR SENSOR (OUT OF RANGE [HI])HAC-169, "DTC Logic"
B2581 EVAP TEMP SEN (SHORT)HAC-172, "DTC Logic"
B2582 EVAP TEMP SEN (OPEN)HAC-172, "DTC Logic"
B2630*SUNLOAD SEN (SHORT)HAC-178, "DTC Logic"
B2631*SUNLOAD SEN (OPEN)HAC-178, "DTC Logic"
B2632 DR AIRMIX ACTR (SHORT)HAC-181, "DTC Logic"
B2633 DR AIRMIX ACTR (OPEN)HAC-181, "DTC Logic"

A/C AUTO AMP.
HAC-213
< ECU DIAGNOSIS >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
*: Perform self-diagnosis under sunshine. When performing indoors, aim a light (more than 60 W) at sunload sensor, otherwise self-diag-
nosis indicates even though the sunload sensor is functioning normally.
WITH INTELLIGENT AIR CONDITIONER SYSTEM
WITH INTELLIGENT AIR CONDITIONER SYSTEM : Reference ValueINFOID:0000000003884794
VALUES ON THE DIAGNOSIS TOOL
CONSULT-III MONITOR ITEM
TERMINAL LAYOUT
B2634 PASS AIRMIX ACTR (SHORT)HAC-183, "DTC Logic"
B2635 PASS AIRMIX ACTR (OPEN)HAC-183, "DTC Logic"
B2636 DR VENT DOOR FAILHAC-185, "DTC Logic"
B2637 DR B/L DOOR FAILHAC-185, "DTC Logic"
B2638 DR D/F1 DOOR FAILHAC-185, "DTC Logic"
B2639 DR DEF DOOR FAILHAC-185, "DTC Logic"
B263D FRE DOOR FAILHAC-188, "DTC Logic"
B263E 20P FRE DOOR FAILHAC-188, "DTC Logic"
B263F REC DOOR FAILHAC-188, "DTC Logic"
B2654 D/F2 DOOR FAILHAC-185, "DTC Logic"
B2655 B/L2 DOOR FAILHAC-185, "DTC Logic"
B2656 BTC FRE DOOR FAILHAC-188, "DTC Logic"
DTCItems
(CONSULT-III screen terms)Reference
Monitor item Condition Value/Status
COMP REQ SIGEngine: Run at idle after
warming up A/C switch: ON
(Compressor operation sta-
tus) On
A/C switch: OFF Off
FAN REQ SIGEngine: Run at idle after
warming up Blower fan: ON On
Blower fan: OFF Off
AMB TEMP SEN Ignition switch ON — −30 - 55°C (−22 - 131°F)
IN-VEH TEMP Ignition switch ON — −30 - 55°C (−22 - 131°F)
INT TEMP SEN Ignition switch ON — −30 - 55°C (−22 - 131°F)
SUNLOAD SEN Ignition switch ON —0 - 1045 W/m
2
(0 - 900 kcal/m2·h)
AMB SEN CAL Ignition switch ON —−30 - 55°C (−22 - 131°F)
IN-VEH CAL Ignition switch ON —−30 - 55°C (−22 - 131°F)
INT TEMP CAL Ignition switch ON —−30 - 55°C (−22 - 131°F)
SUNL SEN CAL Ignition switch ON —0 - 1045 W/m
2
(0 - 900 kcal/m2·h)
FAN DUTYEngine: Run at idle after
warming up Blower fan: ON 21 - 91%
Blower fan: OFF 0%
XM Ignition switch ON —−100 - 150
ENG COOL TEMP Ignition switch ON —Values according to coolant
temperature
VEHICLE SPEED Driving —Equivalent to speedometer
reading

HAC-214
< ECU DIAGNOSIS >[WITH 7 INCH DISPLAY]
A/C AUTO AMP.
PHYSICAL VALUES
JSIIA1205ZZ
Te r m i n a l N o .
(Wire color)Description
ConditionVa l u e
(Approx.)
+−Signal nameInput/
Output
10
(L/R)Ground LAN signalInput/
Output—
11
(L/W)GroundPower supply for each door
motorInput Ignition switch ON Battery voltage
12
(O)Ground ION ON/OFF signal OutputBlower fan ON 0 V
Blower fan OFF 12 V
14
(G)Ground Gas sensor signal InputNOTE:
The signal is different by mea-
surement environment of a ve-
hicle
15
(O)Ground Sunload sensor signal Input — —
16
(R/G)Ground Intake sensor signal Input — —
17
(V/W)Ground ACC Power supply — Ignition switch ACC Battery voltage
19
(B)Ground Ground — Ignition switch ON 0 V
20
(G/W)Ground IGN Power supply — Ignition switch ON Battery voltage
28
(G/Y)GroundIon control mode output sig-
nalOutputClean mode 12 V
Ion control mode 0 V
SJIA1453J
ZJIA1163J

A/C AUTO AMP.
HAC-215
< ECU DIAGNOSIS >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
WITH INTELLIGENT AIR CONDITIONER SYSTEM : Wiring Diagram - AIR CONDI-
32
(L/Y)Ground Blower motor control signal Output Ignition switch ON
 Blower speed: 1st speed
(manual)
34
(P)GroundA/C auto amp. connection
recognition signalOutput Ignition switch ON 5V
35
(O/B)Ground Ambient sensor signal Input — —
36
(LG)Ground In-vehicle sensor signal Input — —
37
(B/Y)Ground Sensor ground — Ignition switch ON 0 V
39
(B)Ground Ground — Ignition switch ON 0 V
40
(Y/R)Ground BATT Power supply — Ignition switch OFF Battery voltage Te r m i n a l N o .
(Wire color)Description
ConditionVa l u e
(Approx.)
+−Signal nameInput/
Output
JSIIA0096ZZ

HAC-224
< ECU DIAGNOSIS >[WITH 7 INCH DISPLAY]
A/C AUTO AMP.
WITH INTELLIGENT AIR CONDITIONER SYSTEM : DTC Inspection Priority Chart
INFOID:0000000003884796
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
WITH INTELLIGENT AIR CONDITIONER SYSTEM : DTC IndexINFOID:0000000003884797
Compressor : ON
Air outlet : AUTO
Air inlet : FRE (Fresh)
Blower fan speed : AUTO
Set temperature : Setting before communication error occurs
Priority Detected items (DTC)
1 U1000: CAN COMM CIRCUIT
 U1010: CONTROL UNIT (CAN)
2 B257B: AMB TEMP SEN (SHORT)
 B257C: AMB TEMP SEN (OPEN)
 B2578: IN CAR SENSOR (OUT OF RANGE [LOW])
 B2579: IN CAR SENSOR (OUT OF RANGE [HI])
 B2581: EVAP TEMP SEN (SHORT)
 B2582: EVAP TEMP SEN (OPEN)
 B262A: GAS SENSOR (SHORT)
 B262B: GAS SENSOR (OPEN)
 B2630: SUNLOAD SEN (SHORT)
 B2631: SUNLOAD SEN (OPEN)
 B2632: DR AIRMIX ACTR (SHORT)
 B2633: DR AIRMIX ACTR (OPEN)
 B2634: PASS AIRMIX ACTR (SHORT)
 B2635: PASS AIRMIX ACTR (OPEN)
 B2636: DR VENT DOOR FAIL
 B2637: DR B/L DOOR FAIL
 B2638: DR D/F1 DOOR FAIL
 B2639: DR DEF DOOR FAIL
 B263D: FRE DOOR FAIL
 B263E: 20P FRE DOOR FAIL
 B263F: REC DOOR FAIL
 B2654: D/F2 DOOR FAIL
 B2655: B/L2 DOOR FAIL
 B2656: BTC FRE DOOR FAIL
 B2657: GAS SENSOR CIRCUIT (SHORT)
 B2658: GAS SENSOR CIRCUIT (OPEN)
DTCItems
(CONSULT-III screen terms)Reference
U1000 CAN COMM CIRCUITHAC-164, "
DTC Logic"
U1010 CONTROL UNIT (CAN)HAC-165, "DTC Logic"
B257B AMB TEMP SEN (SHORT)HAC-166, "DTC Logic"
B257C AMB TEMP SEN (OPEN)HAC-166, "DTC Logic"
B2578 IN CAR SENSOR (OUT OF RANGE [LOW])HAC-169, "DTC Logic"
B2579 IN CAR SENSOR (OUT OF RANGE [HI])HAC-169, "DTC Logic"
B2581 EVAP TEMP SEN (SHORT)HAC-172, "DTC Logic"
B2582 EVAP TEMP SEN (OPEN)HAC-172, "DTC Logic"
B262A GAS SENSOR (SHORT)HAC-175, "WITH INTELLIGENT AIR
CONDITIONER SYSTEM : DTC Logic"

A/C AUTO AMP.
HAC-225
< ECU DIAGNOSIS >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
*: Perform self-diagnosis under sunshine. When performing indoors, aim a light (more than 60 W) at sunload sensor, otherwise self-diag-
nosis indicates even though the sunload sensor is functioning normally.B262B GAS SENSOR (OPEN)HAC-175, "
WITH INTELLIGENT AIR
CONDITIONER SYSTEM : DTC Logic"
B2630*SUNLOAD SEN (SHORT)HAC-178, "DTC Logic"
B2631*SUNLOAD SEN (OPEN)HAC-178, "DTC Logic"
B2632 DR AIRMIX ACTR (SHORT)HAC-181, "DTC Logic"
B2633 DR AIRMIX ACTR (OPEN)HAC-181, "DTC Logic"
B2634 PASS AIRMIX ACTR (SHORT)HAC-183, "DTC Logic"
B2635 PASS AIRMIX ACTR (OPEN)HAC-183, "DTC Logic"
B2636 DR VENT DOOR FAILHAC-185, "DTC Logic"
B2637 DR B/L DOOR FAILHAC-185, "DTC Logic"
B2638 DR D/F1 DOOR FAILHAC-185, "DTC Logic"
B2639 DR DEF DOOR FAILHAC-185, "DTC Logic"
B263D FRE DOOR FAILHAC-188, "DTC Logic"
B263E 20P FRE DOOR FAILHAC-188, "DTC Logic"
B263F REC DOOR FAILHAC-188, "DTC Logic"
B2654 D/F2 DOOR FAILHAC-185, "DTC Logic"
B2655 B/L2 DOOR FAILHAC-185, "DTC Logic"
B2656 BTC FRE DOOR FAILHAC-188, "DTC Logic"
B2657 GAS SENSOR CIRCUIT (SHORT)HAC-175, "WITH INTELLIGENT AIR
CONDITIONER SYSTEM : DTC Logic"
B2658 GAS SENSOR CIRCUIT (OPEN)HAC-175, "WITH INTELLIGENT AIR
CONDITIONER SYSTEM : DTC Logic"
DTCItems
(CONSULT-III screen terms)Reference

HAC-228
< SYMPTOM DIAGNOSIS >[WITH 7 INCH DISPLAY]
INSUFFICIENT COOLING
INSUFFICIENT COOLING
DescriptionINFOID:0000000003884801
Symptom
 Insufficient cooling
 No cool air comes out. (Air flow volume is normal.)
Inspection procedureINFOID:0000000003884802
1.CHECK WITH A GAUGE OF RECOVERY/RECYCLING RECHARGING EQUIPMENT
Connect the recovery/recycling recharging equipment to the vehicle and perform the pressure inspection with
the gauge.
Is there refrigerant?
YES >> GO TO 2.
NO-1 >> Check for refrigerant leakages with the refrigerant leakage detecting fluorescent leak detector.
Refer to HA-32, "
Inspection".
NO-2 >> GO TO 2 after repairing or replacing the parts according to the inspection results.
2.CHECK CHARGED REFRIGERANT AMOUNT
1. Connect recovery/recycling recharging equipment to the vehicle and discharge the refrigerant.
2. Recharge with the proper amount of refrigerant and perform the inspection with the refrigerant leakage
detecting fluorescent leak detector. Refer to HA-32, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Refill the refrigerant and repair or replace the parts according to the inspection results.
3.CHECK REFRIGERANT CYCLE PRESSURE
Connect recovery/recycling recharging equipment to the vehicle and perform the performance test. Refer to
HA-30, "
Performance Chart".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Perform the diagnosis with the gauge pressure. Refer to HA-8, "
Trouble Diagnosis For Unusual
Pressure".
4.CHECK SETTING OF TEMPERATURE SETTING TRIMMER
Using CONSULT-III, check the setting of “TEMP SET CORRECT” on “WORK SUPPORT” of HVAC. Refer to
HAC-110, "
WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : Temperature Setting Trimmer" (WITH-
OUT INTELLIGENT AIR CONDITIONER SYSTEM) or HAC-114, "
WITH INTELLIGENT AIR CONDITIONER
SYSTEM : Temperature Setting Trimmer" (WITH INTELLIGENT AIR CONDITIONER SYSTEM).
1. Check that the temperature setting trimmer is set to “+ direction”.
NOTE:
The control temperature can be set with the setting of the temperature setting trimmer.
2. Set temperature control dial to “0”.
Are the malfunction solved?
YES >> Perform the setting separately if necessary. END.
NO >> GO TO 5.
5.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT-III
1. Using CONSULT-III, perform “SELF-DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC is displayed in the trouble diagnosis results.
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to
HAC-164, "
DTC Logic" or HAC-165, "DTC Logic".
Is any DTC displayed?
YES >> Perform the diagnosis that is applicable to the sensor and the door motor. Refer to HAC-212,
"WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : DTC Index" (WITHOUT INTELLI-

INSUFFICIENT HEATING
HAC-231
< SYMPTOM DIAGNOSIS >[WITH 7 INCH DISPLAY]
C
D
E
F
G
H
J
K
L
MA
B
HAC
N
O
P
INSUFFICIENT HEATING
DescriptionINFOID:0000000003884803
Symptom
 Insufficient heating
 No warm air comes out. (Air flow volume is normal.)
Inspection procedureINFOID:0000000003884804
1.CHECK COOLING SYSTEM
1. Check engine coolant level and check for leakage. Refer to CO-8, "
Inspection".
2. Check radiator cap. Refer to CO-12, "
RADIATOR CAP : Inspection".
3. Check water flow sounds of engine coolant. Refer to CO-9, "
Refilling".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refill the engine coolant and repair or replace the parts according to the inspection results.
2.CHECK OPERATION
1. Press temperature control dial (driver side) and raise temperature setting to 32°C (90°F) after warming up
the engine.
2. Check that warm air blows from the outlets.
Is the inspection result normal?
YES >> END.
NO >> GO TO 3.
3.CHECK SETTING OF TEMPERATURE SETTING TRIMMER
Using CONSULT-III, check the setting of “TEMP SET CORRECT” on “WORK SUPPORT” of HVAC. Refer to
HAC-110, "
WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : Temperature Setting Trimmer" (WITH-
OUT INTELLIGENT AIR CONDITIONER SYSTEM) or HAC-114, "
WITH INTELLIGENT AIR CONDITIONER
SYSTEM : Temperature Setting Trimmer" (WITH INTELLIGENT AIR CONDITIONER SYSTEM).
1. Check that the temperature setting trimmer is set to “− direction”.
NOTE:
The control temperature can be set by the temperature setting trimmer.
2. Set temperature control dial to “0”.
Are the malfunction solved?
YES >> Perform the setting separately if necessary. END.
NO >> GO TO 4.
4.CHECK WITH SELF-DIAGNOSIS FUNCTION OF CONSULT-III
1. Using CONSULT-III, perform “SELF-DIAGNOSIS RESULTS” of HVAC.
2. Check if any DTC is displayed in the trouble diagnosis results.
NOTE:
If DTC is displayed along with DTC U1000 or U1010, first diagnose the DTC U1000 or U1010. Refer to
HAC-164, "
DTC Logic" or HAC-165, "DTC Logic".
Is any DTC displayed?
YES >> Perform the diagnosis that is applicable to the sensor and the door motor. Refer to HAC-212,
"WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : DTC Index" (WITHOUT INTELLI-
GENT AIR CONDITIONER SYSTEM) or HAC-224, "
WITH INTELLIGENT AIR CONDITIONER
SYSTEM : DTC Index" (WITH INTELLIGENT AIR CONDITIONER SYSTEM).
NO >> GO TO 5.
5.CHECK WITH ACTIVE TEST OF CONSULT-III
1. Using CONSULT-III, perform “HVAC TEST” in “ACTIVE TEST” of HVAC to check each output device.
Refer to HAC-156, "
WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : CONSULT-III Function"
(WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM) or HAC-159, "WITH INTELLIGENT AIR CON-
DITIONER SYSTEM : CONSULT-III Function" (WITH INTELLIGENT AIR CONDITIONER SYSTEM).
NOTE:
