EM-38
< ON-VEHICLE REPAIR >
OIL PAN AND OIL STRAINER
OIL PAN AND OIL STRAINER
Exploded ViewINFOID:0000000003802261
Removal and InstallationINFOID:0000000003802262
REMOVAL
CAUTION:
To avoid the danger of being scalded, never drain engine oil when the engine is hot.
NOTE:
When removing oil pan (lower) or oil strainer only, take step 1 then step 18 and 19.
1. Drain engine oil. Refer to LU-8, "
Draining".
CAUTION:
Never spill engine oil on drive belt.
2. Drain engine coolant. Refer to CO-8, "
Draining".
CAUTION:
Never spill engine coolant on drive belt.
3. Remove following parts:
 Front road wheel and tires (RH and LH)
1. Oil pan (upper) 2. O-ring 3. Oil pan gasket (front)
4. Relief valve 5. Oil pressure switch 6. Oil cooler
7. Connector bolt 8. Oil filter 9. Oil strainer
10. Drain plug 11. Drain plug washer 12. Oil pan (lower)
13. Rear plate cover 14. Crankshaft position sensor (POS) 15. Oil pan gasket (rear)
A. Refer to LU-10
B. To oil pump C. Oil pan side
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA1636GB

EM-44
< ON-VEHICLE REPAIR >
FUEL INJECTOR AND FUEL TUBE
FUEL INJECTOR AND FUEL TUBE
Exploded ViewINFOID:0000000003802264
CAUTION:
Never remove or disassemble parts unless instructed as shown in the figure.
Removal and InstallationINFOID:0000000003802265
REMOVAL
WARNING:
 Put a “CAUTION: FLAMMABLE” sign in the workshop.
 Be sure to work in a well ventilated area and furnish workshop with a CO
2 fire extinguisher.
 Never smoke while servicing fuel system. Keep open flames and sparks away from the work area.
 To avoid the danger of being scalded, never drain engine coolant when engine is hot.
1. Remove air duct (inlet), air cleaner cases (upper and lower) with mass air flow sensor and air duct assem-
bly. Refer to EM-26, "
Exploded View".
2. Remove engine cover. Refer to EM-24, "
Exploded View".
3. Release the fuel pressure. Refer to EC-411, "
Inspection".
4. Remove front wiper arm and extension cowl top. Refer to WW-105, "
Exploded View" and EXT-20,
"Exploded View".
1. Fuel feed hose 2. Quick connector cap 3. Fuel tube
4. O-ring 5. Fuel damper 6. Fuel damper cap
7. Clip 8. O-ring (black) 9. Fuel injector
10. O-ring (green)
A. Refer to EM-44
Refer to GI-4, "Components" for symbols in the figure.
JPBIA1714GB

IGNITION COIL, SPARK PLUG AND ROCKER COVER
EM-49
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
IGNITION COIL, SPARK PLUG AND ROCKER COVER
Exploded ViewINFOID:0000000003802267
Removal and InstallationINFOID:0000000003802268
REMOVAL
1. Remove the following parts:
 Engine cover: Refer to EM-24, "
Exploded View".
 Air cleaner cases (upper and lower) and air duct assembly: Refer to EM-26, "
Exploded View".
 Intake manifold collector: Refer to EM-28, "
Exploded View".
2. Disconnect PCV hose from rocker cover.
1. Ignition coil 2. Spark plug 3. PCV hose
4. Clamp 5. PCV valve 6. O-ring
7. Rocker cover (bank 1) 8. PCV hose 9. Rocker cover gasket (bank 1)
10. O-ring 11.Camshaft position sensor (PHASE)
(bank 1)12. Oil filler cap
13. Rocker cover (bank 2) 14. Rocker cover gasket (bank 2) 15.Camshaft position sensor (PHASE)
(bank 2)
16. PCV hose 17. Clamp
A. To intake manifold collector B. Refer to EM-49
C. Camshaft bracket side
D. To air duct assembly
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA1637GB

EM-50
< ON-VEHICLE REPAIR >
IGNITION COIL, SPARK PLUG AND ROCKER COVER
3. Remove camshaft position sensor (PHASE) (bank 1 and bank
2).
CAUTION:
 Handle carefully to avoid dropping and shocks.
 Never disassemble
 Never allow metal powder to adhere to magnetic part at
sensor tip.
 Never place sensors in a location where they are exposed
to magnetism.
4. Remove PCV valve and O-ring from rocker cover, if necessary.
5. Remove oil filler cap from rocker cover, if necessary.
6. Remove ignition coil.
CAUTION:
Never shock ignition coil.
7. Remove harness clips on the rocker cover.
8. Loosen bolts in reverse order shown in the figure.
9. Remove rocker cover gasket from rocker cover.
10. Use scraper to remove all traces of liquid gasket from cylinder head and camshaft bracket (No. 1).
CAUTION:
Never scratch or damage the mating surface when cleaning off old liquid gasket.
INSTALLATION
A : Keep off any magnetic materials
: Engine front
JPBIA0454ZZ
JPBIA1634ZZ

EM-68
< REMOVAL AND INSTALLATION >
ENGINE ASSEMBLY
 Place chocks at front and back of rear wheels.
 For engines not equipped with engine slingers, attach proper slingers and bolts described in PARTS
CATALOG.
CAUTION:
 Always be careful to work safely, avoid forceful or uninstructed operations.
 Never start working until exhaust system and engine coolant are cool enough.
 If items or work required are not covered by the engine section, refer to the applicable sections.
 Always use the support point specified for lifting.
 Use either 2-pole lift type or separate type lift as best you can. If board-on type is used for unavoid-
able reasons, support at the rear axle jacking point with transmission jack or similar tool before
starting work, in preparation for the backward shift of center of gravity.
 For supporting points for lifting and jacking point at rear axle, refer to GI-30, "
Garage Jack and
Safety Stand and 2-Pole Lift".
REMOVAL
Outline
At first, remove the engine and the transaxle assembly with front suspension member downward. Then sepa-
rate the engine and the transaxle.
Preparation
1. Release fuel pressure. Refer to EC-411, "Inspection".
2. Drain engine coolant. Refer to CO-8, "
Draining".
CAUTION:
 Perform this step when the engine is cold.
 Never spill engine coolant on drive belt.
3. Remove the following parts:
 Engine cover: Refer to EM-24, "
Exploded View".
 Front road wheel and tires
 Splash guards (RH and LH): Refer to EXT-22, "
FENDER PROTECTOR : Exploded View".
 Air duct (inlet), air cleaner cases (upper and lower) with mass air flow sensor and air duct assembly:
Refer to EM-26, "
Exploded View".
 Battery and battery tray: Refer to PG-109, "
Removal and Installation".
 Drive belt: Refer to EM-12, "
Removal and Installation".
 Reservoir tank of radiator. Refer to CO-13, "
Exploded View".
 Front wiper arm: Refer to WW-105, "
Exploded View".
4. Disconnect engine room harness at the TCM, ECM and other sides.
CAUTION:
To keep clean harness connector and avoid damage and foreign materials, cover them completely
with plastic bags or something similar.
5. Remove battery bracket with ECM and TCM.
6. Remove extension cowl top. Refer to EXT-20, "
Exploded View".
Engine Room
1. Disconnect heater hoses. Refer to CO-25, "Exploded View".
 Install plug to avoid leakage of engine coolant.
2. Remove EVAP hose. Refer to EM-28, "
Exploded View".
3. Disconnect fuel feed hose quick connector at fuel tube side. Refer to EM-44, "
Exploded View".
 Install plug to avoid leakage of fuel.
4. Disconnect transaxle shift control cable at transaxle side. Refer to TM-319, "
Exploded View" (VQ25DE) or
TM-157, "
Exploded View" (VQ35DE).
5. Disconnect brake booster vacuum hose at engine side. Refer to EM-28, "
Exploded View".
6. Disconnect ground cable.
7. Disconnect A/C compressor piping at A/C compressor side. Refer to HA-36, "
Exploded View".
8. Disconnect suction hoses of power steering oil pump at reservoir tank side. Refer to ST-34, "
Exploded
View".
 Install plug to avoid leakage of power steering fluid.
9. Disconnect CVT fluid cooler hoses from radiator. Refer to CO-13, "
Exploded View".

ENGINE ASSEMBLY
EM-69
< REMOVAL AND INSTALLATION >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
10. Remove starter motor. Refer to STR-15, "VQ25DE : Exploded View" (VQ25DE) or STR-20, "VQ35DE :
Exploded View" (VQ35DE).
Vehicle Underbody
1. Remove front drive shafts (RH and LH). Refer to FAX-16, "Exploded View".
2. Remove exhaust front tube. Refer to EX-5, "
Exploded View".
3. Remove heat insulator.
4. Disconnect steering lower joint at power steering gear assembly side, and release steering lower shaft.
Refer to ST-16, "
Exploded View".
5. Disconnect front stabilizer connecting rod. Refer to FSU-14, "
Exploded View".
6. Remove strut assembly and steering knuckle fixing nuts and bolts. Refer to FSU-9, "
Exploded View" and
FA X - 8 , "
Exploded View".
7. Remove front wheel sensor (RH and LH) for ABS from steering knuckle. Refer to BRC-57, "
FRONT
WHEEL SENSOR : Exploded View".
8. Remove front brake caliper assembly with piping connected, and temporarily secure it to aside for vehicle
side. Refer to BR-34, "
BRAKE CALIPER ASSEMBLY : Exploded View".
9. Disconnect power steering piping at a point between vehicle and engine. Refer to ST-34, "
Exploded
View".
 Install plug to avoid leakage of power steering fluid.
10. Remove rear plate cover from oil pan (upper). Then remove bolts fixing drive plate to torque converter.
Refer to EM-38, "
Exploded View" and TM-332, "Removal and Installation" (VQ25DE) or TM-168,
"Removal and Installation" (VQ35DE).
11. Remove transaxle joint bolts which pierce at oil pan (upper) lower rear side. Refer to EM-38, "
Exploded
View".
12. Remove crankshaft position sensor (POS). Refer to EM-38, "
Exploded View".
CAUTION:
 Handle carefully to avoid dropping and shocks.
 Never disassemble.
 Never allow metal powder to adhere to magnetic part at sensor tip.
 Never place sensors in a location where they are exposed to magnetism.
Removal
1. Use a manual lift table caddy (commercial service tool) or equiv-
alently rigid tool such as a transmission jack. Securely support
bottom of front suspension member.
CAUTION:
Put a piece of wood or something similar as the supporting
surface, secure a completely stable condition.
2. Remove engine mounting insulator (RH) and engine mounting bracket (RH).
3. Remove mounting bolt between transverse link and front suspension member with power tool.
4. Remove front suspension member mounting nuts and bolts. Refer to FSU-16, "
Exploded View".
5. Carefully lower jack, or raise lift to remove the engine and the transaxle assembly and front suspension
member. When performing work, observe the following caution:
CAUTION:
 Confirm there is no interference with the vehicle.
 Check all connection points have been disconnected.
 Keep in mind the center of vehicle gravity changes. If necessary, use jack(s) to support the vehi-
cle at rear jacking point(s) to prevent it from falling it off the lift.
Separation
PBIC1190E

EM-84
< DISASSEMBLY AND ASSEMBLY >
CAMSHAFT
CAMSHAFT
Exploded ViewINFOID:0000000003802283
Removal and InstallationINFOID:0000000003802284
REMOVAL
1. Remove front timing chain case, camshaft sprocket, timing chain and rear timing chain case. Refer to EM-
52, "Exploded View" and EM-79, "Exploded View".
1. Camshaft bracket (No. 3, 4) 2. Camshaft bracket (No. 2) 3. Seal washer
4. Camshaft bracket (No. 1) 5. Dowel pin 6. Camshaft (EXH) (bank 1)
7. Camshaft (INT) (bank 1) 8. Valve lifter 9.Timing chain tensioner (secondary)
(bank 1)
10. Spring 11. Plunger 12.Timing chain tensioner (secondary)
(bank 2)
13. Cylinder head (bank 2) 14. Dowel pin 15. Camshaft sensor bracket
16. Camshaft (EXH) 17. Camshaft signal plate (INT) 18. Camshaft (INT)
19. Cylinder head (bank 1) 20. Camshaft signal plate (INT) 21. Camshaft sensor bracket
A. Refer to EM-84
Refer to GI-4, "Components" for symbols in the figure.
JPBIA1719GB

CAMSHAFT
EM-85
< DISASSEMBLY AND ASSEMBLY >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
2. Loosen camshaft sensor bracket bolts in reverse order as
shown in the figure.
NOTE:
The order of loosening bolts in the same for bank 1 and bank 2.
3. Remove camshaft brackets.
 Mark camshafts, camshaft brackets and bolts so they are placed in the same position and direction for
installation.
 Equally loosen camshaft bracket bolts in several steps in
reverse order as shown in the figure.
4. Remove camshafts.
5. Remove valve lifters.
 Identify installation positions, and store them without mixing them up.
6. Remove timing chain tensioners (secondary) (1) from cylinder
head.
 Remove timing chain tensioner (secondary) with its stopper
pin (C) attached.
NOTE:
Stopper pin should be attached when timing chain (secondary)
is removed.
INSTALLATION
: Engine front
JPBIA1960ZZ
: Engine front
JPBIA0257ZZ
A: Bank 1
B: Bank 2
JPBIA0121ZZ
