Page 1536 of 5121
ELECTRONIC CONTROLLED ENGINE MOUNT
EC-75
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component DescriptionINFOID:0000000003856489
1. ASCD steering switch 2. CANCEL switch 3. RESUME/ACCELERATE switch
4. SET/COAST switch 5. MAIN switch
1. Fuel level sensor unit and fuel pump
harness connector2. Fuel pressure regulator 3. Fuel level sensor unit and fuel pump
: Vehicle front
JMBIA1120ZZ
JMBIA1385ZZ
Component Reference
Camshaft position sensor (PHASE)EC-222, "
Description"
Crankshaft position sensor (POS)EC-218, "Description"
Electronic controlled engine mount control solenoid valveEC-331, "Description"
Page 1537 of 5121
![NISSAN TEANA 2008 Service Manual EC-76
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
EVAPORATIVE EMISSION SYSTEM
EVAPORATIVE EMISSION SYSTEM
System DiagramINFOID:0000000003949755
System DescriptionINFOID:0000000003949756
INPUT/OUTPUT SIGNAL NISSAN TEANA 2008 Service Manual EC-76
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
EVAPORATIVE EMISSION SYSTEM
EVAPORATIVE EMISSION SYSTEM
System DiagramINFOID:0000000003949755
System DescriptionINFOID:0000000003949756
INPUT/OUTPUT SIGNAL](/manual-img/5/57391/w960_57391-1536.png)
EC-76
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
EVAPORATIVE EMISSION SYSTEM
EVAPORATIVE EMISSION SYSTEM
System DiagramINFOID:0000000003949755
System DescriptionINFOID:0000000003949756
INPUT/OUTPUT SIGNAL CHART
*1: ECM determines the start signal status by the signals of engine speed and battery voltage.
*2: This signal is sent to the ECM through CAN communication line.
JMBIA1524GB
Sensor Input signal to ECM ECM function Actuator
Crankshaft position sensor (POS)
Engine speed*
1
Piston position
EVAP canister
purge flow controlEVAP canister purge vol-
ume control solenoid valve Camshaft position sensor (PHASE)
Mass air flow sensor Amount of intake air
Engine coolant temperature sensor Engine coolant temperature
Air fuel ratio (A/F) sensor 1Density of oxygen in exhaust gas
(Mixture ratio feedback signal)
Throttle position sensor Throttle position
Accelerator pedal position sensor Accelerator pedal position
Battery
Battery voltage*
1
ABS actuator and electric unit (control unit)
Vehicle speed*2
Page 1541 of 5121
![NISSAN TEANA 2008 Service Manual EC-80
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
EVAPORATIVE EMISSION SYSTEM
Component Parts Location
INFOID:0000000003857776
1. Intake valve timing control solenoid
valve (bank 1)2. Intake valve timing NISSAN TEANA 2008 Service Manual EC-80
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
EVAPORATIVE EMISSION SYSTEM
Component Parts Location
INFOID:0000000003857776
1. Intake valve timing control solenoid
valve (bank 1)2. Intake valve timing](/manual-img/5/57391/w960_57391-1540.png)
EC-80
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
EVAPORATIVE EMISSION SYSTEM
Component Parts Location
INFOID:0000000003857776
1. Intake valve timing control solenoid
valve (bank 1)2. Intake valve timing control solenoid
valve (bank 2)3. Electronic controlled engine mount
control solenoid valve
4. Fuel injector (bank 2) 5. Cooling fan motor-2 6. A/F sensor 1 (bank 2)
7. Ignition coil (with power transistor)
and spark plug (bank 2)8. Camshaft position sensor (PHASE)
(bank 2)9. Crankshaft position sensor (POS)
10. Engine coolant temperature sensor 11. Cooling fan motor-1 12. ECM
13. Refrigerant pressure sensor 14. Battery current sensor 15. IPDM E/R
16. Mass air flow sensor (with intake air
temperature sensor)17. Electric throttle control actuator 18. Power valve actuator 2 (VQ35DE
models)
19. EVAP canister purge volume control
solenoid valve20. Camshaft position sensor (PHASE)
(bank 1)21. Ignition coil (with power transistor)
and spark plug (bank 1)
22. A/F sensor 1 (bank 1) 23. Fuel injector (bank 1) 24. VIAS control solenoid valve 1 and 2
(VQ35DE models)
25. Power valve actuator 1
JMBIA1373ZZ
Page 1542 of 5121
EVAPORATIVE EMISSION SYSTEM
EC-81
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Mass air flow sensor (with intake air
temperature sensor)2. Electric throttle control actuator
: Vehicle front
1. Ignition coil (with power transistor)
and spark plug (bank 1)2. Fuel injector (bank 1) 3. Fuel injector (bank 2)
4. Ignition coil (with power transistor)
and spark plug (bank 2)5. EVAP canister
: Vehicle front
1. Knock sensor (bank 1) 2. Knock sensor (bank 2) 3. Knock sensor
: Vehicle front
JMBIA1374ZZ
JMBIA1375ZZ
JMBIA1376GB
JMBIA1377ZZ
Page 1543 of 5121
EC-82
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
EVAPORATIVE EMISSION SYSTEM
1. Crankshaft position sensor (POS) 2. Camshaft position sensor (PHASE)
(bank 2)3. Camshaft position sensor (PHASE)
(bank 1)
: Vehicle front
1. Refrigerant pressure sensor 2. Battery current sensor
: Vehicle front
1. ECM 2. Fuel pump fuse 3. IPDM E/R
: Vehicle front
JMBIA1378ZZ
JMBIA1379ZZ
PBIB1686E
Page 1544 of 5121
EVAPORATIVE EMISSION SYSTEM
EC-83
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. A/F sensor 1 (bank 1) harness con-
nector2. A/F sensor 1 (bank 1) 3. A/F sensor 1 (bank 2) harness con-
nector
4. A/F sensor 1 (bank 2)
: Vehicle front
1. HO2S2 (bank 1) 2. HO2S2 (bank 2) 3. HO2S2 (bank 2) harness connector
4. Tie-rod (RH) 5. Power steering pressure sensor 6. HO2S2 (bank 1) harness connector
: Vehicle front
1. Electronic controlled engine mount
control solenoid valve2. VIAS control solenoid valve 1 3. VIAS control solenoid valve 2
4. EVAP canister purge volume control
solenoid valve
JMBIA1116ZZ
JMBIA1380ZZ
JMBIA1381GB
Page 1545 of 5121
EC-84
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
EVAPORATIVE EMISSION SYSTEM
1. Electronic controlled engine mount
control solenoid valve2. VIAS control solenoid valve 3. EVAP canister purge volume control
solenoid valve
1. Intake valve timing control solenoid
valve (bank 1)2. Intake valve timing control solenoid
valve (bank 2)3. Data link connector
1. Stop lamp switch 2. ASCD brake switch 3. Accelerator pedal position sensor
1. ASCD steering switch 2. CANCEL switch 3. RESUME/ACCELERATE switch
4. SET/COAST switch 5. MAIN switch
JMBIA1382GB
JMBIA1383ZZ
JMBIA1384ZZ
JMBIA1120ZZ
Page 1546 of 5121
EVAPORATIVE EMISSION SYSTEM
EC-85
< FUNCTION DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Component DescriptionINFOID:0000000003856493
1. Fuel level sensor unit and fuel pump
harness connector2. Fuel pressure regulator 3. Fuel level sensor unit and fuel pump
: Vehicle front
JMBIA1385ZZ
Component Reference
A/F sensor 1EC-163, "
Description"
Accelerator pedal position sensorEC-304, "Description"
Camshaft position sensor (PHASE)EC-222, "Description"
Crankshaft position sensor (POS)EC-218, "Description"
Engine coolant temperature sensorEC-157, "Description"
EVAP canister purge volume control solenoid valveEC-231, "Description"
Mass air flow sensorEC-149, "Description"
Throttle position sensorEC-160, "Description"
