88 Control systemsCOMAND introductionCOMAND shortcut buttons
Use the COMAND shortcut buttons to se-
lect main functions directly.
Example:

Switching directly to Radio or CD
menu: Press M once or twice.COMAND display
In the COMAND display, you will find the
function currently selected and the corre-
sponding menus. The COMAND display is
divided into several areas.
1Status line
2Main functions
3Main area
4Submenus
5Climate control settings
A white bar under the main functions 2 in-
dicates the active area.
Once you have selected a main
function2, the main area 3 is active.
i
During Rear View Camera* operation
(
page 487) it is not possible to operate the
COMAND shortcut buttons.
Function
Page
1
PFavorite button
263
2
MShortcut button for:

CD/DVD


radio
124
103
3
LBack button
96
4
OSeat menu
282
5
NShortcut button for:

telephone*


navigation
141
195
6
oCOMAND on/off
button
87
7
,Volume control
98
8
FMute button
98

89 Control systems
COMAND introduction
Instrument cluster multifunction
display
This section describes features and con-
trols via the COMAND controller, display
and shortcut buttons only.
Please refer to the “Instrument cluster
control system” section of this manual
(page 287) for function descriptions and
operation of the instrument cluster multi-
function display and multifunction steering
wheel buttons as they relate to COMAND
features described in this section.Adjusting COMAND display
illumination
1Knob

Brightening illumination: Turn
knob1 clockwise.

Dimming illumination: Turn knob1
counterclockwise.Swiveling COMAND display
1Button for swiveling display to the left
2Button for swiveling display to the right
You can swivel the COMAND display to the
left or right. The buttons are on the
right-hand side of the instrument cluster.
i
The layout of the menus may vary depending
on your vehicle’s equipment. This manual shows
the menus for a fully equipped vehicle.

90 Control systemsCOMAND introductionTelephone keypad
With the help of the telephone keypad, you
can use your mobile phone if it is inserted
in the cradle.
1Telephone keypad
2Folding coverCOMAND controller
Use the COMAND controller to select
menu functions shown on the COMAND
display.
1COMAND controllerYou can operate the COMAND controller
as follows:


press briefly or press and hold


rotate to the left or right


slide to the left, right, up, down or
diagonally
In this way, you can move through the
menus, select menu items or exit menus.
You can move through the menus either by
rotating or sliding the controller.
Operating COMAND controller

91 Control systems
COMAND introduction
Symbol
How to use the COMAND controller
Function
n

Press briefly.


Select menu item.


Exit full-screen image with Navi.

Press and hold until the selected ac-
tion has been carried out.


Save a station.


Accept a destination for navigation.
ymz

Rotate.


Move through vertical or horizontal menus.


Move through text.


Program settings.
qmr

Slide.


Move through vertical menus.


Exit horizontal menus.

Slide and hold.


Move through a navigation map.
omp

Slide.


Move through horizontal menus.


Exit vertical menus.

Slide and hold.


Fast forward or reverse for audio CD or audio DVD playback.


Move through a navigation map.
wmx

Slide and hold.


Move through a navigation map.

92 Control systemsCOMAND introductionOperating COMAND
Menu overview
The illustration below shows the structure
of the main functions and their main
menus.Each main function has a main menu. Each
menu item in the main menu in turn has
several submenu items.
Navi
Page
Audio
Page
Telephone*
Page
Commands/menusMap Display
198
FM/AM Radio
102
Telephone*
141
Mode
201
Sat Radio
108
Address Book*
167
CD
116
Telephone OFF*
143
DVD-Audio
116
MP3
116
Audio OFF
101
Audio AUX
129

93 Control systems
COMAND introduction
Video DVD
Page
Vehicle
Page
Commands/menusVideo DVD
132
Exterior Lighting Delayed Switch-off
264
Submenu overview
134
Locator Lighting
265
Switching to video DVD mode
134
Exterior Mirror Convenience Settings
266
Pause playback
136
Automatic Locking
267
DVD menu
138
Easy Entry/Exit Feature
268
Video AUX
130
Interior Lighting Delayed Switch-off
270
Interior Ambient Light
269
Rear Window Sunshade
271
Trunk Opening-height Restriction*
272

94 Control systemsCOMAND introductionCalling up the main menuIllustration: audio main menuYou can call up the main menu of a main
function in the following manner:
Moving to the main function line:
Slideqm.

Selecting a main function: Slide omp
or rotate ymz.

Confirming selection: Press n.Vertical menus

Moving through the menu:
Slidermq or rotate ymz.

Selecting a menu item: Press n.

Exiting a menu without making a se-
lection: Slide ompin the opposite di-
rection of the list orientation or press
back button L.Horizontal menus

Moving through the menu:
Slideomp or rotate ymz.

Selecting a menu item: Press n.

Exiting a menu without making a se-
lection: Slide rmqin the opposite di-
rection of the list orientation or press
back button L.

95 Control systems
COMAND introduction
Entering charactersIllustration: entering a navigation destina-
tionSelecting characters
Slide omp or rotate ymz.

Confirming selection: Press n.
COMAND completes your entry as
soon as it can be clearly identified. In
this case, you do not need to switch to
the list.Deleting individual characters

Select and press ) repeatedly in the
bottom line.
Deleting entire words or numbers

Press and hold ) in the bottom line
until the word or number is deleted.
Exiting character entry

Select and press “Back” in the bottom
line.
or

Press back button L in the center
console (
page 88).
Switching to the list

Slide qm.
or

Select and press ? in the second line
from the bottom.

Exiting list: Slide om to select “Back”.Accepting first entry

Press nuntil you exit the character
entry window.
Selecting list item
Illustration: list of towns and cities for navi-
gation1Symbol for other selection options
(e.g. county)
Selecting a line: Slide rmq or
rotateymz.
