2008 MERCEDES-BENZ S-Class Comand Manual

392 Controls in detailMemory functionPrior to operating the vehicle, the driver
should check and adjust the seat height,
seat position fore and aft, and seat back-
rest angle if necessary, to ensure adequate
control, reach, and comfort. The head re-
straint should also be adjusted for proper
height. See also the section on air bags
(page 42) for proper seat positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, operation
and comfort. Both the interior and exterior
rear view mirrors should be adjusted for
adequate rear vision.
Fasten seat belts. Infants and small chil-
dren should be seated in a properly se-
cured restraint system that complies with
U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian
Motor Vehicle Safety Standards 213 and
210.2.With the memory function you can store up
to three different configurations.
Each stored position on the driver’s side
includes the following settings:


Driver’s seat: head restraint height,
seat and backrest position, backrest
curvature in lumbar area


Multicontour seat*: sides of backrest,
backrest curvature in lumbar and
shoulder area


Drive-dynamic multicontour seat*:
activation/deactivation


Steering wheel position


Exterior rear view mirrors positionWarning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s un-
supervised access to a vehicle could result
in an accident and/or serious personal
injury.

393 Controls in detail
Memory function
Each stored position on the passenger side
includes the following settings:

Seat position and lumbar support


Multicontour seat*: previously saved
setting


Drive-dynamic multicontour seat*: ac-
tivation/deactivation
Each stored position in the rear passenger
compartment includes the following set-
tings (Canada only):


Seat position


Multicontour seat*: previously saved
settingMMemory button
1 2 3Memory position buttons
Storing positions into memory
Adjust the seat (
page 373) to the de-
sired position.

On the driver’s side: Adjust the steering
wheel (
page 386) and the exterior
rear view mirrors (
page 388) to the
desired position.

Press memory buttonM.

Release memory buttonM and press
one of the memory position buttons
within 3 seconds.
All the settings are stored with the se-
lected position.
Recalling positions from memory
Press and hold one of the position
buttons until the seat, steering wheel
and exterior rear view mirrors have fully
moved to the stored positions.
!
Do not operate the power seats using the
memory button if the seat backrest is in an ex-
cessively reclined position. Doing so could cause
damage to front or rear seats.
First move seat backrest to an upright position.
i
Releasing the button immediately stops
movement to the stored positions.
The multicontour seat* and/or lumbar support
will continue to be adjusted.

394 Controls in detailMemory functionStoring exterior rear view mirror park-ing position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gearR.
For information on activating the parking
position, see “Activating exterior rear view
mirror parking position” (
page 391).
1Memory button M
2Adjustment button
3Selector switch for right or left exterior
mirror

Stop the vehicle.

Make sure the ignition is switched on
(page 370).

Press switch3 until the exterior mir-
ror on the front passenger side is se-
lected.

Adjust the passenger-side exterior rear
view mirror with button2 so that you
see the rear wheel and the road curb.

Press memory button M.

Within 3 seconds, press one of the
adjustment buttons2.
The parking position is stored if the
mirror does not move.
i
If the mirror does move, repeat the above
steps. After the setting is stored, you can move
the mirror again.

395 Controls in detail
Fastening the seat belts
Fastening the seat belts
Warning!
G
Always fasten your seat belt before driving
off. Always make sure all of your passengers
are properly restrained.
Failure to wear and properly fasten and
position your seat belt greatly increases
your risk of injuries and their likely severity
in an accident. You and your passengers
should always wear seat belts.
If you are ever in an accident, your injuries
can be considerably more severe without
your seat belt properly buckled. Without
your seat belt buckled, you are much more
likely to hit the interior of the vehicle or be
ejected from it. You can be seriously injured
or killed.
In the same crash, the possibility of injury or
death is lessened if you are wearing your
seat belt. The air bags can only provide the
protection they were designed to afford if
the occupants are using their seat belts
(page 42).
Warning!
G
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing position. Thus, we strongly recommend
that children be placed in the rear seats
whenever possible. Regardless of seating
position, children 12 years old and under
must be seated and properly secured in an
appropriately sized infant restraint, toddler
restraint, or booster seat recommended for
the size and weight of the child. For addi-
tional information, see “Children in the vehi-
cle” (
page 58).
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
Warning!
G
Never let more people ride in the vehicle
than there are seat belts available. Be sure
everyone riding in the vehicle is correctly re-
strained with a separate seat belt. Never use
a seat belt for more than one person at a
time.Warning!
G
Never ride in a moving vehicle with the seat
backrest in an excessively reclined position
as this can be dangerous. You could slide
under the seat belt in a collision. If you slide
under it, the seat belt would apply force at
the abdomen or neck. That could cause se-
rious or even fatal injuries. The seat back-
rest and seat belt provide the best restraint
when the wearer is in a nearly upright posi-
tion and the seat belt is properly positioned
on the body.

396 Controls in detailFastening the seat belts
1Seat belt outlet
2Latch plate
3Buckle
4Release button

Pull the seat belt smoothly from the
seat belt outlet 1.

Place the shoulder portion of the seat
belt across the top of your shoulder
and the lap portion across your hips.

Push latch plate2 into buckle3 until
it clicks.

If necessary, adjust the seat belt to the
correct height (
page 398) (depend-
ing on vehicle production date).

If necessary, tighten the lap portion to
a snug fit by pulling shoulder portion
up.

To release the seat belt, press release
button4 and guide latch plate back to
seat belt outlet.
Warning!
G
Read and observe the additional warning no-
tices printed in the “Safety and Security”
section (
page 40).

397 Controls in detail
Fastening the seat belts
Proper use of seat belts

Do not twist the seat belt when fasten-
ing.


Adjust seat belt so that the shoulder
portion is located as close as possible
to the middle of the shoulder (it should
not touch the neck). Never pass the
shoulder portion of the seat belt under
your arm.


Position the lap belt as low as possible
on your hips (over hip joint) and not
across the abdomen.


Place the seat backrest in a nearly up-
right position.


Never use a seat belt for more than one
person at a time.


Do not fasten a seat belt around a per-
son and another object at the same
time. When using a seat belt to secure
infant restraints or toddler restraints or
children in booster seats, always follow
the child seat manufacturer’s instruc-
tions.


Check your seat belt during travel to
make sure that it is properly posi-
tioned.


Make sure the seat belt is always fitted
snugly. Take special care of this when
wearing loose clothing.For more information, see “Seat belts”
(
page 52).
Seat belt height adjustment
automatically
Depending on production date, your vehi-
cle automatically adjusts the seat belt
height for the driver’s and passenger’s
seat as well as for the rear outer seats.
Comply with the instructions on how to
properly fasten a seat belt (
page 395).
Warning!
G
Do not pass seat belts over sharp edges.
They could tear.
Do not allow the seat belt to get caught in
the door or in the seat adjustment mecha-
nism. This could damage the seat belt.
Never attempt to make modifications to
seat belts. This could impair the effective-
ness of the seat belts.
Do not bleach or dye seat belts as this may
severely weaken them. In a crash, they may
not be able to provide adequate protection.
Damaged seat belts or seat belts that were
highly stressed in an accident must be re-
placed. Contact an authorized
Mercedes-Benz Center.

398 Controls in detailFastening the seat beltsSeat belt height adjustment manually
Depending on vehicle production date, you
can adjust the height of the seat belt for
the driver’s and front passenger seat. The
seat belts for the rear outer seats are ad-
justed automatically.
1Seat belt height adjuster
2Release button

Raising: Slide the seat belt height
adjuster1 upward.
The seat belt height adjuster1 engag-
es in different positions.

Lowering: Press and hold release
button2.

Slide the seat belt height adjuster1
downward.

Release button and make sure the seat
belt height adjuster1 engages into
place.

399 Controls in detail
Lighting
Lighting
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
i
If you drive in countries where vehicles drive
on the other side of the road than the country in
which the vehicle is registered, you must have
the headlamps modified for symmetrical low
beams. Relevant information can be obtained at
any authorized Mercedes-Benz Center.
i
The active Bi-Xenon headlamps monitor
your steering angle and driving speed, then auto-
matically shift their beams to either side to bet-
ter follow the curvature of the road ahead,
increasing usable illumination over conventional
headlamps.
1‚
Standing lamps, left (turn left two
stops)
2ˆ
Standing lamps, right (turn left
one stop)
3M
Off
Daytime running lamp mode
(page 401)
4*
Automatic headlamp mode
Daytime running lamp mode
(page 401)
5C
Parking lamps (also tail lamps, li-
cense plate lamps, side marker
lamps, instrument panel lamps)
6B
Low beam headlamps or high
beam headlamps
7‡
Front fog lamps
8†
Rear fog lamp
i
If you hear a warning signal you have forgot-
ten to switch off the low beam headlamps or the
parking lamps before opening the driver’s door.
In addition the message “Please Switch Off
Lights” appears in the multifunction display.
Switch off the low beam headlamps or the park-
ing lamps.
If the message “Turn Lights Off or Remove Key”
appears in the multifunction display remove the
SmartKey from the starter switch or switch off
the automatic headlamp mode.
!
Failure to switch off the exterior lamps when
leaving the vehicle may result in a discharged
battery.
