2007 SUZUKI AERIO Owners Manual

Downloaded from www.Manualslib.com manuals search engine 14-3 SPECIFICATIONS
54G27-03E
ITEM: Lights WATTAGE BULB No.
Headlight 12V 60/55W HB2
Turn signal light Front 12V 21W 7440
Rear 12V 21W 7440
Side marker light 12V 3.8W 194
Parking light 12V 5W –
Tail/brake light 12V 5/21W –
License plate light 12V 5W –
Back-up light 12V 21W –
Interior light 12V 10W –
Spot light 12V 8W W16W
Meter pilot, warning, indicator lights 12V 1.4W –
High-mount stop light 12V 18W 921
Front fog light Type A 12V 55W –
Type B 12V 35W –
Specifications: 1, 2, 5, 6, 7, 10, 11

Downloaded from www.Manualslib.com manuals search engine 14-4 SPECIFICATIONS
54G27-03E
ITEM: Wheel
Tire size, front and rear P185/65R14 or P195/55R15
Tire pressure For the specified tire pressure, see the Tire Information Label located
on the driver’s door lock pillar.
ITEM: Steering
Toe IN 1.0 ± 2 mm (0.04 ± 0.08 in.)
Camber angle –0° 10’ ± 1°
Caster angle 2° 11’
ITEM: Capacities
Coolant (including reserve tank) 7.0 L (14.8 US pt)
Fuel tank 50 L (13.2 US gal)
Engine oil (replaced with filter) 4.7 L (5.0 quarts)
Transaxle oil Manual transaxle: 2.3 L (4.9 US pt)
4-speed automatic transaxle: 7.7 L (16.3 US pt)
Rear differential oil 0.7 L (1.5 US pt)
Transfer gear box oil 0.75 L (1.6 US pt)
Specifications: 1, 2, 5, 6, 7, 10, 11

Downloaded from www.Manualslib.com manuals search engine 15-1 INDEX
15
54G27-03E
INDEXSymbols“AIR BAG” Light
..................................................................4-5
“CRUISE” Indicator Light
...................................................4-6
“O/D OFF” Indicator Light ..................................................4-6
“PANIC” button function
....................................................2-3
“PASS AIRBAG OFF” Indicator
..........................................4-14
“SET” Indicator Light
..........................................................4-6
Numerics4-Speed Automatic Transaxle
............................................6-4
AA/T Selector Position Indicator
..........................................4-7
Accelerator Pedal
................................................................5-2
Accessory Socket ................................................................5-10
Adding Engine Coolant
.......................................................9-18
Adjusting Seat Position ......................................................2-11
Adjusting Seatbacks
...........................................................2-12
Air Cleaner
...........................................................................9-20
Air Conditioning System
.....................................................9-43
All Seat Belts Except Rear Center
.....................................2-16
Anti-Lock Brake System (ABS)
..........................................6-7
Anti-Lock Brake System (ABS) Warning Light
.................4-3
Armrest
.................................................................................5-6
Assist Grips
.........................................................................5-7
Audio Systems .....................................................................4-26
Automatic Heating and Air Conditioning System
(Climate Control) .................................................................4-22
Automatic Locking Retractor (ALR)
..................................2-15
Automatic Transaxle Fluid
..................................................9-16
BBasic Operations
................................................................ 4-29
Battery
.................................................................................. 9-35
Brake Fluid
.......................................................................... 9-22
Brake Pedal ..................................................................5-2
, 9-23
Brake System Warning Light
............................................. 4-3
Brakes
.................................................................................. 9-22
Braking ................................................................................. 6-7
Break-In ................................................................................ 6-9
Brightness Control
............................................................. 4-8
Bulb Replacement ............................................................... 9-38
CCatalytic Converter
............................................................. 6-9
Changing Engine Oil and Filter
......................................... 9-12
Changing Wheels
................................................................ 9-31
Charging Light
.................................................................... 4-4
Child Lock System (rear side doors)
................................ 2-6
Child Restraint Systems
..................................................... 2-22
Cigarette Lighter and Ashtray
........................................... 4-11
Clock
.................................................................................... 4-13
Clutch Pedal
.................................................................5-2
, 9-25
Coat Hooks
.......................................................................... 5-8
Compact Spare Tire
............................................................ 9-30
Corrosion Prevention ......................................................... 11-1
Cruise Control
..................................................................... 3-6
Cup Holder and Storage Area
............................................ 5-9
DDaily Inspection Checklist
................................................. 6-1

Downloaded from www.Manualslib.com manuals search engine 15-2 INDEX
54G27-03E
Daytime Running Light (D.R.L.) Indicator Light
...............4-7
Daytime Running Light (D.R.L.) System
............................3-3
Door Locks
...........................................................................2-1
Driver’s Seat Belt Reminder Light
.....................................4-4
Driving on Hills
....................................................................7-1
Driving on Slippery Roads
..................................................7-2
EEmergency Locking Retractor (ELR)
.................................2-15
Emission Compliance Label (for U.S.A.)
...........................12-2
Engine Block Heater
............................................................6-3
Engine Coolant
....................................................................9-17
Engine Coolant Level Check
..............................................9-18
Engine Coolant Replacement .............................................9-18
Engine Hood
........................................................................5-8
Engine Oil and Filter
............................................................9-11
Engine Serial Number .........................................................12-1
Exhaust Gas Warning .........................................................6-1
Eyeglasses Holder
...............................................................5-8
FFluid Level Check
................................................................9-16
Fog Light Switch ..................................................................4-11
Folding Rear Seats ..............................................................5-4
Frame Hooks
........................................................................5-11
Front Passenger’s Seat Belt Reminder Light
...................4-13
Front Seat Back Pocket
......................................................5-13
Fuel Filler Cap
......................................................................5-3
Fuel Gauge
...........................................................................4-9
Fuel Pump Labeling
............................................................1-1
Fuel Recommendation ........................................................1-1
Fuses
....................................................................................9-35
FUSES AND PROTECTED CIRCUITS
.................................13-1Fuses in the Engine Compartment
.................................... 9-36
Fuses under the Dash Board
............................................. 9-36
GGasoline Containing MTBE
................................................ 1-1
Gasoline/Ethanol blends
.................................................... 1-1
Gasoline/Methanol blends ................................................. 1-1
Gear Oil
................................................................................ 9-14
Gear Oil Level Check
.......................................................... 9-15
Gear Oil Replacement ......................................................... 9-15
Gearshift Lever
.................................................................... 5-2
GLOSSARY OF TIRE TERMINOLOGY
............................... 9-32
Glove Box
............................................................................ 4-14
HHazard Warning Switch
...................................................... 4-10
Head Restraints
................................................................... 2-12
Headlight Aiming ................................................................ 9-37
Heating and Air Conditioning System
.............................. 4-15
Heating System
................................................................... 4-16
High Beam Indicator Light
................................................. 4-6
Highway Driving
.................................................................. 7-1
Horn
...................................................................................... 3-8
How the ABS Works
........................................................... 6-9
IIdentification Numbers
....................................................... 12-1
If the Engine is Flooded ..................................................... 10-6
If the Engine Overheats ...................................................... 10-6
If the Starter Does Not Operate
......................................... 10-6
If You Can Not Shift Automatic Transaxle Gearshift
Lever Out of “P” (PARK)
.................................................... 10-8
If Your Vehicle Gets Stuck ................................................. 7-2
Ignition Key Reminder
........................................................ 2-1

Downloaded from www.Manualslib.com manuals search engine 15-3 INDEX
54G27-03E
Ignition Switch
.....................................................................3-1
Improving Fuel Economy
....................................................6-10
Information Display
.............................................................4-12
Inside Rearview Mirror ........................................................2-10
Installation with Lap-Shoulder Seat Belts
(child restraint with no top strap)
......................................2-24
Installation with the LATCH System ..................................2-26
Installation-Child Restraint with Top Strap
.......................2-29
Instrument Cluster
...............................................................4-2
Instrument Panel
.................................................................4-1
Interior Light Switch ............................................................5-6
Internal Trunk Release ........................................................2-7
JJacking Instructions
............................................................10-1
Jump Starting Instructions
.................................................10-4
KKeyless Entry System
.........................................................2-3
Keys
......................................................................................2-1
LLane change signal
.............................................................3-4
Lap-Shoulder Belt
................................................................2-15
Lighting Operation ..............................................................3-3
Lighting/Turn Signal Control Lever
...................................3-3
Lights “On” reminder
..........................................................3-3
Listening to a CD
.................................................................4-33
Listening to the Radio
.........................................................4-31
Low Fuel Warning Light ......................................................4-5
MMaintenance Recommended under Severe Driving
Conditions
............................................................................9-7
Maintenance Schedule
........................................................9-2Malfunction Indicator Light
................................................ 4-5
Manual Heating and Air Conditioning System
................. 4-19
Manual Transaxle
................................................................ 6-6
Mirrors
.................................................................................. 2-10
NNational Highway Traffic Safety Administration
(NHTSA)
............................................................................... 12-4
OOdometer
............................................................................. 4-7
Oil Level Check
................................................................... 9-11
Oil Pressure Light ............................................................... 4-4
On-Board Vehicle Computers and Event Data
Recorders
............................................................................ 12-3
Open Door Warning Light
.................................................. 4-6
Outside Rearview Mirrors .................................................. 2-10
Outside Rearview Mirrors Defroster Switch
..................... 4-11
PParking Brake Lever
....................................................5-1
, 9-24
Pedals
.................................................................................. 5-1
Periodic Maintenance Schedule
........................................ 9-3
Power Assisted Brakes
...................................................... 6-7
Power Door Locking System
............................................. 2-2
Power Mirror Control
.......................................................... 2-11
Power Steering
.................................................................... 9-24
Power Steering Fluid
.......................................................... 9-24
Power Window Controls ..................................................... 2-8
Programming/Removing the transmitter code
yourself
................................................................................ 2-5
RRadio Antenna
..................................................................... 4-33
Rear Center Seat Belt
......................................................... 2-17

Downloaded from www.Manualslib.com manuals search engine 15-4 INDEX
54G27-03E
Rear Window Defroster Switch
..........................................4-10
Rear Window Wiper/Washer Switch
..................................3-5
Refill with Oil and Check for Leaks ....................................9-13
Refilling
................................................................................9-12
Remote Audio Controls
.............................................. 3-8
, 4-43
Replace the Oil Filter
...........................................................9-13
Replacement of the transmitter battery
.............................2-4
Reporting Safety Defects
....................................................12-4
SSafety Certification Label
...................................................12-2
Seat Adjustment
..................................................................2-11
Seat Belt Extender ...............................................................2-30
Seat Belt Hanger
..................................................................2-21
Seat Belt Inspection
............................................................2-22
Seat Belt Pretensioner System
..........................................2-31
Seat Belt Reminder
..............................................................2-19
Seat Belts and Child Restraint Systems
...........................2-13
Selection of Coolant
............................................................9-17
Shoulder Anchor Height Adjuster
......................................2-21
Side Door Locks
..................................................................2-1
Snow Tires
...........................................................................9-31
Spark Plugs ..........................................................................9-21
SPECIFICATIONS
................................................................14-1
Specified Fluid
.....................................................................9-16
Specified Gear Oil ................................................................9-14
Specified Oil
.........................................................................9-11
Speedometer ........................................................................4-7
Spot Light
.............................................................................5-7
Starting the Engine
..............................................................6-2
Steering Wheel
.....................................................................9-24
Stowing Rear Center Lap-Shoulder Belt
...........................2-19Sun Visor
............................................................................. 5-6
Supplemental Restraint System (air bags)
....................... 2-32
TTachometer
.......................................................................... 4-9
Temperature Gauge
............................................................ 4-10
Thermometer
....................................................................... 4-13
Tilt Steering Lock Lever
..................................................... 3-6
Tire Chains
.......................................................................... 7-3
Tire Changing Tools
........................................................... 5-12
Tire Inflation Pressure ........................................................ 9-26
Tire Inspection
.................................................................... 9-27
Tire Rotation
........................................................................ 9-29
Tire Sidewall Labeling
........................................................ 9-25
Tire Size
............................................................................... 9-26
Tires
..................................................................................... 9-25
Towing a Disabled Vehicle
................................................. 10-5
Towing Your Vehicle (recreational towing)
...................... 8-2
Trailer Towing
..................................................................... 8-2
Trip meter
............................................................................ 4-7
Troubleshooting
.................................................................. 4-47
Trunk Lid
.............................................................................. 2-7
Trunk Light .......................................................................... 5-13
Turn Signal Indicators
........................................................ 4-6
Turn Signal Operation ........................................................ 3-4
UUniform Tire Quality Grading
............................................. 9-29
Unlatching and Latching Detachable Connector
............. 2-18
Using the Transaxle
............................................................ 6-4
VVehicle Cleaning
................................................................. 11-3
Vehicle Identification Number
........................................... 12-1

Downloaded from www.Manualslib.com manuals search engine 15-5 INDEX
54G27-03E
Vehicle Loading
........................................................... 8-1
, 9-32
WWarning and Indicator Lights
.............................................4-3
Warranties
............................................................................12-2
Washing
................................................................................11-4
Waxing ..................................................................................11-5
Windows ...............................................................................2-8
Windshield Washer
.............................................................3-5
Windshield Washer Fluid
....................................................9-19
Windshield Wiper and Washer Lever
................................3-4
Windshield Wipers
..............................................................3-4
Wiper Blades
........................................................................9-41

Downloaded from www.Manualslib.com manuals search engine 15-6 INDEX
54G27-03E
MEMO
