2007 SUZUKI AERIO Owners Manual

Downloaded from www.Manualslib.com manuals search engine 5-6 OTHER CONTROLS AND EQUIPMENT
54G27-03E
Armrest (if equipped)
54G464
From the stowed (fully up) position, lower
the armrest as far as it will go. Then raise it
slowly to the desired position. When not in
use, return the armrest to the stowed posi-
tion.
Sun Visor
79J161
The sun visors can be pulled down to block
glare coming through the windshield, or
they can be unhooked and turned to the
side to block glare coming through the side
window.
Interior Light Switch
52D071
The interior light switch has three posi-
tions, which functions as described below.
(1) The light comes on and stays on
regardless of whether the door is
open or closed.
(2) The light comes on when the door is
opened.
After closing all doors, the light will
remain on for about 15 seconds and
then fade out. If you insert the key into
the ignition switch during that time,
the light will start to fade out immedi-
ately.
After removing the key from the igni-
tion switch, the light will turn on for
about 15 seconds and then fade out.
(3) The light remains off even when the
door is opened.
CAUTION
To avoid damage to the armrest, do
not lean on it or allow a child to sit on
it.
1
2
CAUTION
When unhooking and hooking a sun
visor, be sure to handle it by the hard
plastic parts or the sun visor can be
damaged.EXAMPLE
Folding Rear Seats: 3

Downloaded from www.Manualslib.com manuals search engine 5-7 OTHER CONTROLS AND EQUIPMENT
54G27-03E
54G051
NOTE:
The number of doors involved in the light-
ing operation of the interior light depends
on the vehicle specification. If there is a
switch (rubber projection) at the door
opening as shown, the door is involved in
the lighting operation.
Spot Light
65D022
Push the switch to turn on the light and
push it again to turn off the light.
Assist Grips (if equipped)
54G249
Assist grips are provided for passenger
convenience.
EXAMPLE
CAUTION
To avoid damaging the assist grip
and the molded headlining, do not
hang down the assist grip.
Folding Rear Seats: 3

Downloaded from www.Manualslib.com manuals search engine 5-8 OTHER CONTROLS AND EQUIPMENT
54G27-03E
Coat Hooks (if equipped)
54G303
You can hang clothing on the coat hooks.
These hooks are not designed for large or
heavy items.
Eyeglasses Holder
(if equipped)
86G067
To use the eyeglasses holder, open the
cover. Do not put heavy or sharp items in
the box.
Engine Hood
54G485
To open the engine hood:
1) Pull the hood release handle located on
the outboard side of the driver’s side of
the instrument panel. This will disen-
gage the engine hood lock half-way.
54G058
2) Push the under-hood release lever
sideways with your finger, as shown in
the illustration. While pushing the lever,
lift up the engine hood.
CAUTION
If you park your vehicle outdoors in
direct sunlight or in hot weather, the
eyeglasses holder can get very hot
since it is close to the roof. So, when
parking in such conditions:
 Do not leave eyeglasses in the
holder. The heat may distort plastic
lenses or frames.
 Do not place flammable items, such
as a lighter, in the holder. The heat
may cause a fire.
Folding Rear Seats: 3

Downloaded from www.Manualslib.com manuals search engine 5-9 OTHER CONTROLS AND EQUIPMENT
54G27-03E
54G497
3) Continue to lift up the hood until it is
high enough to support with the prop
rod.
To close the engine hood:
1) Lift the hood up slightly and remove the
prop rod from the hole. Put the prop rod
back to the holding clip.
2) Lower the hood close to the bumper,
then let it drop down.
Make sure the hood is securely latched
after closing.
Cup Holder and Storage Area
(if equipped)
54G466
Cup holders are provided in the center
console.
54G469
The reversible board is equipped for the
purpose of CD holder or a tray.
WARNING
Make sure the hood is fully closed
and latched before driving. If it is not,
it can fly up unexpectedly during
driving, obstructing your view and
resulting in an accident.
WARNING
Do not use the cup holder or the stor-
age bin to hold cups containing hot
liquids or sharp-edged, hard or
breakable objects. Objects in these
bins may be thrown about during a
sudden stop or impact, and could
cause personal injury.EXAMPLE
EXAMPLE
Folding Rear Seats: 3
Armrest: 3

Downloaded from www.Manualslib.com manuals search engine 5-10 OTHER CONTROLS AND EQUIPMENT
54G27-03E
(if equipped)
54G473
Push the release button and open the lid.
Accessory Socket
(if equipped)
54G512
(if equipped)
54G486
This socket can be used to provide 12 volt/
120 watt power for electrical accessories.
CAUTION
Use of inappropriate electrical acces-
sories can cause damage to your
vehicle’s electrical system. Make
sure that any electrical accessories
you use are designed to plug into this
type of socket.
Sun Visor: 5
Interior Light Switch: 7

Downloaded from www.Manualslib.com manuals search engine 5-11 OTHER CONTROLS AND EQUIPMENT
54G27-03E
Frame HooksFront (type A)
54G468
Front (type B)
54G532
Rear (type A)
54G646
Rear (type B)
54G534
Frame hooks (1) are provided on the front
and rear of the vehicle for use in emer-
gency situations.
For type A model, remove the cover to
access the front hook (1). Unhook the
lower part of the cover (a) and then remove
the cover (a).
For type B model, remove the cover to
access hook (1) as follows.
Front:
Remove clip (a), unhook the lower part of
the cover (b) and then remove the cover
(b).
Rear:
Unhook the lower part of the cover (c) and
then remove the cover (c).
To tow your vehicle on the road or highway,
follow the towing instruction in “EMER-
GENCY SERVICE” or “VEHICLE LOAD-
ING AND TOWING” section.
(1)
(a)
EXAMPLE
(1)
(a)
(b)
EXAMPLE
(2)
(1)
EXAMPLE
(2) (1)
(c)
EXAMPLE
WARNING
Do not use the frame hooks (1) to tow
another vehicle or to have your vehi-
cle towed on the road or highway.
The hooks (1) are designed for use in
emergency situations only, such as if
your vehicle or another vehicle gets
stuck in deep mud or snow.
Spot Light: 7
Assist Grips: 3
Coat Hooks:

Downloaded from www.Manualslib.com manuals search engine 5-12 OTHER CONTROLS AND EQUIPMENT
54G27-03E
The hook (2) is provided for sea shipping
purposes only. It can break if used for any
other purpose.
54G634
54G635
The hooks (3) and frame holes (4) are pro-
vided for shipping purposes only.
Tire Changing Tools
54G420
The jack, wheel wrench and jack handle
are stowed in the rear right of luggage
compartment.
Turn the knob and remove the cover to
access the tools.
To remove the jack, turn its shaft counter-
clockwise and pull the jack out of the stor-
age bracket. To stow the jack, place it in
the storage bracket and turn the shaft
clockwise until the jack is securely held in
place.
CAUTION
Do not use the right hand frame
hook, or the towing rope will bear
against the front bumper, possibly
damaging it.
(3)
EXAMPLE
(4)
EXAMPLE
Eyeglasses Holder:
Engine Hood: 5

Downloaded from www.Manualslib.com manuals search engine 5-13 OTHER CONTROLS AND EQUIPMENT
54G27-03E
Front Seat Back Pocket
(if equipped)
60B119
This pocket is provided for holding light
and soft things such as gloves, newspa-
pers or magazines.
Trunk Light
54G314
When you open the trunk lid, the trunk light
comes on and remains on as long as you
keep the lid open.
WARNING
The jack should be used only to
change wheels. It is important to read
the jacking instructions in the
“EMERGENCY SERVICE” section of
this manual before attempting to use
the jack.
WARNING
After using the jack, jack handle and
wheel wrench, be sure to stow them
securely or they can cause injury if
an accident occurs.
WARNING
Do not put hard or breakable objects
in the pocket. If an accident occurs,
objects such as bottles, cans, etc.
can injure the occupants in the rear
seat.EXAMPLE
CAUTION
Do not keep the trunk lid open for a
long time, or the battery will dis-
charge.EXAMPLE
