2007 SUZUKI AERIO Owners Manual

Downloaded from www.Manualslib.com manuals search engine 12-4 GENERAL INFORMATION
54G27-03E
Reporting Safety DefectsIf you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition to
notifying American Suzuki Motor Corp.
If NHTSA receives similar complaints,
it may open an investigation, and if it
finds that a safety defect exists in a
group of vehicles, it may order a recall
and remedy campaign. However,
NHTSA cannot become involved in
individual problems between you, your
dealer, or American Suzuki Motor
Corp.
To contact NHTSA, you may call the
Vehicle Safety Hotline toll-free at 1-
888-327-4236 (TTY: 1-800-424-9153);
go to http://www.safercar.gov; or write
to: Administrator, NHTSA, 400 Sev-
enth Street, SW., Washington, D.C.
20590. You can also obtain other infor-
mation about motor vehicle safety
from http://www.safercar.gov.To contact American Suzuki, owners
in the continental United States can
call toll-free 1-800-934-0934, or write
to:
American Suzuki Motor Corporation
Automotive Customer Relations
3251 East Imperial Highway
Brea, CA 92821-6795
For owners outside the continental
United States, please refer to the dis-
tributor’s address listed in your War-
ranty Information booklet.
For vehicles registered for use and
principally operated in Canada please
contact Suzuki Canada Inc. at 1-905-
889-2677 extension 2254 or write to:
Suzuki Canada Inc.
Customer Relations
100 East Beaver Creek Road
Richmond Hill, On
L4B 1J6

Downloaded from www.Manualslib.com manuals search engine 12-5 GENERAL INFORMATION
54G27-03E
MEMO

Downloaded from www.Manualslib.com manuals search engine 13-1 FUSES AND PROTECTED CIRCUITS
54G27-03E
13
FUSES AND PROTECTED CIRCUITS
54G220
COLOR/SIZE (AMPS)
PROTECTED CIRCUIT
In engine
compartment MAIN
FUSE
BOX(1) BLACK (80) All Electric Loads
(2) YELLOW (60) Ignition Switch
(3) YELLOW (60) Circuit Fuse Box, Relay Box
(4) YELLOW (60) ABS Controller
(5) ORANGE (30) Blower Fan Main Relay
(6) BLUE (15) Right Headlight, Meter
(7) BLUE (15) Left Headlight
(8) GREEN (30) Radiator Fan Relay
(9) YELLOW (20) Air Conditioning
(10) BLUE (15) Fuel Injection Controller, Cruise Control
(11) BLUE (15) Brake Light(1) (5) (4) (3) (2)
(6)
(7)
(8)
(9)
(10)
(11)
Fuses and Protected Circuits: 7

Downloaded from www.Manualslib.com manuals search engine 13-2 FUSES AND PROTECTED CIRCUITS
54G27-03E
54G221
COLOR/SIZE (AMPS)
PROTECTED CIRCUIT
In engine
compartment FUSE
BOX(30) BLANK –
(31) BLUE (15) Fog Light
(32) BLUE (15) Horn(30)
(31)
(32)
Fuses and Protected Circuits: 7

Downloaded from www.Manualslib.com manuals search engine 13-3 FUSES AND PROTECTED CIRCUITS
54G27-03E
54G222
COLOR/SIZE (AMPS)
FUSE NAME PROTECTED CIRCUIT
Under the
dashboard FUSE
BOX(12) RED (10) HEATER Air Conditioning, Mirror Heater Switch
(13) BLANK – –
(14) YELLOW (20) REAR DEFOG Rear Defroster
(15) BLUE (15) RADIO·DOMEFuel Injection Controller, Dome Light, Spot Light,
Luggage Compartment Light, Radio, A/T Controller
(16) RED (10) AIR BAG 2 Air Bag
(17) RED (10) HAZARD Hazard Light, Keyless Entry
(18) BLANK – –
(19) RED (10) TAILParking/Marker Light (Front & Rear), License Plate
Light
(20) YELLOW (20) DOOR LOCK Door Lock Control
(21) BLANK – –
(22) BLUE (15) AIR BAG Air Bag
(12) (13) (14) (15) (16) (17) (18) (19)
(22) (23) (24) (25) (26) (27)(28) (29)(20) (21)
(33)
(34)
Fuses and Protected Circuits: 7

Downloaded from www.Manualslib.com manuals search engine 13-4 FUSES AND PROTECTED CIRCUITS
54G27-03E
54G222
COLOR/SIZE (AMPS)
FUSE NAME PROTECTED CIRCUIT
Under the
dashboard FUSE
BOX(23) BLUE (15) IGGenerator, Ignition Coil, O
2 Sensor Heater, Fuel
Injection Controller, A/T Controller
(24) RED (10) TURN·BACK Turn Signal Light, Back Up Light
(25) BLUE (15) WIPER WASHER Wiper & Washer
(26) RED (10) ABS Anti-lock Brake System
(27) RED (10) METER Meter
(28) BLUE (15) CIGAR Cigar Lighter, Mirror Heater, Radio, Power Mirror
(29) BLANK – –
CAS-
SETTE
FUSE(33) ORANGE (30) P/W Power Window
Under the
dashboard
(34) BLANK – –
(12) (13) (14) (15) (16) (17) (18) (19)
(22) (23) (24) (25) (26) (27)(28) (29)(20) (21)
(33)
(34)
Fuses and Protected Circuits: 7

Downloaded from www.Manualslib.com manuals search engine 14-1 SPECIFICATIONS
54G27-03E
14
SPECIFICATIONSNOTE:
Specifications are subject to change without notice.
4WD: 4-wheel drive
2WD: 2-wheel drive
ITEM: Dimensions UNIT: mm (in.)
Overall length4350 (171.3)
Overall width without side mold 1690 (66.5)
with side mold 1720 (67.7)
Overall height1545 (60.8)
Wheelbase2480 (97.6)
Tread Front 1450 (57.1)
Rear 1445 (56.9)
Minimum ground clearance 150 (5.9)
ITEM: Weight
Gross axle weight rating
See the safety certification label and the tire information label which
are located on the driver’s door lock pillar. Gross vehicle weight rating
Vehicle capacity weight
Specifications: 1, 2, 5, 6, 7, 10, 11

Downloaded from www.Manualslib.com manuals search engine 14-2 SPECIFICATIONS
54G27-03E
ITEM: Engine
Type J23A (16 valve DOHC)
Number of cylinders 4
Bore 90.0 mm (3.54 in.)
Stroke 90.0 mm (3.54 in.)
Piston displacement 2290 cm
3 (139.7 cu.in, 2290 cc)
Compression ratio 9.3 : 1
ITEM: Electrical
Ignition timing 3° – 17° B.T.D.C. at idle speed
Standard spark plug NGK IFR5J11
Battery GP24 12V
Fuses See “INSPECTION AND MAINTENANCE” and “FUSES AND PRO-
TECTED CIRCUITS” sections.
Specifications: 1, 2, 5, 6, 7, 10, 11
