–fourthfour-digitcodemeansdateofmanu-facture.If,forexample,thelastfournumbersread0204,thetirewasproducedinthe2ndweekof2004.
CTireplycompositionandmaterial
Thenumberoflayersinthetreadandsidewallsandtheirmaterialcomposition.
DMaximumpermissibleinationpressure
Themaximumpermissiblecoldinflationpressuretowhichatirecanbeinflated.
Donotexceedthepermissibleinflationpressure.
EMaximumLoadrating
Themaximumloadinkilogramsandpoundscanbecarriedbythetire.Ifyoureplacetiresalwaysuseatirethathasthesamemaximumloadratingasthefactoryinstalledtire.
FRadial
Theidentificationindicatesifthetirehasradialstructure.
GTermoftubelessortubetire
Identificationfortubelesstires.
Speedcodeletter
Thespeedcodeletterindicatesthemaximumpermissiblespeedforthetire.Thiscodeletterisshownonthetiresidewall.
T=upto118mph(190km/h)
H=upto131mph(210km/h)
V=upto150mph(240km/h)
W=upto167mph(270km/h)
Y=upto186mph(300km/h)
Tipondriving
TireswithamaximumspeedratingthatislowerthanthespecifiedmaximumvehiclespeedmaybemountedonlyiftheybearanM+Sidentificationonthetiresidewall.
Pleasenotethatinadditiontothewintertires,all-seasonandall-terraintiresarealsosubjecttospeedlimitsandbearthisidentification.
Inscriptiononlightalloywheels
Maintenancenote
Protectthevalveinsertsagainstsoilingwithvalvecaps.Useonlyplasticvalvecaps.Soiledvalveinsertscancauseagraduallossofair.
A-RimwidthininchesB-Rim-angecontourcodeletterC-Symbolfordrop-centerrimD-RimdiameterininchesE-DoublehumpF-Rimoffsetinmm
Noteonoperation
TherimwidthininchesAandtherimoffsetFarevisiblefromtheoutside.Thisinformationcanbefoundnearthetirevalve.
PracticalTips,EmergencyService247

LoadingInformation
Denitions
TheCurbweight-actualweightofyourvehicle-vehicleweightincludingstandardandoptionalequipment,fluidsandemergencytools.Thisweightdoesnotincludepassengersandcargo.
TheGrossVehicleWeightissumofthecurbweightandtheweightofpassengersandcargocombined.
TheGrossVehicleWeightRatingisthemaxi-mumtotalweightofvehicle,passengers,luggageandoptionalequipment.
TheGrossAxleWeightRatingisthemaximumloadlimitforthefrontortherearaxle.Thisinformationislocatedonthesafetycompliancestickerlocatedinthedriver’ssidedoorjamb.
Fordeterminingthecompatibilityofthetireandvehicleloadcapabilities:
Pleaseobservethechapter”TIRES,RIMS,TRACKS”onpage298.
Theloadcapacitycoefficient(e.g.“101”)isaminimumrequirement.
TheGrossCombinedWeightRatingisthemaxi-mumtotalweightratingofvehicle,passengersandcargo.
TheVehicleCapacityWeight-LoadLimit-isthemaximumtotalweightlimitspecifiedoftheload(passengersandcargo)forthevehicle.Thisisthe
maximumweightofpassengersandcargothatcanbeloadedintothevehicle.Thisinformationcanbefoundonthetirepressureplate.
Themaximumloadedvehicleweightisthesumofcurbweight,accessoryweight,vehiclecapacityweightandproductionoptionsweight.
Theloadratingisthemaximumloadthatatireisratedtocarryforagiveninflationpressure.
Themaximumloadratingistheloadratingforatireatthemaximumpermissbleinflationpressure.
Thecargocapacityisthepermissibleweightofcargo,thesubtractedweightofpassengersfromtheloadlimit.
Neverexceedthepermissiblelimits.
Danger!
Riskoflossofcontrol,damagetovehicleandseriouspersonalinjuryordeath.
Neverexceedthespecifiedaxleloads.Overloadingcanshortentheservicelifeofthetiresandcar,aswellasleadtodangerousvehiclereactionsandlongbrakingdistances.Damageduetooverloadingisnotcoveredbythevehiclewarranty.
Examplefordeterminingthecombinedweightofoccupantsandcargo
VehicleLoadCapacity
Thecombinedweightofoccupantsandcargoshouldneverexceedtheweightshownonthetireplateinthevehicle.
Pleaseobservethechapter”TIREPRESSUREPLATE”onpage240.
Neverexceedthenumberofpassengersshownonthetirepressureplateinthevehicle.
248PracticalTips,EmergencyService

Determiningthecombinedweightofoccupants
andcargo:
Addtheweightofalloccupantsandthenaddthetotalluggageweight(gure).
Stepsfordeterminingcorrectloadlimit
1.Locatethestatement"ThecombinedweightofoccupantsandcargoshouldneverexceedXXXpounds"onyourvehicle’splacard(dependingonthedateofmanufacture).
2.Determinethecombinedweightofthedriverandpassengerthatwillberidinginyourvehicle.
3.SubtractthecombinedweightofthedriverandpassengerfromXXXkilogramsorXXXpounds.
4.Theresultingfigureequalstheavailableamountofcargoandluggageloadcapacity.Forexample,ifthe"XXX"amountequals400lbs.andtherewillbetwo-150lbpassengersinyourvehicle,theamountofavailablecargoandluggageloadcapacityis100lbs.(400-300(2x150)=100lbs.).
5.Determinethecombinedweightofluggageandcargobeingloadedonthevehicle.ThatweightmaynotsafelyexceedtheavailablecargoandluggageloadcapacitycalculatedinStep4.
PracticalTips,EmergencyService249

FlatTire
Generalinformation
Warning!
Failuretofollowtheseinstructionsmayresultinseriouspersonalinjuryordeathtoyouortobystanders.
Ifyouhaveaflattire,moveasafedistanceofftheroad.Turntheemergencyflasheronanduseotherwarningdevicestoalertothermotorists.Settheparkingbrake.
Donotparkyourvehiclewhereitmaycontactdrygrass,brushorotherflammablematerials.Thehotpartsoftheexhaustsystemcouldsetsuchmaterialsonfire,therebycausingbothpropertydamageandseriouspersonalinjuryordeath.
Atiresealantandcompressorwithpressuretesterarelocatedinthetoolboxintheluggagecompartment.
PleaseobservethesafetyandoperatinginstructionsonthespecialsealantbottlewithaspecialPorschepartnumberandonthecompressor-theseareessential.
Caution!
Sealingthetirewiththetirerepairkitisonlyanemergencyrepair.Evenwiththetireair-tight,itmaybeusedonlyforshorttripsinanemergency.Themaximumpermittedspeedis50mph(80km/h).
Donotusecommerciallyavailablesealantortireinflatingbottles.Useonlythetiresealantlocatedintheluggagecompartment.
Warning!
Riskofaccidentresultinginseriouspersonalinjuryordeath.
Havetiresreplacedbyaspecialistworkshopassoonaspossible.
Avoidhardaccelerationandhighcorneringspeeds.
A-FillerbottleB-Fillerhose
Tiresealant
Usage
Thetiresealantcanbeusedtosealsmallcuts,especiallyinthetiretread.
Sealingthetirewiththetiresealantisonlyanemergencyrepair,soyoucandrivetothenextworkshop.Evenwiththetireair-tight,itmaybeusedonlyforshorttripsinanemergency.
250PracticalTips,EmergencyService

Thetiresealantandacompressorwithpressuretestercanbefoundinthetoolboxintheluggagecompartment.
Thetiresealantcomprises:
–Afillerbottle
–Afillerhose
–Avalveturnerand
–Asparevalveinsert
–Astickerdenotingthemaximumpermissiblespeedforthedriver’sfieldofvision.
Danger!
Riskofaccidentresultinginseriouspersonalinjuryordeath.
Usethetiresealantonlyinthecaseofcutsorpuncturesnolargerthan0.15in.(4mm).
Neverusethetiresealantiftherimisdam-aged.
Warning!
Thesealantishighlyammableandharmfultohealth.
Fire,nakedflameandsmokingareprohibitedwhenhandlingtiresealant.
Avoidcontactwithskin,eyesandclothingduetocausticchemicalpropertiesofthetiresealant.
Keeptiresealantawayfromchildren.
Donotinhalevapors,duetoconsequentharmtopersonalhealthresultinginseriouspersonalinjuryordeath.
Incaseofcontactwiththesealant:
Ifsealantgetsontheskinorintheeyes,thoroughlyrinsetheaffectedpartofthebodyoffimmediately.
Changesoiledclothingimmediately.
Getmedicalattentionimmediatelyintheeventofanallergicreaction.
Ifsealantwasswallowed,thoroughlyrinseoutthemouthwithoutdelayanddrinkplentyofwater.Donotinducevomiting.Getmedicalattentionimmediately.
A-FillerbottleB-FillerhoseC-PlugofthellerhoseD-ValveturnerE-ValveinsertF-Tirevalve
Insertingsealant
1.Leavetheobjectthatcausedthepunctureinthetire.
2.Removesealantandtheenclosedstickerfromtheluggagecompartment.
3.Adherethestickerinthedriver’sfieldofvision.
4.ShakefillerbottleA.
PracticalTips,EmergencyService251

5.ScrewfillerhoseBontothefillerbottle.Thefillerbottleisnowopen.
6.UnscrewvalvecapfromtirevalveF.
7.RemovevalveinsertEfromthetirevalvewithvalveturnerD.Keepthevalveinsertinacleananddryplace.
8.RemoveplugCofthefillerhoseB.
9.Pushfillerhoseontothetirevalve.
10.Holdfillerbottlehigherthanthelevelofthetirevalveandpressittogetherforcefullyuntilthebottleiscompletelyemptiedintothetire.
11.Pullfillerhoseoffthetirevalve.
12.Twistthevalveinsertfirmlyintothetirevalveusingthevalveturner.
13.Connectthecompressortothecigarettelighterandinflatethetiretotheprescribedtirepressure.
Pleaseobservethechapter”TIREPRESSUREFORCOLDTIRES”onpage299.
14.Screwvalvecapontothetirevalve.
15.Checkthetirepressureafterdrivingforaround10minutes.Ifthetirepressureislessthan22psi(1.5bar),donotcontinuedriving.Ifavalueofmorethan22psi(1.5bar)isindicated,correctthepressuretotheprescribedvalue.
16.PleaseconsultyourauthorizedPorschedealer.
CareInstructions
Afterdrying,anysealantthatemergescanbepeeledofflikeafilm.
Warning!
Riskofaccidentresultinginseriouspersonalinjuryordeath.
HavethetirereplacedbyanauthorizedPorschedealerimmediately.
Avoidhardaccelerationandhighcorneringspeeds.
Donotexceedmaximumspeedof50mph(80km/h).
Pleasealwaysobservethesafetyandoper-atinginstructions,whichcanbefoundintheseparateoperatinginstructionsforthesealantandonthecompressor.
Frontjackingpoint
Liftingthevehicle
Liftingthevehiclewithaliftingplatformor
garagelift
Thecarmustberaisedonlyattheillustratedjackingpoints.
252PracticalTips,EmergencyService

Rearjackingpoint
Danger!
Seriouspersonalinjuryordeathand/orseriousdamagetotheengineorthevehiclemayoccur,ifyouliftthevehicleimproperly.
Neverliftthevehicleatanyotherplacethanthejackingpoints.
Neverliftthevehiclebytheengine,transmis-sionoraxles.
Donotdamageanysensitivecomponentsinthevicinityofthejackingpoints.
Platformlift
Beforethecarisdrivenontoaliftingplatform,itmustbeensuredthatthereisenoughspacebetweentheliftingplatformandthevehicle.
Garagelift
Agarageliftmaybeusedonlyattheillustratedjackingpoints.
PracticalTips,EmergencyService253

WheelBolts
Danger!
Riskofwheelboltbreakageandwheelseparation,resultinginseriouspersonalinjuryordeath.
Followallinstructionsconcerningwheelbolts.
Alwayscleanthewheelboltsbeforefitting.
ApplyathincoatofOptimolyTA(aluminumpaste)onthethreadandbetweentheboltheadandmovablesphericalcapring(arrows).Thebearingsurfaceofthesphericalcapfacingthewheelmustnotbegreased.
Replacedamagedwheelbolts.OnlyusetheOriginalPorschewheelboltsspeciallydesignedforthisvehicletype.
Tighteningtorque
Tighteningtorqueofwheelbolts:130Nm/96ftlb.
WheelSecuringBolts
Ifthewheelshavetoberemovedattheworkshop,pleasedonotforgettohandoverthewrenchsocketforthewheelsecuringboltsalongwiththecarkey.
Thewrenchsocketforthewheelsecuringboltsisinthetoolbox.
Toloosenortightenthewheelboltwithanti-theftprotection,awrenchsocketwiththeappropriatecodingmustbeusedbetweenthewheelboltandthewheel-boltspanner.
Whenpositioningthewrenchsocket,ensurethatitengagesfullyintheteethofthewheelbolt.
