2007 MERCEDES-BENZ ML320CDI Comand Manual

88 Safety and SecurityOccupant safetyChildren can be killed or seriously injured by
an inflating air bag. Note the following
important information when circumstances
require you to place a child in the front pas-
senger seat:

Your vehicle is equipped with air bag
technology designed to turn off the front
passenger front air bag in your vehicle
when the system senses the weight of a
typical 12-month-old child or less along
with the weight of a standard appropri-
ate child restraint on the front passen-
ger seat.


A child in a rear-facing child restraint on
the front passenger seat will be serious-
ly injured or even killed if the front
passenger front air bag inflates in a
collision which could occur under some
circumstances, even with the air bag
technology installed in your vehicle. The
only means to completely eliminate this
risk is to never place a child in a rear-fac-
ing child restraint in the front seat. We
therefore strongly recommend that you
always place a child in a rear-facing
child restraint in the back seat.


If you must install a rear-facing child
restraint on the front passenger seat
because circumstances require you to
do so, make sure that the
59indicator lamp is illumi-
nated, indicating that the front passen-
ger front air bag is deactivated. Should
the 59indicator lamp not
illuminate or go out while the restraint is
installed, please check installation.
Periodically check the
59indicator lamp while
driving to make sure the
59indicator lamp is illumi-
nated. If the 59indicator
lamp goes out or remains out, do not
transport a child on the front passenger
seat until the system has been repaired.
A child in a rear-facing child restraint on
the front passenger seat will be serious-
ly injured or even killed if the front pas-
senger front air bag inflates.


If you have to place a child in a
forward-facing child restraint on the
front passenger seat, move the seat as
far back as possible, use the proper
child restraint recommended for the
age, size and weight of the child, and
secure child restraint with the vehicle’s
seat belt according to the child seat
manufacturer’s instructions. For
children larger than the typical
12-month-old child, the front passenger
front air bag may or may not be
activated (
page 87).


89 Safety and Security
Occupant safety
The 59indicator lamp is
located in the center console.
159indicator lamp
The 59indicator lamp1 will
be illuminated, except with the SmartKey
removed from the starter switch or with
the starter switch in position0
(page 39).
i
Deployment of the driver front air bag does
not mean that the front passenger front air bag
also should have deployed.
The Occupant Classification System (
page 85)
may have determined:


that the seat was empty or occupied by the
weight up to or less than that of a typical
12-month-old child seated in a standard
child restraint – both instances where the
system suppresses deployment of the front
passenger front air bag even though the im-
pact met the criteria and was of sufficient
severity to deploy the driver front air bag.


that the seat was occupied by a small individ-
ual (such as a young teenager or a small
adult) or a child weighing more than the
weight of a typical 12-month-old child in a
standard child restraint – instances where
the system may suppress deployment of the
front passenger front air bag even though
the impact met the criteria and was of suffi-
cient severity to deploy the driver front air
bag.
Warning!
G
If the 1indicator lamp and the
59indicator lamp are lit at the
same time, there is a malfunction in the
Occupant Classification System. The front
passenger front air bag will be deactivated
in this case. Have the system checked as
soon as possible by qualified technicians.
Contact an authorized Mercedes-Benz Light
Truck Center.
In order to ensure proper operation of the
air bag system and OCS:

Do not place more than 4.4 lbs (2 kg)
into the parcel net on the back of the
front passenger seat. Otherwise, the
OCS may not be able to properly
approximate the occupant weight
category.


Do not place objects under and/or
around the front passenger seat.


90 Safety and SecurityOccupant safety
Self-test Occupant Classification
System
After turning the SmartKey in the starter
switch to position1 or2 or pressing the
KEYLESS-GO* start/stop button once or
twice, the 59indicator lamp
(page 89) located in the center console
illuminates. If an adult occupant is properly
sitting on the front passenger seat and the
system senses the occupant as being an
adult, the 59indicator lamp
will illuminate and go out after approxi-
mately 6 seconds.
If the seat is not occupied and the system
senses the front passenger seat as being
empty, the 59indicator lamp
will illuminate and not go out.For more information, see the “Practical
hints” section (
page 426).


Do not hang anything from or attach any
items to the seats.


Do not stuff objects such as books be-
tween the middle console and the front
passenger seat.


Do not move the front passenger seat
backwards against stiff objects.


Sit properly belted in a nearly upright
position with your back against the seat
backrest.


Do not lean on the armrests or lift your-
self from the seat by using the handle
over the door as this may cause the OCS
to be unable to correctly approximate
the occupant weight category.


Only have the seat repaired or replaced
by an authorized Mercedes-Benz Light
Truck Center.


Read and observe all warnings in this
chapter.
Warning!
G
If the 59indicator lamp should
not illuminate, the system is not functioning.
You must see an authorized Mercedes-Benz
Light Truck Center before seating any child
on the front passenger seat.Warning!
G
Never place anything between seat cushion
and child seat (e.g. pillow), since it reduces
the effectiveness of the Occupant Classifi-
cation System. The bottom of the child seat
must make full contact with the passenger
seat cushion. An incorrectly mounted child
seat could cause injuries to the child in case
of an accident, instead of increasing protec-
tion for the child.
Follow the manufacturer’s instructions for
installation of child seats.


91 Safety and Security
Occupant safety
Child seat anchors – LATCH type
This vehicle is equipped with two LATCH
(Lower A
nchors and T
ethers for CH
ildren)
type anchors (at each of the outer rear
seats) for the installation of a LATCH child
seat with matching mounting fittings.The LATCH anchors are blended with
covers.
1Anchorage ring covers

Remove anchorage ring cover1 from
the seat on which a child seat is to be
installed.
Warning!
G
Children too big for a toddler restraint must
ride in seats using regular seat belts. Posi-
tion shoulder belt across chest and shoul-
der, not face or neck.
A booster seat may be necessary to achieve
proper belt positioning for children over
41 lbs until they reach a height where a
lap/shoulder belt fits properly without a
booster.
Install child seat according to manufactu-
rer’s instructions.
T h e c h i l d s e a t m u s t b e f i r m l y a t t a c h e d t o t h e
right and left side anchors2 (
page 92).
An incorrectly mounted child seat may come
loose during an accident which could result
in serious injury or death to the child.
Damaged or impact damaged child seats or
child seat mounting fittings must be re-
placed.
Do not leave children unattended in the ve-
hicle, even if the children are secured in a
child restraint system.

92 Safety and SecurityOccupant safety2Anchors
Install a LATCH type child seat accord-
ing to the manufacturer’s instructions.Installation of infant and child restraint
system
This vehicle is equipped with tether
anchorages for a top tether strap at each
of the rear seating positions.
1Anchorage ring
2Hook

Move the respective head restraint to
its uppermost position (
page 129).

Guide top tether strap between head
restraint and top of seat backrest.
1Anchorage ring
2Hook
!
Make sure the seat belt for the center seat
can operate freely with a child seat installed.
i
Non-LATCH type child seats may also be
used and can be installed using the vehicle’s
seat belt system. Install child seat according to
the manufacturer’s instructions.
i
For safety, make sure hook2 has attached
to anchorage ring1 beyond the safety catch, as
illustrated.

93 Safety and Security
Occupant safety

Securely fasten hook2, which is part
of the tether strap, to anchorage
ring1.
Make sure

the top tether strap is not twisted


the head restraint is installed and
positioned such that the top tether
strap can pass freely between the
head restraint and top of seat back-
rest


top tether strap is positioned be-
tween the seat backrest and the
cargo compartment cover blind (if
installed)


the top tether strap is positioned
between the seat backrest and the
partition net* (if installed)

Lower the head restraint if necessary
(page 129).
Make sure the top tether strap can
pass freely between the head restraint
and top of seat backrest.

Install the child restraint system and
tighten the top tether strap according
to the child restraint manufacturer’s in-
structions.
Blocking of rear door window operation
With the override switch you can disable
the rear side window switches in the rear
door panels.
Warning!
G
After installing top tether straps, make sure
that the seat backrests are in an upright po-
sition and are properly locked. Check for
secure locking by pushing and pulling on the
seat backrests. If a seat backrest is not
properly locked, the seat backrest could
fold. The child seat would no longer be prop-
erly supported or positioned to provide its
intended benefit.
Warning!
G
Activate the override switch when children
are riding in the back seats of the vehicle.
The children could otherwise injure them-
selves, e.g. by becoming trapped in the win-
dow opening.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.

94 Safety and SecurityOccupant safetyThe override switch is located on the
driver’s door control panel.
1Override switch
For more information on power windows,
see “Power windows” (
page 236).Disabling

Press override switch1 until it engag-
es.
The switch engages in the recessed
position.
The rear door windows can no longer
be operated using the switches located
in the rear doors.
Enabling

Press override switch1 once more.
The switch disengages from its
recessed position back to its original
position.
The rear door windows can again be
operated using the switches located in
the rear doors.
i
Operating the rear door windows using the
switches located on the door control panel of the
driver’s door is still possible.

95 Safety and Security
Panic alarm
Panic alarm
1Âbutton
Activating
Press and hold button1 for at least
1 second.
The SmartKey or SmartKey with
KEYLESS-GO* must be within
30 ft (9 m) of the vehicle.
An audible alarm and flashing exterior
lamps will operate briefly.
Deactivating
Press button1 again.
The SmartKey or SmartKey with
KEYLESS-GO* must be within
30 ft (9 m) of the vehicle.
or

Insert SmartKey or the SmartKey with
KEYLESS-GO* in the starter switch.
or

Press the KEYLESS-GO* start/stop
button (
page 41).
The SmartKey with KEYLESS-GO* must
be in the vehicle.
i
USA only:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
Canada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
