39 Getting started
Unlocking
Unlocking with KEYLESS-GO*
With the KEYLESS-GO function, you can
lock or unlock the vehicle without using
the remote control buttons on the
SmartKey and start the engine without in-
serting the SmartKey into the starter
switch.

Grasp an outside door handle or the
tailgate handle.
All turn signal lamps flash once. The ve-
hicle unlocks. The locking knobs in the
doors move up. The anti-theft alarm
system is disarmed. The locator light-
ing comes on if the feature is enabled
in the control system (
page 172).

Enter the vehicle.
For more information, see “SmartKey with
KEYLESS-GO*” (
page 112).
Starter switch positions
i
To unlock the vehicle, the SmartKey with
KEYLESS-GO must be outside the vehicle, no
further than approximately 3 feet (1 meter) away
from the respective door.Warning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO* with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
i
If the vehicle has been parked for more than
72 hours, you must pull an outside door handle
in order to activate the KEYLESS-GO function.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.

108 Controls in detailIn the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed in your vehicle.
If you are already familiar with the basic
functions of your vehicle, this section will
be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are
given at the beginning of each segment.Locking and unlocking
For more information on locking and un-
locking, see the “Getting started” section
(page 38) and (
page 68).
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys are a differ-
ent color to help distinguish each
SmartKey unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks:

the doors


the tailgate


the fuel filler flap
SmartKey with remote control1‹ Lock button
2Š Unlock button* for tailgate
3Locking tab for mechanical key
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 95)

121 Controls in detail
Locking and unlocking
Closing the tailgate
Closing the tailgate from the inside
electrically*
In vehicles with power tailgate* you can
close the tailgate from the inside using the
remote tailgate switch.
Press remote tailgate switch1
(page 120) until tailgate begins to
close.
The tailgate closes. While the tailgate is
closing an acoustic signal sounds. The
indicator lamp in the remote tailgate
switch goes out.
To interrupt the closing procedure:

Press or pull remote tailgate switch1
(page 120).If the tailgate comes into contact with an
object while closing (e.g. luggage that has
been piled too high) the closing procedure
is stopped and the tailgate reopens.
i
You can also close the tailgate manually
(
page 122).
Warning!
G
Maintain sight of the area around the rear of
the vehicle while operating the tailgate with
the door mounted switch. Monitor the
closing procedure carefully to make sure no
one is in danger of being injured.
To interrupt the closing procedure, press or
pull the door mounted remote tailgate
switch.
Even with the SmartKey or the SmartKey
with KEYLESS-GO* removed from the
starter switch or the SmartKey with
KEYLESS-GO* removed from the vehicle,
the remote tailgate switch can be operated.
Therefore, do not leave children unattended
i n t h e v e h i c l e , o r w i t h a c c e s s t o a n u n l o c k e d
vehicle. Unsupervised use of vehicle equip-
ment may cause an accident and/or serious
personal injury.
Warning!
G
Only drive with the tailgate closed as,
among other dangers such as blocked
visibility, exhaust fumes may enter the
vehicle interior.

123 Controls in detail
Locking and unlocking
Closing the tailgate from the outside
(vehicles without KEYLESS-GO*)
In vehicles with power tailgate* you can
close the tailgate from the outside using
the tailgate closing switch or the
Šbutton on the SmartKey.
1Tailgate closing switch
Press tailgate closing switch1 briefly.
The tailgate closes and an acoustic
warning sounds.If the tailgate comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the tailgate reopens.
i
You can also close the tailgate manually
(
page 122).Warning!
G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the cargo compartment opening when clos-
ing the tailgate. Be especially careful when
small children are around. To stop the clos-
ing procedure, do one of the following:

Press tailgate closing switch1.


Press the Šbutton on the SmartKey.


Press or pull the remote tailgate switch
(on the driver’s door).
Even with the SmartKey removed from the
starter switch, the tailgate closing switch
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment may cause
an accident and/or serious personal injury.Warning!
G
Only drive with the tailgate closed as,
among other dangers such as blocked
visibility, exhaust fumes may enter the vehi-
cle interior.i
Do not place the SmartKey in the open
cargo compartment. You may lock yourself out.
i
If the vehicle was previously centrally
locked, the tailgate will lock automatically after
closing it. The turn signals will flash three times
to confirm locking.

317 Controls in detail
Useful features
Programming the integrated remote
control
Step 1:
Switch on the ignition (
page 40).Step 2:

If you have previously programmed a
signal transmitter button and wish to
retain its programming, proceed to
step 3.
If you are programming the integrated
remote control for the first time, press
and hold the two outer signal transmit-
ter buttons2 and4 and release
them only when indicator lamp1
begins to flash after approximately
20 seconds (do not hold the button for
longer than 30 seconds). This proce-
dure erases any previous settings for
all three channels and initializes the
memory.
If you later wish to program a second
and/or third hand-held transmitter to
the remaining two signal transmitter
buttons, do not repeat this step and be-
gin directly with step 3.Step 3:

Hold end of the hand-held remote
control5 of the device you wish to
train approximately 2 to 5 in
(5 to 12 cm) away from the signal
transmitter button (2, 3 or4) to be
programmed, while keeping the indica-
tor lamp1 in view.
Step 4:

Using both hands, simultaneously
press hand-held remote control
button6 and the desired signal trans-
mitter button (2, 3 or4). Do not
release the buttons until step 5 is com-
pleted.
Indicator lamp1 will flash, first slowly
and then rapidly.
When programming a garage door opener,
park the vehicle outside the garage.
Do not run the engine while programming
the integrated remote control. Inhalation of
exhaust gas is hazardous to your health.
All exhaust gas contains carbon monoxide
(CO), and inhaling it can cause unconscious-
ness and possible death.
i
Indicator lamp1 flashes immediately the
first time the signal transmitter button is
programmed. If this button has already been
programmed, the indicator lamp will only start
flashing after 20 seconds.


318 Controls in detailUseful featuresStep 5:
After indicator lamp1 changes from a
slow to a rapidly flashing light, release
the hand-held remote control button
and the signal transmitter button.
Step 6:

Press and hold the just-trained signal
transmitter button (2, 3 or4) and
observe indicator lamp1.
If indicator lamp1 stays on
constantly, programming is complete
and your device should activate when
the respective signal transmitter
button (2, 3 or4) is pressed and re-
leased.Step 7:

To program the remaining two signal
transmitter buttons, repeat the steps
above starting with step 3.
Rolling code programming
To train a garage door opener (or other
rolling code devices) with the rolling code
feature, follow these instructions after
completing the “Programming” portion
(steps 1 through 6) of this text. (A second
person may make the following training
procedures quicker and easier.)
Step 8:

Locate “training” button on the garage
door opener motor head unit.
Exact location and color of the button
may vary by garage door opener brand.
Depending on manufacturer, the
“training” button may also be referred
to as “learn” or “smart” button. If there
is difficulty locating the transmitting
button, refer to the garage door opener
Operator’s Manual.Step 9:

Press the “training” button on the ga-
rage door opener motor head unit.
The “training light” is activated.
You have 30 seconds to initiate the follow-
ing two steps.
Step 10:

Return to the vehicle and firmly press,
hold for 2 seconds and release the pro-
grammed signal transmitter button
(2, 3 or4).
Step 11:

Press, hold for 2 seconds and release
same signal transmitter button a sec-
ond time to complete the training pro-
cess.
i
If indicator lamp1 flashes rapidly for about
2 seconds and then turns to a constant light,
continue with programming steps 8 through 12
as your garage door opener may be equipped
with the “rolling code” feature.
i
Some garage door openers (or other rolling
code equipped devices) may require you to
press, hold for 2 seconds and release the same
signal transmitter button a third time to
complete the training process.


319 Controls in detail
Useful features
Step 12:
Confirm the garage door operation by
pressing the programmed signal trans-
mitter button (2, 3 or4).
Step 13:

To program the remaining two signal
transmitter buttons, repeat the steps
above starting with step 3.
Gate operator/Canadian programming
Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission
which may not be long enough for the
integrated signal transmitter to pick up the
signal during programming. Similar to this
Canadian law, some U.S. gate operators
are designed to “time-out” in the same
manner.
If you live in Canada or if you are having
difficulties programming a gate operator
(regardless of where you live) by using the
programming procedures, replace step 4
with the following:Step 4:

Press and hold the signal transmitter
button (2, 3 or4). Do not release
this button until it has been successful-
ly trained.

While still holding down the signal
transmitter button (2, 3 or4),
“cycle” your hand-held remote control
button6 as follows: Press and hold
button6 for 2 seconds, then release
it for 2 seconds, and again press and
hold it for 2 seconds. Repeat this se-
quence on the hand-held remote con-
trol until the frequency signal has been
learned. Upon successful training,
indicator lamp1 will flash slowly and
then rapidly after several seconds.

Proceed with programming step 5 and
step 6 to complete.Reprogramming a single signal trans-
mitter button
To program a device using a signal trans-
mitter button previously trained, follow
these steps:

Switch on the ignition (
page 40).

Press and hold the desired signal
transmitter button (2, 3 or4).
Do not release the button.

Indicator lamp1 will begin to flash af-
ter 20 seconds. Without releasing the
signal transmitter button, proceed with
programming starting with step 3.
i
Upon completion of programming the inte-
grated remote control, make sure you retain the
hand-held remote control that came with the ga-
rage door opener, gate operator or other device.
You may need it for use in other vehicles, for fu-
ture programming of an integrated remote con-
trol, or simply for continued use as a hand-held
remote control to operate the respective device
in other situations.

557 Index
Cup holders 298
Cleaning 299
Front center console 299
Front center console,
Removing/Installing 299
Rear armrest 299
Curb weight 395
Current transmission program
mode (AMG vehicles only) 147
D
Date display, Setting 169, 170
Daytime running lamp mode 138
Setting 171
Deep water see Standing water
Defogging windshield 213, 227
Defrosting, Front 213, 227
Defrosting, Rear 205
Delayed shut-off
Exterior lamps 172
Interior lighting 173
Department of Transportation see DOT
Diesel engine
Preglow indicator lamp 29Difficulties
While driving 63
While starting 57
Digital clock see Clock
Digital speedometer 147, 155
Dimensions, Vehicle 541
Direction of rotation (tires) 368
Displays
Digital speedometer 147, 155
Distronic* 253
Maintenance service indicator 401
Messages in the
multifunction display 428
Multifunction display 147
Outside temperature 147, 155
Selecting 168
Symbol messages 446
Text messages 430
Vehicle status message 163, 428
Vehicle system settings,
Control system 151, 153, 164
Distance to empty (range), Trip
Computer 180Distronic* 250
Activating 256
Cleaning system sensor 408
Control system 255
Deactivating 259
Distance warning function* 179, 263
Driving hints 261
Messages in the
multifunction display 432
Sensor cover 408
Warning and indicator lamps 253
Door
Entry lamps 144
Locking, In an emergency 476
Locking/unlocking,
KEYLESS-GO* 39, 68
Locking/unlocking, SmartKey 38, 68
Messages in the
multifunction display 455
Opening from inside/outside 109,
118
Remote door unlock (Tele Aid*) 315
Unlocking, Mechanical key 475
