2007 Hyundai Accent Owner's Manual

1
FEATURES OF YOUR HYUNDAI
101
1
FEATURES OF YOUR HYUNDAI
101
1
FEATURES OF YOUR HYUNDAI
101
Face-Level
Selecting the "Face" mode will cause air to be discharged through the facelevel vents.
This is used to select fresh outside airor recirculating inside air.
FreshRecirculation
With the "
" mode selected, air en-
ters the vehicle from outside and is heated or cooled according to the other functions selected. With the "
" mode selected, air from
within the passenger compartment is drawn through the heating system and heated or cooled according to the otherfunctions selected. NOTE: It should be noted that prolonged operation of the heating system in "
" mode will give rise to misting
of the windshield and side windows and the air within the passenger com- partment will become stale. In addi-tion prolonged use of the air condi- tioning with the "
" mode selected
may result in the air within the pas- senger compartment becoming ex- cessively dry. B670D01MC-AAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, instrument panel outlets, or windshield. Five sym-bols are used to represent Face, Bi- Level, Floor, Floor-Defrost and Defrost air position.The MAX A/C mode is used to cool the inside of the vehicle faster (If installed).
B670D02MC
B670D01MC

1FEATURES OF YOUR HYUNDAI
102
Bi-Level
Air is discharged through the face vents and the floor vents. This makes itpossible to have cooler air from the dashboard vents and warmer air from the floor outlets at the same time. Floor-Level
Air is discharged through the floor vents,windshield defroster nozzle, side de-froster nozzle and side ventilator. If the "Floor" mode is selected, the "Fresh" mode will be activated. Floor-Defrost Level
Air is discharged through the wind-shield defroster nozzle, the floor vents,side defroster nozzle and side ventila- tor. If the "Floor-Defrost" mode is selected,the A/C will turn on automatically and "Fresh" mode will be activated.
B670D03MCB670D04MC B670D05MC

1
FEATURES OF YOUR HYUNDAI
103
1
FEATURES OF YOUR HYUNDAI
103
1
FEATURES OF YOUR HYUNDAI
103
Defrost-Level
Air is discharged through the wind- shield defroster nozzle, side defrosternozzle, side ventilator. If the "Defrost" mode is selected, the A/ C will turn on automatically and "Fresh"mode will be activated to improve wind- shield defrosting.
B670D06MC
MAX A/C-Level (If Installed)
Air is discharged through the face level vents. If the "MAX A/C" mode is selected, theA/C will turn on automatically and "Re- circulation" mode will be activated. B670D07MC
* The A/C or the air intake controlswitch returns to its former setting.
A/C
ON
ON or OFF * ON or OFF *
ONON Air Intake
Control Switch
or *
NOTE:
o The air intake control switch will change to "
" mode when the
ignition switch is turned "ON" with the MAX A/C mode selected.
o When you change to another mode
from MAX A/C, the A/C and the airintake control switch are set as shown in the following chart.

1FEATURES OF YOUR HYUNDAI
104HEATING CONTROLS
B690A02A-AAT
B670E02A-AAT Temperature Control This control is used to adjust the degree of heating or cooling desired. For normal heating operation, set the air intake control to the fresh air ( ) position and the air flow control to the floor ( ) position.For faster heating, the air intake con- trol should be set in the recirculate ( ) position.If the windows fog up, set the air flow control to the defrost ( ) position (The air conditioning will be turned on auto-matically) and the air intake control to the fresh air ( ) position. For maximum heat, move the tem-perature control to "Warm".
Cool
Warm
B670E01MC B690A01MC
BI-LEVEL HEATING
B700A02A-AAT
Your Hyundai is equipped with bi-level heating controls. This makes it pos- sible to have cooler air from the dash- board vents and warmer air from thefloor outlets at the same time. To use this feature:
o Set the air intake control to the fresh air ( ) position.
o Set the air flow control at the bi-level
( ) position.
o Adjust the fan speed control to the desired speed.
o Set the temperature control between "Cool" and "Warm".
B700B01MC

1
FEATURES OF YOUR HYUNDAI
105
1
FEATURES OF YOUR HYUNDAI
105
1
FEATURES OF YOUR HYUNDAI
105
To remove the frost or exterior fog on the windshield:
o Set the air flow control to the defrost (
) position. (The A/C will turn on
automatically and "Fresh" mode will be activated.)
o Set the temperature control to warm.
o Set the fan speed control to position "3" or "4".
B720A02MC
DEFROSTING/DEFOGGINGVENTILATION
B720A02FC-GAT Use the heating/ventilation system to defrost or defog the windshield: To remove interior fog on the windshield:
o Set the air flow control to the defrost(
) position. (The A/C will turn on
automatically and "Fresh" mode will be activated.)
o Set the temperature control to the desired position.
o Set the fan speed control between "1" and "4" position.
B710A01A-AAT
To operate the ventilation system:
o Set the air intake control to "Fresh"
mode ( ).
o To direct all intake air to the dash- board vents, set the air flow control to the (
) position.
o Adjust the fan speed control to the desired speed.
o Set the temperature control between "Cool" and "Warm".
B710A02MC B720A01MC

1FEATURES OF YOUR HYUNDAI
106
B730A01L-AAT Operation Tips
o To keep dust or unpleasant fumesfrom entering the car through the ventilation system, temporarily set the air intake control at the (
)
position. Be sure to return the control to the (
) position when the
irritation has passed to keep fresh air in the vehicle. This will help keep thedriver alert and comfortable.
o Air for the heating/cooling system is
drawn in through the grilles justahead of the windshield. Care should be taken that these are not blocked by leaves, snow, ice or other ob-structions.
o To prevent interior fog on the wind-
shield, set the air intake control tothe fresh air (
) position, fan
speed to the desired position, turn on the air conditioning system, and ad-just temperature control to desired temperature.
NOTE: When the A/C is operated continu- ously on the floor-defrost level ( ) or defrost level ( ), it may causefog to form on the exterior wind- shield. If this occurs, set the air flow control to the face level posi-tion ( ) and fan speed control to the low position.
AIR CONDITIONING SYSTEM
B740A01MC
B740A01A-AAT (If Installed) Air Conditioning Switch
The air conditioning is turned on by pushing the A/C button on the heating/ air conditioning control panel.

1
FEATURES OF YOUR HYUNDAI
107
1
FEATURES OF YOUR HYUNDAI
107
1
FEATURES OF YOUR HYUNDAI
107
For dehumidified heating:
o Turn on the fan control switch.
o Turn on the air conditioning switch. The air conditioning indicator light should come on at the same time.
o Set the air intake control switch to the fresh air (
) position.
o Set the air flow control to the face
(
) position.
o Adjust the fan control to the desired speed.
o For more rapid action, set the fan at one of the higher speeds.
o Adjust the temperature control to
provide the desired amount of warmth.
B740B02A-AAT Air Conditioning Operation (Cooling)
B740C01A-AAT De-Humidified Heating
To use the air conditioning to cool the interior:
o Turn on the fan control switch.
o Push the air conditioning switch by pushing in on the switch.The air conditioning indicator lightshould come on at the same time.
o Set the air intake control to the
(
)position.
o Set the temperature control to "Cool". ("Cool" provides maximum cooling. The temperature may be moderatedby moving the control toward "Warm".) o Adjust the fan control to the desired
speed. For greater cooling, turn the fan control to one of the higher speeds or temporarily select the (
)posi-
tion on the air intake control.
B740B01MC
B740C01MC

1FEATURES OF YOUR HYUNDAI
108
B740D01A-AAT Operation Tips
o If the interior of the car is hot whenyou first get in, open the windows for a few minutes to expel the hot air.
o When you are using the air condi-
tioning system, keep all windowsclosed to keep hot air out.
o When moving slowly, as in heavy
traffic, shift to a lower gear.This increases engine speed, which in turn increases the speed of the air conditioning compressor.
o On steep grades, turn the air condi- tioning off to avoid the possibility ofthe engine overheating.
o During winter months or in periods when the air conditioning is not usedregularly, run the air conditioningonce every month for a few min- utes. This will help circulate the lubricantsand keep your system in peak oper- ating condition.
