2007 CHEVROLET IMPALA Owners Manual

Front Seats
Manual Passenger Seat
Your vehicle may have a manual passenger seat.
Lift the bar located under the front of the seat to
unlock it. Slide the seat to where you want it
and release the bar. Try to move the seat with your
body to be sure the seat is locked in place.
Power Seats
If the vehicle has power seats, the controls used to
operate them are located on the outboard side of the
seats. To adjust the seat, do any of the following:
Move the seat forward or rearward by sliding
the control forward or rearward.
Raise or lower the front part of the seat cushion
by moving the front of the control up or down.
Raise or lower the rear part of the seat cushion
by moving the rear of the control up or down.
Driver’s Seat with Manual Lumbar,
Power Seat Control, and Power Recline shown
9

Your driver’s seat may have power reclining
seatbacks. See “Power Reclining Seatbacks”
underReclining Seatbacks on page 11for
more information.
Manual Lumbar
If your vehicle has manual lumbar, the lever is
located on the outboard side of the driver’s
seat near the front of the seat cushion.Lift up on the lever repeatedly to increase lumbar
support. Push down on the lever repeatedly to
decrease lumbar support.
Heated Seats
If your vehicle has this
feature, the buttons that
control temperature for
the driver’s and front
passenger’s seats are
located on the climate
control panel. See
Climate Control System
on page 168.
Press the button once to warm the seat to a high
temperature. Both lights below the heated seat
symbol will come on. Press the button a second
time to reduce the seat to a lower temperature. The
bottom light will be lit. Press the button a third time
to turn the heated seat off.
The heated seat feature will need to be turned
on each time the ignition is turned off and back
on again.
Driver’s Seat with Manual Lumbar and
8-way Power Controls shown
10

Reclining Seatbacks
Manual Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if
you try to adjust a manual driver’s seat
while the vehicle is moving. The sudden
movement could startle and confuse you,
or make you push a pedal when you do
not want to. Adjust the driver’s seat only
when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on
the seatback to be sure it is locked.Your vehicle may have a manual recline function
on the front passenger’s seat. There may be
manual recline on the driver’s seat.
To recline the seatback, do the following:
1. Lift the recline lever.
2. Move the seatback to the desired position,
then release the lever to lock the seatback
in place.
3. Push and pull on the seatback to make
sure it is locked.
Passenger’s Seat with Manual Recline and
Power Seat Control shown
11

To return the seatback to an upright position,
do the following:
1. Lift the lever fully without applying pressure
to the seatback and the seatback will return
to the upright position.
2. Push and pull on the seatback to make
sure it is locked.
Power Reclining Seatback
The driver’s seat may have a power reclining
seatback. The control used to operate it is located
on the outboard side of the seat cushion rear of
the horizontal power seat control.
Press control rearward to recline the seatback.
Press control forward to raise the seatback.
Driver’s Seat with Manual Lumbar,
Power Seat Control, and Power Recline shown
12

{CAUTION:
Sitting in a reclined position when your
vehicle is in motion can be dangerous.
Even if you buckle up, your safety belts
cannot do their job when you are reclined
like this.
The shoulder belt cannot do its job
because it will not be against your body.
Instead, it will be in front of you. In a
crash, you could go into it, receiving neck
or other injuries.
The lap belt cannot do its job either. In a
crash, the belt could go up over your
abdomen. The belt forces would be there,
not at your pelvic bones. This could cause
serious internal injuries.
For proper protection when the vehicle is
in motion, have the seatback upright.
Then sit well back in the seat and wear
your safety belt properly.
Do not have a seatback reclined if your vehicle
is moving.
Head Restraints
Adjust the head restraint so that the top of the
restraint is at the same height as the top of
the occupant’s head. This position reduces the
chance of a neck injury in a crash.
13

Pull the head restraint
up to raise it. To lower
the head restraint,
press the button,
located on the top of the
seatback, and push
the restraint down.Center Seat
Your vehicle may have a front center seat. There
are cupholders on the underside of the seat
cushion. To use them, ip the seat cushion
forward. This seat can also be used as a storage
area by lowering the seatback. SeeCenter
Console Storage Area on page 144. The seatback
doubles as an armrest for the driver or front
passenger when the center seat is unoccupied.
For information on safety belts for this position,
seeCenter Front Passenger Position on page 34.
14

Rear Seats
Split Folding Rear Seat
Flip and Fold Feature
If your vehicle has this feature, you can ip the
bottom seat cushion(s) forward and fold the
seatback(s) down for an extended at cargo area.
To use this feature, do the following:
Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
1. Disconnect the rear
center safety belt
latch from the
mini buckle, if your
vehicle has this,
by using an object
such as a car key.Insert the key into the slot in the mini buckle
and press the release button.
2. Flip the bottom seat cushion forward by
pulling up on the tab located in the center
of the seat cushion where the seatback meets
the seat cushion. There is a tab on both
rear seats.
Make sure the front seats are not reclined.
If they are, the seat cushion will not ip
forward completely.
15

3. Lower the
seatback(s) by
pulling forward on
the tab located
on the outboard side
of the seatback(s).
Make sure the front seats are not reclined.
If they are, the rear seatbacks will not
fold down all the way.To return the seats to the normal position, do the
following:
{CAUTION:
If the seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on the
seatback to be sure it is locked.
1. Raise the seatback up and make sure it
latches.
16
