2007 BMW MOTORRAD K 1200 S Rider's Manual (in English)

Front, Michelin, Pilot Power B, 120/70 ZR17 M/C
(58W)
Rear, Michelin, Pilot Power P, 190/50 ZR17 M/C
(73W)
Front, Michelin, Pilot Road TL, 120/70 ZR17 M/C
(58W)
Rear, Michelin, Pilot Road R TL, 190/50 ZR17 M/
C (73W)
Front, Pirelli, Diabolo E TL, 120/70 ZR17 M/C
(58W)
Rear, Pirelli, Diabolo E TL, 190/50 ZR17 M/C
(73W)
Front wheel
Front wheel, type Cast aluminium, MT H2
Front wheel rim size 3.50" x 17"
Tyre designation, front 120/70 ZR 17
Rear wheel
Rear wheel type Cast aluminium, MT H2
Rear wheel rim size 6.00" x 17"
Tyre designation, rear 190/50 ZR17
10143zTechnical data

Tyre pressure
Tyre pressure, front 2.5 bar, one-up, tyre cold2.5 bar, two-up and/or with luggage, tyre cold
Tyre pressure, rear 2.9 bar, one-up, tyre cold 2.9 bar, two-up and/or with luggage, tyre coldElectricsElectrical rating of on-board socketmax 5 A
Fuses All circuits are electronically protected, so plug-
in fuses are no longer necessary. If an electronic
fuse trips and de-energises a circuit, the circuit is
active as soon as the ignition is switched on after
the fault has been rectified.
Battery
Battery, manufacturer and designation Yuasa YTX 14 BS
Battery type AGM (Absorptive Glass Mat) battery
Battery rated voltage 12 V
Battery rated capacity 14 Ah
Technical data
Spark plugs, manufacturer and designation NGK KR9CI
Electrode gap of spark plug 0.8 mm, When new
10144zTechnical data

Lighting
Bulb for high-beam headlight H7 / 12 V / 55 W
Bulb for low-beam headlight H7 / 12 V / 55 W
Bulb for parking light W5W / 12 V / 5 W
Bulb for tail light/brake light P21W / 12 V / 21 W
Bulbs for flashing turn indicators, front W16W / 12 V / 16 W
Bulbs for flashing turn indicators, rear R10W / 12 V / 10 WFrameFrame typeLight alloy weldment with bolt-on tubular steel
rear frame
Type plate location Frame cross-tube, rear
VIN location Frame side section, front right
10145zTechnical data

DimensionsLength of motorcycle2182 mm
Height of motorcycle 1211 mm, At DIN unladen weight
Width of motorcycle 905 mm, Across mirrors
Front-seat height 820 mm, Without rider
with OE Front seat, low: 790 mm, Without riderWeightsUnladen weight 248 kg, DIN unladen weight, ready for road, 90 %
load of fuel, without optional extras
Permissible gross weight 450 kg
Maximum payload 202 kg
10146zTechnical data

Riding specificationsTop speed>200 km/h
10147zTechnical data

10148zTechnical data

Service
Service
BMW Motorrad service . ........... 150
BMW Motorrad service quality ..... 150
BMW Motorrad Service Card: on-
the-spot breakdown assistance .... 150
BMW Motorrad service network . . . 151
Maintenance work ................. 151
Confirmation of maintenance
work ............................... 152
Confirmation of service . . .......... 157
11149zService

BMW Motorrad serviceAdvanced technology requires
specially adapted methods of
maintenance and repair.If maintenance and re-
pair work is performed in-
expertly, it could result in con-
sequential damage and thus con-
stitute a safety risk.
BMW Motorrad recommends you
to have all the associated work
on your motorcycle carried out
by a specialist workshop, prefer-
ably an authorised BMW Motor-
rad dealer.
Your authorised BMW Motorrad
dealer can provide information on
BMW services and the work un-
dertaken as part of each service.
Have all maintenance and repair
work carried out confirmed in the
"Service" chapter in this manual.
Authorised BMW Motorrad deal-
ers are supplied with the latest
technical information and have the necessary technical know-
how. BMW Motorrad recom-
mends that you contact your au-
thorised BMW Motorrad dealer
if you have questions regarding
your motorcycle.
BMW Motorrad service
qualityAlong with its reputation for en-
gineering quality and high reliab-
ility, BMW Motorrad is a byword
for excellent quality of service.
To ensure that your BMW is al-
ways in optimum condition, BMW
Motorrad recommends that you
have the maintenance work re-
quired for your motorcycle car-
ried out regularly, preferably by
your authorised BMW Motor-
rad dealer. For generous treat-
ment of claims submitted after
the warranty period has expired,
evidence of regular maintenance
is essential.
Certain signs of wear, moreover,
may otherwise not be noticed
until it is too late to put them
right at moderate cost. Your au-
thorised BMW Motorrad dealer's
mechanics know every detail of
your motorcycle and can take re-
medial action if necessary before
minor faults develop into serious
problems. By having the neces-
sary repairs done properly and
in good time, you save time and
money in the long run.
BMW Motorrad Service
Card: on-the-spot
breakdown assistanceIn the event of a breakdown, the
BMW Motorrad Service Card is-
sued with each new BMW mo-
torcycle enables you to access
an extensive range of services
such as breakdown assistance,
motorcycle transportation etc.
(details can differ from country to
country). In the event of a break-
