2006 TOYOTA RAV4 injector

2AZ-FE FUEL – FUEL INJECTORFU–11
FU
(c) Remove the 2 bolts, then remove the fuel delivery
pipe together with the 4 fuel injectors.
NOTICE:
Be careful not to drop the fuel injectors when
removing the fuel delivery pipe.
(d) Remove the 2 delivery pipe spacers from the
cylinder head.
(e) Remove the 4 insulators from the cylinder head.
8. REMOVE FUEL INJECTOR ASSEMBLY
(a) Pull the 4 fuel injectors out of the fuel delivery pipe.
INSPECTION
1. INSPECT FUEL INJECTOR ASSEMBLY
(a) Measure the resistance between the injector
terminals.
Standard resistance:
11.6 to 12.4
at 20C (68F)
If the result is not as specified, replace the injector.
(b) Inspect the injector injection.
CAUTION:
Keep the injector away from sparks during the
test.
(1) Connect SST (fuel tube connector) to SST
(hose), then connect them to the fuel pipe
(vehicle side).
SST 09268-31011 (09268-41500, 90467-
13001, 95336-08070)
(2) Install the O-ring to the fuel injector.
A125334
A125335
A097399E02
A116182
A088382E01

FU–122AZ-FE FUEL – FUEL INJECTOR
FU
(3) Connect SST (adapter and hose) to the
injector, and hold the injector and union with
SST (clamp).
SST 09268-31011 (09268-41110, 09268-
41130, 09268-41310)
(4) Put the injector into the graduated cylinder.
CAUTION:
Install a suitable vinyl tube onto the injector
to contain gasoline spray.
(5) Operate the fuel pump.
(6) Connect SST (wire) to the injector and the
battery for 15 seconds, and measure the
injection volume with the graduated cylinder.
Test each injector 2 or 3 times.
SST 09842-30080
Standard injection volume:
76 to 92 cm
3 (4.6 to 5.6 cu in.) per 15
seconds
Standard difference between each injector:
16 cm
3 (1.0 cu in.) or less
(c) Inspect the fuel leakage.
(1) Disconnect the SST (wire) tester probes from
the battery and check the fuel leakage from the
injector.
Standard fuel drop:
1 drop or less per 12 minutes
(2) Turn the ignition switch OFF.
(3) Disconnect the cable from the negative (-)
battery terminal.
(4) Remove SST.
SST 09842-30080
(5) Disconnect the intelligent tester from the DLC3.
(6) Reconnect the fuel inlet hose (rear fuel pipe) to
the fuel main tube.
INSTALLATION
1. INSTALL FUEL INJECTOR ASSEMBLY
(a) Apply a light coat of gasoline or spindle oil to new O-
rings, then install one onto each fuel injector.
A116183E02
A075915E04
A116184
A097400E02

2AZ-FE FUEL – FUEL INJECTORFU–13
FU
(b) Apply a light coat of gasoline or spindle oil to the
part of the fuel delivery pipe which comes into
contact with the O-ring of the fuel injector.
(c) Apply a light coat of gasoline or spindle oil to the O-
ring again, then install the right and left fuel injectors
onto the fuel delivery pipe.
NOTICE:
Make sure that the O-ring is not cracked or
jammed when installing.
(d) Check that the fuel injector rotates smoothly. If the
fuel injector does not rotate, replace the O-ring.
2. INSTALL FUEL DELIVERY PIPE SUB-ASSEMBLY
(a) Install 4 new insulators into the cylinder head.
(b) Install the 2 delivery pipe spacers onto the cylinder
head.
(c) Install the fuel delivery pipe together with the 4 fuel
injectors, then temporarily tighten the 2 bolts.
NOTICE:
Be careful not to drop the fuel injectors when
installing the fuel delivery pipe.
(d) Check that the fuel injector rotates smoothly.
If the fuel injector does not rotate, replace the O-
ring.
(e) Tighten the 2 bolts to the specified torque.
Torque: 20 N*m (205 kgf*cm, 15 ft.*lbf)
A131629E01
A125335
A097444E02
A125334

FU–142AZ-FE FUEL – FUEL INJECTOR
FU
(f) Connect the 4 fuel injector connectors.
(g) Install the 2 wire harness clamps.
3. CONNECT NO. 2 VENTILATION HOSE
(a) Connect the ventilation hose to the ventilation valve.
NOTICE:
Make sure that the paint mark and hose clamp
are at the correct angle when installing the hose.
4. CONNECT FUEL MAIN TUBE
(a) Connect the fuel main tube.
(b) Push the fuel tube connector until it makes a "click"
sound.
(c) Install the fuel pipe clamp.
(d) Install the fuel tube to the fuel hose clamp.
5. INSTALL AIR CLEANER CAP SUB-ASSEMBLY (See
page ES-413)
6. INSTALL NO. 1 ENGINE COVER (See page ES-414)
7. CONNECT CABLE TO BATTERY NEGATIVE
TERMINAL
8. CHECK FOR FUEL LEAKAGE
(a) Make sure that there are no fuel leaks after
performing maintenance on the fuel system.
(1) Connect the intelligent tester to the DLC3.
(2) Turn the ignition switch ON, and push the
intelligent tester main switch ON.
NOTICE:
Do not start the engine.
(3) Select the Active Test mode on the intelligent
tester.
HINT:
Refer to the intelligent tester operator's manual
for further details.
(4) Check that there are no leaks from the fuel
system.
(5) Turn the ignition switch OFF.
(6) Disconnect the intelligent tester from the DLC3.
A125333
A095428E02
B127990E01

2GR-FE FUEL – FUEL SYSTEMFU–9
FU
ON-VEHICLE INSPECTION
1. CHECK FUEL PUMP OPERATION
(a) Connect the intelligent tester to the DLC3.
(b) Turn the ignition switch ON.
NOTICE:
Do not start the engine.
(c) Select the following tester menus: DIAGNOSIS,
ENHANCED OBD II, ACTIVE TEST and FUEL
PUMP/SPD. Operate the fuel pump.
(d) Touch the fuel hose in the engine compartment to
check the fuel flow, and you will be able to hear the
sound of the fuel pump.
(e) Stop the fuel pump. If there is no fuel flow, the fuel
pump may not be operating. Check the fuel pump
circuit.
2. CHECK FUEL PRESSURE
(a) Check that the battery positive voltage is above 12
V.
(b) Perform the "DISCHARGE FUEL SYSTEM
PRESSURE" procedures (see page FU-1).
(c) Disconnect the cable from the negative (-) battery
terminal.
(d) Disconnect the fuel main tube (see page FU-22).
(e) Install SST (pressure gauge) using SST and a fuel
tube connector as shown in the illustration.
SST 09268-41048 (90467-13001, 95336-08070,
09268-41500), 09268-45014 (09268-41200,
09268-41220, 09268-41250)
(f) Wipe up any gasoline.
(g) Reconnect the cable to the negative (-) battery
terminal.
(h) Start the engine.
(i) Measure the fuel pressure at idle.
Standard fuel pressure:
304 to 343 kPa (3.1 to 3.5 kgf/cm
2,44.1 to 49.7
psi)
• If the fuel pressure is greater than the standard
value, replace the fuel pump.
• If the fuel pressure is less than the standard
value, check the connection of the fuel hose and
the fuel pump.
(j) Stop the engine.
(k) Check that the fuel pressure remains as specified
for 5 minutes after the engine stops.
Standard fuel pressure:
147 kPa (1.5 kgf/cm
2, 21 psi) or more
If the fuel pressure is not as specified, check the fuel
pump or fuel injector.
(l) After checking the fuel pressure, carefully
disconnect the negative (-) battery cable, and
remove SST and fuel tube connector to prevent
gasoline from splashing.
(m) Reconnect the fuel main tube (see page FU-29).
B127989E01
A129461E01

2GR-FE FUEL – FUEL INJECTORFU–13
FU
REMOVAL
CAUTION:
Do not allow fuel to spray when removing the pipe
between the high pressure side fuel pump and the fuel
injector. The fuel in the pipe is highly pressurized.
1. DISCHARGE FUEL SYSTEM PRESSURE
CAUTION:
• The "DISCHARGE FUEL SYSTEM PRESSURE"
procedures must be performed before
disconnecting any part of the fuel system.
• After performing the "DISCHARGE FUEL SYSTEM
PRESSURE" procedures, pressure will remain in
the fuel line. When disconnecting the fuel line,
place a cloth or equivalent over fittings to reduce
the risk of fuel spray.
(a) Remove the console box (see page IP-16).
(b) Start the engine. After the engine has stopped, turn
the ignition switch OFF.
HINT:
DTC P0171/P0172 (system too lean) may be set.
(c) Check that the engine does not start.
(d) Remove the fuel tank cap, and let the air out of the
fuel tank.
(e) Connect the connector.
(f) Install the console box (see page IP-23).
2. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the
cable from the negative (-) battery terminal to
prevent airbag and seat belt pretensioner activation.
3. REMOVE ENGINE ASSEMBLY
(a) Remove the engine (see page EM-21).
4. REMOVE INTAKE AIR SURGE TANK ASSEMBLY
(See page EM-27)
5. DISCONNECT FUEL MAIN TUBE
(a) Remove the No. 2 fuel pipe clamp.
A128750E01
A128750E01
A134142E01

FU–142GR-FE FUEL – FUEL INJECTOR
FU
(b) Pinch the tube connector and then pull out the fuel
pipe.
NOTICE:
• Check for foreign matter in the fuel tube
around the fuel tube's connector. Clean it if
necessary. Foreign matter can affect the O-
ring's ability to seal the connector and fuel
main pipe.
• Do not use any tools to separate the
connector and pipe.
• Do not forcefully bend or twist the hose.
• Keep the connector and pipe free from
foreign matter.
• If the connector and pipe are stuck together,
pinch the connector and turn it carefully to
disconnect it.
• Put the connector in a plastic bag to prevent
damage and contamination.
6. REMOVE FUEL INJECTOR ASSEMBLY
(a) Disconnect the 6 injector connectors.
(b) Remove the 5 bolts and fuel delivery pipe together
with the 6 injectors.
NOTICE:
Be careful not to drop the fuel injectors when
removing the fuel delivery pipe.
(c) Remove the 6 insulators from the intake manifold.
A110596E01
A134143
A134144
A134145

2GR-FE FUEL – FUEL INJECTORFU–15
FU
(d) Pull out the 6 fuel injectors from the fuel delivery
pipe.
(e) Remove the O-ring from each fuel injector.
A134146
