2006 TOYOTA RAV4 Ws atf

U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–209
AX
44. INSTALL MANUAL VALVE LEVER SHAFT OIL SEAL
(a) Coat a new oil seal with ATF, and install it to the
transaxle.
(b) Install the oil seal to the transaxle.
45. INSTALL PARKING LOCK ROD SUB-ASSEMBLY
(a) Install the parking lock rod to the manual valve lever.
46. INSTALL MANUAL VALVE LEVER SUB-ASSEMBLY
(a) Install a new spacer and manual valve lever shaft to
the transaxle.
(b) Using a pin punch and hammer, tap in a new pin.
(c) Turn the spacer and lever shaft to align the small
hole for locating the staking position in the spacer
with the staking position mark on the lever shaft.
(d) Using a pin punch, stake the spacer through the
small hole.
(e) Check that the spacer does not turn.
D003632E01
D003905E01
D003565E02
D003564E01
D003930E01

AX–210U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
47. INSTALL MANUAL VALVE LEVER SHAFT RETAINER
SPRING
(a) Using needle-nose pliers, install the retainer spring.
48. INSTALL PARKING LOCK PAWL BRACKET
(a) Install the parking lock pawl bracket with the 2 bolts.
Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf)
Bolt length:
25 mm (0.984 in.)
49. INSTALL MANUAL DETENT SPRING SUB-
ASSEMBLY
(a) Install the manual detent spring with the 2 bolts.
NOTICE:
Make sure to install the manual detent spring
and cover in this order.
Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) for bolt A
12 N*m (122 kgf*cm, 9 ft.*lbf) for bolt B
HINT:
Each bolt length is indicated below.
Bolt length:
27 mm (1.063 in.) for bolt A
16 mm (0.630 in.) for bolt B
50. INSTALL B-3 ACCUMULATOR PISTON
(a) Coat a new O-ring with ATF, and install it to the B-3
accumulator piston.
D003559E01
D003561E02
D003560E01
D003904E05

U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–211
AX
(b) Coat the accumulator B-3 piston and spring with
ATF, and install them to the transaxle.
Standard accumulator spring
51. INSTALL C-1 ACCUMULATOR PISTON
(a) Coat 2 new O-rings with ATF, and install them to the
C-1 accumulator piston.
(b) Coat the accumulator C-1 piston with ATF, and
install it to the transaxle.
Standard accumulator spring
52. INSTALL C-3 ACCUMULATOR PISTON
(a) Coat a new O-ring with ATF, and install it to the C-3
accumulator piston.
(b) Coat the C-3 accumulator piston with ATF, and
install it to the transaxle.
D025512E02
Spring Free length
Outer diameterColor
B-3 Inner 60.24 mm (2.3716 in.)
15.9 mm (0.626)Yellowish green
B-3 Outer 74.61 mm (2.9374 in.)
21.7 mm (0.854 in.)Blue
D003903E01
D003557E02
Spring Free length
Outer diameterColor
C-1 81.53 mm (3.2098 in.)
18.5 mm (0.728 in.)Pink
D003902E02
C083146E01

AX–212U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
(c) Install the compression spring from the C-3
accumulator piston.
53. INSTALL CHECK BALL BODY
(a) Install the check ball body and spring.
54. INSTALL TRANSMISSION WIRE
(a) Coat a new O-ring with ATF, and install it to the
transaxle solenoid wire.
(b) Install the solenoid wire retaining bolt.
Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
55. INSTALL BRAKE DRUM GASKET
(a) Coat a new brake drum gasket with ATF, and install
it to the transaxle.
D003555E01
D003554E02
C050156E01
C050009E01
C083129E01

U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–213
AX
56. INSTALL TRANSAXLE CASE 2ND BRAKE GASKET
(a) Coat a new transaxle case 2nd brake gasket with
ATF, and install it to the transaxle.
57. INSTALL NO. 1 GOVERNOR APPLY GASKET
(a) Coat a new governor apply gasket No. 1 with ATF,
and install it to the transaxle.
58. INSTALL TRANSMISSION VALVE BODY ASSEMBLY
(a) Make sure that the manual valve lever position,
install the valve body with the 17 bolts to the
transaxle.
Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
HINT:
Each bolt length is indicated below.
Bolt length:
25 mm (0.984 in.) for bolt A
41 mm (1.614 in.) for bolt B
45 mm (1.771 in.) for bolt C
NOTICE:
• Push the valve body against the accumulator
piston spring and the check ball body to
install it.
• When installing the valve body to the
transaxle case, do not hold the solenoids.
• Tighten the bolts marked by * in the
illustration first temporarily because they are
positioning bolts.
(b) Connect the 5 solenoid connectors.
(c) Install the ATF temperature sensor, clamp and bolt.
Torque: 6.6 N*m (67 kgf*cm, 58 in.*lbf)
C083128E01
C083127E01
D003553E09
D025591E01

AX–214U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
59. INSTALL VALVE BODY OIL STRAINER ASSEMBLY
(a) Coat a new O-ring with ATF, and install it to the oil
strainer.
(b) Install the oil strainer and 3 bolts to the valve body.
Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
60. INSTALL AUTOMATIC TRANSAXLE OIL PAN SUB-
ASSEMBLY
(a) Install the 3 magnets in the oil pan.
(b) Install a new oil pan gasket to the oil pan.
(c) Install the oil pan to the transaxle with the 18 bolts.
Torque: 7.6 N*m (77 kgf*cm, 67 in.*lbf)
NOTICE:
Because the bolts are seal bolts, apply seal
packing to new bolts and tighten them within 10
minutes after application.
61. INSTALL SPEED SENSOR
(a) Coat 2 new O-rings with ATF, and install them to the
2 sensors.
(b) Install the 2 sensors with the 2 bolts to the transaxle.
Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
D009180E01
D009179E01
C134981E01
D009176E02
D003900E01

U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–215
AX
62. INSTALL OIL COOLER INLET TUBE UNION
(a) Coat a new O-ring with ATF, and install it to the
union.
(b) Install the union to the transaxle.
Torque: 27 N*m (276 kgf*cm, 20 ft.*lbf)
63. INSTALL OIL COOLER OUTLET TUBE UNION
(a) Coat a new O-ring with ATF, and install it to the
union.
(b) Install the union to the transaxle case.
Torque: 25 N*m (255 kgf*cm, 18 ft.*lbf)
64. INSTALL NO. 1 TRANSAXLE CASE PLUG
(a) Coat 4 new O-rings with ATF, and install them to the
4 plugs.
(b) Install the 4 plugs to the transaxle.
Torque: 7.4 N*m (75 kgf*cm, 65 in.*lbf)
65. INSTALL BREATHER PLUG HOSE
(a) Install the breather plug hose to the breather plug.
66. INSTALL PARK/NEUTRAL POSITION SWITCH
ASSEMBLY
(a) Install the park/neutral position switch onto the
manual valve lever shaft and temporarily install the
2 adjusting bolts.
(b) Install a new lock plate and the nut.
Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
(c) Temporarily install the control shaft lever.
C127450
C127449
C134982
D008034E02
D008093E01

AX–216U241E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
(d) Turn the lever counterclockwise until it stops, and
then turn it clockwise 2 notches.
(e) Remove the control shaft lever.
(f) Align the groove with neutral basic line.
(g) Tighten the 2 bolts.
Torque: 6.9 N*m (70 kgf*cm, 61 in.*lbf)
(h) Using a screwdriver, stake the nut with the lock
plate.
(i) Install the control shaft lever, washer and nut.
Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf)
67. INSTALL SPEEDOMETER DRIVEN HOLE COVER
SUB-ASSEMBLY
(a) Coat a new O-ring with ATF and install it to the hole
cover.
(b) Install the hole cover to the transaxle with the bolt.
D008094E01
D009642E01
D008033E01
D008032E01
