2006 TOYOTA PRIUS key

142
INFORMATION
You can insert a genuine key while in
the “IGON” mode or with the hybrid
system starting. Do not insert any key
other than genuine keys.
25p103a
Without depressing the brake pedal
Each time you press the “POWER”
switch briefly without the brake pedal
depressed, the hybrid system mode
changes in the order of “OFF”, “ACC”,
“IGON” and then back to “OFF”.
1) “ACC” (Green indicator is turned on)
Accessories such as the radio operate.
Pressing the “POWER” switch briefly with-
out depressing the brake pedal in the
“OFF” mode turns on this mode.
The key can be removed at this position.
The hybrid system is automatically turned
off.In the “ACC” mode, pressing the “POW-
ER” switch briefly while depressing the
brake pedal will start the hybrid system.
If you leave your vehicle in the “ACC”
mode for about an hour, the hybrid system
is automatically turned off.
2) “IGON” (Amber indicator is turned
on)
All accessories are operable.
Pressing the “POWER” switch briefly with-
out depressing the brake pedal in the
“ACC” mode turns on this mode.
In the “IG
−ON” mode, pressing the
“POWER” switch briefly while depressing
the brake pedal will start the hybrid sys-
tem. However, if “N” position is selected,
the hybrid system will be turned in the
“OFF” mode.
3) “OFF” (Indicator is turned off)
The hybrid system is off. The key can
be removed at this position.
You may hear a motor sound in the en-
gine compartment for a few seconds after
the system is turned off and about 90
seconds have passed.
Once you remove the key, the hybrid ve-
hicle immobilizer system is automatically
set. See “Hybrid vehicle immobilizer sys-
tem” on page 21.
—Selecting the push button
start system mode
(without smart function)

143
25p104a
With the brake pedal depressed
The hybrid system will start and stop
by pressing the “POWER” switch briefly
with the brake pedal depressed.
You may hear a motor sound in the en-
gine compartment when the brake pedal is
depressed with the hybrid system off.
1) “START” (Amber indicator comes on
for a few seconds.)
The hybrid system is ready to operate
and all accessories are operable. (“IG
ON”)
Insert the key and press the “POWER”
switch briefly with the brake pedal de-
pressed.For starting tips, see “How to start the
hybrid system—” on page 348.
If, in an emergency, you must turn the
hybrid system off while the vehicle is
moving, press the “POWER” switch more
than 3 seconds. At this time, the “ACC”
mode and shift position “N” are automati-
cally enabled.
2) “OFF” (Indicator is turned off)
The hybrid system is off. The key can
be removed at this position.
You may hear a motor sound in the en-
gine compartment for a few seconds after
the system is turned off and about 90
seconds have passed.
Once you remove the key, the hybrid ve-
hicle immobilizer system is automatically
set. See “Hybrid vehicle immobilizer sys-
tem” on page 21.
Approximately 5 hours after the engine is
turned off, you may hear a sound coming
from underneath the luggage compartment
for several minutes. This is normal opera-
tion and does not indicate a malfunction.
(See “Leak detection pump” on page 448.)
NOTICE

The hybrid system cannot be
started when the shift position is in
“N”. Be sure to put it in “P” and
then start the system.
 Do not leave the hybrid system in
“ACC” or “IGON” for a long time.
The 12 volt battery will discharge.
 The hybrid mode in which the bat-
tery is discharged or disconnected
is retained in memory, and that
mode is turned on when power is
applied.

177
27p185
6. When this screen is displayed, inputthe Passkey displayed on the screen
into the phone.
For the operation of the phone, see the
manual that comes with your cellular
phone.
If you want to cancel it, touch “Cancel”.
27p186
7. When the connection is completed, this screen is displayed.
You do not need to enter the phone in
case of using the same one.
27p187
When this screen is displayed, follow the
guidance on the screen to try again.

179
27p191
When the connection is completed, this
screen is displayed.
Now you can use the Bluetooth phone.
Reconnecting the Bluetooth phone
If the Bluetooth phone is disconnected
with a poor reception from the Blue-
tooth network when the “ACC” or “IG
ON” mode is enabled, the system auto-
matically reconnects the Bluetooth
phone. In this case, the connection
result is not displayed.
If the Bluetooth is disconnected on pur-
pose such as you turned your cellular
phone off, this does not happen. Recon-
nect it by the following methods.
Select the Bluetooth phone again.
Enter the Bluetooth phone.
(b)Calling on the Bluetooth phone
After you enter the Bluetooth phone,
you can call by using handsfree sys-
tem. You can call using the 7 methods
described below.
(i) By dial
You can call by inputting the telephone
number.
This cannot be operated while you are
driving.
27p192
Touch the desired key to input the tele-
phone number.

180
Each time you touch “ ”, an inputted
digit is deleted.
When you touch “
”, the number you
called last is inputted.
Touch “
” or push the button of the
steering wheel.
(ii) By phone book
You can call by phone book data which
is transferred from your cellular phone.
The system has one phone book. You
can register up to 1000 numbers.
This cannot be operated while you are
driving.
27p193
Touch the desired key to input the tele-
phone number.
1. Touch the “Phone Book” switch to display “Phone Book” screen.
27p194
2. Select the desired number from the
list.

188
(d) Ta l k i n g o n t h e B l u e t o o t h
phone
27p209
While you are talking on the phone,
this screen is displayed. You can do
the operations below on the screen.
To adjust the volume of the other party’s
voice:Touch “–” or “+” or use the volume
switch of the steering wheel.
To hang up the phone: Touch the “
” switch or push the
button of the steering wheel
To mute your voice: Touch the “Mute” switch. To input a Key:
Touch the “0 −9” switch.
To transfer the call Touch the “Transfer Call” switch.
You cannot change from hands −free call
to cellular phone call while you are driv-
ing.
When you change from cellular phone call
to hands −free call, the hands −free screen
will be displayed and you can operate it
on the screen.
Transferring method and behavior are dif-
ferent depending on the cellular phone
which you have.
For the operation of the phone, see the
manual that comes with your cellular
phone.
27p206
Touch the desired number to input the
key.
To hang up the phone:
Touch “
” or push the button of
the steering wheel.
This cannot be operated while you are
driving.

195
27p227
2. Use the software keyboard to inputthe name.
27p228
3. Input the number and touch “OK”.
27p229
4. Touch the desired switch you wantto register in.

197
27p233
3. Use the software keyboard to inputthe name.
27p234
4. Input the number and touch “OK”.
Deleting the speed tone individually.
You can delete “1” to “6” of the speed
tone.
If you delete them all at once, all of 6
numbers are deleted.
27p235
1. Touch the “Delete” switch of “Speed Tone”.
