Vehicle recovery
208
L
LASHING POINTS
Front
Rear
TRANSPORTING THE VEHICLE
The recommended method for
recovery/transportation or the vehicle is on a
transporter or trailer de signed for that purpose.
Ensure that transporta tion is carried out by
suitably qualified persons , and that the vehicle
is secured correctly.
TOWING THE VEHICLE ON FOUR
WHEELS
Note: The recommended recovery method is
to raise all four wheels.
Towing procedure
1. The vehicle should be parked on firm level
ground, with the park brake on, and the
gear selector in P if an automatic gearbox
is fitted.
2. Secure the towing attachment from the
recovery vehicle to the front towing eye.
See TOWING POINTS (page 207).
3. Dock the remote control, and switch on the
ignition. See GENERAL INFORMATION
(page 113).
WARNING
The front and rear lashing points must
only be used for securing the vehicle
during transportation. Use for any other
purpose may result in da mage to the vehicle,
and serious injury.
E81780
E81781
WARNINGS
Ensure that the remote control remains
docked whilst the vehicle is being
towed. Removing the remote control will
engage the steering lo ck, which will prevent
the vehicle from steering correctly.
If the engine cannot be run whilst the
vehicle is being towed, there will be no
power assistance for the steering or brakes.
This will result in grea ter effort being required
to steer or slow the vehicle, and greatly
increased stopping distances.
CAUTIONS
The vehicle should only be towed in a
forward direction with all four wheels on
the ground. Towing in a reverse direction with
two wheels on the ground will result in serious
damage to the transmission.
The vehicle should only be towed for a
maximum of 80 km (50 miles), at a
maximum speed of 80 k m/h (50 mph). Towing
for a greater distance, or at a higher speed may
result in serious dama ge to the transmission.

209
Vehicle recovery
R
4. Apply the foot brake, and select neutral.
5. With the footbrake still applied, release the
park brake.
6. The vehicle can now be towed a maximum
of 80 km (50 miles) at a maximum speed
of 80 kmh (50 mph).
7. Upon arrival at the destination, ensure
wherever possible that the vehicle is
parked on firm level ground.
8. Apply the park brake, and place the
selector lever into the P (park) position.
9. Switch off the ignition, and remove the
remote control.
10. Remove the towing attachment from the
towing eye.
CAUTION
Leaving the ignition switched on for
extended periods will ca use the battery to
drain.
WARNING
Use extreme caution when detaching
towing equipment. Vehicle movement
is possible which can resu lt in serious injuries.

Telephone
254
L
TelephoneGENERAL INFORMATION
Note: The vehicle tele phone system is
designed to function with a wide variety of
Bluetooth telephones. As these telephones
have a wide range of audio and echo
performance characteristics, it may take a few
seconds for the vehicl e telephone system to
adapt and deliver optimum audio performance.
It may be necessary to reduce the in-vehicle
volume slightly to fully optimise audio
performance and reduce echo. Note:
The vehicle's Bluetooth telephone
system can be used with an appropriate
Bluetooth-equipped mobile telephone.
Note: Please refer to your Land Rover
Dealer/Authorised Repairer for a list of
compatible telephones.
Telephone networks
The Telephone netw ork standard allows you to
use your telephone in many countries.
However, telephone reception may be poor or
unavailable in remote re gions. This may be due
to the inadequate power of the transmitter,
which results in a weak signal or incomplete
coverage.
WARNINGS
Using the telephone ne ar the car: do not
telephone inside a garage or near an
open car bonnet. The air may contain fuel
vapours and the tele phone could produce
sparks and start a fire.
Unusual ambient conditions: Switch off
the telephone in areas where high
explosives are being used. High frequency
remote controls could be interfered with and
cause an explosion. Switch off your telephone
in areas with a high explosion risk. This
includes filling stations, fuel storage areas or
chemical factories, as well as places where the
air contains fuel vapour, chemicals or metal
dust. The telephone might possibly produce
sparks and cause a fire or explosion.
Medical equipment: The functioning of
cardiac pacemakers or hearing aids
may be impaired when the phone is in use.
Check with a doctor or manufacturer whether
any such devices you or your passengers are
using are sufficiently protected against
high-frequency energy.
Always stow your mobile phone
securely. In an accident loose items can
cause injury.

Index
275
R
Preset buttons . . . . . . . . . . . . . . . . . . . . . 238 Recalling a preset channel . . . . . . . . . 239
Scrolling through presets . . . . . . . . . . 239
Storing channels as presets . . . . . . . . 238
Principle of operation Airbag deployment effects . . . . . . . . . . 61
Airbag operation . . . . . . . . . . . . . . . . . . 60
Airbags . . . . . . . . . . . . . . . . . . . . . . . . . 59
Before driving off-road . . . . . . . . . . . . 136
Brake pads . . . . . . . . . . . . . . . . . . . . . 123
Deployment and deflation . . . . . . . . . . . 60
Dynamic Stability Control (DSC) . . . . . 140
Gradient release control (GRC) . . . . . . 136
Introduction . . . . . . . . . . . . . . . . . . . . . 58
Roll stability control (RSC) . . . . . . . . . 140
Seat belt checks . . . . . . . . . . . . . . . . . . 55
Seat belt safety . . . . . . . . . . . . . . . . . . . 54
Seat belts . . . . . . . . . . . . . . . . . . . . . . . 54
Wet conditions . . . . . . . . . . . . . . . . . . 123
Priority programme type (PTY) . . . . . . . . 231 PTY search - Premium audio . . . . . . . 232
PTY seek - Standard audio . . . . . . . . . 233
PTY selection - Premium audio . . . . . 231Q
Quick start . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Audio system . . . . . . . . . . . . . . . . . . . . . 27
Automatic transmission . . . . . . . . . . . . . 23
Bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CD autochanger . . . . . . . . . . . . . . . . . . . 30
CD OPERATION . . . . . . . . . . . . . . . . . . . 30
Clock setting . . . . . . . . . . . . . . . . . . . . . 31
Cruise control . . . . . . . . . . . . . . . . . . . . 24
DAB radio. . . . . . . . . . . . . . . . . . . . . . . . 29
Driving position memory . . . . . . . . . . . . 10
Engine starting . . . . . . . . . . . . . . . . . . . . . 8
Exterior lighting . . . . . . . . . . . . . . . . . . . 22
Facia. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Gearshift interlocks . . . . . . . . . . . . . . . . 23
Heating and ventilation. . . . . . . . . . . . . . 14
Hill Descent Control (HDC) . . . . . . . . . . 25
Instrument pack . . . . . . . . . . . . . . . . . . . 19
Manual seat adjustment . . . . . . . . . . . . . 11
Master lock and unlock switches . . . . . . . 9
Overhead console . . . . . . . . . . . . . . . . . 12
Parking aid . . . . . . . . . . . . . . . . . . . . . . . 26
Passenger airbag deactivation . . . . . . . . 13
Power operated seat adjustment . . . . . . 10
Radio operation . . . . . . . . . . . . . . . . . . . 29
Remote control . . . . . . . . . . . . . . . . . . . . 7
Seat belts and Child restraints . . . . . . . . 13
Single CD player. . . . . . . . . . . . . . . . . . . 30
Steering column adjustment . . . . . . . . . 12
Steering column lock . . . . . . . . . . . . . . . 12
Tailgate . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Telephone - Bluetooth system . . . . . . . . 31
Terrain Response system. . . . . . . . . . . . 25
Warning indicators (attention) . . . . . . . . 21
Warning indicators (information) . . . . . . 21
Windows and Door mirrors . . . . . . . . . . 11
Wipers and washers. . . . . . . . . . . . . . . . 22
R
Radio data system (RDS) . . . . . . . . . . . . . 228 Selecting RDS . . . . . . . . . . . . . . . . . . . 228
Radio reception . . . . . . . . . . . . . . . . . . . . 218
Rain sensor . . . . . . . . . . . . . . . . . . . . . . . . 87
Operation . . . . . . . . . . . . . . . . . . . . . . . . 88
Rear fog lamps . . . . . . . . . . . . . . . . . . . . . . 73

Index
276
L
Rear seat controls . . . . . . . . . . . . . . . . . . 252
Rear seats . . . . . . . . . . . . . . . . . . . . . . . . . 51 Folding the rear seats . . . . . . . . . . . . . . 52
Raising the rear seats . . . . . . . . . . . . . . 53
Rear window wiper and washers . . . . . . . . 89 Reversing . . . . . . . . . . . . . . . . . . . . . . . 89
Wash/wipe . . . . . . . . . . . . . . . . . . . . . . 89
Wiper . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Recommended towing weights . . . . . . . . 152
Reduced engine performance . . . . . . . . . 128 Check engine - petrol models only . . . 128
Engine management syst em (EMS) fault . .
128
Refuelling . . . . . . . . . . . . . . . . . . . . . . . . 145 Fuel filler . . . . . . . . . . . . . . . . . . . . . . . 145
Regional mode (REG) . . . . . . . . . . . . . . . 228 Regional mode - Premium audio . . . . 228
Regional mode - Standard audio. . . . . 229
Remote control . . . . . . . . . . . . . . . . . . . . . 41
Repairing minor paint damage . . . . . . . . 156
Repeat compact disc tracks. . . . . . . . . . . 248
Resetting the audio unit. . . . . . . . . . . . . . 233
Running out of fuel . . . . . . . . . . . . . . . . . 144
Running-in . . . . . . . . . . . . . . . . . . . . . . . 128
S
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Safety precautions . . . . . . . . . . . . . . . . . . 142
Seat belt height adjustment . . . . . . . . . . . . 56
Seat belt reminder . . . . . . . . . . . . . . . . . . . 55
Seat belts
Principle of operation . . . . . . . . . . . . . . 54
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 240 Advanced settings . . . . . . . . . . . . . . . . 242
Auto-tune . . . . . . . . . . . . . . . . . . . . . . 241
DAB radio text . . . . . . . . . . . . . . . . . . . 241
DAB search . . . . . . . . . . . . . . . . . . . . . 240
FM traffic and news. . . . . . . . . . . . . . . 244
Shuffle/random . . . . . . . . . . . . . . . . . . . . 247 Random selection - Premium audio . . 248
Random selection - Standard audio . . 248
Sitting in the correct position . . . . . . . . . . 47
Snow chains . . . . . . . . . . . . . . . . . . . . . . 192
Stability control . . . . . . . . . . . . . . . . . . . . 141 Principle of operation . . . . . . . . . . . . . 140 Starting a diesel engine. . . . . . . . . . . . . . . 115
Automatic transmission . . . . . . . . . . . . 115
Manual transmission . . . . . . . . . . . . . . 115
Stopping the engine . . . . . . . . . . . . . . . 116
Starting a petrol engine. . . . . . . . . . . . . . . 114 Starting . . . . . . . . . . . . . . . . . . . . . . . . 114
Stopping the engine . . . . . . . . . . . . . . . 114
Starting the engine General information . . . . . . . . . . . . . . . 113
Station preset buttons . . . . . . . . . . . . . . . 226
Storage compartments . . . . . . . . . . . . . . . 112
Sun visors. . . . . . . . . . . . . . . . . . . . . . . . . 107
Sunroof. . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Supplementary restraints system Principle of operation . . . . . . . . . . . . . . . 58
T
Technical specificationsAccessory wheels and tyres . . . . . . . . . 194
Capacities . . . . . . . . . . . . . . . . . . . . . . . 170
Fuel consumption . . . . . . . . . . . . . . . . . 146
Fuel specification . . . . . . . . . . . . . . . . . 146
Lubricants and fluids . . . . . . . . . . . . . . 169
Transmission fluids a nd capacities. . . . 122
Telephone . . . . . . . . . . . . . . . . . . . . . . . . . 261
General information . . . . . . . . . . . . . . . 254
Telephone controls . . . . . . . . . . . . . . . . . . 255 Telephone controls - Steering wheel . . 256
Telephone setup . . . . . . . . . . . . . . . . . . . . 258 Dialled calls . . . . . . . . . . . . . . . . . . . . . 259
Missed calls . . . . . . . . . . . . . . . . . . . . . 258
Phone settings . . . . . . . . . . . . . . . . . . . 259
Received calls. . . . . . . . . . . . . . . . . . . . 258
Telephone main menu . . . . . . . . . . . . . 258
Telephone voice control . . . . . . . . . . . . . . 270
Terrain response . . . . . . . . . . . . . . . . . . . . 132 Principle of operation . . . . . . . . . . . . . . 132
Tow bar. . . . . . . . . . . . . . . . . . . . . . . . . . . 153 Tow bar dimensions a nd mounting points .
153
Towing a trailer . . . . . . . . . . . . . . . . . . . . . 150 Trailer electrical connection . . . . . . . . . 150
Towing points . . . . . . . . . . . . . . . . . . . . . . 207
Front and rear towing eyes . . . . . . . . . . 207
Towing the vehicle on four wheels . . . . . . 208 Towing procedure . . . . . . . . . . . . . . . . 208

Index
277
R
Track selection . . . . . . . . . . . . . . . . . . . . 246
Traction control . . . . . . . . . . . . . . . . . . . . 139
Traffic information control . . . . . . . . . . . 226 Traffic Programme (TP) preference . . 227
Transmission Technical specifications . . . . . . . . . . . 122
Transporting the vehicle . . . . . . . . . . . . . 208
Trip computer . . . . . . . . . . . . . . . . . . . . . . 99
Type approvals . . . . . . . . . . . . . . . . . . . . 215
Declarations of conformity . . . . . . . . . 215
Tyre care . . . . . . . . . . . . . . . . . . . . . . . . . 177 Age degradation . . . . . . . . . . . . . . . . . 178
Directional tyres . . . . . . . . . . . . . . . . . 180
Flat spots . . . . . . . . . . . . . . . . . . . . . . 182
Pressure compensation for ambient
temperature changes . . . . . . . . . . . 182
Punctured tyres . . . . . . . . . . . . . . . . . 178
Replacement tyres . . . . . . . . . . . . . . . 179
Tyre checks. . . . . . . . . . . . . . . . . . . . . 179
Tyre pressures . . . . . . . . . . . . . . . . . . 180
Tyre wear . . . . . . . . . . . . . . . . . . . . . . 178
Tyre glossary. . . . . . . . . . . . . . . . . . . . . . 193 Terms used . . . . . . . . . . . . . . . . . . . . . 193
Tyre repair kit . . . . . . . . . . . . . . . . . . . . . 187
Checking the tyre pressure after a repair . . 191
Land Rover tyre repair kit . . . . . . . . . . 189
Land Rover tyre repair kit safety information 188
Using the Land Rover tyre repair kit . . 190
U
Using booster cables. . . . . . . . . . . . . . . . 173 Disconnecting the cables . . . . . . . . . . 173
Using cruise control . . . . . . . . . . . . . . . . 130 Engaging cruise control . . . . . . . . . . . 130
Increasing the cruise speed . . . . . . . . 131
Reducing the cruise speed . . . . . . . . . 130
Suspending cruise control . . . . . . . . . 130
Using HDC. . . . . . . . . . . . . . . . . . . . . . . . 137
HDC operation . . . . . . . . . . . . . . . . . . 137
Selecting HDC . . . . . . . . . . . . . . . . . . . 137
Warning messages . . . . . . . . . . . . . . . 138
Using seat belts during pregnancy . . . . . . 57
Using snow chains . . . . . . . . . . . . . . . . . 192 Using stability control. . . . . . . . . . . . . . . . 141
Deactivating DSC . . . . . . . . . . . . . . . . . 141
DSC . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
DSC system fault . . . . . . . . . . . . . . . . . 141
Reactivating DSC . . . . . . . . . . . . . . . . . 141
Using terrain response . . . . . . . . . . . . . . . 132
Before driving off-road . . . . . . . . . . . . . 132
Driver override options . . . . . . . . . . . . 132
Terrain response messages . . . . . . . . . 134
Terrain Response operation . . . . . . . . . 133
Using the key . . . . . . . . . . . . . . . . . . . . . . . 40
Using the parking aid . . . . . . . . . . . . . . . . 127
Front PDC deactivation. . . . . . . . . . . . . 127
PDC activation . . . . . . . . . . . . . . . . . . . 127
Sensor care . . . . . . . . . . . . . . . . . . . . . 127
System fault . . . . . . . . . . . . . . . . . . . . . 127
Using the remote control . . . . . . . . . . . . . . 41 Approach lighting. . . . . . . . . . . . . . . . . . 42
Emergency alarm . . . . . . . . . . . . . . . . . . 43
Locking . . . . . . . . . . . . . . . . . . . . . . . . . 42
Remote battery . . . . . . . . . . . . . . . . . . . 43
Remote control . . . . . . . . . . . . . . . . . . . 41
Single and double locking . . . . . . . . . . . 42
Tailgate . . . . . . . . . . . . . . . . . . . . . . . . . 43
Unlocking . . . . . . . . . . . . . . . . . . . . . . . . 41
Using the telephone . . . . . . . . . . . . . . . . . 261 Ending telephone calls . . . . . . . . . . . . . 263
Making telephone calls. . . . . . . . . . . . . 262
Receiving telephone calls . . . . . . . . . . . 264
Selecting telephone mode . . . . . . . . . . 261
Telephone in-call menu . . . . . . . . . . . . 265
Voice mail . . . . . . . . . . . . . . . . . . . . . . 266
Using traction control . . . . . . . . . . . . . . . . 139
Before driving off-road . . . . . . . . . . . . . 139
Electronic Traction Control (ETC). . . . . 139
Using winter tyres . . . . . . . . . . . . . . . . . . 183
V
Vehicle build date plate . . . . . . . . . . . . . . . 210
Vehicle identification number (VIN) . . . . . 210
Vehicle identification plate . . . . . . . . . . . . 210
Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
VIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
Volume control . . . . . . . . . . . . . . . . . . . . . 223 Automatic Volume Control (AVC). . . . . 223
Reset volume settings . . . . . . . . . . . . . 223

303-14 ELECTRONIC ENGINE CONTROLS
Diesel
FREELANDER 2 - LR2 - VIN: 000201 onwards (LHD) (02 / 05) 23
BU-BN,0.75WH-GN,0.35BU-RD,1.0GN-BU,0.75GN-BU,0.75BU,0.75VT-OG,0.5BU-WH,0.5BU-OG,0.5BN,0.5
BU-WH,0.5
BU-WH,0.5
BU-OG,0.5
BK-GY,0.5WH-BN,0.75GY-BN,0.5GN,0.75GN,0.75GN-OG,0.35
GN,1.0
VT,0.75BN-YE,2.5YE-VT,0.35WH-OG,0.5
BU-OG,0.5
BU,0.75VT-GN,0.5VT-WH,0.75
GN,1.0
GY-YE,1.5GY-YE,1.5BU-OG,0.5GY-VT,0.5BN-GN,0.5YE,0.5
BU-OG,0.5
GY-YE,1.5RD,6.0GN-VT,0.75
BU-RD,0.5
BK-YE,6.0BK-YE,2.5
GN,0.75BU,0.5BK-GY,1.5VT-OG,0.5BU-WH,0.5BN-YE,0.5
BK-YE,0.5BK-YE,0.75
BU-WH,0.5
BK-YE,1.0BK-YE,1.5BK-GY,2.5
C21D-3 C21C-3
Switch-Clutch-BOT (S471)
Junction box-Central (P101)
Module (CEM) (D316)
Central Electronics
FS27
5.0 Amps
module (ECM) (D131)
Engine control-
H Sheet1V Sheet1N Sheet1M Sheet1T Sheet1
C11L-3 C11M-3C12G-11 C12H-11
A Sheet1F Sheet1G Sheet1B Sheet1
WAKE UP FET-ECM
FS22
20.0 Amps
X
Sheet1R
Sheet1
pump (R103) Relay-Fuel-(PCB)
Start control unit (D391)control (D294)
Module-Transmission-
C11P-8 C11N-8
C11N-9 C11P-9C11L-14 C11M-14C11N-3 C11P-3C11N-2 C11P-2
Generator (M100)
Y
Sheet3
lamp (S103)
Switch-Reverse-
module (ECM) (D131)
Engine control-Fuel (M151) Pump-12.00 Amps
Unit-Fuel Tank (D179)
level (T220)
Sensor-Engine coolant-
gear inhibit (N182)
Solenoid-Reverse
C2E903-1
C2E903-2
C1E104F-A2
I_S_GLWC1E104G-K4O_T_GLWC1E104H-E4 A-C RELAY
C1E104H-K3
IGN
S1BB08S3E903
C1E104F-K1 O_S_STRTNC1E104H-L4V_V_BATT+1RC1E104H-F4 ECR_RLYC1E104H-L3V_V_BATT+2RC1E104F-C4 O_S_STRT
C1E104H-C2
B_D_LINC1E104G-J2
I_S_PKRN/CLTCHC1E104H-D4
O_T_FAN1C1BP02A-8C1BP02A-26C1BP02A-44C1BP02C-74C1BP02B-43
FUEL EJECT SENSORCLUTCH BOTSTART REQUESTREVERSE GEARCOOLANT LEVELWAKE UP
C1BP02B-27
C1BP02C-43C1BP02C-35C1BP02C-50
LIN 3CRASH
C1BP02A-11
F/P SENSOR GNDF/P SENSOR
C1BP02A-45
IGN RLY
C1BP02G-1 BATT A
C1BP02B-46C1BP02B-30C1BP02B-48C1BP02B-76
S2BB27
S2D139B
C2DC35-1 PWR
G6D139-1
C1ET02-5C1ET02-1VBATTC1ET02-11 IGN
S1BB42
C1DC14-1C1E104H-D1 I_S_WAKEC1E104H-F2
I_S_T50RC1E104H-C1I_S_CRASH
S3D135
C1ET47D-1
G3D135-1
C4E515-4C2DC35-3LINC4E515-1
Pump Sender -veC4E515-2 Pump Sender +veC4E515-6 Remote Sender +veC4E515-5
Remote Sender -veC2DC35-5 START
C3ET58-1
C1MC21-2S2DC35
C1MC21-1
C3ET58-2
S2D139DS1D130D
S2D139AG1D130B-1
C4E515-3
G4D149B-1

303-14 ELECTRONIC ENGINE CONTROLS
Diesel
FREELANDER 2 - LR2 - VIN: 000201 onwards (RHD) (02 / 05) 24
BU-BN,0.75WH-GN,0.35BU-RD,1.0GN-BU,0.75GN-BU,0.75BU,0.75VT-OG,0.5BU-WH,0.5BU-OG,0.5BN,0.5
BU-WH,0.5
BU-WH,0.5
BU-OG,0.5
BK-GY,0.5WH-BN,0.75GY-BN,0.5GN,0.75GN,0.75GN-OG,0.35
GN,1.0
VT,0.75BN-YE,2.5YE-VT,0.35WH-OG,0.5
BU-OG,0.5
BU,0.75VT-GN,0.5VT-WH,0.75
GN,1.0
GY-YE,1.5GY-YE,1.5BU-OG,0.5GY-VT,0.5BN-GN,0.5YE,0.5
BU-OG,0.5
GY-YE,1.5RD,6.0GN-VT,0.75
BU-RD,0.5
BK-YE,6.0BK-YE,2.5
GN,0.75BU,0.5BK-GY,1.5VT-OG,0.5BU-WH,0.5BN-YE,0.5
BK-YE,0.5BK-YE,0.75
BU-WH,0.5
BK-YE,1.0BK-YE,1.5BK-GY,2.5
C21D-3 C21C-3
Switch-Clutch-BOT (S471)
Junction box-Central (P101)
Module (CEM) (D316)
Central Electronics
FS27
5.0 Amps
module (ECM) (D131)
Engine control-
H Sheet1V Sheet1N Sheet1M Sheet1T Sheet1
C11L-3 C11M-3C12G-11 C12H-11
A Sheet1F Sheet1G Sheet1B Sheet1
WAKE UP FET-ECM
FS22
20.0 Amps
X
Sheet1R
Sheet1
pump (R103) Relay-Fuel-(PCB)
Start control unit (D391)control (D294)
Module-Transmission-
C11P-8 C11N-8
C11N-9 C11P-9C11L-14 C11M-14C11N-3 C11P-3C11N-2 C11P-2
Generator (M100)
Y
Sheet3
lamp (S103)
Switch-Reverse-
module (ECM) (D131)
Engine control-Fuel (M151) Pump-12.00 Amps
Unit-Fuel Tank (D179)
level (T220)
Sensor-Engine coolant-
gear inhibit (N182)
Solenoid-Reverse
C2E903-1
C2E903-2
C1E104F-A2
I_S_GLWC1E104G-K4O_T_GLWC1E104H-E4 A-C RELAY
C1E104H-K3
IGN
S1BB08S3E903
C1E104F-K1 O_S_STRTNC1E104H-L4V_V_BATT+1RC1E104H-F4 ECR_RLYC1E104H-L3V_V_BATT+2RC1E104F-C4 O_S_STRT
C1E104H-C2
B_D_LINC1E104G-J2
I_S_PKRN/CLTCHC1E104H-D4
O_T_FAN1C1BP02A-8C1BP02A-26C1BP02A-44C1BP02C-74C1BP02B-43
FUEL EJECT SENSORCLUTCH BOTSTART REQUESTREVERSE GEARCOOLANT LEVELWAKE UP
C1BP02B-27
C1BP02C-43C1BP02C-35C1BP02C-50
LIN 3CRASH
C1BP02A-11
F/P SENSOR GNDF/P SENSOR
C1BP02A-45
IGN RLY
C1BP02G-1 BATT A
C1BP02B-46C1BP02B-30C1BP02B-48C1BP02B-76
S2BB27
S2D139B
C2DC35-1 PWR
G6D139-1
C1ET02-5C1ET02-1VBATTC1ET02-11 IGN
S1BB42
C1DC14-1C1E104H-D1 I_S_WAKEC1E104H-F2
I_S_T50RC1E104H-C1I_S_CRASH
S3D135
C1ET47D-1
G3D135-1
C4E515-4C2DC35-3LINC4E515-1
Pump Sender -veC4E515-2 Pump Sender +veC4E515-6Remote Sender +veC4E515-5
Remote Sender -veC2DC35-5 START
C3ET58-1
C1MC21-2S2DC35
C1MC21-1
C3ET58-2
S2D139DS1D130D
S2D139AG1D130B-1
C4E515-3
G4D149B-1
