2005 NISSAN X-TRAIL ECO mode

BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM POW-
ER SOURCE)
AT-375
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT

DTC Confirmation ProcedureECS00CT1
CAUTION:

Always drive vehicle at a safe speed.

If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait
at least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine.
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Drive vehicle under the following conditions.
SLCT LVR POSI: D position
VHCL SPEED SE: higher than 20 km/h (12 MPH)
4. If the check result is NG, go to AT- 3 7 7 , "
Diagnostic Procedure" .
WITHOUT CONSULT-II
1. Start engine.
2. Drive vehicle under the following conditions.
Selector lever position: D position
Vehicle speed: higher than 20 km/h (12 MPH)
3. Perform self-diagnosis.
Refer to AT- 5 2 , "
Diagnostic Procedure Without CONSULT-II" .
4. If the check result is NG, go to AT- 3 7 7 , "
Diagnostic Procedure" .
SAT014K
SCIA5358E
SCIA5598E

AT-382
[ALL]
ENGINE SPEED SIGNAL

ENGINE SPEED SIGNALPFP:24825
DescriptionECS004UC
The engine speed signal is sent from the ECM to the TCM.
CONSULT-II Reference ValueECS00CT2
Remarks: Specification data are reference values.
On Board Diagnosis LogicECS00CT3
DTC Confirmation ProcedureECS00CT4
CAUTION:

Always drive vehicle at a safe speed.

If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait
at least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode for
“A/T” with CONSULT-II.
2. Start engine and maintain the following conditions for at least 10
consecutive seconds.
VHCL SPEED SE: 10 km/h (6 MPH) or more
THRTL POS SEN: More than 1.2V
SLCT LVR POSI: D position
3. If the check result is NG, go to AT- 3 8 4 , "
Diagnostic Procedure" .
WITHOUT CONSULT-II
1. Start engine.
2. Drive vehicle under the following conditions for more than 10 seconds.
Selector lever position: D position
Vehicle speed: higher than 10 km/h (6 MPH)
Throttle position: greater than 1.0/8 of the full throttle position
3. Perform self-diagnosis.
Refer to AT- 5 2 , "
Diagnostic Procedure Without CONSULT-II" .
4. If the check result is NG, go to AT- 3 8 4 , "
Diagnostic Procedure" .
Monitor item Condition Display value
ENGINE SPEED (rpm) Engine running Approximately matches the tachometer
reading.
Diagnostic trouble code Malfunction is detected when... Check item (Possible cause)
: ENGINE SPEED SIG
TCM does not receive the proper voltage
signal from ECM.

Harness or connectors
(The sensor circuit is open or shorted.)
: 9th judgement flicker
SAT014K
SCIA5599E

LINE PRESSURE SOLENOID VALVE
AT-387
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT

LINE PRESSURE SOLENOID VALVEPFP:31940
DescriptionECS004UF
The line pressure solenoid valve regulates the oil pump discharge
pressure to suit the driving condition in response to a signal sent
from the TCM.
The line pressure duty cycle value is not consistent when the
closed throttle position switch is ON. To confirm the line pres-
sure duty cycle at low pressure, the accelerator (throttle)
should be open until the closed throttle position switch is OFF.
CONSULT-II Reference ValueECS00CT5
Remarks: Specification data are reference values.
NOTE:
The line pressure duty cycle value is not consistent when the closed throttle position switch is “ON”. To confirm the line pressure duty
cycle at low pressure, the accelerator (throttle) should be open until the closed throttle position switch is “OFF”.
On Board Diagnosis LogicECS00CT6
Possible CauseECS00CT7
Check the following items.

Harness or connector
(The solenoid circuit is open or shorted.)

Line pressure solenoid valve
DTC Confirmation ProcedureECS00CT8
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode for
“A/T” with CONSULT-II.
SCIA0735E
Monitor item Condition Specification
Line pressure solenoid valve dutySmall throttle opening
(Low line pressure)
↓
Large throttle opening
(High line pressure)Approximately 24%
↓
Approximately 95%
Diagnostic trouble code Malfunction is detected when... Check items (Possible cause)
: LINE PRESSURE S/V
TCM detects an improper voltage drop
when it tries to operate the solenoid valve.

Harness or connectors
(The solenoid circuit is open or shorted.)

Line pressure solenoid valve
: 10th judgement flicker
SAT014K

AT-394
[ALL]
MAIN POWER SUPPLY AND GROUND CIRCUIT

MAIN POWER SUPPLY AND GROUND CIRCUITPFP:00100
DescriptionECS00CS1
When the power supply to the TCM is cut OFF, for example because the battery is removed, and the self-diag-
nostics memory function stops, malfunction is detected.
On Board Diagnosis LogicECS00CS2

Diagnostic trouble code “INITIAL START” with CONSULT-II is detected when TCM dose not receive the
voltage signal from the battery power supply.

This is not a malfunction message. (Whenever shutting “OFF” a power supply to the TCM, this message
appears on the screen.)
Possible CauseECS00CS3
Harness or connector
(Battery or ignition switch and TCM circuit is open or shorted.)
DTC Confirmation ProcedureECS00CS4
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
WITH CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Wait for at least 2 consecutive seconds.
4. If DTC is detected, go to AT- 3 9 6 , "
Diagnostic Procedure" .
SAT014K

AT-530
[ALL]
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsECS00CXK
*1: Refer to MA-17, "Fluids and Lubricants" .
Shift ScheduleECS00CXL
VEHICLE SPEED WHEN SHIFTING GEARS AND THROTTLE POSITION
For 85X23 model
For 85X64 model
VEHICLE SPEED WHEN PERFORMING LOCK-UP
Unit: km/h (MPH)
NOTE:

Lock-up vehicle speed indicates the speed in D4 position.

Perform lock-up inspection after warming up engine.

Lock-up vehicle speed may vary depending on the driving conditions and circumstances. EngineQR20DE QR25DE
Automatic transaxle model RE4F04B (4WD)
Automatic transaxle assembly Model code number 85X23 85X64
Transaxle gear ratio1st 2.785
2nd 1.545
3rd 1.000
4th 0.694
Reverse 2.272
Final drive 4.425 4.087
Recommended fluid Genuine Nissan ATF or equiualent*1
Fluid capacity (Imp qt)8.5 (7-1/2)
Throttle posi-
tionShift patternVehicle speed km/h (MPH)
D
1 → D2D2 → D3D3 → D4D4 → D3D3 → D2D2 → D1
Full throttleComfort53 - 61
(33 - 38)99 - 107
(62 - 67)156 - 164
(97 - 102)152 - 160
(94 - 99)89 - 97
(53 - 60)41 - 49
(25 - 30)
Auto power53 - 61
(33 - 38)99 - 107
(62 - 67)156 - 164
(97 - 102)152 - 160
(94 - 99)89 - 97
(55 - 60)41 - 49
(25 - 30)
Half throttleComfort34 - 42
(21 - 26)64 - 72
(40 - 45)124 - 138
(77 - 82)82 - 90
(51 - 56)41 - 49
(25 - 30)5 - 13
(3 - 8)
Auto power38 - 46
(24 - 29)70 - 78
(44 - 48)124 - 132
(77 - 82)81 - 89
(50 - 55)44 - 53
(27 - 33)5 - 13
(3 - 8)
Throttle posi-
tionShift patternVehicle speed km/h (MPH)
D
1 → D2D2 → D3D3 → D4D4 → D3D3 → D2D2 → D1
Full throttleComfort57 - 65
(35 - 40)107 - 115
(66 - 71)167 - 175
(104 - 109)163 - 171
(101 - 106)97 - 105
(60 - 65)41 - 49
(25 - 30)
Auto power57 - 65
(35 - 40)107 - 115
(66 - 71)167 - 175
(104 - 109)163 - 171
(101 - 106)97 - 105
(60 - 65)41 - 49
(25 - 30)
Half throttleComfort36 - 44
(22 - 27)71 - 79
(44 - 49)131 - 139
(81 - 86)77 - 85
(48 - 53)38 - 46
(23 - 28)5 - 13
(3 - 8)
Auto power42 - 50
(26 - 31)79 - 87
(49 - 54)131 - 139
(81 - 86)77 - 85
(48 - 53)45 - 53
(28 - 33)5 - 13
(3 - 8)
Model code No. 85X23 85X64
Vehicle speed Throttle position 1/8 58 - 66 (36 - 41) 61 - 69 (38 - 43)

TF-2 Engine Control Signal ............................................. 44
DIAGNOSTIC PROCEDURE .............................. 44
CAN Communication Line ...................................... 45
DIAGNOSTIC PROCEDURE .............................. 45
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 46
4WD Indicator Lamp and LOCK Indicator Lamp Do
Not Turn ON for Approx. 1 Second When The Igni-
tion Switch Is Turned to ON .................................... 46
DIAGNOSTIC PROCEDURE .............................. 46
4WD Warning Lamp Does Not Turn ON When The
Ignition Switch Is Turned to ON .............................. 47
DIAGNOSTIC PROCEDURE .............................. 47
4WD Warning Lamp Does Not Turn OFF Several
Seconds after Engine Started ................................. 48
DIAGNOSTIC PROCEDURE .............................. 48
4WD Mode Cannot Be Switched after Engine Is
Started .................................................................... 49
DIAGNOSTIC PROCEDURE .............................. 49
Heavy Tight-Corner Braking Symptom Occurs
When the Vehicle Is Driven in AUTO Mode and the
Steering Wheel Is Turned Fully to Either Side after
the Engine Is Started .............................................. 50
DIAGNOSTIC PROCEDURE .............................. 50
Vehicle Does Not Enter 4WD Mode Even Though
4WD Warning Lamp Turned to OFF ....................... 51
DIAGNOSTIC PROCEDURE .............................. 52
While Driving, 4WD Warning Lamp Flashes Rapidly
(When Flashing in Approx. 1 Minute and Then Turn-
ing OFF) ................................................................. 52
While Driving, 4WD Warning Lamp Flashes Slowly
(When Continuing to Flash until Turning Ignition
Switch OFF) ............................................................ 53
DIAGNOSTIC PROCEDURE .............................. 534WD CONTROL UNIT ............................................... 54
Removal and Installation ......................................... 54
REMOVAL ............................................................ 54
INSTALLATION .................................................... 54
SIDE OIL SEAL ......................................................... 55
Removal and Installation ......................................... 55
REMOVAL ............................................................ 55
INSTALLATION .................................................... 55
AIR BREATHER HOSE ............................................. 56
Components ............................................................ 56
Removal and Installation ......................................... 56
TRANSFER ASSEMBLY ........................................... 57
Removal and Installation ......................................... 57
COMPONENTS ................................................... 57
REMOVAL ............................................................ 57
INSTALLATION .................................................... 58
Disassembly and Assembly .................................... 59
COMPONENTS ................................................... 59
ASSEMBLY INSPECTION ................................... 60
DISASSEMBLY .................................................... 64
INSPECTION AFTER DISASSEMBLY ................ 68
SELECTING ADJUSTING SHIMS ....................... 69
ASSEMBLY .......................................................... 70
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 76
General Specifications ............................................ 76
Inspection and Adjustment ...................................... 76
PRELOAD TORQUE BEFORE DISASSEMBLY ... 76
PRELOAD TORQUE AFTER DISASSEMBLY
AND REASSEMBLY ............................................ 76
BACKLASH .......................................................... 76
COMPANION FLANGE RUNOUT ....................... 76
SELECTIVE PARTS ............................................ 76

TF-12
ALL MODE 4X4 SYSTEM

4WD MODE SWITCH
AUTO Mode

Electronic control allows optimal distribution of torque to front/rear wheels to match road conditions.

4WD mode makes possible stable driving, with no wheel spin, on snowy roads or other slippery surfaces.

On roads which do not require 4WD, AUTO mode contributes to improved fuel economy by driving in con-
ditions close to front-wheel drive.

Sensor inputs determine the vehicle's turning condition, and tight cornering/braking are controlled by dis-
tributing optimum torque to rear wheels.
LOCK Mode

Front/rear wheel torque distribution is fixed, ensuring stable driving when climbing slopes.

Vehicle will switch automatically to AUTO mode if vehicle speed increases. If vehicle speed then
decreases, the vehicle automatically returns to direct 4-wheel driving conditions.

LOCK mode will change to AUTO mode automatically, when the vehicle speed exceeds approx. 30 km/h
(19 MPH). The LOCK indicator light keeps illuminating.
NOTE:
If there is a significant difference in pressure or wear between tires, full vehicle performance is not available.
LOCK mode may be prohibited, or speeds at which LOCK mode is enabled may be restricted detecting tire
conditions.
2WD Mode
Vehicle is in front-wheel drive.
NOTE:

If front wheels are slipping in 2WD mode, do not switch to AUTO or LOCK. This can cause difficulties for
the system.

Even if the 4WD mode switch is in 2WD mode, the 4WD control unit occasionally automatically change to
AUTO mode depending on the driving condition (For example; Depressing the acceleration firmly). This is
not malfunction. However, 4WD indicator lamp dose not illuminate.
4WD INDICATOR LAMP AND LOCK INDICATOR LAMP
The following is the indications of indicator lamp.
4WD WARNING LAMP
Turns ON when there is a malfunction in 4WD system. It indicates that the vehicle is in fail-safe mode and
change to front-wheel drive or shifting driving force-4WD (Rear-wheels still have some driving torque).
Also turns ON when ignition switch is turned ON, for purpose of lamp check. Turns OFF approximately for 1
seconds after the engine starts if system is normal.
4WD Warning Lamp Indication
Condition 4WD indicator lamp LOCK indicator lamp
AUTO mode ON OFF
LOCK mode ON ON
2WD mode OFF OFF
Lamp check Turns ON for approx. 1 second when ignition switch is turned ON.
SDIA2298E
Condition 4WD warning lamp
Lamp checkTurns ON when ignition switch is turned ON. Turns OFF
approx. 1 seconds after engine start.
4WD system malfunctionON
Protection function is activated due to heavy load to electric con-
trolled coupling. (4WD system is not malfunctioning and 4WD system
changes to 2WD mode.)Rapid flashing: 2 times/second
(Flashing in approx. 1 minute and then turning OFF.)

ALL MODE 4X4 SYSTEM
TF-13
C
E
F
G
H
I
J
K
L
MA
B
TF

System DiagramEDS001VC
Large difference in diameter of front/rear tiresSlow flashing: 1 time/2 seconds
(Continuing to flash until turning ignition switch OFF)
Other than above (system normal) OFFCondition 4WD warning lamp
SDIA1866E
