2005 NISSAN X-TRAIL ECO mode

AT-178
[EURO-OBD]
DTC P1760 OVERRUN CLUTCH SOLENOID VALVE

DTC P1760 OVERRUN CLUTCH SOLENOID VALVEPFP:31940
DescriptionECS004S9
The overrun clutch solenoid valve is activated by the TCM in
response to signals sent from the park/neutral position (PNP) switch,
overdrive control switch, vehicle speed and throttle position sensors.
The overrun clutch operation will then be controlled.
On Board Diagnosis LogicECS00CUJ
Possible CauseECS00CUK
Check the following items.

Harness or connector
(The solenoid circuit is open or shorted.)

Overrun clutch solenoid valve
DTC Confirmation ProcedureECS00CUL
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously conducted, always turn ignition switch OFF and
wait at least 5 seconds before conducting the next test.
TESTING CONDITION:
Always drive vehicle on a level road to improve accuracy of test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode for
“A/T” with CONSULT-II.
2. Start engine.
3. Accelerate vehicle to a speed of more than 10 km/h (6 MPH)
with “D” position (O/D ON).
4. Release accelerator pedal completely with D position (O/D
OFF).
WITH GST
Follow the procedure “WITH CONSULT-II”.
SCIA0718E
Diagnostic trouble code Malfunction is detected when... Check items (Possible cause)
: OVERRUN CLUTCH S/V
TCM detects an improper voltage drop
when it tries to operate the solenoid valve.

Harness or connectors
(The solenoid circuit is open or shorted.)

Overrun clutch solenoid valve
: P1760
SAT014K

AT-192
[EURO-OBD]
DTC VEHICLE SPEED SENSOR MTR

DTC VEHICLE SPEED SENSOR MTRPFP:24814
DescriptionECS004SM
The vehicle speed sensor·MTR is built into the speedometer assem-
bly. The sensor functions as an auxiliary device to the revolution sen-
sor when it is malfunctioning. The TCM will then use a signal sent
from the vehicle speed sensor·MTR.
On Board Diagnosis LogicECS00CUR
Possible CauseECS00CUS
Check the following items.

Harness or connector
(The sensor circuit is open or shorted.)

Vehicle speed sensor
DTC Confirmation ProcedureECS00CUT
CAUTION:

Always drive vehicle at a safe speed.

If conducting this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait
at least 5 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode for
“A/T” with CONSULT-II.
SCIA0716E
Diagnostic trouble code Malfunction is detected when... Check items (Possible cause)
: VHCL SPEED SEN·MTR
TCM does not receive the proper voltage
signal from the sensor.

Harness or connectors
(The sensor circuit is open or shorted.)

Combination meter

4WD/ABS control unit : 2nd judgement flicker
SAT014K

AT-198
[EURO-OBD]
DTC CONTROL UNIT (RAM), CONTROL UNIT (ROM)

DTC CONTROL UNIT (RAM), CONTROL UNIT (ROM)PFP:31036
DescriptionECS004SP
The TCM consists of a microcomputer and connectors for signal
input and output and for power supply. The unit controls the A/T.
On Board Diagnosis LogicECS00CUU
Possible CauseECS00CUV
TCM.
DTC Confirmation ProcedureECS00CUW
NOTE:
If “DTC Confirmation Procedure” has been previously conducted, always turn ignition switch OFF and
wait at least 5 seconds before conducting the next test.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode for
A/T with CONSULT-II.
2. Start engine.
3. Run engine for at least 2 seconds at idle speed.
4. If the check result is NG, go to AT- 1 9 9 , "
Diagnostic Procedure" .
SAT574J
Diagnostic Trouble Code No. Malfunction is detected when.... Check Item (Possible Cause)
: CONTROL UNIT (RAM),
CONTROL UNIT (ROM)TCM memory (RAM) or (ROM) is malfunc-
tioning.

TCM
SAT014K
SCIA5358E

AT-200
[EURO-OBD]
DTC CONTROL UNIT(EEPROM)

DTC CONTROL UNIT(EEPROM)PFP:31036
DescriptionECS004SR
The TCM consists of a microcomputer and connectors for signal
input and output and for power supply. The unit controls the A/T.
On Board Diagnosis LogicECS00CUX
Possible CauseECS00CUY
TCM.
DTC Confirmation ProcedureECS00CUZ
NOTE:
If “DTC Confirmation Procedure” has been previously conducted, always turn ignition switch OFF and
wait at least 5 seconds before conducting the next test.
WITH CONSULT-II
1. Turn ignition switch “ON” and select “DATA MONITOR” mode for
A/T with CONSULT-II.
2. Start engine.
3. Run engine for at least 2 seconds at idle speed.
4. If the check result is NG, go to AT- 2 0 1 , "
Diagnostic Procedure" .
SAT574J
Diagnostic trouble code Malfunction is detected when... Check item (Possible cause)
: CONT UNIT (EEP ROM)TCM memory (EEP ROM) is malfunction-
ing.

TCM
SAT014K
SCIA5358E

DTC CONTROL UNIT(EEPROM)
AT-201
[EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

Diagnostic ProcedureECS004SS
1. CHECK DTC
With CONSULT-II
1. Turn ignition switch ON and select “SELF DIAGNOSIS” mode for A/T with CONSULT-II.
2. Move selector lever to R position.
3. Depress accelerator pedal (Full throttle position).
4. Touch “ERASE”.
5. Turn ignition switch OFF for 10 seconds.
6. Perform AT- 2 0 0 , "
DTC Confirmation Procedure" .
Is the
“CONT UNIT (EEP ROM)” displayed again?
YES >> Replace TCM.
NO >>INSPECTION END

ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION
AT-243
[EXC.F/EURO-OBD]
D
E
F
G
H
I
J
K
L
MA
B
AT

2. Touch “SELF-DIAG RESULTS”.
Display shows malfunction experienced since the last erasing
operation.
CONSULT-II performs “REAL TIME DIAG”.
Also, any malfunction detected while in this mode will be dis-
played at real time.
SELF-DIAGNOSTIC RESULT TEST MODE
CAUTION:
If malfunction is detected in multiple systems including CAN communication line, CAN communication line trouble diagnosis
shall be performed first.
SAT987J
Items (CONSULT-II screen terms) Malfunction is detected when... Remarks
No failure
(NO SELF DIAGNOSTIC FAIL-
URE INDICATED FURTHER
TESTING MAY BE REQUIRED)

No failure has been detected.
INITIAL START

This is not a malfunction message (Whenever shutting off a power
supply to the TCM, this message appears on the screen.)
VHCL SPEED SEN·A/T

TCM does not receive the proper voltage signal from the sensor.
VHCL SPEED SEN·MTR

TCM does not receive the proper voltage signal from the sensor.
THROTTLE POSI SEN

TCM receives an excessively low or high voltage from the sensor.
SHIFT SOLENOID/V A

TCM detects an improper voltage drop when it tries to operate the
solenoid valve.
SHIFT SOLENOID/V B

TCM detects an improper voltage drop when it tries to operate the
solenoid valve.
OVERRUN CLUTCH S/V

TCM detects an improper voltage drop when it tries to operate the
solenoid valve.
T/C CLUTCH SOL/V

TCM detects an improper voltage drop when it tries to operate the
solenoid valve.
BATT/FLUID TEMP SEN

TCM receives an excessively low or high voltage from the sensor.To be displayed in case
of abnormality and when
no recording is made.
ENGINE SPEED SIG

TCM does not receive the proper voltage signal from the ECM.
LINE PRESSURE S/V

TCM detects an improper voltage drop when it tries to operate the
solenoid valve.
CAN COMM CIRCUIT

When malfunction is detected in CAN communication line.
CONTROL UNIT (RAM)

TCM memory (RAM) is malfunctioning Refer to AT-286
CONTROL UNIT (ROM)

TCM memory (ROM) is malfunctioning Refer to AT-286
CONT UNIT (EEP ROM)

TCM memory (EEP ROM) is malfunctioning. Refer to AT-286

AT-272
[EXC.F/EURO-OBD]
TROUBLE DIAGNOSIS — BASIC INSPECTION

5. CHECK LOCK-UP (D4 TO D4 L/U)
Check lock-up (D
4 to D4 L/U).
Specified speed when lock-up occurs. Refer to AT- 5 3 0 , "
VEHICLE SPEED WHEN PERFORMING LOCK-UP"
.
Read vehicle speed, throttle opening when lock-up duty
becomes 94%. Refer to AT- 2 4 4 , "
DATA MONITOR MODE (A/T)" .
Does A/T perform lock-up at the specified speed?
YES >> GO TO 6.
NO >>

Mark the box on the DIAGNOSTIC WORKSHEET.

GO TO AT- 3 11 , "A/T Does Not Perform Lock-Up" .

Continue “Road Test”.
6. CHECK HOLD LOCK-UP
Continue Road Test.
When lock-up duty becomes 94%. Refer to AT- 2 4 4 , "
DATA MONITOR MODE (A/T)" .
Does A/T hold lock-up condition for more than 30 seconds?
YES >> GO TO 7.
NO >>

Mark the box on the DIAGNOSTIC WORKSHEET.

GO TO AT- 3 1 2 , "A/T Does Not Hold Lock-Up Condition" .

Continue “Road Test”.
7. CHECK SHIFT DOWN (D4 L/U TO D4 )
Release accelerator pedal.
When lock-up duty becomes 4%. Refer to AT- 2 4 4 , "
DATA
MONITOR MODE (A/T)" .
Is lock-up released when accelerator pedal is released?
YES >> GO TO 8.
NO >>

Mark the box on the DIAGNOSTIC WORKSHEET.

GO TO AT- 3 1 4 , "Lock-Up Is Not Released" .

Continue “Road Test”.
8. CHECK SHIFT DOWN (D4 TO D3 )
Decelerate vehicle by applying foot brake lightly.
Read gear position and engine speed. Refer to AT- 2 4 4 ,
"DATA MONITOR MODE (A/T)" .
Does engine speed return to idle smoothly when A/T is shifted from
D4 to D3 ?
YES >> 1. Stop vehicle.
2. GO TO AT- 2 7 3 , "
Cruise Test — Part 2" .
NO >>

Mark the box on the DIAGNOSTIC WORKSHEET.

GO TO AT- 3 1 5 , "Engine Speed Does Not Return To
Idle (Light Braking D4 → D3 )" .

Continue “Road Test”.
SAT957I
SAT958I
SAT959I

CAN COMMUNICATION LINE
AT-329
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT

[ALL]CAN COMMUNICATION LINEPFP:31940
DescriptionECS004UJ
CAN (Control Area Network) is a serial communication line for real time application. It is an on-vehicle multi-
plex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
On Board Diagnosis LogicECS004UK
Possible CauseECS00CT9
Harness or connector
(CAN communication line is open or shorted.)
DTC Confirmation ProcedureECS004UL
NOTE:
If “DTC Confirmation Procedure” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Wait at least 6 seconds or start engine and wait for at least 6
seconds.
4. If DTC is detected, go to AT- 3 3 1 , "
Diagnostic Procedure" .
WITHOUT CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Wait at least 6 seconds or start engine and wait at least 6 sec-
onds.
3. Perform self-diagnosis.
Refer to AT- 5 2 , "
Diagnostic Procedure Without CONSULT-II" .
4. If DTC is detected, go to AT- 3 3 1 , "
Diagnostic Procedure" .
Diagnostic trouble code Malfunction is detected when... Check items (Possible cause)
: CAN COMM CIRCUIT
When a malfunction is detected in CAN
communication line.

Harness or connectors
(CAN communication line is open or
shorted.)
: 11th judgement flicker
SAT014K
SCIA4673E
