PERIODIC MAINTENANCE
MA-9
C
D
E
F
G
H
I
J
K
MA
B
MA

ENGINE AND EMISSION CONTROL MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage <30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, D = Check filter and drain water
NOTE:

Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”.

(1) If valve noise increases, check valve clearance.

(2) Never use CG-4 oil.

(3) Oil filter element assembly and O-ring seal are replacement parts.

(4) First replace at 100,000 Km (60,000 miles)/60 months, then every 60,000Km (36,000 miles)/36 months. After first
replacement, perform "I" (checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of
replacement interval.

(5) If engine power decreases, black exhaust smoke is emitted or engine noise increases, perform this maintenance item.
CHASSIS AND BODY MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage <30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L = Lubricate. MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence page Perform on a kilometer basis, but on an annual basis
when driving less than 20,000 km (12,000 miles) per
yearkm x 1,000
(Miles x
1,000)
Months20
(12)
1240
(24)
2460
(36)
3680
(48)
48100
(60)
60120
(72)
72
Engine compartment and under vehicle
Intake & exhaust valve clearanceSee
NOTE (1)EM-185
Drive belts I I I I I IMA-29
Engine oil (recommended oil.)See
NOTE (2)RRRRRRMA-35
Engine oil filter (Use Eco filter or equivalent)See
NOTE (3)RRRRRRMA-36
Engine anti-freeze coolant (Use Genuine Nissan
Anti-freeze Coolant (L250) or equivalent)See
NOTE (4)IRMA-30
Cooling system I I I I I IMA-32
Fuel lines I I IMA-34
Air cleaner filter RRMA-35
Fuel filterDRDRDRMA-34
Fuel injectorSee
NOTE (5)EM-167
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
page Perform on a kilometer basis, but on an annual
basis when driving less than 20,000 km
(12,000 miles) per yearkm x 1,000
(Miles x 1,000)
Months20
(12)
1240
(24)
2460
(36)
3680
(48)
48100
(60)
60120
(72)
72
Underhood and under vehicle
Headlamp aiming I I I I I ILT- 3 5
Brake & clutch, systems and fluid (For level &
leaks)IIIIIIMA-44,
MA-39
Brake fluidRRRMA-44
Brake booster vacuum hoses, connections &
check valveIIIBR-25
Power steering fluid & lines (For level & leaks) I I I I I IMA-45
Manual transaxle gear oil (For leaks) I I I I I IMA-39
Transfer gear oil (For level & leaks) I I I I I IMA-41

PERIODIC MAINTENANCE
MA-11
C
D
E
F
G
H
I
J
K
MA
B
MA

Maintenance operation: Check = Check and correct or replace as necessary.
Driving conditionMaintenance itemMainte-
nance
opera-
tionMaintenance intervalRefer-
ence
page
A...........Air cleaner filterPetrol models ReplaceEvery 30,000 km
(18,000 miles) or 24
monthsMA-24
Diesel models ReplaceEvery 30,000 km
(18,000 miles) or 18
monthsMA-35
ABCD
........Engine oil &
engine oil filter Petrol models ReplaceEvery 7,500 km (4,500
miles) or 6 monthsMA-24
,
MA-25
Diesel models ReplaceEvery 10,000 km (6,000
miles) or 6 monthsMA-35,
MA-36
A...E.......Fuel filter Diesel models Check &
drain
waterEvery 10,000 km (6,000
miles) or 6 monthsFL-17
ReplaceEvery 20,000 km
(12,000 miles) or 12
monthsMA-34
.....F......Brake fluidPetrol models ReplaceEvery 15,000 km (9,000
miles) or 12 monthsMA-44Diesel models ReplaceEvery 20,000 km
(12,000 miles) or 12
monthsMA-44
..C
....H
....Differential gear
oilPetrol models ReplaceEvery 30,000 km
(18,000 miles) or 24
monthsMA-43
Diesel models ReplaceEvery 30,000 km
(18,000 miles) or 18
monthsMA-43
..C....H....Automatic trans-
axle fluidPetrol models ReplaceEvery 30,000 km
(18,000 miles) or 24
monthsMA-41
......GH....Steering gear &
linkage, axle &
suspension parts,
propeller shaft,
front drive shafts
& exhaust systemPetrol models InspectEvery 7,500 km (4,500
miles) or 6 months for
4WD modelsMA-45
,
MA-46
,
MA-42
,
MA-46
,
MA-39Every 15,000km
(9,000miles) or 12
months for 2WD models
Diesel models InspectEvery 10,000 km (6,000
miles) or 6 months for
4WD modelsMA-45
,
MA-46
,
MA-42
,
MA-46
,
MA-39Every 20,000 km
(12,000 miles) or 12
months for 2WD models
A.C...GHI...Brake pads,
rotors & other
brake compo-
nentsPetrol models InspectEvery 7,500 km (4,500
miles) or 12 months for
2WDMA-45
,
MA-44
,
MA-45
Diesel models InspectEvery 10,000 km (6,000
miles) or 6 monthsMA-45
,
MA-44
,
MA-45
A...........Air conditioner fil-
terPetrol models ReplaceEvery 15,000 km (9,000
miles) or 12 monthsATC-130

Diesel models ReplaceEvery 10,000 km (6,000
miles) or 6 monthsATC-130

MA-12
PERIODIC MAINTENANCE

ENGINE AND EMISSION CONTROL MAINTENANCE (QR20DE AND QR25DE PETROL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace,.
NOTE:

Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”.

(1)Periodic maintenance is not required. However, if valve noise increases, check valve clearance.

(2) Replace the drive belt if found damaged or if the auto belt tensioner reading reaches the maximum limit.

(3) First replace at 90,000 Km (54,000 miles), then every 60,000 km (36,000 miles). Perform "I" (Checking the mixture ratio
and correcting the mixture ratio if necessary) at the middle of replacement interval.

(4) Fuel filter is maintenance-free. For service procedures, refer to FL section.

(5) For Russia only. MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence
page Perform at number of kilometers (miles) basis
only.km x
1,000
(Miles x
1,000)15
(9)30
(18)45
(27)60
(36)75
(45)90
(54)105
(63)120
(72)
Engine compartment and under vehicle
Intake and exhaust valve clearanceSee
NOTE (1)EM-64
Drive beltSee
NOTE (2)I IIIIIIIMA-20
Engine oil (Use recommended oil.)RRRRRRRRMA-24
Engine oil filter (Use NISSAN genuine part or
equivalent)RRRRRRRRMA-25
Engine anti-freeze coolant (Use Genuine NIS-
SAN Anti-freeze Coolant (L250) or equivalent.)See
NOTE (3)IRIMA-20
Cooling system I I I IMA-22
Fuel linesIIMA-24
Air cleaner filterRRMA-24
Fuel filter (In-tank type)See
NOTE (4)FL-4
Spark plugs (Conventional type) R R R RMA-26
Spark-plugs (Platinum-tipped type)See
NOTE (5)RRRRMA-26
EVAP vapor lines (With carbon canister) I IMA-28

PERIODIC MAINTENANCE
MA-13
C
D
E
F
G
H
I
J
K
MA
B
MA

CHASSIS AND BODY MAINTENANCE (QR20DE AND QR25DE PETROL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L = Lubricate.
NOTE:

(1) Inspect once per year.

Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”.
*: For 4WD models only. MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
page Perform at number of kilometers (miles)
basis only.km x 1,000
(Miles x
1,000)15
(9)30
(18)45
(27)60
(36)75
(45)90
(54)105
(63)120
(72)
Underhood and under vehicle
Headlamp aiming I I I ILT- 3 5
Brake & clutch, systems and fluid (For
level & leaks)IIIIMA-39,
MA-44
Brake fluidRRMA-44
Brake booster vacuum hoses, connec-
tions & check valveIIBR-25
Power steering fluid & lines (For level &
leaks)IIIIMA-45
Manual transaxle gear oil (For leaks) I I I IMA-39
Automatic transaxle fluid (For level &
leaks)IIIIMA-40
Transfer gear oil (For level & leaks) I I I IMA-41
Differential gear oil (For level & leaks or
replace)IIIIMA-43
Steering gear & linkage, axle & suspen-
sion parts, propeller shaft, front drive
shafts & exhaust systemI* I I* IMA-45,
MA-46
,
MA-42
,
MA-46
,
MA-39
Wheel alignment (If necessary, rotate &
balance wheels)IIIIFSU-6,
MA-43
Brake pads, rotors & other brake compo-
nentsIIIIMA-45,
MA-45
,
MA-44
Foot brake, parking brake & clutch (For
free play, stroke & operation)IIIIBR-6,
PB-3
CL-5
Air conditioner filterRRRRAT C - 1 3 0
Body corrosionSee
NOTE (1)MA-48

MA-14
PERIODIC MAINTENANCE

ENGINE AND EMISSION CONTROL MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, D = Check filter and drain water
NOTE:

Maintenance items with “ ” should be performed more frequently according to “Maintenance Under Severe Driving
Conditions”.

(1) If valve noise increases, check valve clearance.

(2) Never use CG-4 oil.

(3) Oil filter element assembly and O-ring seal are replacement parts.

(4) First replace at 100,000 Km (60,000 miles), then every 60,000Km (36,000 miles). After first replacement, perform "I"
(checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.

(5) If engine power decreases, black exhaust smoke is emitted or engine noise increases, perform this maintenance item.
CHASSIS AND BODY MAINTENANCE (YD22DDTI DIESEL ENGINE)
(Annual Mileage >30,000 Km/year)
Abbreviations: I = Inspect and correct or replace as necessary, R = Replace, L = Lubricate. MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence page
Perform at number of kilometers (miles) basis only.km x 1,000
(Miles x
1,000)20
(12)40
(24)60
(36)80
(48)100
(60)120
(72)
Engine compartment and under vehicle
Intake & exhaust valve clearanceSee
NOTE (1)EM-185
Drive belts I I I I I IMA-29
Engine oil (Use recommended oil.)See
NOTE (2)RRRRRRMA-35
Engine oil filter (Use Eco filter or equivalent)See
NOTE (3)RRRRRRMA-36
Engine anti-freeze coolant (Use Genuine NISSAN
Anti-freeze Coolant (L250) or equivalent)See
NOTE (4)IRMA-30
Cooling system IIIIIIMA-32
Fuel linesIIMA-34
Air cleaner filter RRMA-35
Fuel filterDDRDDRMA-34
Fuel injectorSee
NOTE (5)EM-167
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
page
Perform at number of kilometers (miles) basis only.km x 1,000
(Miles x
1,000)20
(12)40
(24)60
(36)80
(48)100
(60)120
(72)
Underhood and under vehicle
Headlamp aiming I I ILT- 3 5
Brake & clutch, systems and fluid (For level & leaks) IIIIIIMA-44,
MA-39
Brake fluidRRMA-44
Brake booster vacuum hoses, connections & check
valveIIBR-25
Power steering fluid & lines (For level & leaks) IIIIIIMA-45
Manual transaxle gear oil (For leaks) I I IMA-39
Transfer gear oil (For level & leaks)IIIIIIMA-41
Differential gear oil (For level & leaks or replace)IIIIIIMA-43

MA-16
PERIODIC MAINTENANCE

ABCD
........Engine oil &
engine oil filter Petrol models ReplaceEvery 7,500 km
(4,500 miles) MA-24
,
MA-25
Diesel models ReplaceEvery 10,000 km
(6,000 miles) MA-35,
MA-36
A...E.......Fuel filter Diesel models Check &
drain
waterEvery 10,000 km
(6,000 miles) FL-17
ReplaceEvery 30,000 km
(18,000 miles) MA-34
.....F......Brake fluidPetrol models ReplaceEvery 30,000 km
(18,000 miles) MA-44Diesel models ReplaceEvery 30,000 km
(18,000 miles) MA-44
..C
....H
....Differential gear
oilPetrol models ReplaceEvery 30,000 km
(18,000 miles) MA-43Diesel models ReplaceEvery 30,000 km
(18,000 miles) MA-43
..C....H....Automatic trans-
axle fluidPetrol models ReplaceEvery 60,000 km
(36,000 miles) MA-41
......GH....Steering gear &
linkage, axle &
suspension
parts, propeller
shaft, front drive
shafts & exhaust
systemPetrol models InspectEvery 15,000 km (9,000
miles) for 4WD modelsMA-45
,
MA-46
,
MA-42
,
MA-46
,
MA-39Every 30,000 km
(18,000 miles) for 2WD
models
Diesel models InspectEvery 15,000 km (9,000
miles) for 4WD modelsMA-45
,
MA-46
,
MA-42
,
MA-46
,
MA-39Every 30,000 km
(18,000 miles) for 2WD
models
A.C...GHI...Brake pads,
rotors & other
brake compo-
nentsPetrol models InspectEvery 15,000 km
(9,000 miles) MA-45
,
MA-44
,
MA-45
Diesel models InspectEvery 10,000 km
(6,000 miles) MA-45
,
MA-44
,
MA-45
A...........Air conditioner
filterPetrol models ReplaceEvery 15,000 km
(9,000 miles) ATC-130Diesel models ReplaceEvery 10,000 km
(6,000 miles) ATC-130
Driving conditionMaintenance itemMainte-
nance
opera-
tionMaintenance intervalRefer-
ence
page

MA-22
ENGINE MAINTENANCE (QR20DE·QR25DE)

FLUSHING COOLING SYSTEM
1. Install reservoir tank if removed, and radiator drain plug.
CAUTION:
Be sure to clean drain plug and install with new O-ring.

If water drain plug on cylinder block is removed, close and tighten it. Refer to EM-89, "CYLIN-
DER BLOCK" .
2. Fill radiator and reservoir tank with water and reinstall radiator cap.
3. Run the engine and warm it up to normal operating temperature.
4. Rev the engine two or three times under no-load.
5. Stop the engine and wait until it cools down.
6. Drain water from the system. Refer to MA-20, "
DRAINING ENGINE COOLANT" .
7. Repeat steps 1 through 6 until clear water begins to drain from radiator.
Checking Cooling SystemELS000ZF
WARNING:

Do not remove radiator cap when the engine is hot. Serious burns occur from high-pressure
engine coolant escaping from radiator.

Wrap a thick cloth around radiator cap and carefully remove the cap. First, turn the cap a quarter
of a turn to release built-up pressure. Then turn the cap all the way.
CHECKING COOLING SYSTEM HOSES
Check hoses for improper attachment, leaks, cracks, damage, loose connections, chafing and deterioration.
CHECKING RADIATOR
Check radiator for mud or clogging. If necessary, clean radiator as follows.

Be careful not to bend or damage radiator fins.

When radiator is cleaned without removal, remove all surrounding parts such as cooling fan, radiator
shroud and horns. Then tape harness and connectors to prevent water from entering.
1. Apply water by hose to the back side of the radiator core vertically downward.
2. Apply water again to all radiator core surface once per minute.
3. Stop washing if any stains no longer flow out from the radiator.
4. Blow air into the back side of radiator core vertically downward.

Use compressed air lower than 490 kPa (4.9 bar, 5 kg/cm2 , 71 psi) and keep distance more than 30 cm
(11.8 in).
5. Blow air again into all the radiator core surfaces once per minute until no water sprays out.
CHECKING RADIATOR CAP

Check valve seat of radiator cap.
–Check if valve seat is swollen to the extent that the edge of the
plunger cannot be seen when watching it vertically from the top.
–Check if valve seat has no soil and damage.
PBIC2816E

MA-24
ENGINE MAINTENANCE (QR20DE·QR25DE)

Checking Fuel LinesELS000ZG
Inspect fuel lines, filler cap and tank for improper attachment, leaks,
cracks, damage, loose connections, chafing or deterioration. If nec-
essary, repair or replace damaged parts.
Changing Air Cleaner FilterELS000ZH
VISCOUS PAPER TYPE
The viscous paper type filter does not need cleaning between
replacement intervals. Refer to MA-7, "
PERIODIC MAINTE-
NANCE" .
Changing Engine OilELS000ZI
WARNING:

Be careful not to burn yourself, as engine oil may be hot.

Prolonged and repeated contact with used engine oil may cause skin cancer; try to avoid direct
skin contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand
cleaner as soon as possible.
1. Warm up engine, put vehicle horizontally and check for oil leakage from engine components. Refer to LU-
7, "ENGINE OIL LEAKAGE" .
2. Stop engine and wait for 10 minutes.
3. Loosen oil filler cap and then remove drain plug.
4. Drain engine oil.
5. Install drain plug with new washer. Refer to EM-27, "
OIL PAN
AND OIL STRAINER" .
CAUTION:
Be sure to clean drain plug and install with new washer.
6. Refill with new engine oil.
Engine oil specification and viscosity:
Refer to MA-17, "
RECOMMENDED FLUIDS AND LUBRICANTS" .
Engine oil capacity (Approximate):
Unit: (lmp qt)
SMA803A
PBIC0526E
Oil pan drain plug:
: 34.3 N·m (3.5 kg-m, 25 ft-lb)
PBIC2410E
Drain and refill With oil filter change 4.1 (3-5/8)
Without oil filter change 3.7 (3-1/4)
Dry engine (Overhaul)4.7 (4-1/8)
