ATC-158
REFRIGERANT LINES

Removal and Installation of Dual-pressure SwitchEJS00289
REMOVAL
1. Use a refrigerant collecting equipment (for HFC-134a) to discharge the refrigerant.
2. Remove liquid tank. Refer to ATC-156, "
Removal and Installation of Liquid Tank" .
3. Using a vise, secure liquid tank, and remove dual-pressure
switch.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:

Apply compressor oil to O-ling of dual pressure switch when installing it.

When recharging refrigerant, check for leaks.
Removal and Installation of EvaporatorEJS000VG
REMOVAL
1. Use a refrigerant collecting equipment (for HFC-134a) to discharge the refrigerant.
2. Remove extension cowl top panel.
3. Disconnect low-pressure flexible hose and high-pressure pipe
from evaporator.
CAUTION:
Cap or wrap the joint of low-pressure flexible hose and
high-pressure pipe with a suitable material such as a vinyl
tape to avoid the entry of air.
4. Remove mounting screws, and then remove expansion valve
cover.
5. Remove mounting bolts, and then remove expansion valve.
6. Remove blower unit. Refer to ATC-125, "
BLOWER UNIT" .
RJIA0699E
Tightening torque :10.8 N·m (1.1 kg-m, 8.0 ft-lb)
RJIA0082E
RJIA2423E

REFRIGERANT LINES
ATC-159
C
D
E
F
G
H
I
K
L
MA
B
AT C

7. Remove foot duct (passenger side).
8. Remove mounting screws, and then remove evaporator cover.
9. Slide evaporator, and then remove it from heater & cooling unit.
10. Remove intake sensor from evaporator, and then remove evap-
orator.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:

Replace the O-rings of low-pressure flexible hose and high-pressure pipe with new ones, then
apply compressor oil to them when installing them.

Mark the mounting position of intake sensor bracket.

When recharging refrigerant, check for leaks.
Removal and Installation of Expansion ValveEJS004GG
REMOVAL
1. Use a refrigerant collecting equipment (for HFC-134a) to discharge the refrigerant.
2. Remove extension cowl top panel.
3. Disconnect low-pressure flexible hose and high-pressure pipe from evaporator.
CAUTION:
Cap or wrap the joint of low-pressure flexible hose and high-pressure pipe with a suitable material
such as a vinyl tape to avoid the entry of air.
4. Remove mounting screws, and then remove expansion valve
cover.
5. Remove mounting bolts, and then remove expansion valve.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:

Replace the O-rings of expansion valve and piping with new ones, and then apply compressor oil
to them when installing them.

When recharging refrigerant, check for leaks.
RJIA0084E
RJIA0051E
RJIA2423E

ATC-160
REFRIGERANT LINES

Checking for Refrigerant LeaksEJS000VJ
Perform a visual inspection of all refrigeration parts, fittings, hoses and components for signs of A/C lubricant
leakage, damage and corrosion. A/C lubricant leakage may indicate an area of refrigerant leakage. Allow
extra inspection time in these areas when using either an electronic refrigerant leak detector or fluorescent
dye leak detector.
If dye is observed, confirm the leak with an electronic refrigerant leak detector. It is possible a prior leak was
repaired and not properly cleaned.
When searching for leaks, do not stop when one leak is found but continue to check for additional leaks at all
system components and connections.
When searching for refrigerant leaks using an electronic leak detector, move the probe along the suspected
leak area at 1 to 2 inches per second and no further than 1/4 inch from the component.
CAUTION:
Moving the electronic leak detector probe slower and closer to the suspected leak area will improve
the chances of finding a leak.
Checking System for Leaks Using the Fluorescent Leak DetectorEJS000VK
1. Check A/C system for leaks using the UV lamp and safety goggles (J-42220) in a low sunlight area (area
without windows preferable). Illuminate all components, fittings and lines. The dye will appear as a bright
green/yellow area at the point of leakage. Fluorescent dye observed at the evaporator drain opening indi-
cates an evaporator core assembly (tubes, core or expansion valve) leak.
2. If the suspected area is difficult to see, use an adjustable mirror or wipe the area with a clean shop rag or
cloth, with the UV lamp for dye residue.
3. After the leak is repaired, remove any residual dye using dye cleaner (J-43872) to prevent future misdiag-
nosis.
4. Perform a system performance check and verify the leak repair with an approved electronic refrigerant
leak detector.
NOTE:
Other gases in the work area or substances on the A/C components, for example, anti-freeze, windshield
washer fluid, solvents and lubricants, may falsely trigger the leak detector. Make sure the surfaces to be
checked are clean.
Clean with a dry cloth or blow off with shop air.
Do not allow the sensor tip of the detector to contact with any substance. This can also cause false readings
and may damage the detector.
Dye InjectionEJS000VL
(This procedure is only necessary when recharging the system or when the compressor has seized and was
replaced.)
1. Check A/C system static (at rest) pressure. Pressure must be at least 345 kPa (3.45 bar, 3.52 kg/cm
2 , 50
psi).
2. Pour one bottle (1/4 ounce / 7.4 cc) of the A/C refrigerant dye into the injector tool (J-41459).
3. Connect the injector tool to the A/C LOW-PRESSURE side service fitting.
4. Start engine and switch A/C ON.
5. When the A/C operating (compressor running), inject one bottle (1/4 ounce / 7.4 cc) of fluorescent dye
through the low-pressure service valve using dye injector tool J-41459 (refer to the manufacture's operat-
ing instructions).
6. With the engine still running, disconnect the injector tool from the service fitting.
CAUTION:
Be careful the A/C system or replacing a component, pour the dye directly into the open system con-
nection and proceed with the service procedures.
7. Operate the A/C system for a minimum of 20 minutes to mix the dye with the system oil. Depending on the
leak size, operating conditions and location of the leak, it may take from minutes to days for the dye to
penetrate a leak and become visible.

ATC-164
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
CompressorEJS00281
LubricantEJS00282
RefrigerantEJS00283
Engine Idling SpeedEJS00284
Refer to EC-45, "Idle Speed and Ignition Timing Check" for QR engine (WITH EURO-OBD), EC-558, "Idle
Speed and Ignition Timing Check" for QR engine (WITHOUT EURO-OBD), EC-1012, "Basic Inspection" for
YD engine (WITH EURO-OBD) or EC-1382, "
Basic Inspection" for YD engine (WITHOUT EURO-OBD).
Belt TensionEJS00285
Refer to EM-13, "DRIVE BELTS" for QR engine or EM-140, "DRIVE BELTS" for YD engine.
ModelWith QR engine With YD engine
Calsonic Kansei make CWV-615MZEXEL VALEO CLIMATE CONTROL make
DKV-11G
Type V-6 variable displacement Vane rotary
Displacement
cm
3 (cu in)/revMax. 146 (8.91)
110 (6.71)
Min. 13.5 (0.824)
Cylinder bore × stroke
mm (in)35.2 (1.386) × [2.3 - 25.0 (0.091 - 0.984)] -
Direction of rotation Clockwise (viewed from drive end)
Drive beltPoly V
ModelWith QR engine With YD engine
Calsonic Kansei make CWV-615MZEXEL VALEO CLIMATE CONTROL
make DKV-11G
Name Nissan A/C System Oil Type S (DH-PS) Nissan A/C System Oil Type R (DH-PR)
Part number KLH00-PAGS0 KLH00-PAGR0
Capacity
m (lmp fl oz)Total in system 180 (6.3)
Compressor (Service part)
charging amount180 (6.3)
Ty p eHFC-134a (R-134a)
Capacity
kg (lb)0.55 (1.21)

AV-30
AUDIO

Trouble DiagnosesEKS00EHY
AUDIO UNIT
InspectionEKS00EHX
AUDIO UNIT
All voltage inspections are made with:

Ignition switch ON or ACC

Audio unit ON

Audio unit connected
ANTENNA
Using a jumper wire, clip an auxiliary ground between antenna and body.

If reception improves, check antenna ground (at body surface).

If reception does not improve, check main feeder cable for short circuit or open circuit.
Symptom Possible causes Repair order
Audio unit inoperative (no digital
display and no sound from speak-
ers).1. 10A fuse
2. 15A fuse
3. Audio unit ground
4. Audio unit1. Check 10A fuse [No. 4, located in fuse block
(J/B)]. Turn ignition switch ON and verify that
battery positive voltage is present at terminal
10 (with cassette deck), 3 (without cassette
deck) of audio unit.
2. Check 15A fuse (No. 32, located in fuse and
fusible link box) and verify that battery posi-
tive voltage is present at terminal 6 (with cas-
sette deck), 9 (without cassette deck) of
audio unit.
3. Check audio unit ground.
4. Remove audio unit for repair.
Individual rear speaker is noisy or
inoperative.1. Each speaker
2. Output circuit to each speaker1. Check speaker.
2. Check the output circuits to each speaker
between audio unit and each speaker.
AM/FM stations are weak or noisy. 1. Roof antenna
2. Audio unit ground
3. Audio unit1. Check roof antenna.
2. Check audio unit ground condition.
3. Remove audio unit for repair.
Audio unit generates noise in AM
and FM modes with engine run-
ning.1. Poor audio unit ground
2. Loose or missing ground bonding straps
3. Ignition condenser or rear window defogger
noise suppressor condenser
4. Ignition coil
5. Audio unit1. Check audio unit ground.
2. Check ground bonding straps.
3. Replace ignition condenser or rear window
defogger noise suppressor condenser.
4. Check ignition coil.
5. Remove audio unit for repair.
Audio unit generates noise in AM
and FM modes with accessories
on (switch pops and motor noise).1. Poor audio unit ground
2. Antenna
3. Accessory ground
4. Malfunctioning accessory1. Check audio unit ground.
2. Check antenna.
3. Check accessory ground.
4. Replace accessory.

NAVIGATION SYSTEM
AV-99
C
D
E
F
G
H
I
J
L
MA
B
AV

MAP DVD-ROM
DESTINATION, WAY POINTS OR MENU CONTENTS CANNOT BE CHOSEN OR SET
VOICE GUIDANCE
Symptom Possible cause Remedy
The message “Error” appears
after operation.Map DVD-ROM is soiled or partially damaged.Check the DVD-ROM and wipe it clean with a
soft cloth.
In case you see any damage, replace the
DVD-ROM.
Symptom Possible cause Remedy
Turn list is not displayed.Route calculation has not yet been requested.Set the destination and request route calcula-
tion.
The vehicle mark is not on the suggested route.Please drive the vehicle along the suggested
route.
Route guidance is off. Turn the route guidance on.
In re-routing, the way points are
not included in the calculation.The system has judged that the vehicle has
already passed the point.If you want to go to that point again, edit the
route again.
Route information is not dis-
played.Route calculation has not yet been requested.Set the destination and request route calcula-
tion.
The vehicle mark is not on the suggested route.Please drive the vehicle along the suggested
route.
Route guidance is off. Turn the route guidance on.
Route is not calculated automati-
cally.The vehicle is not running on a route that can
be calculated from.Enter the route that can be calculated from.
Alternatively, you can calculate the route man-
ually. In this case, the entire route will be cal-
culated again.
It is impossible to request a
detour.Your vehicle is not running on the suggested
route.Restart route calculation or join the suggested
route.
The detour found is the same as
the previous suggestion.The system took many conditions into consider-
ation, but the same result was obtained.This is not malfunction.
It is impossible to set the way-
points.The number of way points exceeds 5.It is impossible to set more than 5 way points.
Please divide them in groups to find them all.
Symptom Possible cause Remedy
The voice guidance is not avail-
able.Voice guidance is only available at certain inter-
sections marked with
. In some cases, the
guidance is not available even when the vehicle
should make a turn.System is not malfunction.
The vehicle is off the suggested route.Return to the recommended route or re-search
the route.
Voice guidance is set off. Turn the voice guidance on.
Route guidance is set off. Turn the route guidance on.
The guidance content does not
correspond to the actual condition.The content of the voice guidance may vary,
depending on the types of junctions to make
turns on.Follow the actual rules and regulations.

PS-1
POWER STEERING SYSTEM
G STEERING
CONTENTS
C
D
E
F
H
I
J
K
L
M
SECTION PS
A
B
PS

POWER STEERING SYSTEM
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Steering System .............................. 3
PREPARATION ........................................................... 4
Special Service Tools [SST] ..................................... 4
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 5
NVH Trouble shooting Chart .................................... 5
POWER STEERING FLUID ........................................ 6
Checking Fluid Level ................................................ 6
Checking Fluid Leakage ........................................... 6
Air Bleeding Hydraulic System ................................. 6
STEERING WHEEL .................................................... 8
On-Vehicle Inspection and Service .......................... 8
CHECKING CONDITION OF INSTALLATION ...... 8
CHECKING STEERING WHEEL PLAY ................ 8
CHECKING NEUTRAL POSITION STEERING
WHEEL ................................................................. 8
CHECKING STEERING WHEEL TURNING
FORCE .................................................................. 8
CHECKING FRONT WHEEL TURNING ANGLE ..... 9
Removal and Installation ........................................ 10
REMOVAL ........................................................... 10
INSTALLATION ................................................... 10
STEERING COLUMN ................................................11
Removal and Installation ......................................... 11
COMPONENT ...................................................... 11
REMOVAL OF LOWER SHAFT, HOLE COVER,
CLAMP AND HOLE COVER SEAL ..................... 11
INSTALLATION OF LOWER SHAFT, HOLE
COVER, CLAMP AND HOLE COVER SEAL ...... 12
REMOVAL OF STEERING COLUMN ASSEM-
BLY ...................................................................... 12
INSPECTION AFTER REMOVAL ....................... 13
INSTALLATION OF STEERING COLUMN
ASSEMBLY ......................................................... 13INSPECTION AFTER INSTALLATION ................ 13
Disassembly and Assembly .................................... 14
COMPONENT ..................................................... 14
DISASSEMBLY ................................................... 14
INSPECTION AFTER DISASSEMBLY ................ 14
ASSEMBLY ......................................................... 14
INSPECTION AFTER ASSEMBLY ...................... 15
POWER STEERING GEAR AND LINKAGE ............ 16
Removal and Installation ........................................ 16
COMPONENT ..................................................... 16
REMOVAL ........................................................... 16
INSTALLATION ................................................... 17
Disassembly and Assembly .................................... 18
COMPONENT ..................................................... 18
DISASSEMBLY ................................................... 19
INSPECTION AFTER DISASSEMBLY ................ 20
ASSEMBLY ......................................................... 22
POWER STEERING OIL PUMP ............................... 27
On-Vehicle Inspection and Service ......................... 27
OIL PUMP PULLEY HYDRAULIC PRESSURE
INSPECTION ...................................................... 27
Removal and Installation (QR20DE and QR25DE
Engine Models) ....................................................... 27
REMOVAL ........................................................... 27
INSTALLATION ................................................... 27
Disassembly and Assembly(QR20DE and
QR25DE Engine Models) ....................................... 28
INSPECTION BEFORE DISASSEMBLY ............. 28
DISASSEMBLY ................................................... 28
INSPECTION AFTER DISASSEMBLY ................ 29
ASSEMBLY ......................................................... 29
Removal and Installation (YD22DDTi Engine
Model) ..................................................................... 32
Disassembly and Assembly (YD22DDTi Engine
Model) ..................................................................... 33
INSPECTION BEFORE DISASSEMBLY ............. 33
DISASSEMBLY ................................................... 34
INSPECTION AFTER DISASSEMBLY ................ 35
ASSEMBLY ......................................................... 35

PS-6
POWER STEERING FLUID

POWER STEERING FLUIDPFP:KLF20
Checking Fluid LevelEGS001BV

Check fluid level with engine stopped.

Make sure that fluid level is between MIN and MAX.

Fluid levels at HOT and COLD are different. Do not confuse
them.
CAUTION:

The fluid level should not exceed the MAX line. Excessive
fluid will cause fluid leakage from the cap.

Do not reuse drained power steering fluid.

Recommended fluid is Type DEXRONTM III or equivalent.
Checking Fluid LeakageEGS001BW
Check hydraulic connections for fluid leakage, cracks, damage,
looseness, or wear.
1. Run engine until the fluid temperature reaches 50 to 80° C (122
to 176°F) in reservoir tank, and keep engine speed idle.
2. Turn steering wheel several times from full left stop to full right
stop.
3. Hold steering wheel at each lock position for five seconds and
carefully, check for fluid leakage.
CAUTION:
Do not hold the steering wheel in a locked position for more
than 10 seconds. (There is the possibility that oil pump may
be damaged.)
4. If fluid leakage at connections is noticed, then loosen flare nut and then retighten. Do not overtighten con-
nector as this can damage O-ring, washer and connector.
5. If fluid leakage from oil pump is noticed, check oil pump. Refer to PS-27, "
POWER STEERING OIL
PUMP" .
6. Check steering gear boots for accumulation of fluid indicating from steering gear.
Air Bleeding Hydraulic SystemEGS001BX
If air bleeding is not complete, the following symptoms can be observed.

Bubbles are created in reservoir tank.

Clicking noise can be heard from oil pump.

Excessive buzzing in the oil pump.
NOTE:
Fluid noise may occur in the steering gear or oil pump. This does not affect performance or durability of
the system.
1. Turn steering wheel several times from full left stop to full right stop with engine off.
CAUTION:
Turn steering wheel while filling reservoir tank with fluid so as not to lower fluid level below the
MIN line.
2. Start engine and hold steering wheel at each lock position for 3 seconds at idle to check for fluid leakage.
3. Repeat step 2 above several times at approximately 3 second intervals.
CAUTION:
Do not hold the steering wheel in a locked position for more than 10 seconds. (There is the possi-
bility that oil pump may be damaged.)
4. Check fluid for bubbles and while contamination.HOT : Fluid temperature 50 - 80 °C (122 - 176°F)
COLD : Fluid temperature 0 - 30°C (32 - 86°F)
SGIA0232J
SGIA0506E
