MT-1
MANUAL TRANSAXLE
C TRANSMISSION/TRANSAXLE
CONTENTS
D
E
F
G
H
I
J
K
L
M
SECTION MT
A
B
MT
MANUAL TRANSAXLE
PRECAUTIONS .......................................................... 3
Service Notice or Precautions .................................. 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 6
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 8
NVH Troubleshooting Chart ..................................... 8
DESCRIPTION ............................................................ 9
Cross-Sectional View ............................................... 9
DOUBLE-CONE SYNCHRONIZER ..................... 11
TRIPLE-CONE SYNCHRONIZER ....................... 11
REVERSE GEAR NOISE PREVENTION FUNC-
TION (SYNCHRONIZING METHOD) .................. 11
M/T OIL ..................................................................... 12
Changing M/T Oil ................................................... 12
DRAINING ........................................................... 12
FILLING ............................................................... 12
Checking M/T Oil .................................................... 12
OIL LEAKAGE AND OIL LEVEL ......................... 12
SIDE OIL SEAL ........................................................ 14
Removal and Installation ........................................ 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 14
POSITION SWITCH .................................................. 15
Checking ................................................................ 15
BACK-UP LAMP SWITCH .................................. 15
PARK/NEUTRAL POSITION SWITCH ............... 15
CONTROL LINKAGE ............................................... 16
Components of Control Device and Cable ............. 16
Removal and Installation ........................................ 17
AIR BREATHER HOSE ............................................ 18
Removal and Installation ........................................ 18
TRANSAXLE ASSEMBLY ........................................ 19
Removal and Installation ........................................ 19
COMPONENTS .................................................. 19
REMOVAL ........................................................... 20
INSTALLATION ................................................... 21
Disassembly and Assembly (RS5F51A) ................ 22
COMPONENTS .................................................. 22DISASSEMBLY ................................................... 26
ASSEMBLY ......................................................... 30
ADJUSTMENT .................................................... 36
Disassembly and Assembly (RS6F51A) ................. 40
COMPONENTS ................................................... 40
DISASSEMBLY ................................................... 44
ASSEMBLY ......................................................... 48
ADJUSTMENT .................................................... 54
INPUT SHAFT AND GEARS .................................... 58
Disassembly and Assembly (RS5F51A) ................. 58
DISASSEMBLY ................................................... 58
INSPECTION AFTER DISASSEMBLY ................ 59
ASSEMBLY ......................................................... 62
Disassembly and Assembly (RS6F51A) ................. 66
DISASSEMBLY ................................................... 66
INSPECTION AFTER DISASSEMBLY ................ 67
ASSEMBLY ......................................................... 69
MAINSHAFT AND GEARS ....................................... 73
Disassembly and Assembly (RS5F51A) ................. 73
DISASSEMBLY ................................................... 73
INSPECTION AFTER DISASSEMBLY ................ 74
ASSEMBLY ......................................................... 76
Disassembly and Assembly (RS6F51A) ................. 80
DISASSEMBLY ................................................... 80
INSPECTION AFTER DISASSEMBLY ................ 81
ASSEMBLY ......................................................... 83
REVERSE IDLER SHAFT AND GEARS .................. 89
Disassembly and Assembly (RS5F51A) ................. 89
DISASSEMBLY ................................................... 89
INSPECTION AFTER DISASSEMBLY ................ 89
ASSEMBLY ......................................................... 90
Disassembly and Assembly (RS6F51A) ................. 90
DISASSEMBLY ................................................... 90
INSPECTION AFTER DISASSEMBLY ................ 91
ASSEMBLY ......................................................... 91
FINAL DRIVE ............................................................ 93
Disassembly and Assembly (RS5F51A) ................. 93
PRE-INSPECTION .............................................. 93
DISASSEMBLY ................................................... 93
INSPECTION AFTER DISASSEMBLY ................ 94
PRECAUTIONS
MT-3
D
E
F
G
H
I
J
K
L
MA
B
MT
PRECAUTIONSPFP:00001
Service Notice or PrecautionsECS008BM
Do not reuse transaxle oil, once it has been drained.
Check oil level or replace oil with vehicle on level surface.
During removal or installation, keep inside of transaxle clear of dust or dirt.
Check for the correct installation status prior to removal or disassembly. If matching mark are required, be
certain they do not interfere with the function of the parts they are applied.
In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If
tightening sequence is specified, use it.
Be careful not to damage sliding surfaces and mating surfaces.
MT-8
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartECS008BP
Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
tion. If necessary, repair or replace these parts.
Reference pageMA-39
MT-22
(RS5F51A), MT-40
(RS6F51A)
MT-16
MT-25
(RS5F51A), MT-43
(RS6F51A)
MT-23
(RS5F51A), MT-41
(RS6F51A)
SUSPECTED PARTS
(Possible cause)
OIL (Oil level is low.)
OIL (Wrong oil.)
OIL (Oil level is high.)
GASKET (Damaged)
OIL SEAL (Worn or damaged)
O-RING (Worn or damaged)
SHIFT CONTROL LINKAGE (Worn)
CHECK PLUG RETURN SPRING AND CHECK BALL (Worn or damaged)
SHIFT FORK (Worn)
GEAR (Worn or damaged)
BEARING (Worn or damaged)
BAULK RING (Worn or damaged)
INSERT SPRING (Damaged)
SymptomsNoise 1 2 3 3
Oil leakage 31222
Hard to shift or will not shift 1 1 2 3 3
Jumps out of gear 1 2 3 3
MT-12
M/T OIL
M/T OILPFP:KLD20
Changing M/T OilECS008BR
DRAINING
1. Start engine and let it run to warm up transaxle.
2. Stop engine. Remove drain plug and then drain oil.
3. Set a gasket on drain plug and install it to transaxle case. Tighten drain plug to the specified torque. Refer
to MT-22, "
Case and Housing Components" (RS5F51A) or MT-40, "Case and Housing Components"
(RS6F51A).
CAUTION:
Do not reuse gasket.
FILLING
1. Remove plug (for 2WD models) or filler plug (for 4WD models).
Fill with new oil to transaxle.
2. After refilling oil, check oil level.
3. Set a O-ring on plug (for 2WD models) or gasket on filler plug
(for 4WD models) and then install it to clutch housing.
CAUTION:
Do not reuse O-ring or gasket.
4. Tighten plug mounting bolt (for 2WD models) or filler plug (for 4WD models) to the specified torque. Refer
to MT-22, "
Case and Housing Components" (RS5F51A) or MT-40, "Case and Housing Components"
(RS6F51A).
Checking M/T OilECS008BS
OIL LEAKAGE AND OIL LEVEL
Make sure that oil is not leaking from transaxle or around it.
Remove plug (for 2WD models) or filler plug (for 4WD models).
Measure oil level using a suitable gauge as shown in the figure, and then check if it is within the specifica-
tions.
CAUTION:
Do not start engine while checking oil level.
–For 2WD modelsOil grade and viscosity: Refer to MA-17, "
Fluids and
Lubricants" .
Oil capacity (reference):
Approx. 2.2 (3-7/8 lmp pt)
PCIB1572E
Oil level “L” : 55.0 - 61.0 mm (2.17 - 2.40 in)
PCIB1477E
MT-14
SIDE OIL SEAL
SIDE OIL SEALPFP:32113
Removal and InstallationECS008BT
REMOVAL
Clutch housing side oil seal used on 4WD vehicles is attached to transfer. Be sure to replace it
when transfer is removed.
1. Remove drive shaft from transaxle. Refer to FAX-11, "
Removal and Installation" .
2. Remove oil seal with a flat-bladed screwdriver.
CAUTION:
Be careful not to damage the case surface when removing
oil seal.
INSTALLATION
1. Using the drift, drive the oil seal straight until it protrudes from
the case end equal to dimension A shown in the figure.
CAUTION:
Apply multi-purpose grease onto oil seal lip. (For clutch
housing side of 4WD models)
Do not reuse oil seal.
2. Install all parts in the reverse order of removal and check oil
level after installation. Refer to MT-12, "
Checking M/T Oil" .
SCIA0824E
Dimension “A”
: Within 0.5 mm (0.020 in) of flush with the case.
Drift to be used:
Transaxle case side : ST30720000
Clutch housing side : ST30720000
SCIA1776E
TRANSAXLE ASSEMBLY
MT-21
D
E
F
G
H
I
J
K
L
MA
B
MT
17. Remove transaxle assembly from the vehicle.
CAUTION:
Secure transaxle assembly to a jack while removing it.
INSTALLATION
Note the following, and install in the reverse order of removal.
When installing the transaxle assembly to the engine, install the mounting bolts following the standard
below.
CAUTION:
When installing transaxle assembly, be careful not to bring transaxle input shaft into contact with
clutch cover.
–QR engine models
*: Tightening the bolt for 4WD models.
–YD engine models
After installation, check oil level, and check for leaks and loose
mechanisms. Refer to MT-12, "
Checking M/T Oil" .
MTD0062D
Bolt No. 1 2 3* 4 5 6
Quantity 2 1 1 2 2 2
Bolt length “ ”
mm (in)40
(1.57)75
(2.95)45
(1.77)40
(1.57)30
(1.18)40
(1.57)
Tightening torque
N·m (kg - m, ft- lb)74.5
(7.6, 55)42.7
(4.4, 31)35.3
(3.6, 26)
SCIA0353E
Bolt No. 1 2 3 4 5 6
Quantity 2 2 1 1 3 1
Bolt length “ ”
mm (in)55
(2.17)50
(2.76)120
(4.72)45
(1.77)40
(1.57)35
(1.38)
Tightening torque
N·m (kg - m, ft- lb)44
(4.5, 32)33.5
(3.4, 25)
SCIA0748E
TRANSAXLE ASSEMBLY
MT-27
D
E
F
G
H
I
J
K
L
MA
B
MT
5. Remove check plugs (3 pieces), check springs (3 pieces), check
balls (3 pieces) and shift check sleeve (1 piece).
6. Remove transaxle case mounting bolts.
7. Remove bore plug from transaxle case.
CAUTION:
Be careful not to damage transaxle case.
8. While spreading the snap ring of mainshaft rear bearing located
at bore plug hole, remove transaxle case from clutch housing.
9. Remove oil gutter, baffle plate from transaxle case.
10. Remove snap ring, mainshaft rear bearing adjusting shim from
transaxle case.
11. Remove input shaft rear bearing adjusting shim and reverse
idler gear adjusting shim.
12. Remove differential side bearing outer race from transaxle case
using the puller, and then remove differential side bearing
adjusting shim from transaxle case.
13. Remove welch plug from transaxle case.
SCIA0396E
SCIA0983E
SCIA0897E
SCIA0402E
MT-28
TRANSAXLE ASSEMBLY
14. Remove differential side oil seal from transaxle case.
CAUTION:
Be careful not to damage transaxle case.
15. Remove magnet from clutch housing.
16. With shift lever in 5th position, remove mounting bolts from
reverse lever assembly. Lift reverse lever assembly to remove.
CAUTION:
Be careful not to lose shifter cap.
17. Pull out reverse fork rod then remove reverse shift fork.
18. Shift 3rd-4th fork rod to 3rd position. Remove retaining pin of 5th
shift fork using a pin punch.
19. Remove stopper rings for 5th-reverse bracket.
20. Pull out 5th-reverse fork rod and remove 5th shift fork and 5th-
reverse bracket.
21. Remove check balls (2 pieces) from clutch housing.
22. Remove retaining pin of 3rd-4th bracket using a pin punch.
23. Remove stopper rings for 3rd-4th shift fork.
24. Pull out 3rd-4th fork rod and remove 3rd-4th shift fork and 3rd-
4th bracket.
25. Remove interlock pin and shift check sleeve from clutch hous-
ing.
SCIA0397E
SCIA0390E
SCIA0391E
SCIA0392E
SCIA0393E
