STEERING
Wheel free play:Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II
or III
Tires
Ti r e siz e W heel siz e
P215/65R16 96T 240 (2.4, 35)
240 (2.4, 35) 1761/2JJ
P225/60R17 98T
Compact spare tire Ti r e siz e k P a (k gf / c m
2 or bar, psi) Wheel size
T155/80R17 101M 420 (4.2, 60) 17 4T
Wheel nut torque, N·m (kgf·m, ft·lbf): 103 (10.5, 76)
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire inflation pressure” through “Aluminum
wheel precautions”, pages 463 through 474, in Section 7 −2.
Tire size and cold tire inflation pressure:
Tire pressure,
kPa (kgf/cm
2 or bar, psi)
1661/2JJ

04 SIENNA_U (L/O 0408)
492
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
Engine compartment
Instrument panel (driver’s side)
Fuses (type A)1. ETCS 10 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system
2. EFI NO.1 20 A: Multiport fuel injection
system/se quential multiport fuel injec-
tion system, “EFI NO.2” fuse
3. HLP RL 15 A: Right−hand headlight
(low beam)
4. DRL 20 A: Daytime running light sys-
tem, “H −LP RH” and “H −LP LH” fuses
5. ALTS 7.5 A: Charging system
6. HLP LL 15 A: Left−hand headlight
(low beam), front fog lights
Instrument panel (passenger’s side)
7. DOOR NO.2 25 A: Power door lock
system
8. HAZ 15 A: Turn signal lights, emergen-
cy flashers
9. RAD NO.3 30 A: Audio system
10. A/F 25 A: A/F sensor
11. HORN 10 A: Horns
12. EFI NO.2 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
Fuses

04 SIENNA_U (L/O 0408)
493
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
13. DOME 10 A: Interior lights, personal
lights, vanity lights, door courtesy
lights, luggage compartment light, igni-
tion switch light, multi −information dis-
play
14. ECUB 10 A: Power sliding door, air
conditioning system, power windows,
multiplex communication system, meter
and gauge, wireless remote control
system
15. RAD NO.1 20 A: Audio system, navi-
gation system
16. SPARE 15 A: Spare fuse
17. SPARE 20 A: Spare fuse
18. SPARE 30 A: Spare fuse
19. SPARE 30 A: Spare fuse
20. SPARE 7.5 A: Spare fuse
21. HLP RH 10 A: Right−hand headlight
22. HLP LH 10 A: Left−hand headlight
23. RSE 7.5 A: Rear seat audio system,
rear seat entertainment system
24. MIR HTR 10 A: Outside rear view mir-
ror heaters
25. RAD2 7.5 A: Audio system, navigation
system, rear seat audio system, rear
seat entertainment system 26. PWR OUTLET 15 A:
Power outlets
27. CIG 15 A: Cigarette lighter
28. ECU ACC 7.5 A: Shift lock control
system, air c onditioning system, power
rear view mirror control
29. GAUGE2 7.5 A: Meter and gauge
30. IGN 7.5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, SRS airbag system, multiplex
communication system
31. INJ 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
32. RR WIP 15 A: Rear window wiper
33. WIP 30 A: Windshield wiper and rear
window wiper
34. GAUGE1 10 A: Back−up lights, turn
signal lights, emergency flashers
35. SHTR 15 A: Seat heaters
36. WSH 20 A: Windshield washer and
rear window washer
37. HTR 10 A: Air conditioning system 38. ECUIG 10 A:
Toyota park assist sys-
tem, rear view monitor system, multi-
plex communication system, multiport
fuel injection system/sequential multi-
port fuel injection system, anti −lock
brake system, traction control system,
vehicle stability control system, shift
lock control system, dynamic laser
cruise control system, seat heaters,
power back door, electronic moon roof,
multi −information display, auto anti−
glare inside rear view mirror, power
windows, power outlets (115V)
39. PANEL 10 A: Air conditioning system,
seat heaters, audio system, navigation
system, power sliding door, power back
door, multi −information display, rear
wi

ndow defogger, emergency flashers,
instrument panel lights, steering switch
lights
40. TAIL 10 A: Stop/tail lights, license
plate lights, parking lights, side marker
lights
41. S/ROOF 25 A: Electronic moon roof
42. AC INV 15 A: Power outlets (115V)
43. FR DEF 15 A: Windshield wiper de−
icer
44. AM1 7.5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system

04 SIENNA_U (L/O 0408)
494
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
45. STOP 10 A: Stop/tail lights, high
mounted stoplight, shift lock control
system, anti −lock brake system, trac-
tion control system, vehicle stability
control system, multiport fuel injection
system/s equential multiport fuel injec-
tion system, multiplex communication
system
46. P/W 25 A: Power windows
47. OBD 7.5 A: On−board diagnosis sys-
tem
48. FOG 15 A: Front fog lights
49. P/VENT 15 A: Power quarter windows
50. ST 7.5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
51. A/C 7.5 A: Manual air conditioning sys-
tem
Fuses (type B)
52. MAIN 30 A: Headlights, daytime run-
ning light system, “H −LP RL” and “H −
LP LL” fuses
53. AM2 30 A: “INJ”, “IGN” and “GAUGE2”
fuses
54. P/SEAT 30 A: Power seats
55. PWR 30 A: Power windows Fuses (type C)
56. SPARE 50 A: Spare fuse
57. HTR 50 A: Air conditioning system,
“A/C” fuse
58. FAN 50 A: Electric cooling fans
59. PBD 30 A: Power back door
60. RPSD 30 A: Right side power sliding
door
61. LPSD 30 A: Left side power sliding
door
62. RR A/C 40 A: Rear air conditioning
system
63. DEF 40 A: Rear window defogger,
“MIR HTR” fuse
64. ABS1 50 A: Anti−lock brake system,
traction control system, vehicle stability
control system
65. ABS2 30 A: Anti−lock brake system,
traction control system, vehicle stability
control system
66. ST 30 A: Starting system
Fuse (type D)
67. ALT 140 A: Charging system, “RR
A/C”, “HTR”, “FAN”, “PBD”, “R− PSD”,
“L −PSD” and “DEF” fuses

04 SIENNA_U (L/O 0408)
495
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS
Reporting safety defects for U.S. owners
Reporting safety defects for U.S. owners496
. . . . . . . . . . . . . . . . . . . . . .
SECTION 9

04 SIENNA_U (L/O 0408)
496
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately in-
form the National Highway Traffic
Safety Administration (NHTSA) in
addition to notifying Toyota Motor
Sales, U.S.A., Inc.
(Toll−free: 1 −800 −331 −4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of ve-
hicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or Toyota Motor
Sales, U.S.A., Inc. To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
toll
−free at 1 −800 −424 −9393 (or
366 −0123 in Washington, D.C.
area) or write to: NHTSA, U.S.
Department of Transportation,
Washington, D.C. 20590. You can
also obtain other information about
motor vehicle safety from the Hot-
line.
Reporting safety defects
for U.S. owners

04 SIENNA_U (L/O 0408)
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
Publication No. OM45422U
Part No. 01999-45422
Printed in Japan 01−0408 −00
Quick index
 If a service reminder indicator or warning buzzer comes on 167 . . . . . . . .
 If your vehicle will not start 406 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
 If your engine stalls while driving 409 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 If your vehicle overheats 410 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
 If you have a flat tire 411 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
 If your vehicle needs to be towed 427 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Tips for driving during break −in period 366 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 How to start the engine 394 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
 General maintenance 443 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Gas station information
Fuel type:
UNLEADED gasoline, Octane Rating 87 (Research Octane Number 91)
or higher.
See page 366 for detailed information.
Fuel tank capacity:
79 L (21 gal., 17.5 Imp. gal.)
Engine oil: API grade SL “Energy −Conserving” or ILSAC multigrade engine oil is
recommended.
See page 457 for detailed information.
Tire information: See pages 463 through 474.
Tire inflation pressure: See page 491.
gU3
C

04 SIENNA_U (L/O 0408)
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
You should know as much about the quality and
importance of proper main tenance of your new
vehicle as the people who built it.
The Toyota authorized Repair Manual
tells you how to maint ain your vehicle and
enables you to correct ly perform your own
maintenance.
The best way to keep your new vehicle in top
running order is to maintain it properly from
the moment you drive it off the showroom
floor.
The Toyota authorized Repair Manual is
