2004 TOYOTA SIENNA Owners Manual

04 SIENNA_U (L/O 0408)
411
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
1. Reduce your speed gradually,keeping a straight line. Move cau-
tiously off the road to a safe place
well away from the traffic. Avoid
stopping on the center divider of
a highway. Park on a level spot
with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission in “P”.
4. Have everyone get out of the ve- hicle on the side away from traffic.
5. Read the following instructions thoroughly.
NOTICE
Do not continue driving with a
deflated tire. Driving even a
short distance can damage a
tire and wheel beyond repair.
Some vehicles are equipped with
runflat (RFT) tires. The runflat
tire allows you to continue driving
for up to 160 km (100 miles) at a
speed below 90 km/h (55 mph)
even if any tire goes flat. However,
in some conditions (such as high
temperatures), you could not con-
tinue driving for up to 160 km (100
miles).
When the tire goes flat or when the
tire pressure is below 100 kPa (1.0
kgf/cm
2 or bar, 15 psi), the tire
must be replaced. If you are not
sure, consult your Toyota dealer.
Do not use the repaired tire. There is an “RFT” or “DSST” mark on
the sidewall of the run
−flat tire.
For details about the run −flat tire, see
“Run −flat tires” on page 469 in Sec-
tion 7 −2.
Vehicles with compact spare tire—
When you replace the tire, see
“—Compact spare tire” through “—Af-
ter changing wheels”, pages 413
through 425 in this Section.
If you have a flat tire—
—Standard tires information —Runflat tires information

04 SIENNA_U (L/O 0408)
412
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
CAUTION
As the runflat tire allows you to
continue driving if any tire goes
flat, the tire performance is not
the same as normal condition. If
the runflat tire goes flat, take
your vehicle to the nearest Toyo-
ta dealer or authorized tire dealer
as soon as possible, observing
the following instructions:
Decelerate as soon as possible
to the lowest appropriate
speed that conditions permit.
Do not drive for longer than
160 km (100 miles) or over 90
km/h (55 mph).
 Avoid abrupt steering wheel
maneuvering and braking. If
t h e veh i cl e ti res det eri o rat e,
you could lose control of the
steering wheel or the brakes,
causing death or serious inju-
ry.
Do not replace or repair the tire
by yourself. When the tires
must be replaced or repaired,
consult your Toyota dealer or
authorized tire dealer.NOTICE
 Take due care not to go over
a curb stone and be careful
of holes in the road because
deflated tire pressure affects
tire cushion performance.
The wheels, tires, body, sus-
pension and other compo-
nents could be damaged.
 Your ground clearance is re-
duced if the runflat tire
goes flat, so avoid driving
over obstacles and drive
slowly on rough, unp aved
roads and speed bumps.
Also, do not attempt to go
through an automatic car
wash as the vehicle may get
caught, resulting in damage.

04 SIENNA_U (L/O 0408)
413
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
Compact spare tire
The compact spare tire is designed
for temporary emergency use only.
The compact spare tire is identified
by the distinctive wording
“TEMPORARY USE ONLY” molded
into the side wall of the tire.
The compact spare tire saves space
in your luggage compartment, and its
lighter weight helps to improve fuel
economy and permits easier installa-
tion in case of a flat tire.The compact spare tire can be used
many times, if necessary. It has tread
life of up to 4800 km (3000 miles) de-
pending on road conditions and your
driving habits. When tread wear indi-
cators appear on the tire, replace the
tire.
See also the tire information on page
463 in Section 7−
2 for details on the
tread wear indicators and other ser-
vice information.CAUTION
 The compact spare tire was de-
signed especially for your To-
yota. Do not use it on any other
vehicle.
 Do not use more than one com-
pact spare tire at the same
time.
 The pressure for the compact
spare tire must be 420 kPa (4.2
kgf/cm
2 or bar, 60 psi).
 Do not exceed 80 km/h (50
mph) when driving with the
compact spare tire.
Replace the compact spare tire
with the standard tire as soon
as possible.
 Avoid sudden a cceleration,
sudden d eceleration and sharp
turns with the compact spare
tire.
NOTICE
Your ground clearance is re-
duced when the compact spare
tire is installed so avoid driving
over obstacles and drive slowly
on rough, unpaved roads and
speed bumps. Also, do not at-
tempt to go through an auto-
matic car wash as the vehicle
may get caught, resulting in
damage.
—Compact spare tire

04 SIENNA_U (L/O 0408)
414
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
1. Get the required tools andspare tire.
1. Wheel nut wrench
2. Jack handle
3. Jack
4. Spare tire
To prepare yourself for an emergency,
you should familiarize yourself with
the use of the jack, each of the tools
and their storage locations.To remove the tools, turn the knob
counterclockwise and remove the
cover.To remove the jack, turn the jack joint
by hand until the jack becomes free.
—Required tools and spare
tire (twowheel drive models)

04 SIENNA_U (L/O 0408)
415
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
To store the jack, turn the jack joint
until the jack base fits securely with
the vehicle body.
This prevents the jack from flying for-
ward during a collision or sudden
stop.To remove the wheel nut wrench, turn
the wingnut counterclockwise.
When storing the wheel nut wrench,
turn the wingnut clockwise and make
sure the wrench is securely held.To remove the spare tire:
1. Slide the front passenger ’s seat to the front −most lock position and
the right side second seat to the
rear −most lock position so they
will not interfere with the wheel nut
wrench.
Open the right side sliding door
and you will find the flap on the
floor. Pull back the flap to find the
spare tire clamp bolt.

04 SIENNA_U (L/O 0408)
416
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
2. Loosen the spare tire clamp boltby turning it counterclockwise with
the wheel nut wrench.3. After the tire is lowered completelyto the ground, remove the holding
bracket.
When storing the spare tire, put it in
place with the outer side of the wheel
facing up. Then secure the tire, taking
care that the tire goes straight up
without catching on any other part, to
prevent it from flying forward during
a collision or sudden braking.
As the tire carrier is designed for the
compact spare tire, the standard tire
cannot be stored there.
CAUTION
Do not remove the spare tire
when jacking up the vehicle. The
tire carrier and the spare tire may
interfere with the jack and cause
a serious accident.
NOTICE
 To secure spare tire clamp
bolt:
Do not use impact wrench,
but wheel nut wrench.
 After taking out or stowing
the spare tire, make sure to
secure the tire carrier by
tightening the clamp bolt to
prevent the holding bracket
from hitting the under body
of the vehicle during driving.
 Do not store the flat spare
tire with the tire carrier so it
may not be held securely.

04 SIENNA_U (L/O 0408)
417
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
1. Get the required tools andspare tire.
1. Wheel nut wrench
2. Jack handle
3. Jack
4. Spare tire
To prepare yourself for an emergency,
you should familiarize yourself with
the use of the jack, each of the tools
and their storage locations.To remove the tools, turn the knob
counterclockwise and remove the
cover.To remove the jack, turn the jack joint
by hand until the jack becomes free.
—Required tools and spare
tire (allwheel drive models)

04 SIENNA_U (L/O 0408)
418
2004 SIENNA from Aug. ’04 Prod. (OM45422U)
To store the jack, turn the jack joint
until the jack base fits securely with
the vehicle body.
This prevents the jack from flying for-
ward during a collision or sudden
stop.To remove the wheel nut wrench, turn
the wingnut counterclockwise.
When storing the wheel nut wrench,
turn the wingnut clockwise and make
sure the wrench is securely held.To remove the spare tire:
1. Remove the lid.
2. Loosen the nut and remove it.
3. Remove the spare tire cover.
4. Loosen the bolt, then remove the bolt and spacer.
Then take the spare tire out of the
vehicle.
