2004 TOYOTA LAND CRUISER Owners Manual

49
2004 L/C100 from Aug ’03 Prod. (OM60A04U)
For your safety and comfort, adjust the
head restraint before driving.
To raise: Pull it up.
To lower: Push it down while pressing the
lock release button.
Front head restraint only—You can also
move the head restraint forward or back-
ward. If such adjustment is desired, pull
or push the head restraint.
Rear center head restraint—When an oc-
cupant sits on the rear center seat, al-
ways pull up the rear center head re-
straint to the lock position.
The head restraint is most effective when
it is close to your head. Therefore, using
a cushion on the seatback is not recom-
mended.
CAUTION
Adjust the center of the head re-
straint so that it is closest to the
top of your ears.
After adjusting the head re-
straint, make sure it is locked in
position.
Do not drive with the head re-
straints removed.
Seat heaters
Left side
front seatRight side
front seat
To turn on the seat heater, push the
switch to “HI” (high heating tempera-
ture) or “LO” (low heating temperature).
To turn off the seat heater, push the
switch lightly on the opposite side.
The key must be in the “ON” position.
CAUTION
Occupants must use caution when op-
erating the seat heater because it
may make them feel too hot or cause
burns at low temperatures (erythema,
varicella). Use extra caution for;
Babies, small children, elderly
persons, sick persons or handi-
capped persons
Persons who have delicate skin
Persons who are exhausted
Persons who have taken alcohol
or drugs which induce sleep
(sleeping drug, cold remedy, etc.)
To prevent the seat from overheating,
do not use the seat heater with a
blanket, cushion, or other insulating
objects which cover the seat.

50
2004 L/C100 from Aug ’03 Prod. (OM60A04U)
NOTICE
Do not put unevenly weighed ob-
jects on the seat and do not stick
sharp objects (needles, nails, etc.)
into the seat.
 When cleaning the seats, do not
use organic substances (paint thin-
ner, benzine, alcohol, gasoline,
etc.). They may damage the heater
and seat surface.
 To prevent the battery from being
discharged, turn the switch off
when the engine is not running.
Toyota strongly urges that the driver and
passengers in the vehicle be properly re-
strained at all times with the seat belts
provided. Failure to do so could increase
the chance of injury and/or the severity of
injury in accidents.
The seat belts provided for your vehicle
are designed for people of adult size,
large enough to properly wear them.
Child. Use a child restraint system ap-
propriate for the child until the child be-
comes large enough to properly wear the
vehicle’s seat belts. (For details, see
“Child restraint” on page 79.)
If a child is too large for a child restraint
system, the child s hould sit in the rear
seat and must be restrained using the
vehicle’s seat belt. According to accident
statistics, the child is safer when properly
restrained in the rear seat than in the
front seat.
If a child must sit in the front seat, the
seat belts should be worn properly. If an
accident occurs and the seat belts are not
worn properly, the force of the rapid infla-
tion of the airbag may cause death or
serious injury to the child. Do not allow any children to stand up or
kneel on either rear or front seats. An
unrestrained child could suffer serious in-
jury or death during emergency braking or
a collision. Also, do not let the child sit
on your lap. Holding a child in your arms
does not provide sufficient restraint.
Pregnant woman.
Toyota recommends the
use of a seat belt. Ask your doctor for
specific recommendations. The lap belt
should be worn securely and as low as
possible over the hips and not on the
waist.
Injured person. Toyota recommends the
use of a seat belt. Depending on the inju-
ry, first check with your doctor for specific
recommendations.
Seat belts—
—Seat belt precautions

51
2004 L/C100 from Aug ’03 Prod. (OM60A04U)
CAUTION
Persons should ride in their seats
properly wearing their seat belts
whenever the vehicle is moving.
Otherwise, they are much more likely
to suffer serious bodily injury or
death in the event of sudden braking
or a collision.
When using the seat belts, observe
the following:
Use the belt for only one person
at a time. Do not use a single
belt for two or more people—ev-
en children.
To reduce the risk of sliding un-
der the lap belt during a colli-
sion, avoid reclining the seat-
back any more than needed. The
seat belts provide maximum
protection in a frontal or rear
collision when the driver and the
passengers are sitting up
straight and well back in the
seats. If you are reclined, the lap
belt may slide past your hips
and apply restraint forces direct-
ly to the abdomen. In the event
of a frontal collision, the more
the seat is reclined, the greater
the risk of personal injury.
Be careful not to damage the
belt webbing or hardware. Take
care that they do not get caught
or pinched in the seat or doors.
Inspect the belt system periodi-
cally. Check for cuts, fraying,
and loose parts. Damaged parts
should be replaced. Do not dis-
assemble or modify the system.
Keep the belts clean and dry. If
they need cleaning, use a mild
soap solution or lukewarm water.
Never use bleach, dye, or abra-
sive cleaners, or allow them to
come into contact with the belt—
they may severely weaken the
belts. (See “Cleaning the interi-
or” on page 276.)
Replace the belt assembly (in-
cluding bolts) if it has been
used in a severe impact. The en-
tire assembly should be replaced
even if damage is not obvious.

52
2004 L/C100 from Aug ’03 Prod. (OM60A04U)
Ta bBuckle
Adjust the seat as needed and sit up
straight and well back in the seat. To
fasten your belt, pull it out of the re-
tractor and insert the tab into the
buckle.
You will hear a click when the tab locks
into the buckle.
The seat belt length automatically adjusts
to your size and the seat position.
The retractor will lock the belt during a
sudden stop or on impact. It also may
lock if you lean forward too quickly. A
slow easy motion will allow the belt to
extend, and you can move around freely. When the shoulder belt is completely ex-
tended and is then retracted even slightly,
the belt is locked in that position and
cannot be extended. This feature is used
to hold the child restraint system securely.
(For details, see “Child restraint” on page
79.) To free the belt again, fully retract
the belt and then pull the belt out once
more.
If the seat belt cannot be pulled out of the
retractor, firmly pull the belt and release
it. You will then be able to smoothly pull
the belt out of the retractor.
CAUTION
After inserting the tab, make
sure the tab and buckle are
locked and that the lap and
shoulder portions of the belt are
not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent
you from properly latching the
tab and buckle.
If the seat belt does not function
normally, immediately contact
your Toyota dealer. Do not use
the seat until the seat belt is
fixed, because it cannot protect
an adult occupant or your child
from injury.
—Fastening 3point seat belts

53
2004 L/C100 from Aug ’03 Prod. (OM60A04U)
Ta k e u p
slack
Keep as low on hips as possible
To o h i g h
Adjust the position of the lap and
shoulder belts.
Position the lap belt as low as possible
on your hips–not on your waist, then ad-
just it to a snug fit by pulling the shoulder
portion upward through the latch plate.
CAUTION
Both highpositioned lap belts
and loosefitting belts could
cause serious injuries due to slid-
ing under the lap belt during a
collision or other unintended
event. Keep the lap belt posi-
tioned as low on hips as pos-
sible.
Do not place the shoulder belt
under your arm.
l13197b
Seat belts with an adjustable shoulder
anchor—
Adjust the shoulder anchor position to
your size.
To raise: Slide the anchor up.
To lower: Push in the lock release button
and slide the anchor down.
After adjustment, make sure the anchor is
locked in position.

54
2004 L/C100 from Aug ’03 Prod. (OM60A04U)
CAUTION
Always make sure the shoulder belt
is positioned across the center of
your shoulder. The belt should be
kept away from your neck, but not
falling off your shoulder. Failure to
do so could reduce the amount of
protection in an accident and cause
serious injuries in a collision.
To release the belt, press the buckle
release button and allow the belt to
retract.
If the belt does not retract smoothly, pull
it out and check for kinks or twists. Then
make sure it remains untwisted as it re-
tracts.
—Fastening 2point seat belt
Lengthen
Ta b
Buckle
Sit up straight and well back in the
seat. To fasten your belt, insert the tab
into the buckle.
You will hear a click when the tab locks
into the buckle.
If the belt is not long enough for you, hold
the tab at a right angle to the belt and
pull on the tab.

55
2004 L/C100 from Aug ’03 Prod. (OM60A04U)
CAUTION
After inserting the tab, make
sure the tab and buckle are
locked and that the lap portion
of the belt is not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent
you from properly latching the
tab and buckle.
If the seat belt does not function
normally, immediately contact
your Toyota dealer. Do not use
the seat until the seat belt is
fixed, because it cannot protect
an adult occupant or your child
from injury.
To o h i g h
Adjust to a snug fit
Keep as low on hips as possible
Remove excess length of the belt and
adjust the belt position.
To shorten the belt, pull the free end of
the belt.
Position the lap belt as low as possible
on your hips—not on your waist, then ad-
just it to a snug fit.
CAUTION
Both highpositioned and loosefit-
ting lap belts could cause serious in-
juries due to sliding under the lap belt
during a collision or other unintended
event. Keep the lap belt positioned as
low on hips as possible.
To release the belt, press the buckle
release button.

56
2004 L/C100 from Aug ’03 Prod. (OM60A04U)
—Seat belt extender
If your seat belt cannot be fastened se-
curely because it is not long enough, a
personalized seat belt extender is avail-
able from your Toyota dealer free of
charge.
Please contact your local Toyota dealer to
order the proper required length for the
extender. Bring the heaviest coat you ex-
pect to wear for proper measurement and
selection of length. Additional ordering in-
formation is available at your Toyota deal-
er.
CAUTION
When using the seat belt extender,
observe the following precautions.
Failure to follow these instructions
could reduce the effectiveness of the
seat belt restraint system in case of
an accident, increasing the chance of
personal injury.
Remember that the extender pro-
vided for you may not be safe
when used on a different vehicle,
for another person, or at a differ-
ent seating position than the one
originally intended.
If the seat belt extender has been
connected to the driver ’s seat belt
buckle without wearing the seat belt
when using the extender in the
driver ’s seat, the SRS driver ’s air-
bag system will judge that the driv-
er wears the seat belt even if not
wearing it. In this case, the driver ’s
airbag may not activate correctly,
causing death or serious injury in
the event of collision. Be sure to
wear the seat belt with the seat belt
extender.
Be sure to wear the seat belt with-
out the seat belt extender if you
can fasten the seat belt without the
extender.
Do not use the seat belt extender
when installing a child restraint
system on the front or rear passen-
ger seat. If installing a child re-
straint system with the seat belt
extender connected to the seat belt,
the seat belt will not securely hold
the child restraint system, which
could cause death or serious injury
to the child or other passengers in
the event of collision.
