2004 SUBARU FORESTER sensor

EN(H4DOTC 2.5)-151
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
AJ:DTC P0502 VEHICLE SPEED SENSOR CIRCUIT LOW INPUT
DTC DETECTING CONDITION:
Immediately at fault recognition
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode OPERATION, Clear Memory Mode.> and Inspection Mode Inspection Mode.>.
WIRING DIAGRAM:
EN-02368
i10
B135B21
123
4
56
78
9
1011 12
1314 15 16
B17
i3
567
82 1
94 310
24 22 23 2511 12 13 14 15
26 27
2816 17 18 19
20 21
29 30 31 32 33 34 35
E E
i10
B38
i3B17
E2 B21
B135B225 109
26
2
21
1
No.5
ECM
3
16
7
12
AT
:AT MODEL
MT
:MT MODEL
MT
AT
IGNITION
RELAYBATTERY
TCM
VEHICLE SPEED
SENSOR
COMBINATION
METERB56
3412
123456789101112131415161718192021222324252627282930
12
789 56 3
410 11 1219 20 21
29 30 31 13 14 15 1617
27 2818
22 23 24 25 26
B56
B225
RELAY BLOCK (BLACK)
10111213
1415161718
1920212223
2425262728
2930313233
3435363738
12
934
56
78
219
32
1234 5610 11 12 13 14 15716
23 3019 20
22 26 27 28 29817
24 3118
25

EN(H4DOTC 2.5)-152
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK HARNESS BETWEEN VEHICLE
SPEED SENSOR AND ECM CONNECTOR.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from vehicle
speed sensor ECM.
3) Measure the resistance of harness
between vehicle speed sensor connector and
chassis ground.
Connector & terminal
(B17) No. 1 — Chassis ground:Is the resistance more than 1
MΩ?Go to step 2.Repair ground short
circuit in harness
between vehicle
speed sensor and
ECM connector.
2 CHECK POOR CONTACT.
Check poor contact in vehicle speed sensor
connector.Is there poor contact in vehicle
speed sensor connector?Repair poor con-
tact in vehicle
speed sensor con-
nector.Replace the vehi-
cle speed sensor.
Vehicle Speed
Sensor.>

EN(H4DOTC 2.5)-153
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
AK:DTC P0503 VEHICLE SPEED SENSOR INTERMITTENT/ERRATIC/HIGH
DTC DETECTING CONDITION:
Immediately at fault recognition
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode OPERATION, Clear Memory Mode.> and Inspection Mode Inspection Mode.>.
WIRING DIAGRAM:
EN-02368
i10
B135B21
123
4
56
78
9
1011 12
1314 15 16
B17
i3
567
82 1
94 310
24 22 23 2511 12 13 14 15
26 27
2816 17 18 19
20 21
29 30 31 32 33 34 35
E E
i10
B38
i3B17
E2 B21
B135B225 109
26
2
21
1
No.5
ECM
3
16
7
12
AT
:AT MODEL
MT
:MT MODEL
MT
AT
IGNITION
RELAYBATTERY
TCM
VEHICLE SPEED
SENSOR
COMBINATION
METERB56
3412
123456789101112131415161718192021222324252627282930
12
789 56 3
410 11 1219 20 21
29 30 31 13 14 15 1617
27 2818
22 23 24 25 26
B56
B225
RELAY BLOCK (BLACK)
10111213
1415161718
1920212223
2425262728
2930313233
3435363738
12
934
56
78
219
32
1234 5610 11 12 13 14 15716
23 3019 20
22 26 27 28 29817
24 3118
25

EN(H4DOTC 2.5)-160
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
AN:DTC P0545 EXHAUST GAS TEMPERATURE SENSOR CIRCUIT LOW - BANK 1
DTC DETECTING CONDITION:
Immediately at fault recognition
TROUBLE SYMPTOM:
 Hard to start
 Erroneous idling
 Poor driving performance
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode OPERATION, Clear Memory Mode.> and Inspection Mode Inspection Mode.>.
WIRING DIAGRAM:
EN-02369
B1226
B136 ECM
35 24
B2791
2
B279
112
B122
B136
56
782 1
94 310
24 22 23 2511 12 13
1415
26 27
2816
17 18 19 20 21
33 34 29
32 30
31 35
EXHAUST GAS
TEMPERATURE
SENSOR
12345678

EN(H4DOTC 2.5)-161
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK CURRENT DATA.
1) Start the engine.
2) Read the data of exhaust temperature sen-
sor signal using Subaru Select Monitor or
OBD-II general scan tool.
N
OTE:
 Subaru Select Monitor
For detailed operation procedure, refer to
“READ CURRENT DATA SHOWN ON DIS-
PLAY FOR ENGINE”. 2.5)-27, Subaru Select Monitor.>
 OBD-II general scan tool
For detailed operation procedures, refer to the
OBD-II General Scan Tool Operation Manual.Is the temperature more than
1,200°C (2,192°F)?Go to step 2.Repair the poor
contact.
N
OTE:
In this case repair
the following:
 Poor contact of
exhaust tempera-
ture sensor
 Poor contact in
ECM
 Poor contact in
joint connector
2 CHECK HARNESS BETWEEN EXHAUST
TEMPERATURE SENSOR AND ECM CON-
NECTOR.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from exhaust
temperature sensor.
3) Turn the ignition switch to ON.
4) Read the data of exhaust temperature sen-
sor signal using Subaru Select Monitor or
OBD-II general scan tool.
N
OTE:
 Subaru Select Monitor
For detailed operation procedure, refer to
“READ CURRENT DATA SHOWN ON DIS-
PLAY FOR ENGINE”. 2.5)-27, Subaru Select Monitor.>
 OBD-II general scan tool
For detailed operation procedures, refer to the
OBD-II General Scan Tool Operation Manual.Is the temperature less than
372°C (702°F)?Replace the
exhaust tempera-
ture sensor. to FU(H4DOTC
2.5)-40, Exhaust
Temperature Sen-
sor.>Repair ground
short circuit in har-
ness between
exhaust tempera-
ture sensor and
ECM connector.

EN(H4DOTC 2.5)-162
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
AO:DTC P0546 EXHAUST GAS TEMPERATURE SENSOR HIGH - BANK 1
DTC DETECTING CONDITION:
Immediately at fault recognition
TROUBLE SYMPTOM:
 Hard to start
 Erroneous idling
 Poor driving performance
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode OPERATION, Clear Memory Mode.> and Inspection Mode Inspection Mode.>.
WIRING DIAGRAM:
EN-02369
B1226
B136 ECM
35 24
B2791
2
B279
112
B122
B136
56
782 1
94 310
24 22 23 2511 12 13
1415
26 27
2816
17 18 19 20 21
33 34 29
32 30
31 35
EXHAUST GAS
TEMPERATURE
SENSOR
12345678

EN(H4DOTC 2.5)-163
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
Step Check Yes No
1 CHECK CURRENT DATA.
1) Start the engine.
2) Read the data of exhaust temperature sen-
sor signal using Subaru Select Monitor or
OBD-II general scan tool.
N
OTE:
 Subaru Select Monitor
For detailed operation procedure, refer to
“READ CURRENT DATA SHOWN ON DIS-
PLAY FOR ENGINE”. 2.5)-27, Subaru Select Monitor.>
 OBD-II general scan tool
For detailed operation procedures, refer to the
OBD-II General Scan Tool Operation Manual.Is the temperature less than
372°C (702°F)?Go to step 2.Repair the poor
contact.
N
OTE:
In this case repair
the following:
 Poor contact of
exhaust tempera-
ture sensor
 Poor contact in
ECM
 Poor contact in
joint connector
2 CHECK HARNESS BETWEEN EXHAUST
TEMPERATURE SENSOR AND ECM CON-
NECTOR.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from exhaust
temperature sensor.
3) Measure the voltage between exhaust tem-
perature sensor connector and engine ground.
Connector & terminal
(B279) No. 1 (+) — Engine ground (
−):Is the voltage more than 10 V? Repair battery
short circuit in har-
ness between
ECM and exhaust
temperature sen-
sor connector.Go to step 3.
3 CHECK HARNESS BETWEEN EXHAUST
TEMPERATURE SENSOR AND ECM CON-
NECTOR.
1) Turn the ignition switch to ON.
2) Measure the voltage between exhaust tem-
perature sensor connector and engine ground.
Connector & terminal
(B279) No. 1 (+) — Engine ground (
−):Is the voltage more than 10 V? Repair battery
short circuit in har-
ness between
ECM and exhaust
temperature sen-
sor connector.Go to step 4.
4 CHECK HARNESS BETWEEN EXHAUST
TEMPERATURE SENSOR AND ECM CON-
NECTOR.
Measure the voltage between exhaust temper-
ature sensor connector and engine ground.
Connector & terminal
(B279) No. 1 (+) — Engine ground (
−):Is the voltage more than 4 V? Go to step 5.Repair the harness
and connector.
N
OTE:
In this case repair
the following:
 Open circuit in
harness between
ECM and exhaust
temperature sen-
sor connector
 Poor contact of
exhaust tempera-
ture sensor con-
nector
 Poor contact in
ECM connector.
 Poor contact in
joint connector

EN(H4DOTC 2.5)-164
ENGINE (DIAGNOSTIC)
Diagnostic Procedure with Diagnostic Trouble Code (DTC)
5 CHECK HARNESS BETWEEN EXHAUST
TEMPERATURE SENSOR AND ECM CON-
NECTOR.
1) Turn the ignition switch to OFF.
2) Measure the resistance of harness
between exhaust temperature sensor connec-
tor and engine ground.
Connector & terminal
(B279) No. 2 — Engine ground:Is the resistance less than 5
Ω?Replace the
exhaust tempera-
ture sensor. to FU(H4DOTC
2.5)-40, Exhaust
Temperature Sen-
sor.>Repair the harness
and connector.
N
OTE:
In this case repair
the following:
 Open circuit in
harness between
ECM and exhaust
temperature sen-
sor connector
 Poor contact of
exhaust tempera-
ture sensor con-
nector
 Poor contact in
ECM connector.
 Poor contact in
joint connector Step Check Yes No
