2004 SUBARU FORESTER glove box

SL-39
SECURITY AND LOCK
Keyless Entry Control Module
21.Keyless Entry Control Mod-
ule
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the glove box. AL, Glove Box.>
3) Remove the nut, and then remove the keyless
entry control module while disconnecting connec-
tor.
B: INSTALLATION
Install in the reverse order of removal.
SL-00047

EXTERIOR/INTERIOR TRIM
EI
Page
1. General Description ....................................................................................2
2. Front Grille ................................................................................................18
3. Hood Grille ................................................................................................19
4. Front Under Cover ....................................................................................22
5. Front Bumper ............................................................................................23
6. Rear Bumper .............................................................................................30
7. Mud Guard ................................................................................................31
8. Cowl Panel ................................................................................................32
9. Side Sill Spoiler .........................................................................................33
10. Side Garnish .............................................................................................34
11. Front Door Trim .........................................................................................35
12. Rear Door Trim .........................................................................................36
13. Glove Box..................................................................................................37
14. Roof Rail ...................................................................................................38
15. Console Box ..............................................................................................39
16. Instrument Panel Assembly ......................................................................40
17. Upper Inner Trim .......................................................................................43
18. Lower Inner Trim .......................................................................................44
19. Rear Quarter Trim .....................................................................................45
20. Sun Visor...................................................................................................46
21. Roof Trim ..................................................................................................47
22. Rear Gate Trim .........................................................................................48
23. Floor Mat ...................................................................................................49
24. Luggage Floor Mat ....................................................................................50
25. Instrument Panel Center Compartment ....................................................51
26. Heat Shield Cover .....................................................................................52

EI-12
EXTERIOR/INTERIOR TRIM
General Description
14.INSTRUMENT PANEL
 LHD MODEL
(1) Pad & frame (7) Center panel (13) Grille cover
(2) Center compartment (8) Air vent grille (14) Air vent grille (Defroster)
(3) Grille cover (9) Cup holder (15) Switch panel
(4) Lower cover (10) Glove box panel (16) Passenger’s airbag module
(5) Coin box (11) Glove box lid
(6) Meter visor (12) Steering beam
EI-00793
(9)
(14)
(16)
(4)
(3)
(2)
(13)
(12)
(11) (15)
(1)
(8)
(10)
(5)
(6)
(7)
A
A

EI-13
EXTERIOR/INTERIOR TRIM
General Description
 RHD MODEL
(1) Pad & frame (7) Center panel (13) Grille cover
(2) Center compartment (8) Air vent grille (14) Air vent grille (Defroster)
(3) Grille cover (9) Cup holder (15) Switch panel
(4) Lower cover (10) Glove box panel (16) Passenger’s airbag module
(5) Coin box (11) Glove box lid
(6) Meter cover (12) Steering beam
EI-00226
(12)
(14)
(3)
(2)
(11)
(10)
(9)(13)
(1)
(7)
(8)
(15)(4)
(5)
(6)A
A
(16)

EI-37
EXTERIOR/INTERIOR TRIM
Glove Box
13.Glove Box
A: REMOVAL
1) Open the glove box.
2) Loosen the screws to remove glove box.
B: INSTALLATION
Install in the reverse order of removal.
(A) Hook
(B) Clip
EI-00057
(B)
(A)
(B)

CC-7
CRUISE CONTROL SYSTEM
Cruise Control Module
3. Cruise Control Module
A: NOTE
Engine Control Module (ECM) controls cruise con-
trol system (Turbo model).
B: REMOVAL
1. NON-TURBO MODEL
1) Disconnect the ground cable from battery.
2) Remove the glove box. AL, Glove Box.>
3) Disconnect the connector from cruise control
module.
4) Remove the bolt, then detach the cruise control
module (A).
2. TURBO MODEL
Control Module (ECM).>
C: INSTALLATION
1. NON-TURBO MODEL
Install in the reverse order of removal.
NOTE:
Attach the part number label, facing the rear side of
the vehicle.
2. TURBO MODEL
gine Control Module (ECM).>
CC-00013
(A)

EN(H4SO)-45
ENGINE (DIAGNOSTIC)
Compulsory Valve Operation Check Mode
15.Compulsory Valve Operation
Check Mode
A: OPERATION
1) Prepare the Subaru Select Monitor kit. EN(H4SO)-8, PREPARATION TOOL, General De-
scription.>
2) Connect the diagnosis cable to Subaru Select
Monitor.
3) Insert the cartridge to Subaru Select Monitor.
General Description.>
4) Connect the test mode connector (A) located at
the lower portion of glove box.5) Connect the Subaru Select Monitor to data link
connector located in the lower portion of the instru-
ment panel (on the driver’s side).
CAUTION:
Do not connect the scan tools except for Suba-
ru Select Monitor and OBD-II general scan tool.
6) Turn ignition switch to ON (engine OFF) and turn
Subaru Select Monitor switch to ON.
7) On the «Main Menu» display screen, select the
{Each System Check} and press the [YES] key.
8) On the «System Selection Menu» display
screen, select the {Engine} and press the [YES]
key.
9) Press the [YES] key after the information of en-
gine type was displayed.
10) On the «Engine Diagnosis» display screen, se-
lect the {System Operation Check Mode} and press
the [YES] key.
11) On the «System Operation Check Mode» dis-
play screen, select the {Actuator ON/OFF Opera-
tion} and press the [YES] key.
12) Select the desired compulsory actuator on the
«Actuator ON/OFF Operation» display screen and
press the [YES] key.
13) Pressing the [NO] key completes the compul-
sory valve operation check mode. The display will
then return to the «Actuator ON/OFF Operation»
screen.
EN-00038
EN-00039
EN-00238
(A)
(A) Power switch
ME-00325
EN-00040
(A)

FU(H4DOTC)-51
FUEL INJECTION (FUEL SYSTEM)
Main Relay
21.Main Relay
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the glove box. AL, Glove Box.>
3) Remove the bolt which holds the main relay
bracket on body.
4) Disconnect the connectors from main relay.
B: INSTALLATION
Install in the reverse order of removal.
FU-00009
FU-00317
