2004 SUBARU FORESTER bulb

LI-24
LIGHTING SYSTEM
Rear Turn Signal Light Bulb
20.Rear Turn Signal Light Bulb
A: REMOVAL
1) Remove the rear combination light assembly.
Assembly.>
2) Turn the socket and remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00031

LI-25
LIGHTING SYSTEM
Rear Fog Light Bulb
21.Rear Fog Light Bulb
A: REMOVAL
NOTE:
Rear fog light bulb is attached only to driver’s side
combination light.
1) Remove the rear combination light assembly.
Assembly.>
2) Turn the socket and remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00033

LI-26
LIGHTING SYSTEM
License Plate Light
22.License Plate Light
A: REMOVAL
1) Remove the license plate light mounting screw
(A), and then remove the lens.
2) Remove the bulb.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00034(A)

LI-27
LIGHTING SYSTEM
High-mounted Stop Light
23.High-mounted Stop Light
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the cap (a) by prying on the edge with
screwdriver.
3) Remove the screws (b), and then detach the
cover (c).
4) Remove the screws (d), disconnect the connec-
tor, and then detach the high-mounted stop light.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
LI-00036
(d)
(c)
(a) (b)

LI-28
LIGHTING SYSTEM
Side Turn Signal Light
24.Side Turn Signal Light
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Pull out the light from body while pushing it in di-
rection of vehicle front.
3) Disconnect the harness connector and remove
the light.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Check the bulb for blow out using tester.
2) If NG, replace the side turn signal light assembly
with a new one.
LI-00067

LI-29
LIGHTING SYSTEM
Spot Map Light
25.Spot Map Light
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Insert a flat tip screwdriver to the slot of lens, and
then pry the lens to remove.
3) Remove the spot map light installation screws.
4) Disconnect the harness connectors and remove
the spot map light.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1. SPOT MAP LIGHT BULB
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
2. SPOT MAP LIGHT SWITCH
Measure the spot map light switch resistance.
Switch position Terminal No. Standard
OFF — More than 1 MΩ
ON 1 and 2 18±5.4 Ω
LI-00038
LI-00039

LI-30
LIGHTING SYSTEM
Room Light
26.Room Light
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the lens (A) and room light mounting
screws (B).
3) Disconnect the harness connectors and remove
the room light.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1. ROOM LIGHT BULB
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
2. ROOM LIGHT SWITCH
Measure the resistance between room light switch
terminals.
Switch position Terminal No. Standard
OFF — More than 1 MΩ
ON 1 and 3 1.5±0.5 Ω
DOOR 1 and 2 1.5±0.5 Ω
LI-00040
(B) (B)
(A)
LI-00041
321R52

LI-31
LIGHTING SYSTEM
Luggage Room Light
27.Luggage Room Light
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the lens (A) and luggage room light
mounting screws (B).
3) Disconnect the harness connectors and remove
the luggage room light.
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1. LUGGAGE ROOM LIGHT BULB
1) Visually check the bulb for blow out.
2) Check the bulb specification. IFICATION, General Description.>
3) If NG, replace the bulb with a new one.
2. LUGGAGE ROOM LIGHT SWITCH
Measure the resistance between luggage room light
switch terminals.
LI-00042
(B)
(B)
(A)
Switch position Terminal No. Standard
OFF — More than 1 MΩ
ON 1 and 3 1.5±0.5 Ω
DOOR 1 and 2 1.5±0.5 Ω
LI-00043
(1) (3)
(2)
