2004 MERCEDES-BENZ CLK-CLASS Owners Manual

345 Practical hints
Where will I find...?
Vehicle jackThe vehicle jack is stored in the space un-
derneath the trunk floor together with the
vehicle tool kit in the vehicle tool kit stor-
age well casing.

Remove the vehicle jack from its com-
partment.

Push the crank handle up.

Turn the crank handle clockwise until it
engages (operational position).
Before storing the vehicle jack in its com-
partment:


It should be fully collapsed


The handle must be folded in (storage
position)
Warning!
G
The jack is designed exclusively for jacking
up the vehicle at the jack take-up brackets
built into both sides of the vehicle. To help
avoid personal injury, use the jack only to lift
the vehicle during a wheel change. Never
get beneath the vehicle while it is supported
by the jack. Keep hands and feet away from
the area under the lifted vehicle. Always
firmly set parking brake and block wheels
before raising vehicle with jack.
Do not disengage parking brake while the
vehicle is raised. Be certain that the jack is
always vertical (plumb line) when in use, es-
pecially on hills. Always try to use the jack
on a level surface. Make sure the jack arm is
fully seated in the jack take-up bracket. Al-
ways lower the vehicle onto sufficient ca-
pacity jackstands before working under the
vehicle.
ProCarManuals.com

346 Practical hintsWhere will I find...?Minispare wheel
The Minispare wheel is located in the com-
partment underneath the trunk floor.
1Vehicle tool kit
Wheel wrench
Jack
Wheel bolts for Minispare wheel
2Arrow
3Minispare wheel
4Vehicle tool kit storage well casingRemoving the Minispare wheel

Lift trunk floor cover and engage trunk
floor handle in upper edge of trunk.

Loosen the retaining screw
(page 344) in the middle of storage
well casing.

Remove the storage well casing
(page 344).

Remove vehicle tool kit storage well
casing4.

Remove Minispare wheel3.Storing the Minispare wheel

Place Minispare wheel3 in wheel
well.

Place vehicle tool kit storage well
casing4 over the Minispare wheel.
Make sure the arrow 2 on storage
well casing4 points in the direction of
travel.

Place storage well casing
(page 344) over the vehicle tool kit
storage well casing 4 and turn the re-
taining screw (
page 344) clockwise
as far as it will go to secure the
Minispare wheel.
iThe arrow2 on vehicle tool kit stor-
age well casing4 must point in the di-
rection of travel, otherwise you cannot
place the storage well casing
(page 344) on top and secure the
Minispare wheel with the retaining
screw (
page 344).
ProCarManuals.com

347 Practical hints
Where will I find...?
In the case of a flat tire, you may tempo-
rarily use the Minispare wheel when ob-
serving the following restrictions:

Do not exceed a vehicle speed of
50 mph (80 km/h).


Drive to the nearest tire repair facility
to have the flat tire repaired or re-
placed as appropriate.


Do not operate vehicle with more than
one Minispare wheel mounted.
More information can be found in the
“Technical data” section (
page 403).
Minispare wheel bolts
1Wheel bolt for light alloy rims
2Wheel bolt for Minispare wheel or other
steel rims (located in trunk with spare
wheel)
!To prevent damage, always disengage
trunk floor handle from upper edge of
trunk and lower trunk floor before clos-
ing the trunk lid.Warning!
G
The dimensions of the Minispare wheel are
different from those of the road wheels. As
a result, the vehicle handling characteristics
change when driving with a Minispare wheel
mounted.
The Minispare wheel should only be used
temporarily, and should be replaced with a
regular road wheel as quickly as possible.
!Wheel bolts2 must be used when
mounting the Minispare wheel. The use
of any wheel bolts other than wheel
bolts2 for the Minispare will physical-
ly damage the vehicle's brakes.Warning!
G
Make sure to use the original length wheel
bolts when remounting the original wheel af-
ter it has been repaired.
ProCarManuals.com

348 Practical hintsUnlocking/locking in an emergency
Unlocking/locking in an emergencyUnlocking the vehicle
If you are unable to unlock the vehicle with
the SmartKey or KEYLESS-GO*, open the
driver’s door and the trunk using the me-
chanical key.
1Mechanical key locking tab
2Mechanical key

Move locking tab1 in direction of ar-
row and slide the mechanical key2
out of the housing.Unlocking the driver’s door
1Unlocking
2Locking

Unlock the door with the mechanical
key. To do so, push the mechanical key
in the lock until it stops and turn it to
the left.
iUnlocking your vehicle with the me-
chanical key will trigger the anti-theft
alarm system. To cancel the alarm, do
one of the following:

Press button Œ or ‹ on the
SmartKey.


Insert the SmartKey in the starter
switch.
Vehicles with KEYLESS-GO*


Pull the outside door handle.


Press the KEYLESS-GO* start/stop
button (
page 33).
ProCarManuals.com

349 Practical hints
Unlocking/locking in an emergency
Unlocking the trunk
A minimum height clearance of 5.41 ft
(1.65 m) is required to open the trunk lid.
The lock is located next to the recessed
handle.
1Unlocking in an emergency
2Handle

Insert the mechanical key into the
trunk lid lock.

Turn the mechanical key counterclock-
wise to position1 and hold it in this
position.

Pull the trunk lid handle2 and lift the
trunk lid.
The trunk opens.
Locking the vehicle
If you are unable to lock the vehicle with
the SmartKey, lock it with the mechanical
key as follows:
Close the passenger door and the trunk
lid.

Press the central locking switch in the
cockpit (
page 108).

Check to see whether the locking knob
on the passenger door down. If neces-
sary push it down manually.

Lock the driver’s door with the me-
chanical key.

Lock the trunk lid if necessary with the
mechanical key (
page 106).
! Always make sure there is sufficient
overhead clearance.
ProCarManuals.com

350 Practical hintsUnlocking/locking in an emergencyChanging batteries in the SmartKey/ SmartKey with KEYLESS-GO*
If the batteries in the SmartKey or the
SmartKey with KEYLESS-GO* are dis-
charged, the vehicle can no longer be
locked or unlocked. It is recommended to
have the batteries replaced at an autho-
rized Mercedes-Benz Center.
Batteries contain materials that can harm
the environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries
for recycling.SmartKey
1Mechanical key
2Battery compartment
Replacement batteries: Lithium, type
CR 2025 or equivalent.

Remove mechanical key1
(page 348).

Insert the mechanical key in side open-
ing and push gray slide.
The battery compartment is unlatched.

Pull the battery compartment out of the
SmartKey housing in direction of ar-
row.

Remove the batteries.
Warning!
G
Keep the batteries out of reach of children.
If a battery is swallowed, seek medical help
immediately.
iWhen changing batteries, always re-
place both batteries.
The required replacement batteries are
available at any Mercedes-Benz
Center.
ProCarManuals.com

351 Practical hints
Unlocking/locking in an emergency
3Battery
4Contact spring
Using a lint-free cloth, insert new bat-
teries under the contact spring with the
plus (+) side facing up.

Return battery compartment into hous-
ing until it locks into place.SmartKey with KEYLESS-GO*
1Battery
2Tilt battery up
3Mechanical key
Replacement batteries: Lithium, type
CR 2025 or equivalent.

Remove mechanical key (
page 348).

Insert the mechanical key in side open-
ing and push grey slide.
The battery compartment is unlatched.

Pull the battery compartment out of the
SmartKey housing in direction of ar-
row.

Using mechanical key3, apply pres-
sure to position2.
Battery1 tilts up slightly.

Pull batteries1 out in direction of ar-
row.

Using a lint-free cloth, insert new bat-
teries with the plus (+) side facing up.

Return battery compartment into hous-
ing until it locks into place.
iWhen changing batteries, always re-
place both batteries.
The required replacement batteries are
available at any Mercedes-Benz
Center.
ProCarManuals.com

352 Practical hintsUnlocking/locking in an emergencyFuel filler flap
In case the central locking system does
not release the fuel filler flap, you can open
it manually.
Open trunk lid.

Remove right side trim panel in the
trunk.

Reach inside through opening2 in di-
rection of arrow.

Turn release knob 1 clockwise (ar-
row).
The fuel filler flap can be opened.Manually unlocking the gear selector
lever
In case of power failure, the gear selector
lever can be manually unlocked, e.g. to tow
the vehicle.
Open the storage compartment under
the center armrest (
page 251).

Take out cover 1.

Insert a pin into the opening of
division2 and pry the division out.

Insert a tool3 (e.g. screwdriver) into
the opening.

Perform the following two steps simul-
taneously:
Push pin3 forward in the direction
of the arrow.

Move selector lever from
positionP.

Reinstall the division and cover after re-
moving the tool from the opening.iThe gear selector lever is locked again
when moving it to positionP.
