Parktronic (Parking assist)*
The Parktronic system is an electronic aid
designed to assist the driver during park-
ing maneuvers. It visually and audibly indi-
cates the relative distance between the
vehicle and an obstacle.
The Parktronic system is automatically ac-
tivated when you switch on the ignition
and release the parking brake. The Park-
tronic system deactivates at speeds over
approximately 11 mph (18 km/h). At low-
er speeds the Parktronic system turns on
again.The Parktronic system monitors the sur-
roundings of your vehicle with six sensors
in the front bumper and four sensors in the
rear bumper.
1Sensors in the front bumperWarning!
G
Parktronic is a supplemental system. It is
not intended to, nor does it replace, the
need for extreme care. The responsibility
during parking and other critical maneuvers
always rests with the driver.
Special attention must be paid to objects
with smooth surfaces or low silhouettes
(e.g. trailer couplings, painted posts or road
curbs). Such objects may not be detected by
the system and can damage the vehicle.
The operational function of the Parktronic
system can be affected by dirty sensors, es-
pecially at times of snow and ice, see
“Cleaning the Parktronic* system sensors”
(page 308).
Interference caused by other ultrasonic sig-
nals (e.g. working jackhammers or the air
brakes of trucks) can cause the system to
send erratic indications, and should be tak-
en into consideration.
Warning!
G
Make sure no persons or animals are in the
area in which you are maneuvering. You
could otherwise injure them.
ProCarManuals.com

242 Controls in detailDriving systemsRange of the sensors
To function properly, the sensors must be
free of dirt, ice, snow and slush. Clean the
sensors regularly, being careful not to
scratch or damage the sensors.Front sensors
Rear sensors
Minimum distance
If the system encounters an obstacle in
this range, all the warning lamps come on
and you hear a warning signal. If the obsta-
cle is closer than the minimum distance,
the actual distance may no longer be indi-
cated by the system.
Center
approx. 39 in (100 cm)
Corners
approx. 23,5 in (60 cm)
Center
approx. 47 in (120 cm)
Corners
approx. 32 in (80 cm)
!During parking maneuvers, pay special
attention to objects located above or
below the height of the sensors (e.g.
planters or trailer hitches). The Park-
tronic system will not detect such ob-
jects at close range and damage to
your vehicle or the object may result.
Ultrasonic signals from outside sourc-
es (e.g. truck air brakes or jackham-
mers) may impair the operation of the
Parktronic system.
Center
approx. 8 in (20 cm)
Corners
approx. 6 in (15 cm)
ProCarManuals.com

243 Controls in detail
Driving systems
Warning indicators
Visual signals indicate to the driver the rel-
ative distance between the sensors and an
obstacle. The warning indicator for the
front area is located above the center air
vents in the dashboard. The warning indi-
cator for the rear area is integrated be-
tween the rear backrests.Front area warning indicator1Left side of the vehicle
2Right side of the vehicleEach warning indicator is divided into six
yellow and two red segments for either
side of the vehicle. The Parktronic system
is ready when the border around the indi-
cator is illuminated.
The position of the gear selector lever de-
termines which warning indicators will be
activated.As your vehicle approaches an object, one
or more segments will come on, depending
on the distance. When the eighth segment
comes on, you have reached the minimum
distance.


Front area: An intermittent acoustic
warning will sound as the first red seg-
ment comes on and a constant acous-
tic warning lasting a maximum of three
seconds will sound for the second red
segment. The signal is canceled when
the gear selector lever is placed in
positionP.


Rear area: An intermittent acoustic
warning will sound as the first red seg-
ment comes on and a constant acous-
tic warning lasting a maximum of three
seconds will sound for the second red
segment. The signal is canceled when
the gear selector lever is placed in po-
sition D orP.
Gear selector le-
ver position
Warning indicator
D
Front area activated
R or N
Front and rear area
activated
P
Neither activated
ProCarManuals.com

244 Controls in detailDriving systemsSwitching the Parktronic system
on/off
You can switch off the Parktronic system
manually.
The Parktronic switch is located in the cen-
ter console.
1Parktronic off
2Indicator lamp
3Parktronic onSwitching off the Parktronic system

Press upper half 1 of the switch.
Indicator lamp 2 comes on.
Switching on the Parktronic system

Press lower half 3 of the switch.
Indicator lamp 2 goes out.
ProCarManuals.com

245 Controls in detail
Loading
Loading
Ski sack*
Unfolding and loading
Close soft top completely
(page 219).

Open trunk lid.

Fold luggage cover back in direction of
the arrow.1Left hinge
2Right hinge
3Pull strap

Pull ski sack roller blind upward using
pull strap3.

Manually fold left1 and right
hinges2 of ski sack roller blind all the
way up.4Handle
5Cover
6Armrest

Fold armrest6 down (arrow).

Pull handle4 and swing cover5
down.

ProCarManuals.com

246 Controls in detailLoading7Velcro strap
Unfasten velcro strap7.

Pull ski sack into passenger compart-
ment and unfold.8Flap
9Catch

Pull down catch9.

Open the flap8 downwards in the di-
rection of the arrow.

From trunk, slide skis into ski sack.Warning!
G
The ski sack is designed for up to two pairs
of skis. Do not load the ski sack with other
objects.
Always fasten the ski sack securely. In an
accident, an unfastened ski sack can cause
injury to vehicle occupants.

ProCarManuals.com

247 Controls in detail
Loading
aStrap
Tighten strapa by pulling at the loose
end (arrow) until the skis in the ski sack
are tightly secured.bHook
cEye

Connect hookb to eyec located on
center tunnel in front of rear seat
bench.

Tighten strap by pulling at the loose
end (arrow).Unloading and folding

Loosen both straps.

Disconnect hookb from eyec.

Unload skis.

Close flap8 in trunk.

Fold and flatten ski sack lengthwise.

Place folded ski sack inside recess of
backrest.

Fasten velcro strap

Close ski sack compartment cover.
ProCarManuals.com

248 Controls in detailLoadingClosing ski sack roller blind
1Left hinge
2Right hinge
3Pull strap
Pull ski sack roller blind downward us-
ing pull strap3.

Manually fold left1 and right
hinges2 of ski sack roller blind all the
way down.

To snap ski sack roller blind into place,
press left and right hinges where the
word PRESS can be seen.

Fold luggage cover back and close it
securely (
page 216).Removal of ski sack
For removal of the ski sack we recommend
that you contact an authorized
Mercedes-Benz Center.
Warning!
G
Never drive vehicle with trunk open while
the ski sack is removed. Deadly carbon
monoxide (CO) gases may enter vehicle in-
terior, resulting in unconsciousness and
death.iTo prevent unauthorized persons from
access to the trunk, always close the
flap.
