Page 329 of 400

329 Practical hints
Towing the vehicle
!
To be certain to avoid a possibility of
damage to the drive train, however, we
recommend the drive shaft be discon-
nected at the rear axle drive flange
(vehicles with 4MATIC: disconnected at
the front and rear axle drive flanges) for
any towing beyond a short tow to a
nearby garage.
Warning!
G
If circumstances require towing the vehicle
with all wheels on the ground, always tow
with a tow bar if:
the engine will not run
there is a malfunction in the power
supply or in the vehicle’s electrical
system
as that will be necessary to adequately
control the towed vehicle.
Prior to towing the vehicle with all wheels on
the ground, make certain that the SmartKey
is in starter switch position2.
If the SmartKey is left in starter switch
position0 for an extended period of time, it
can no longer be turned in the switch. In this
case, the steering is locked. To unlock,
remove SmartKey from starter switch and
reinsert.
iTo signal turns while being towed with
the hazard warning flasher in use, turn
SmartKey in starter switch to
position2 and activate the combina-
tion switch for the left or right turn
signal in the usual manner – only the
selected turn signal will operate.
Upon canceling the turn signal, the
hazard warning flasher will operate
again.
Page 330 of 400

330 Practical hintsTowing the vehicleWarning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the ve-
hicle. Adapt your driving accordingly.
!When towing the vehicle with all wheels
on the ground, please note the
following:
With the automatic central locking
activated and the SmartKey in starter
switch position2, the vehicle doors
lock if the left front wheel as well as the
right rear wheel are turning at vehicle
speeds of approx. 9 mph (15 km/h) or
more.
Switch off the tow-away alarm
(page 79).
To prevent the vehicle doors from
locking, deactivate the automatic
central locking (
page 133).
Towing of the vehicle should only be
done using the properly installed
towing eye bolt. Never attach tow
cable, tow rope or tow rod to vehicle
chassis, frame or suspension parts.
iIf the battery is disconnected or
discharged
the SmartKey will not turn in the
starter switch. See notes on the
battery (
page 323) or on jump
starting (page 326).
the gear selector lever will remain
locked in positionP. See notes on
manually unlocking transmission
gear selector lever (
page 308).
Page 331 of 400
331 Practical hints
Towing the vehicle
Installing towing eye bolt
1Cover on right side of front bumper.2Cover on right side of rear bumper.Removing cover
Press mark on cover in direction of
arrow.
L i f t c o v e r o f f t o r e v e a l t h r e a d e d h o l e f o r
towing eye bolt.
The towing eye bolt is supplied with the
tool kit (located in the compartment under-
neath the trunk floor).
Screw towing eye bolt in to its stop and
tighten with lug wrench.
Reinstalling cover
Fit cover and snap into place.
Page 332 of 400
332 Practical hintsFuses
Fuses
Fuse box in passenger compartment
1CoverOpening
Pull cover1 open with a screw driver
or similar tool.
Remove cover rearward.
Closing
Attach cover1 in the front.
Fold cover in until it engages.
Fuse chart
The fuse chart is found in the fuse box in
the passenger compartment. The amper-
ages of the fuses are also given there.
iOnly install fuses that have been tested
and approved by Mercedes-Benz and
that have the specified amperage
rating.
Never attempt to repair or bridge a
blown fuse. Have the cause determined
and remedied by an authorized
Mercedes-Benz Center.
Page 333 of 400
333 Practical hintsFuses
Fuse box in engine compartment
The fuse box is located in the engine
compartment on the left hand side.
1Screw
2Cover
3RetainerRemoving/installing cover
Twist screws1
90° counterclockwise.
Pull up cover2.
Slide out retainer3 and remove cover
by pulling towards front.
Install cover2 in reverse order.Opening fuse box
4Fuse box cover
5Clamps
Release clamps5.
Remove cover4.
Closing fuse box
Ensure that the sealing rubber is
properly positioned.
Press cover4 down and secure with
clamps5.
Page 334 of 400
334 Practical hintsFusesAuxiliary fuse box in trunk
The auxiliary fuse box is located in the
trunk.
1Trim panel
2Cover of auxiliary fuse box
3Special fuse extractorOpening
Pull away trim panel1.
Remove cover2.
Spare fuses
Spare fuses are found in the vehicle tool kit
in the spare wheel well.
Page 335 of 400
335 Technical data
Spare parts service
Warranty coverage
Identification labels
Layout of poly-V-belt drive
Engine
Rims and Tires
Electrical system
Main dimensions
Weights
Fuels, coolants, lubricants, etc.
Consumer information
Page 336 of 400
336 Technical dataSpare parts service
The “Technical data” section provides the
necessary technical data for your vehicle.
Spare parts service
All authorized Mercedes-Benz Centers
maintain a stock of genuine
Mercedes-Benz parts required for mainte-
nance and repair work. In addition, strate-
gically located parts distribution centers
provide quick and reliable parts service.
More than 300 000 different spare parts
for Mercedes-Benz models are available.
Genuine Mercedes-Benz parts are subject
to stringent quality inspections. Each part
has been specifically developed, manufac-
tured or selected for and adapted to
Mercedes-Benz vehicles.
Therefore, genuine Mercedes-Benz parts
should be installed.
!The use of non-genuine Mercedes-Benz
parts and accessories not authorized
by Mercedes-Benz could damage the
vehicle, which is not covered by the
Mercedes-Benz Limited Warranty, or
could compromise the vehicle’s
durability or safety.
