Page 305 of 400
305 Practical hints
Unlocking/locking in an emergency
Unlocking/locking in an emergency
Unlocking the vehicle
If you are unable to unlock the vehicle with
the SmartKey, open the driver’s door and
the trunk using the mechanical key.
The passenger door cannot be unlocked
manually.
1Mechanical key locking tab
2Mechanical key
Move locking tab1 in direction of
arrow and slide mechanical key2 out
of the housing.Unlocking the driver’s door
1Unlocked
2Locked
Unlock the door with the mechanical
key. To do so, push the mechanical key
in the lock until it stops and turn it to
the left1.
iUnlocking your vehicle with the
mechanical key will trigger the
anti-theft alarm system.
To cancel the alarm, do one of the
following:
Press buttonŒ or‹ on the
SmartKey.
Insert the SmartKey in the starter
switch.
Page 306 of 400

306 Practical hintsUnlocking/locking in an emergencyUnlocking the trunk
A minimum height clearance of 5.71 ft
(1.74 m) is required to open the trunk lid.
The lock is located next to the recessed
handle.
1Unlocking in an emergency
2Handle
Slide mechanical key out of the
SmartKey (
page 305).
Insert the mechanical key into the
trunk lid lock.
Turn the mechanical key counterclock-
wise completely to position1 and
hold it in this position.
Pull trunk lid handle2 and lift the
trunk lid.
Locking the vehicle
If you are unable to lock the vehicle with
the SmartKey, lock it with the mechanical
key as follows:
Close the passenger doors and the
trunk.
Press the central locking switch in the
cockpit (
page 91).
Check to see whether the locking
knobs on the passenger doors are
down. If necessary push them down
manually.
Slide mechanical key out of the
SmartKey (
page 305).
Lock the driver’s door with the
mechanical key (
page 305).
Check if the trunk is locked. If
necessary lock the trunk with the
mechanical key (
page 89).
!Always make sure there is sufficient
overhead clearance.
Page 307 of 400

307 Practical hints
Unlocking/locking in an emergency
Changing batteries in the SmartKey
If the batteries in the SmartKey are
discharged, the vehicle can no longer be
locked or unlocked. It is recommended to
have the batteries replaced at an
authorized Mercedes-Benz Center.
Batteries contain materials that can harm
the environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries
for recycling.1Mechanical key
2Battery compartment
Replacement batteries: Lithium, type
CR 2025 or equivalent.
Remove mechanical key1
(page 305).
Insert mechanical key1 in side
opening and push grey slide.
Battery compartment2 is unlatched.
Pull battery compartment2 out of the
SmartKey housing in direction of
arrow.
3Battery
4Contact spring
Remove the batteries.
Using a lint-free cloth, insert new
batteries under contact spring with the
plus (+) side facing up.
Return battery compartment2 into
housing until it locks into place.
Warning!
G
Keep the batteries out of reach of children.
If a battery is swallowed, seek medical help
immediately.
iWhen changing batteries, always
replace both batteries.
The required replacement batteries are
available at any Mercedes-Benz
Center.
Page 308 of 400

308 Practical hintsUnlocking/locking in an emergency
Slide mechanical key1 back into the
SmartKey.
Fuel filler flap
In case the central locking system does
not release the fuel filler flap, you can open
it manually.
Open the trunk lid.
Fold away right-side tail lamp trim.
Reach inside through opening2 in
direction of arrow.
Turn release knob1 clockwise
(arrow).
The fuel filler flap can now be opened.
Manually unlocking the transmission
gear selector lever
In the case of power failure the transmis-
sion gear selector lever can be manually
unlocked, e.g. to tow the vehicle.
1Coin holder
2Tool
Open the storage compartment in front
of the center armrest (
page 218).
Release coin holder1 (e.g. using a
small coin).
Swing coin holder1 aside.
Insert a tool2 (e.g. flat blade
screwdriver) into the opening.
Perform the following two steps
simultaneously:
Push tool2 down.
Move gear selector lever from
positionP.
Reinstall coin holder1 after removing
tool2 from the opening.
iWhen inserting the batteries, make
sure they are clean and free of lint.
iThe gear selector lever is locked again
when moving it to positionP.
Page 309 of 400
309 Practical hints
Opening/closing in an emergency
Opening/closing in an emergency
Sliding/pop-up roof*
You can open or close the sliding/pop-up
roof manually should an electrical
malfunction occur.
The sliding/pop-up roof drive is located
behind the lens1 of the interior overhead
light.
Pry of lens1 using a flat blade
screwdriver.
Slide both locking tabs2 in direction
of arrow.
Lower rear of cover and remove.
Remove cover.
Obtain crank3.
Insert crank3 through hole.
Turn crank3 clockwise to:
slide roof closed
raise roof at the rear
Turn crank3 counterclockwise to:
slide roof open
lower roof at the rear
The sliding/pop-up roof must be
resynchronized after being operated
manually (
page 205).
iDo not disconnect electrical
connectors.
Page 310 of 400
310 Practical hintsReplacing bulbs
Replacing bulbsSafe vehicle operation depends on proper
exterior lighting and signaling. It is there-
fore essential that all bulbs and lamp
assemblies are in good working order at all
times.
Correct headlamp adjustment is extremely
important. Have headlamps checked and
readjusted at regular intervals and when a
bulb has been replaced. See your autho-
rized Mercedes-Benz Center for headlamp
adjustment.
Bulbs Front lamps
iBackup bulbs will be brought into use
when the following lamps malfunction:
Standing lamps
Tail lamps
Rear fog lamp
Lamp
Type
1
Additional turn signal
lamps
LED
2
Turn signal lamp
Halogen
Turn signal lamp
Bi-Xenon*
1156 A
2357 A
3
Halogen headlamps:
Low beam
Bi-Xenon* headlamps:
Low and high beam
H7 (55 W)
D2S-35 W
4
Halogen headlamps:
High beam
Bi-Xenon* headlamps:
High beam flasher
H7 (55 W)
H7 (55 W)
Parking and standing
lamps
W5W
5
Fog lamp
HB4/9006
(55 W)
6
Side marker lamp
W5W
Page 311 of 400

311 Practical hints
Replacing bulbs
Rear lamps Notes on bulb replacement
12 volt bulbs of the same type and
with the specified watt rating.
Switch lights off before changing a bulb
to prevent short circuits.
Always use a clean lint-free cloth when
handling bulbs.
Your hands should be dry and free of oil
and grease.
If the newly installed bulb does not
come on, visit an authorized
Mercedes-Benz Center.
Have the LEDs and bulbs for the
following lamps replaced by an
authorized Mercedes-Benz Center:
Additional turn signals in the
exterior rear view mirrors
High mounted brake lamp
Xenon lamps
Front fog lamps
Lamp
Type
7
High mounted brake
lamp
LED
8
Brake lamp
P21W
9
Turn signal lamp
PY 21 W
a
Backup lamp
P21W
b
Tail, parking,
standing and side
marker lamp
P21/5W
c
License plate lamps
C5W
d
Rear fog lamp,
driver’s side
P21/4W
Warning!
G
Keep bulbs out of reach of children.
Bulbs and bulb sockets can be very hot.
Allow the lamp to cool down before
changing a bulb.
Halogen lamps contain pressurized gas.
A bulb can explode if you
touch or move it when hot
drop the bulb
scratch the bulb
Wear eye and hand protection.
Because of high voltage in Xenon lamps, it is
dangerous to replace the bulb or repair the
lamp and its components. We recommend
that you have such work done by a qualified
technician.
Page 312 of 400

312 Practical hintsReplacing bulbsReplacing bulbs for front lamps
Halogen headlamps
1Bulb socket for turn signal lamp
2Headlamp cover for high beam head-
lamp, parking and standing lamp
3Headlamp cover for low beam head-
lamp4Low beam headlamp bulb
5High beam headlamp bulb
6Bulb socket for parking and standing
lamp bulb
Low and high beam bulb
Switch off the lights.
Open the hood (
page 252).
Press the clamp and remove headlamp
cover2 or3.
Pull electrical connector off.
Unclip the retainer springs and take out
the bulb.
Insert the new bulb so that the base
locates in the recess on the holder.
Clip the retainer springs and plug the
connector onto the bulb.
Align headlamp cover2 or3 and
click into place.
Front turn signal lamp bulb
Switch off the lights.
Open the hood (
page 252).
Twist bulb socket1 counterclockwise
and pull out.
Push bulb into socket, turn counter-
clockwise and remove.
Insert new bulb in socket, push in and
twist clockwise.
Reinsert bulb socket in lamp and twist
clockwise.
