DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)
Revision: August 20072004 QX56
DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)PFP:32702
DescriptionUCS002DV
The revolution sensor detects the revolution of the idler gear parking pawl lock gear and emits a pulse signal.
The pulse signal is sent to the TCM which converts it into vehicle speed.
CONSULT-II Reference ValueUCS002DW
On Board Diagnosis LogicUCS002DX

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “VEH SPD SEN/CIR AT” with CONSULT-II or P0720 without CONSULT-II is
detected under the following conditions.
–When TCM does not receive the proper voltage signal from the sensor.
–After ignition switch is turned “ON”, irregular signal input from vehicle speed sensor MTR before the vehi-
cle starts moving.
Possible CauseUCS002DY

Harness or connectors
(The sensor circuit is open or shorted.)

Revolution sensor

Vehicle speed sensor MTR
DTC Confirmation ProcedureUCS002DZ
CAUTION:

Always drive vehicle at a safe speed.

Be careful not to rev engine into the red zone on the tachometer.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Drive vehicle and check for an increase of “VHCL/S SE·A/T”
value in response to “VHCL/S SE·MTR” value.
If the check result is NG, go to AT-113, "
Diagnostic Procedure" .
If the check result is OK, go to following step.
4. Select “DATA MONITOR” mode for “ENGINE” with CONSULT-II.
5. Start engine and maintain the following conditions for at least 5
consecutive seconds.
VHCL SPEED SE: 30 km/h (19 MPH) or more
THRTL POS SEN: More than 1.0/8
Selector lever: “D” position
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
If the check result is NG, go to AT-113, "
Diagnostic Procedure" .
If the check result is OK, go to following step.
6. Maintain the following conditions for at least 5 consecutive seconds.
ENGINE SPEED: 3,500 rpm or more
THRTL POS SEN: More than 1.0/8
Selector lever: “D” position
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving
conditions required for this test.
If the check result is NG, go to AT-113, "
Diagnostic Procedure" .
Item name Condition Display value (km/h)
VHCL/S SE·A/T During driving Approximately matches the speedometer reading.
BCIA0030E

AT-116
DTC P0725 ENGINE SPEED SIGNAL
Revision: August 20072004 QX56
2. CHECK DTC WITH TCM
With CONSULT-II
1. Start engine.
2. Select “ECU INPUT SIGNALS” in “DATA MONITOR” mode for
“A/T” with CONSULT-II.
3. While monitoring engine speed, check for engine speed change
corresponding to wide-open throttle position signal.
With GST
Follow the procedure “With CONSULT-II”.
OK or NG
OK >> GO TO 3.
NG >> Check the ignition signal circuit.

Refer to EC-583, "IGNITION SIGNAL" .
3. CHECK TCM
Perform TCM input/output signals inspection. Refer to AT- 9 0 , "
TCM Input/Output Signal Reference Values" .
OK or NG
OK >> GO TO 4.
NG >> GO TO 6.
4. CHECK DTC
Perform “DTC Confirmation Procedure”.

Refer to AT-115, "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 5.
5. DETECT MALFUNCTIONING ITEM
Check the following items:

The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the control valve with TCM. Refer to AT-241, "Control Valve With TCM and A/T Fluid
Temperature Sensor 2" .
NG >> Repair or replace damaged parts.
6. DETECT MALFUNCTIONING ITEM
Check the following items:

Power supply and ground circuit for TCM.

The A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
Item name Condition Display value (rpm)
ENGINE SPEED Engine running Closely matches the tachometer reading.
PCIA0041E

AT-118
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE
Revision: August 20072004 QX56
DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVEPFP:31940
DescriptionUCS002E7

The torque converter clutch solenoid valve is activated, with the gear in D4 , D5 by the TCM in response
to signals sent from the vehicle speed sensor and accelerator pedal position sensor (throttle position sen-
sor). Torque converter clutch piston operation will then be controlled.

Lock-up operation, however, is prohibited when A/T fluid temperature is too low.

When the accelerator pedal is depressed (less than 1/8) in lock-up condition, the engine speed should not
change abruptly. If there is a big jump in engine speed, there is no lock-up.
CONSULT-II Reference ValueUCS002E8
On Board Diagnosis LogicUCS002E9

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “TCC SOLENOID/CIRC” with CONSULT-II or P0740 without CONSULT-II is
detected under the following conditions.
–When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
–When TCM detects as irregular by comparing target value with monitor value.
Possible CauseUCS002EA

Torque converter clutch solenoid valve

Harness or connectors
(The solenoid circuit is open or shorted.)
DTC Confirmation ProcedureUCS002EB
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “ENGINE” with CONSULT-II.
3. Start engine and maintain the following conditions for at least 5
consecutive seconds.
VHCL SPEED SE: 80 km/h (50 MPH) or more
ACCELE POS: 0.5/8 - 1.0/8
SELECTOR LEVER: “D” position
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
4. If DTC is detected go to AT-119, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “With CONSULT-II”.
Item name Condition Display value (Approx.) (A)
TCC SOLENOIDWhen performing slip lock-up 0.2 - 0.4
When performing lock-up 0.4 - 0.6
BCIA0030E

AT-124
DTC P0745 LINE PRESSURE SOLENOID VALVE
Revision: August 20072004 QX56
DTC P0745 LINE PRESSURE SOLENOID VALVEPFP:31940
DescriptionUCS002EJ
The line pressure solenoid valve regulates the oil pump discharge pressure to suit the driving condition in
response to a signal sent from the TCM.
The line pressure duty cycle value is not consistent when the closed throttle position signal is “ON”.
To confirm the line pressure duty cycle at low pressure, the accelerator (throttle) should be open until
the closed throttle position signal is “OFF”.
CONSULT-II Reference ValueUCS002EK
On Board Diagnosis LogicUCS002EL

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “L/PRESS SOL/CIRC” with CONSULT-II or P0745 without CONSULT-II is
detected under the following conditions.
–When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
–When TCM detects as irregular by comparing target value with monitor value.
Possible CauseUCS002EM

Harness or connectors
(The solenoid circuit is open or shorted.)

Line pressure solenoid valve
DTC Confirmation ProcedureUCS002EN
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON” and select “DATA MONITOR” mode for
“ENGINE” with CONSULT-II.
2. Engine start and wait at least 5 second.
3. If DTC is detected, go to AT-125, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “With CONSULT-II”.
Item name Condition Display value (Approx.) (A)
LINE PRES SOL During driving 0.2 - 0.6
BCIA0030E

AT-140
DTC P1730 A/T INTERLOCK
Revision: August 20072004 QX56
Judgement of A/T InterlockUCS002FS
When A/T Interlock is judged to be malfunctioning, the vehicle should be fixed in 2nd gear, and should be set
in a condition in which it can travel.
When one of the following fastening patterns is detected, the fail-safe function in correspondence with the indi-
vidual pattern should be performed.
A/T INTERLOCK COUPLING PATTERN TABLE

: NG, X: OK
Diagnostic ProcedureUCS002FT
1. SELF-DIAGNOSIS
With CONSULT-II
1. Drive vehicle.
2. Stop vehicle and turn ignition switch “OFF”.
3. Turn ignition switch “ON”. (Do not start engine.)
4. Select “SELF-DIAG RESULTS” mode for “A/T” with CONSULT-
II.
OK or NG
OK >> GO TO 6.
NG >> Check low coast brake solenoid valve circuit and func-
tion. Refer to AT-169, "
DTC P1772 LOW COAST
BRAKE SOLENOID VALVE" , AT- 1 7 2 , "DTC P1774
LOW COAST BRAKE SOLENOID VALVE FUNCTION"
.
2. CHECK TCM
Perform TCM input/output signals inspection. Refer to AT- 9 0 , "
TCM Input/Output Signal Reference Values" .
OK or NG
OK >> GO TO 3.
NG >> GO TO 4.
3. CHECK DTC
Perform “DTC Confirmation Procedure”.

Refer to AT-139, "DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 5.
Gear positionATF pressure switch output
Fail-safe
functionClutch pressure output pattern after fail-safe func-
tion
SW3
(I/C)SW6
(HLR/
C)SW5
(D/C)SW1
(Fr/B)SW2
(LC/B)I/C HLR/C D/C Fr/B LC/B L/U
A/T interlock
coupling pat-
tern3rd – X X –
Held in
2nd gearOFF OFF ON OFF OFF OFF
4th – X X –
Held in
2nd gearOFF OFF ON OFF OFF OFF
5th X X – X
Held in
2nd gearOFF OFF ON OFF OFF OFF
BCIA0031E

DTC P1752 INPUT CLUTCH SOLENOID VALVE
AT-145
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P1752 INPUT CLUTCH SOLENOID VALVEPFP:31940
DescriptionUCS002G0
Input clutch solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehicle
speed sensor and accelerator pedal position sensor (throttle position sensor). Gears will then be shifted to the
optimum position.
CONSULT-II Reference ValueUCS002G1
On Board Diagnosis LogicUCS002G2

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “I/C SOLENOID/CIRC” with CONSULT-II or P1752 without CONSULT-II is
detected under the following conditions.
–When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
–When TCM detects as irregular by comparing target value with monitor value.
Possible CauseUCS002G3

Harness or connectors
(The solenoid circuit is open or shorted.)

Input clutch solenoid valve
DTC Confirmation ProcedureUCS002G4
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 5
consecutive seconds.
ACCELE POS: 1.5/8 - 2.0/8
Selector lever: “D” position
Gear position: 3rd

4th Gear (I/C ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
5. If DTC is detected go to AT- 1 4 6 , "
Diagnostic Procedure" .
WITH GST
Follow the procedure “With CONSULT-II”.
Item name Condition Display value (Approx) (A)
I/C SOLENOIDInput clutch disengaged. Refer to AT- 2 1
. 0.6 - 0.8
Input clutch engaged. Refer to AT- 2 1
. 0 - 0.05
BCIA0030E

AT-148
DTC P1754 INPUT CLUTCH SOLENOID VALVE FUNCTION
Revision: August 20072004 QX56
DTC P1754 INPUT CLUTCH SOLENOID VALVE FUNCTIONPFP:31940
DescriptionUCS002G6

Input clutch solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehi-
cle speed sensor and accelerator pedal position sensor (throttle position sensor). Gears will then be
shifted to the optimum position.

This is not only caused by electrical malfunction (circuits open or shorted) but also by mechanical mal-
function such as control valve sticking, improper solenoid valve operation.
CONSULT-II Reference ValueUCS002G7
On Board Diagnosis LogicUCS002G8

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “I/C SOLENOID FNCTN” with CONSULT-II or P1754 without CONSULT-II is
detected under the following conditions.
–When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of
pressure switch 3 is irregular during depressing accelerator pedal. (Other than during shift change)
–When TCM detects that relation between gear position and condition of ATF pressure switch 3 is irregular
during releasing accelerator pedal. (Other than during shift change)
Possible CauseUCS002G9

Harness or connectors
(The solenoid and switch circuits are open or shorted.)

Input clutch solenoid valve

ATF pressure switch 3
DTC Confirmation ProcedureUCS002GA
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine.
2. Accelerate vehicle to maintain the following conditions.
ACCELE POSI: 1.5/8 - 2.0/8
Selector lever: “D” position
Gear position: 3rd

4th Gear (I/C ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
3. Perform step “2” again.
4. Turn ignition switch “OFF”, then perform step “1” to “3” again.
5. Check “SELF-DIAG RESULTS” mode for “A/T” with CONSULT-
II. If DTC (P1754) is detected, refer to AT-149, "
Diagnostic Procedure" .
If DTC (P1752) is detected, go to AT- 1 4 6 , "
Diagnostic Procedure" .
If DTC (P1843) is detected, go to AT- 1 7 9 , "
Diagnostic Procedure" .
Item name Condition Display value (Approx)
I/C SOLENOIDInput clutch disengaged. Refer to AT- 2 1
. 0.6 - 0.8 A
Input clutch engaged. Refer to AT- 2 1
. 0 - 0.05 A
ATF PRES SW 3Input clutch engaged. Refer to AT- 2 1
.ON
Input clutch disengaged. Refer to AT- 2 1
. OFF
BCIA0030E

DTC P1757 FRONT BRAKE SOLENOID VALVE
AT-151
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P1757 FRONT BRAKE SOLENOID VALVEPFP:31940
DescriptionUCS002G C
Front brake solenoid valve is controlled by the TCM in response to signals sent from the PNP switch, vehicle
speed sensor and accelerator pedal position sensor (throttle position sensor). Gears will then be shifted to the
optimum position.
CONSULT-II Reference ValueUCS002G D
On Board Diagnosis LogicUCS002G E

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “FR/B SOLENOID/CIRC” with CONSULT-II or P1757 without CONSULT-II is
detected under the following conditions.
–When TCM detects an improper voltage drop when it tries to operate the solenoid valve.
–When TCM detects as irregular by comparing target value with monitor value.
Possible CauseUCS002GF

Harness or connectors
(The solenoid circuit is open or shorted.)

Front brake solenoid valve
DTC Confirmation ProcedureUCS002GG
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “DATA MONITOR” mode for “A/T” with CONSULT-II.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 5
consecutive seconds.
ACCELE POS: 1.5/8 - 2.0/8
Selector lever: “D” position
Gear position: 3rd

4th Gear (FR/B ON/OFF)
Driving location: Driving the vehicle uphill (increased
engine load) will help maintain the driving conditions
required for this test.
5. If DTC is detected go to AT- 1 5 2 , "
Diagnostic Procedure" .
WITH GST
Follow the procedure “With CONSULT-II”.
Item name Condition Display value (Approx) (A)
FR/B SOLENOIDFront brake engaged. Refer to AT- 2 1
. 0.6 - 0.8
Front brake disengaged. Refer to AT- 2 1
. 0 - 0.05
BCIA0030E
