2004 INFINITI QX56 OBD port

DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)
AT-121
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: August 20072004 QX56
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)PFP:31940
DescriptionUCS002ED
This malfunction is detected when the A/T does not shift into 5th gear position or the torque converter clutch
does not lock-up as instructed by the TCM. This is not only caused by electrical malfunction (circuits open or
shorted) but also by mechanical malfunction such as control valve sticking, improper solenoid valve operation,
etc.
CONSULT-II Reference ValueUCS002EE
On Board Diagnosis LogicUCS002EF

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “A/T TCC S/V FNCTN” with CONSULT-II or P0744 without CONSULT-II is
detected under the following conditions.
–When A/T cannot perform lock-up even if electrical circuit is good.
–When TCM detects as irregular by comparing difference value with slip rotation.
Possible CauseUCS002EG

Harness or connectors
(The solenoid circuit is open or shorted.)

Torque converter clutch solenoid valve

Hydraulic control circuit
DTC Confirmation ProcedureUCS002EH
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch “OFF”
and wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine and Select “TCC S/V FNCTN CHECK” of “DTC
WORK SUPPORT” mode for “A/T” with CONSULT-II and touch
“START”.
2. Accelerate vehicle to more than 80 km/h (50 MPH) and maintain
the following condition continuously until “TESTING” has turned
to “COMPLETE”. (It will take approximately 30 seconds after
“TESTING” shows.)
ACCELE POSI: More than 1.0/8 (at all times during step 4)
TCC SOLENOID: 0.4 - 0.6 A
Selector lever: “D” position
[Reference speed: Constant speed of more than 80 km/h (50
MPH)]
–Make sure “GEAR” shows “5”.
–For shift schedule, refer to AT- 6 7 , "Vehicle Speed When Performing and Releasing Complete Lock-
up" .
–If “TESTING” does not appear on CONSULT-II for a long time, select “SELF-DIAG RESULTS”. In
case a 1st trip DTC other than P0744 is shown, refer to applicable “TROUBLE DIAGNOSIS FOR
DTC”.
3. Make sure that “OK” is displayed. (If “NG” is displayed, refer to “DIAGNOSTIC PROCEDURE”.)
Refer to AT- 1 2 2 , "
Diagnostic Procedure" .
Refer to shift schedule, AT-67, "
Vehicle Speed When Performing and Releasing Complete Lock-up" .
Item name Condition Display value (Approx.) (A)
TCC SOLENOIDWhen performing slip lock-up 0.2 - 0.4
When performing lock-up 0.4 - 0.6
BCIA0030E

EC-1
ENGINE CONTROL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION EC
A
EC
Revision: August 20072004 QX56 INDEX FOR DTC ........................................................ 8
Alphabetical Index .................................................... 8
DTC No. Index ....................................................... 12
PRECAUTIONS ........................................................ 16
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ................................................................ 16
On Board Diagnostic (OBD) System of Engine and
A/T .......................................................................... 16
Precaution .............................................................. 16
Wiring Diagrams and Trouble Diagnosis ................ 19
PREPARATION ......................................................... 20
Special Service Tools ............................................. 20
Commercial Service Tools ...................................... 22
ENGINE CONTROL SYSTEM .................................. 23
System Diagram ..................................................... 23
Vacuum Hose Drawing ........................................... 24
System Chart ......................................................... 25
Multiport Fuel Injection (MFI) System .................... 26
Electronic Ignition (EI) System ............................... 28
Nissan Torque Demand (NTD) Control System ..... 29
Air Conditioning Cut Control ................................... 30
Fuel Cut Control (at No Load and High Engine
Speed) .................................................................... 30
CAN communication .............................................. 31
BASIC SERVICE PROCEDURE .............................. 32
Idle Speed and Ignition Timing Check .................... 32
Idle Speed/Ignition Timing/Idle Mixture Ratio
Adjustment ............................................................. 33
Accelerator Pedal Released Position Learning ...... 44
Throttle Valve Closed Position Learning ................ 44
Idle Air Volume Learning ........................................ 44
Fuel Pressure Check .............................................. 46
ON BOARD DIAGNOSTIC (OBD) SYSTEM ............ 49
Introduction ............................................................ 49
Two Trip Detection Logic ........................................ 49
Emission-related Diagnostic Information ................ 50
IVIS (Infiniti Vehicle Immobilizer System — NATS) ... 63
Malfunction Indicator Lamp (MIL) ........................... 63
OBD System Operation Chart ................................ 66TROUBLE DIAGNOSIS ............................................ 71
Trouble Diagnosis Introduction ............................... 71
DTC Inspection Priority Chart ................................. 76
Fail-safe Chart ........................................................ 77
Basic Inspection ..................................................... 79
Symptom Matrix Chart ............................................ 84
Engine Control Component Parts Location ............ 88
Circuit Diagram ....................................................... 94
ECM Harness Connector Terminal Layout ............. 96
ECM Terminals and Reference Value ..................... 96
CONSULT-II Function ...........................................103
Generic Scan Tool (GST) Function .......................116
CONSULT-II Reference Value in Data Monitor .....118
Major Sensor Reference Graph in Data Monitor
Mode .....................................................................121
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .123
Description ............................................................123
Testing Condition ..................................................123
Inspection Procedure ............................................123
Diagnostic Procedure ...........................................124
TROUBLE DIAGNOSIS FOR INTERMITTENT INCI-
DENT .......................................................................127
Description ............................................................127
Diagnostic Procedure ...........................................127
POWER SUPPLY AND GROUND CIRCUIT ...........128
Wiring Diagram .....................................................128
Diagnostic Procedure ...........................................129
Ground Inspection ................................................133
DTC U1000, U1001 CAN COMMUNICATION LINE .135
Description ............................................................135
On Board Diagnosis Logic ....................................135
DTC Confirmation Procedure ...............................135
Wiring Diagram .....................................................136
Diagnostic Procedure ...........................................137
DTC P0037, P0038, P0057, P0058 HO2S2 HEATER .138
Description ............................................................138
CONSULT-II Reference Value in Data Monitor Mode
.138
On Board Diagnosis Logic ....................................138
DTC Confirmation Procedure ...............................139

EC-22Revision: August 2007
PREPARATION
2004 QX56
Commercial Service ToolsUBS00GZA
Tool name
(Kent-Moore No.)Description
Leak detector
i.e.: (J-41416)Locating the EVAP leak
EVAP service port
adapter
i.e.: (J-41413-OBD)Applying positive pressure through EVAP service
port
Fuel filler cap adapter
i.e.: (MLR-8382)Checking fuel tank vacuum relief valve opening
pressure
Socket wrench Removing and installing engine coolant tempera-
ture sensor
Oxygen sensor thread
cleaner
i.e.: (J-43897-18)
(J-43897-12)Reconditioning the exhaust system threads before
installing a new oxygen sensor. Use with anti-
seize lubricant shown below.
a: 18 mm diameter with pitch 1.5 mm for Zirco-
nia Oxygen Sensor
b: 12 mm diameter with pitch 1.25 mm for Tita-
nia Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL specifica-
tion MIL-A-907)Lubricating oxygen sensor thread cleaning tool
when reconditioning exhaust system threads.
S-NT703
S-NT704
S-NT815
S-NT705
AEM488
S-NT779

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-55
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: August 20072004 QX56
For example, the EGR malfunction (Priority: 2) was detected and the freeze frame data was stored in the 2nd
trip. After that when the misfire (Priority: 1) is detected in another trip, the freeze frame data will be updated
from the EGR malfunction to the misfire. The 1st trip freeze frame data is updated each time a different mal-
function is detected. There is no priority for 1st trip freeze frame data. However, once freeze frame data is
stored in the ECM memory, 1st trip freeze data is no longer stored (because only one freeze frame data or 1st
trip freeze frame data can be stored in the ECM). If freeze frame data is stored in the ECM memory and freeze
frame data with the same priority occurs later, the first (original) freeze frame data remains unchanged in the
ECM memory.
Both 1st trip freeze frame data and freeze frame data (along with the DTCs) are cleared when the ECM mem-
ory is erased. Procedures for clearing the ECM memory are described in EC-62, "
HOW TO ERASE EMIS-
SION-RELATED DIAGNOSTIC INFORMATION" .
SYSTEM READINESS TEST (SRT) CODE
System Readiness Test (SRT) code is specified in Mode 1 of SAE J1979.
As part of an enhanced emissions test for Inspection & Maintenance (I/M), certain states require the status of
SRT be used to indicate whether the ECM has completed self-diagnosis of major emission systems and com-
ponents. Completion must be verified in order for the emissions inspection to proceed.
If a vehicle is rejected for a State emissions inspection due to one or more SRT items indicating “INCMP”, use
the information in this Service Manual to set the SRT to “CMPLT”.
In most cases the ECM will automatically complete its self-diagnosis cycle during normal usage, and the SRT
status will indicate “CMPLT” for each application system. Once set as “CMPLT”, the SRT status remains
“CMPLT” until the self-diagnosis memory is erased.
Occasionally, certain portions of the self-diagnostic test may not be completed as a result of the customer's
normal driving pattern; the SRT will indicate “INCMP” for these items.
NOTE:
The SRT will also indicate “INCMP” if the self-diagnosis memory is erased for any reason or if the ECM mem-
ory power supply is interrupted for several hours.
If, during the state emissions inspection, the SRT indicates “CMPLT” for all test items, the inspector will con-
tinue with the emissions test. However, if the SRT indicates “INCMP” for one or more of the SRT items the
vehicle is returned to the customer untested.
NOTE:
If MIL is ON during the state emissions inspection, the vehicle is also returned to the customer untested even
though the SRT indicates “CMPLT” for all test items. Therefore, it is important to check SRT (“CMPLT”) and
DTC (No DTCs) before the inspection.
SRT Item
The table below shows required self-diagnostic items to set the SRT to “CMPLT”.
Priority Items
1Freeze frame data Misfire — DTC: P0300 - P0308
Fuel Injection System Function — DTC: P0171, P0172, P0174, P0175
2 Except the above items (Includes A/T related items)
3 1st trip freeze frame data
Item
(CONSULT-II indication)Performance
Priority*1Required self-diagnostic items to set the SRT to “CMPLT”Corresponding DTC
No.
CATALYST 2 Three way catalyst function P0420, P0430
EVAPORATIVE
SYSTEM2 EVAP control system purge flow monitoring P0441
1 EVAP control system P0442
2 EVAP control system P0456
HO2S 2 A/F sensor 1 P1278, P1288
A/F sensor 1 P1279, P1289
Heated oxygen sensor 2 P0139, P0159
Heated oxygen sensor 2 P1146, P1166
Heated oxygen sensor 2 P1147, P1167

GI-52
TERMINOLOGY
Revision: August 20072004 QX56
Nonvolatile random access memory NVRAM ***
On board diagnostic system OBD system Self-diagnosis
Open loop OL Open loop
Oxidation catalyst OC Catalyst
Oxidation catalytic converter system OC system ***
Oxygen sensor O2S Exhaust gas sensor
Park position switch *** Park switch
Park/neutral position switch PNP switchPark/neutral switch
Inhibitor switch
Neutral position switch
Periodic trap oxidizer system PTOX system ***
Positive crankcase ventilation PCV Positive crankcase ventilation
Positive crankcase ventilation valve PCV valve PCV valve
Powertrain control module PCM ***
Programmable read only memory PROM ***
Pulsed secondary air injection control sole-
noid valvePAIRC solenoid valve AIV control solenoid valve
Pulsed secondary air injection system PAIR system Air induction valve (AIV) control
Pulsed secondary air injection valve PAIR valve Air induction valve
Random access memory RAM ***
Read only memory ROM ***
Scan tool ST ***
Secondary air injection pump AIR pump ***
Secondary air injection system AIR system ***
Sequential multiport fuel injection system SFI system Sequential fuel injection
Service reminder indicator SRI ***
Simultaneous multiport fuel injection sys-
tem*** Simultaneous fuel injection
Smoke puff limiter system SPL system ***
Supercharger SC ***
Supercharger bypass SCB ***
System readiness test SRT ***
Thermal vacuum valve TVV Thermal vacuum valve
Three way catalyst TWC Catalyst
Three way catalytic converter system TWC system ***
Three way + oxidation catalyst TWC + OC Catalyst
Three way + oxidation catalytic converter
systemTWC + OC system ***
Throttle body TBThrottle chamber
SPI body
Throttle body fuel injection system TBI system Fuel injection control
Throttle position TP Throttle position
Throttle position sensor TPS Throttle sensor
Throttle position switch TP switch Throttle switch
Torque converter clutch solenoid valve TCC solenoid valveLock-up cancel solenoid
Lock-up solenoid NEW TERMNEW ACRONYM /
ABBREVIATIONOLD TERM

HARNESS CONNECTOR
PG-69
C
D
E
F
G
H
I
J
L
MA
B
PG
Revision: August 20072004 QX56
HARNESS CONNECTOR (SLIDE-LOCKING TYPE)

A new style slide-locking type connector is used on certain systems and components, especially those
related to OBD.

The slide-locking type connectors help prevent incomplete locking and accidental looseness or discon-
nection.

The slide-locking type connectors are disconnected by pushing or pulling the slider. Refer to the illustra-
tion below.
CAUTION:

Do not pull the harness or wires when disconnecting the connector.

Be careful not to damage the connector support bracket when disconnecting the connector.
[Example]
AEL299C
